Moen LEGEND 7300 Setup guide

Illustrated Parts
TO ORDER PARTS CALL: 1-800-BUY-MOEN
www.moen.com
nOrder by Part Number
LEGEND®
Single-Handle Kitchen Faucet
MODEL HANDLE FINISH
7300 Lever Chrome (less spray)
7310 Lever Chrome
9" Spout Assembly Kit
91194
Diverter
91192
Replacement Cartridge
1200 or 1225
Retainer Clip
1883
Spout O-Ring Kit
117 (12 Pack)
or
96778 (Single Pack)
(Also part of Spout Assembly Kit)
Protégé Spray Head &
Hose Assembly
101474 Black
Protégé Spray Head & Hose Assembly
136103 Black
Handle Assembly Kit
2021
Flo-Control Aerator
3924
Retainer Pivot Nut
92309
Handle Cover
1306
Escutcheon
13323
Spray Escutcheon &
Locknut Assembly
101475
Hardware Package
13805
7310pt: Rev. 4/10
FOR MODELS WITH THREADED CONNECTION
Models 7/03 to 7/07 (Female)
Hydrolock® Connection
136102
FOR MODELS WITH HYDROLOCK® CONNECTION
Gasket
98213
nFor Models After 7/07
Protégé Spray Head &
Hose Assembly
101476 Black
FOR MODELS WITH THREADED CONNECTION
Models 5/00 to7/03 (Male)
