Moen FELICITY TS244 series User manual

10" (254mm) MIN
CENTERS
SPOUT
BASE DIAMETER
2-11/16" (68mm)
8-7/8" (225mm)
2-15/16"
(75mm)
9-3/8"
(238mm)
MIN.
HANDSHOWER
ESCUTCHEON DIA.
2-1/8" (54mm)
4-13/16"
(112mm)
3-5/8"
(92mm)
6"
(152mm)
DESCRIPTION
• Metal construction with various finishes identified by suffix
OPERATION
• Lever style handles
• Rotate hot side handle counterclockwise to open
and clockwise to close
• Rotate cold side handle clockwise to open and
counterclockwise to close
FLOW
• Hand shower meets 2.5 gpm max. (9.5 L/min)
STANDARDS
• Third party certified to CSA B125.1, ASME A112.18.1,
and all applicable requriements referenced therin
• ADA for lever handles
WARRANTY
• Lifetime limited warranty against leaks, drips and finish defects
to the original consumer purchaser
• 5 year warranty if used in commerical installations
CRITICAL DIMENSIONS
(DO NOT SCALE)
FOR MORE INFORMATION CALL: 1-800-BUY-MOEN
www.moen.com
Specifications
CRITICAL DIMENSIONS
(DO NOT SCALE)
Rev. 3/11
FELICITY™
Two-Handle Roman Tub Faucet Trim
with Handheld Shower
Models: TS244 series
Valves: 9992, 9993
