Moen Posi-Temp Single-Handle Tub/Shower 82450ORB User manual

CRITICAL DIMENSIONS
(DO NOT SCALE)
DESCRIPTION
•Metal construction with oil rubbed bronze finish
•Includes adjustable showerhead, arm, flange and
diverter spout
OPERATION
•Handle operates counterclockwise through a 270° arc with
off at 6 o’clock and maximum hot at the 9 o’clock position.
Shut off in clockwise direction
•Adjustable temperature limit stop to control maximum hot
water temperature
•Pressure balancing mechanism maintains selected discharge
temperature to ± 2°
FLOW
•Showerhead is limited to 2.5 gpm (9.5 L/min)
CARTRIDGE
•1222 cartridge design
•Nonmetallic/nonferrous and stainless steel materials
•Accommodates back to back installations
STANDARDS
•Third party certified by CSA to meet CSA B-125, ASME
A112.18.1M and all applicable requirements referenced
therein and complies with the applicable requirements of
ANSI A117.1
WARRANTY
•Lifetime limited warranty against leaks, drips and finish
defects to the original consumer purchaser
•5 year warranty if used in commercial installations
ADA
7" (178mm)
ESCUTCHEON
DIAMETER
2" CC (51mm)
1 7/8" IPS (48mm)
MAX WALL
HOT
INLET
COLD
INLET
FINISHED WALL LINE
FACE OF STUD
4-1/2" (114mm)
WALL OPENING
FLOOR
45" (1143mm)/
48" (1219mm)-SHOWER
32" (813mm)-TUB OR
TUB SHOWER
7-1/2"
(191mm)
MIN.
TUB RIM
6'-6"
(1981mm)
L
C
1 3/8" (35mm)
2 1/2" MAX. (63mm)
1/2" MIN. CC (13mm)
5/8" MIN. IPS (16mm)
FLOOR LINE
1 3/8"
(35mm)
1 1/2"
(38mm)
3/16" (typ) (5mm)
PLASTER GROUND
3-1/2" (89mm) MAX.
2-1/4" (57mm) MIN.
DIAMETER
WALL
OPENING
PLASTIC
TUB/SHOWER
SURROUND
L
C
POSI-TEMP®
Single-Handle Tub/Shower
Model: 82450ORB
Rev. 11/05
Specifications
FOR MORE INFORMATION CALL: 1-800-BUY-MOEN
www.moen.com
