CRITICAL DIMENSIONS
(DO NOT SCALE)
CASA®
Two-Handle Widespread
Lavatory Faucet Trim
Model: TS883 series
NOTE: THIS FAUCET IS DESIGNED
TO BEINSTALLED THRU 3 HOLES,
1" MIN. DIA.
7-7/8"
(200mm)
4-1/4"
(108mm)
4-1/2"
(114mm)
6-1/4"
(108mm)
Max Deck
Thickness
1-1/4"
(32mm)
Escutcheon
2-1/4"
(57mm)
8"
(203mm)
3-1/4"
(83mm) 4"
(102mm)
4-7/8"
(124mm)
1-3/4"
(45mm)
Wall
2" minimum
for lift rod
operation
DESCRIPTION
- Metal construction with various finishes identified by suffix
- 1/2" IPS connections
- Includes metal pop-up type waste assembly
- For use with S948 valve
OPERATION
- Lever style handles
- Maximum handle rotation angle is 90˚ to full on for either handle
- Hot side counterclockwise to open (clockwise to close)
- Cold side clockwise to open (counterclockwise to close)
FLOW
- Flow is limited to 1.5 gpm max (5.7 L/min) at 60 psi, for products made
before October 2008 flow is limited to 2.2 gpm max. (8.3 L/min)
CARTRIDGE
- 1224 cartridge design
- Nonmetallic and stainless steel material
STANDARDS
- Third party certified to WaterSense,® ASME A112.18.1, ICC A117.1 and all applicable
requirements referenced therein
- Certified to ANSI/NSF 61/9
- Complies with California Proposition 65 and with the Federal Safe Water Drinking Act
- ADA for lever handles
WARRANTY
- Lifetime limited warranty against leaks, drips and finish defects to the original
consumer purchaser
- 5 year warranty if used in commercial installations
Rev. 6/08
