Moff Band User manual

A wearable smart toy
version 0.6
Moff Band INSTRUCTION MANUAL
Moff Band

Introduction
Package
Wearing Moff Band
Setting up Moff using a smartphone
Compatibility
Introduction
Installing Moff application
Using Moff Band
Installing and replacing Moff Band’s coin battery
Operating Moff Band
Registering Moff Band to Moff Applications
Playing with Moff Applications
Adding or deleting Moff Band
About Moff Band
Turning the power ON
Turning the power OFF
LED Patterns
Specifications
Sensor
Communication standard
Size and weight
Operating conditions
Battery and service life
Help
Warranty
Precautions about regulation and safety
FCC:Federal Communications Commission Statement
EU
others
Important information about safety
Table of contents

Note about the battery
Information about disposal and recycle
The following items are contained in the Moff Band products package.
1. a main body
2. a silicon cover
3. a wrist band
4. a coin battery(CR2032)
A main body consists of the following parts.
Introduction
Package

1.Attach a silicon cover to main body.
1 2
3 4
2.Run the wrist band to the silicon cover.
Wearing Moff Band

3.1. Put the wrist band on your dominant arm(you are right or left handed).
Then the button is in the direction of the fingertip side.
NOTE: about your dominant arm (right or left handed),this means your arm
used for everyday activities like swinging a racket,throwing a ball,and so on.
Moff Band is designed to be connected to a smartphone with Bluetooth
Smart(Bluetooth 4.0LE). To check a smartphone that is compatible with Moff
Band, please refer to http://support.moff.mobi.
Set up Moff using a smartphone
Compatibility
Installing Moff applications

About Moff Applications, you can search for Moff by inputting it in the
Application Store.If you have Moff Applications installed already,check
available updates and make sure that the latest version wii be installed.
How to download Moff Applications : please refer to the following the WEB
site. http://support.moff.mobi
Remove the battery cover.
1.Check the groove oh the battery cover is fixed.
2.Open the battery cover by rotating it about 10 degrees clockwise to open
using a coin or a screwdriver.
3.Remove the battery cover.
Using Moff Band
Installing and replacing Moff Band’ｓbattery
Removing the battery cover.
Placing the battery

4.When inserting the coin battery(CR2032),make sure that the positive(＋) is
facing in the correct direction.
5.Attach the cover of coin battery.
Align the groove of Moff Band with the tab of the battery cover.
6.Rotate the battery cover about 10 degrees counterclockwise to close using a
coin or a screwdriver.
(NOTE)
※This is a battery cover with a rubber part.After checking the battery cover with
the rubber part,attach the battery cover to Moff.
When you use a coin or a screwdriver, please use the right size. Do not push it
with more than necessary force. Doing so might damage it.

Moff Band operates with the button to turn ON or OFF.
1.From the power-off state, push the button for 0.2 sec. briefly,and the green
LED will light for 3 sec.and will off. The power is ON.
2.To make sure that the power is ON : From the power-on state, push the
button briefly for 0.2 sec. LED will not light.
(Note) LED will not light in the state that is not the battery.
3.From the power-on state, press and hold the button for 3 sec.,and the red
LED will light. If the button is released,the power is OFF.
(Note) To increase the battery life,from the power-on state,when Moff is not
connected to Applications for more than 3 minutes,the power will shut off
automatically.
Operating Moff Band

Wear Moff Band on your dominant arm(you are right or left handed).
When Moff Band is worn on your wrist, it is designed to recognize your motion
most correctly. If you need to help how to wear Moff Band, please refer to
“Wearing Moff Band”
NOTE: Before Moff Band is registered into Moff applications ,Check whether
the battery is installed in Moff Band.
NOTE: Moff Band needs to link from Moff Applications directly,not from
Applications for iOS device.
Start Moff application.
Tap 「Start」
Register Moff Band into Moff application according to directions of the
Registering Moff Band to Moff applications

screen.
If Moff Band is registered to Moff Applications、Moff Application list screen is
displayed.
Playing with Moff Applications

If Moff Band’ｓpower is ON, this screenis displayed.
When the power of Moff Band is not ON, “Connect”button is displayed
on the screen. Turn the power ON, and tap“Connect” button on the screen.
Move Moff Band worn on your arm. It provides play experiences with different
sounds. Enjoy imagining what sounds you can hear by how you play.
(Note)
If the sound is not output, please check the following.
Please increase the volume
Please make sure that the silent switch on the smartphone side is turned
off.
To increase in the battery life, when the Application is running in the
back ground mode for 30 seconds,Moff Band will disconnect from Moff
Applications automatically.
If you do not find how to use Moff Band, please refer to
http://support.moff.mobi or Help in Moff Application.
Moff Specifications

Moff Band transmits data of 6 axis acceleration and gyro sensor to a smart
phone.
Bluetooth Smart(Bluetooth v4.0)
Package contents (Moff,silicon cover,a wrist band,and coin battery)
length width weight
225mm 25mm 30g
CR2032(a coin battery lithium battery) Approximately, 20 hours(At the time of
continuous use)
Temperature -10℃~ 40℃(14°F ~ 104°F)
Relative Humidity 5 to 90% RH (condensation not allowed)
Moff Band does not have a waterproofing function. Please do not use this in
the rain or in the water.
Please refer to “Support(http://support.moff.mobi/)” for troubleshooting and the
support about Moff Band.
For details on warranty,see http://support.moff.mobi/warranty/
Sensor
Communication standard
Size and weight
Battery and battery service life
Ambient operating conditions
Help
Warranty

This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
FCC CAUTION
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures: —Reorient or relocate the receiving antenna. —
Increase the separation between the equipment and receiver. —Connect the
equipment into an outlet on a circuit different from that to which the receiver is
connected. —Consult the dealer or an experienced radio/TV technician for
help.
This transmitter must not be co-located or operated in conjunction with any
other antenna or transmitter.
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment and meets the FCC radio frequency (RF) Exposure
Guidelines. This equipment has very low levels of RF energy that are deemed
to comply without testing of specific absorption ratio (SAR).
Precautions about regulation and safety
FCC:Federal Communications Commission Statement

FCC ID:2ABXRBVMCN5103
Hereby, Moff, Inc., declares that this Moff Band model b001 is in compliance
with the essential requirements and other relevant provisions of Directive
1999/5/EC.
This product uses a module obtained a certification of construction type issued
by Japan Radio Act.
Please read the indication indicated here
Please follow the indication indicated here.
Please do not open a Moff Band. When the substance contained in a
product is processed or discarded by an unsuitable method, it causes
harm to the human body and the environment.
Please do not convert Moff Band.
Please do not use an abradant for cleaning of Moff Band.
Please do not put Moff Band into a dish washer, a washing machine, and
a drier.
Please do not expose Moff Band to a super-high temperature or a super-
cryogenic temperature.
Please use Moff Band in neither a sauna nor a mist room.
Please do not use Moff Band underwater.
Please do not expose Moff Band to a sunlight for a long time.
Please do not put Moff Band near fire.
Do not dispose of Moff Band as “Combustible trash”.
Please do not decompose Moff Band. There are no fixable parts.
Please do not throw or step on Moff Band.
Please keep Moff Band out of the reach of children to prevent accidental
EU
others
Important information about safety

ingestion and choking.
Make sure that all players using the Moff Band are wearing the band and
that it has been tightened.
Make sure that furniture, objects and people are out of the play area so
you don’t accidentally bump into them while playing.
According to the instructions contained in the operating instructions,please
change the battery. please do not use except the coin battery (CR2032).
Please take care about the direction of an electrode. The battery life will be
changed depending on our environmental temperature,the situation,the
aging,,the quality、and the characteristics.
Operating temperature range will be different depending on the battery.Please
use the battery after confirming the specification of the battery to be used.
The WEEE logo signifies specific recycling programs and procedures for
electronic products in countries of the European Union. We encourage the
recycling of our products. If you have further questions about recycling options,
click the link below. EU Waste Electronics Information
(http://www.cryptoman.com/storage/Pubs/EU_Waste_Electronic_Information.pdf)
Note about the battery
Information about disposal and recycle
