E85-A-8-HLD
Proofer and Holding Cabinet
Order Toll Free 1800 551 8795
E85-A-8-HLD
E85-A-8-HLD
Unit shall be a Moffat electrically heated proofer and holding cabinet E.T. L listed (UL Std 197 NSF - 4). The proofer and holding cabinet
shall have a stainless steel interior and stainless steel top and sides. Proofer cabinet shall be fully insulated with a single pane removable
glass door with capacity for up to 16 half size sheet pans or 8 full size sheet pans. A single speed fan shall gently and evenly circulate
air around the proofer cabinet. Cabinet temperature shall be controlled by a thermostat and humidity via a humidity sensor and control.
A thermometer shall indicate the cabinet temperature. A single element shall heat the cabinet with an additional element heating water
in the water tank. Proofer and holding cabinet shall be mounted on casters, fixed at the rear brake and swivel at the front. Proofer
and holding cabinet shall operate independently or in combination with Moffat's Turbofan model E35. Proofer and holding cabinet shall
be fitted with a NEMA 5-15P cordset.
Full view door
Dual proof/holding functions
Variable heat control
Variable humidity control
Stainless steel outer
Stainless steel inner
Low velocity fan
Casters as standard
110V plug in connection
Door removes for cleaning
Auto water fill (hook-up optional)

In line with policy to continually develop and improve its products, Moffat Limited reserves the right to change specifications and design without notice.
Printed in New Zealand © Copyright Moffat Ltd Moffat/5244-E85-A-8-HLD/BH/2M/09.06
U.S.A
Moffat Inc
3765 Champion Boulevard
Winston-Salem
North Carolina 27105
Call Free 1800 551 8795
Ph 336-661 0257
Fax [phone]
Email [e-mail]
www.moffat.com
Canada
Serve Canada
22 Ashwarren Road
Downview
Ontario, M3J 1Z5
Ph 416-631 0601
Fax [phone]
Email [e-mail]
Australia
Moffat Pty Limited
740 Springvale Rd
Mulgrave
Victoria 3170
Australia
Ph 03-9518 3888
Fax [phone]
Email [e-mail]
www.moffat.com.au
New Zealand
Moffat Limited
16 Osborne St
PO Box 10-001
Christchurch
New Zealand
Ph 03-389 1007
Fax [phone]
Email [e-mail]
www.moffat.co.nz
United Kingdom
Blue Seal Limited
Units 6-7 Mount St
Business Park
Birmingham B7 5QU
England
Ph 0121-327 5575
Fax [phone]
Email [e-mail]
www.blue-seal.co.uk
www.moffat.com
Designed and manufactured by
QUALITY
MANAGEMENT STANDARD
ISO 9001
ISO 9001
All Turbofan products are designed and
manufactured by Moffat Ltd using the
internationally recognised ISO 9001
quality management system, covering
design, manufacture and final
inspection, ensuring consistent high
quality at all times.
CONSTRUCTION
8 pan capacity
Stainless steel front and sides
Removable full view door
Strong and stylish handle
Stainless steel racking system
Accepts half or full size pans
Fully insulated
Porcelain control panel
CONTROLS
Off/proof/hold switch
Mechanical thermostat
Variable heat 32°F to 175°F
Variable humidity
Cabinet temperature thermometer
CLEANING AND SERVICING
Easy clean surfaces
Removable racking system
Removable water tank
SPECIFICATIONS
Electrical Requirements
110V, 60Hz, 1P+N+E, 1.65kW, 14.5A
NEMA 5-15P cordset fitted
Water
3/4" thread
80psi max inlet pressure
20psi min inlet pressure
External Dimensions
Width 345/8" (880mm)
Height 351/2" (902mm)
Depth 345/8" (880mm)
Internal Dimensions
Width 18" (460mm)
Height 275/8" (700mm)
Depth 26" (660mm)
Nett Weight
205lbs (93kg)
Packing Data
340lbs (154kg)
37.4ft3(1.06m3)
Width 381/8" (970mm)
Height 393/4" (1090mm)
Depth 393/8" (10 01m m )
Clearances
Left side -
Right side 1”(25mm)
Rear -
To p -
Door swing 251/2”(650mm)
345/8”
(880mm)
E
1
34 5/8”
(880mm)
35
1
/2”
(902mm)
5
7
/8”
(150mm)
15/8”
(40mm)
E
1
