MoistAir MA0601 User manual

1
READ AND SAVE THESE INSTRUCTIONS
Use and Care Guide
TOWER HUMIDIFIER
6 Gallon Output with
Digital Readout
Model MA0601
CAUTION: Before using this
product, read this manual and
follow all its Safety Rules and
Operating Instructions.
•Safety
•Assembly
•Operation
•Maintenance
•Parts
Essick Air Products
5800 Murray St. Little Rock, AR 72209
www.moistair.com
Part No. 1B71940 08/09 Printed in China

2
GENERAL SAFETY INSTRUCTIONS
Safety Signal Words
DANGER: Means if the safety
information is not followed someone
will be seriously injured or killed.
WARNING: Means if the safety
information is not followed someone
could be seriously injured or killed.
CAUTION: Means if the safety
information is not followed someone
may be injured.
1. To reduce the risk of fire or
shock hazard, plug humidifier
directly into a 120 V, A.C.
electrical outlet. Do not use
extension cords.
2. Keep the electric cord out of
traffic areas. To reduce the
risk of fire hazard, never put
the electric cord under rugs,
near heat registers, radiators,
stoves or heaters.
3. Always unplug the humidifier
before moving it, before
cleaning, or whenever the
humidifier is not in service.
4. Keep the humidifier clean
5. Do not put foreign objects
inside the humidifier.
6. Do not allow to be used as a
toy. Close attention is
necessary when used by or
near children.
7. Never use your humidifier
while any part is missing or
damaged in any manner.
8. To reduce the risk of electrical
hazard or damage to
humidifier, do not tilt, jolt or tip
humidifier while unit is
running.
9. To reduce the risk of damage
to humidifier, unplug when not
in use.
10. To reduce the risk of
accidental electrical shock, do
not touch the cord or controls
with wet hands.
11. To reduce the risk of fire, do
not use next to an open
flame source, such as a
candle or other flame source.
12. Note the warning label
shown adjacent.
Table of Contents
General Safety Information............2
Know Your Humidifier....................3
How Your Humidifier Works...........4
Getting you Humidifier Up
and Running ...............................4
Location......................................4
Electrical Hook-up.......................5
Water Fill ....................................6
Setting the Controls....................7
Operating the Controls..................7
Using Your Humidifier ...................8
Filter Replacement and Care ......10
Cleaning and Maintenance..........11
Troubleshooting ..........................13
Parts List for Moist Air
P/N MA0601................................14
Warranty Information...................15
WARNING: To reduce risk of
fire, electric shock, or injury
always unplug before servicing
or cleaning.

3
KNOW YOUR HUMIDIFIER
Description MA0601
* Gallon Output 24/hrs
Capacity of Bottle
Capacity of Base
* Sq. Ft. Coverage
Fans Speeds
Auto Fan Speed
Replacement Filter
Auto Humidistat
Auto Shut Off
Controls
ETL/CETL Listed
Volts
Hertz
Amps (High Speed)
Watts (High Speed)
6 gallons
1.25 gallons
1.25 gallons
1300
3
Yes
MAF-2
Yes
Yes
Electronic Pushbutton
Yes
120 A.C.
60
1.2
81
* Based on an area with average insulation and an 8 foot ceiling height.

4
How Your Humidifier Works
Your new humidifier is designed to satisfy home humidity requirements through
the principle of evaporation of water in the air.
Once the filter becomes saturated, air is drawn in, passes through the filter and
moisture is absorbed into the air. All evaporation occurs in the humidifier so any
residue remains in the filter. This natural process of evaporation virtually
eliminates white dust.
Once removed from its carton,
remove all packing materials.
Verify the filter is properly installed
(See page 9).
Step 1. Location
CAUTION: To reduce the risk
of injury, fire or damage to
humidifier, use only cleaners
specifically recommended for
humidifiers. Never use
flammable, combustible or
poisonous materials to clean
your humidifier. To reduce the
risk of scalds and damage to
humidifier, never put hot water
in humidifier.
WARNING: For your own safety, do not use humidifier if any parts are
damaged or missing.
Selecting a Location
Place humidifier on a flat level surface;
take extra care in leveling when placing
the unit on carpet. Position the humidifier
where the most humidity is needed or
where the most air will be circulated
throughout the house such as near a cold
air return.
Getting Your
Humidifier Up
and Running
Moist air (humidity) produced will
disperse into the whole house, but
the area closest to the unit will
have the highest humidity. If the
unit is positioned close to a
window, condensation may form
on the window pane. If this occurs
the unit should be repositioned in
another location.

5
Positioning the Unit
The humidifier should be positioned with
the back (cord exit side) and sides, at
least 2 inches away from the wall. Air
needs to enter through all of the louvers
in the housing assembly in order for the
humidifier to operate at peak efficiency.
NOTE: Be sure humidistat (located
approximately 4 inches outsi
de humidifier
body on power cord) is free from
obstruction and away from any hot air
register.
WARNING: To reduce the risk of fire or shock hazard, only plug humidifier
into a 120V A.C. outlet. Do not use extension cords.
NOTE: Due to release of cool, moist air from humidifier, it is best to direct air
away from thermostat and hot air registers and to position humidifiers next to an
inside wall. Unit should not be placed where cold air from outside walls or warm
air from a hot air register blows directly on it.
Step 2. Electrical Hook-Up
Locate nearest 120V A.C. wall socket in the location desired, preferably on
inside wall. With the humidifier in the desired location, route the electrical cord
safely so no one will trip or upset the humidifier.
Plug in the electrical cord.
To reduce the risk of electrical shock, this
humidifier has a polarized plug (one blade
is wider than the other). This plug will fit in
a polarized outlet only one way.
If the plug does not fit fully in the outlet,
reverse plug. If it still does not fit, contact
a qualified electrician to install the proper
outlet. Do not change the plug in any way.

6
Step 3. Water Fill
WARNING: To reduce the risk of fire
or shock hazard, do not pour or spill
water into control or motor area. If
controls get wet, let them dry
completely and have unit checked
by qualified service personnel before
plugging in.
After the humidifier is positioned
where it will be operating, you are
ready to fill the humidifier. The bottle
tilts out and away from the base.
Take care not to bump or damage fill
valve assembly on the bottom of the
bottle.
Invert the bottle. Press the valve
stem button into the bottle and turn
clockwise to lock in open position.
Place bottle under the faucet. Fill the
bottle, being careful not to allow any
debris to get in the valve seating.
Once the bottle is full, press the
valve stem button and turn counter
clockwise to release and close.
CAUTION: Use only EPA Registered
Bacteriostat . Under no circumstances
should you use water treatment products
designed for Rotobelt or Ultrasonic
humidifiers.
Place the water bottle back into the
humidifier base. When positioned
properly, the plunger will open and
the water will flow into the base. The
base will hold the entire contents of
the water bottle. Once the bottle is
empty, remove it and repeat the
filling process. The humidifier is now
filled to capacity. For less frequent
filling let the humidifier exhaust both
the water from the bottle and the
base before filling.

7
Recommended
When Outdoor Indoor Relative
Temperature is: Humidity is:
2˚F -18˚C 25%
10˚F -12˚C 30%
> 20˚F -6˚C 35%
Step 4. Setting
the Controls
Where you set your desired
humidity levels depends on
your personal comfort level,
outside temperature and
inside temperature. A starting
Set point of 30%-40% ROOM
humidity is recommended but
there may be conditions that require a different setting.
The chart provided offers general guidelines for selecting indoor humidity.
IMPORTANT: Water damage may result if condensation starts to form
on windows or walls. Humidity SET point should be lowered until
condensation no longer forms. We recommend room humidity levels
do not exceed 50%.
Operating the Controls
Digital Display
Press the power button once to turn
the unit on*. Initially there is a slight
delay while the electronics calibrate.
Two bars (--) appear during this time.
Once calibration is complete a ROOM
humidity reading between 20% – 95%
will be displayed. A flashing 20 display
indicates that the room humidity is less
than 20%.
NOTE: The default settings at initial
startup are (LOW) F1 fan speed and
65% SET humidity. After desired settings
are selected by the user, they remain as
long as the unit remains plugged in and
there is no power interruption. If the unit is
unplugged the original default settings
are employed.
Speed Button
This humidifier is equipped with a
3-speed fan control. Initially depressing the speed button will display the current
speed setting. Each push of the speed button advances the mode through the
settings of (HIGH) F3, (MEDIUM) F2, (LOW) F1 and (AUTO) A.
The selected setting is displayed on the digital readout. The higher the setting, the
faster water is evaporated and released into the air. F1 (LOW) is the quietest
setting and is provided for conditions that do not require a rapid evaporation rate.
When (AUTO) A is selected the humidifier will determine the required fan speed
needed to bring the actual room humidity up to the set humidity.
*Humidifier fan should operate at
initial startup. If it does not, refer
to “Fan not operating (digital
display is illuminated)” in the
“Troubleshooting” section on
page 12 of this manual.
Function
Buttons
Digital
Display

8
Using Your Humidifier
Operating the Controls (con’t)
Humidity Control
This button allows you to adjust the humidity to suit your needs. This humidifier
will automatically cycle on and off as required to maintain the selected setting.
The readout displays both actual (ROOM) and desired (SET) humidity percentage
(%) settings when humidity control button is pressed. The ROOM readout has a
range of 20% to 95%. If the room humidity level is equal to or less than 20% the
display will show a flashing 20.
The SET readout has a range of 25% to 65% and is adjusted in increments of 5%.
Initially depressing the humidity button will display the current humidity setting.
Each additional press of the button increases the setting by 5%. A SET point of
65% operates the humidifier continuously regardless of the ROOM reading. The
humidistat that senses the readings is located on the power cord. Insure that it is
free from obstructions.
Refill Display
For maximum run time both the bottle
and the base should be filled. When
both the bottle and the base are empty
the display alternates the room
humidity reading and “F” (FILL),
indicating that additional water is
required. Also at this time the unit will
automatically switch into DRY OUT
MODE and continue to run on the
lowest speed until the filter is dry.
NOTE: During this time the room humidity level will continue to be monitored and
the humidifier will cycle the fan on and off until the filter is completely dry. The fan
will shut off leaving you with a dry humidifier that is less prone to mold and mildew
growth. If DRY OUT MODE is not desired, refill the humidifier with water and the
fan will return to the set speed.
NOTE: Fan automatically switches to lowest speed during DRY OUT MODE.
Check Filter Indicator
The ability of any humidifier to efficiently
supply humidity output relies heavily on the
condition of the filter. As the filter loads with
impurities it gradually loses its wicking
capability. When this happens, moisture
output is reduced and the humidifier has to
work longer to satisfy the selected setting.
This humidifier has a check filter reminder
timed to appear after 720 hours of
operation. When display shows an
alternating “CF” and the room humidity
setting at 5 second intervals,
it is a reminder
to check the filter condition.
Refill
Indication
Check Filter
Indication

9
Humidistat
The humidistat located on the power cord senses the percentage of humidity in the
air. It causes the humidifier to cycle on and off to maintain the selected humidity
SET point. The fan will turn on if the “ROOM” reading falls 3% below the SET
point and will continue to run the humidifier until a reading of 1% above the SET
point is achieved. The fan will turn off until the ROOM reading falls 3% below the
SET point again.
NOTE:Be sure that the humidistat, which is located on the power cord, is free
from obstruction and away from any hot air source.
Control Lock Out
To avoid unwanted tampering with the humidifier settings the controls can be
locked.
Activation Procedure
After the humidifier functions have been set up, hold the power button down for 5
seconds. The display will show “CL” for 2 seconds; release the power button and
the control will resume the display of the room humidity. The room humidifier will
continue to function with the locked in settings. If buttons are operated while “CL”
is active, the “CL” is displayed and settings are unaffected.
Deactivation Procedure
To deactivate the “CL” function simply press and hold the power button for 5
seconds. “CL”
will flash at the rate of 1 second on and 1 second off for a period of
2 seconds and then resume the display of room humidity.
Filter Replacement and Care
Replace the evaporative wicking filter at least once per humidification season or
more depending on water conditions in your area.
Filter Replacement
1.
Unplug humidifier. Before removing the filter, move the humidifier to an area not
susceptible to water damage. (i.e. kitchen or bath areas).
2. Remove the water bottle and set aside. Be sure not to bump or damage the fill
valve.
3. The upper housing and the base are held together by two hooks at the front of
the housing and a flexible snap in the rear. To remove the housing, press in on the
triangular shaped snap at the rear of the humidifier
, below the cord exit, while lifting
upward, tilting the upper housing forward to clear the hooks at the front of the base.
4. Set the upper housing aside. The filter is now accessible.
CAUTION:To help retard bacteria
growth and keep maximum
efficiency, the filter should be
replaced at least once per season,
or more often under hard water
conditions. Use MAF-2 replacement
filter.
WARNING: To reduce the risk of
shock or injury from moving parts,
always unplug humidifier before
removing or replacing any parts.

10
Filter Replacement and Care (con’t)
Cleaning and Maintenance
5. Take note of the filter position.
Remove the filter. You may want
to clean the base at this time. See
the “Cleaning and Maintenance”
section of this manual.
6. Install a new filter (MAF-2) into
the base. Position the filter
between the uprights in the bottom
of the base. The filter should be
resting on the floor of the base.
7. Return the upper housing to the
base by first placing the hooks
located near the front of the base
into the mating holes in the upper
housing. Then tilt the upper
housing down towards the base
until the rear snap engages the
main housing.
8. Reposition the humidifier to its
operating position.
9. The humidifier is now ready to
be filled for operation.
WARNING: To reduce the risk of
injury, fire or damage to humidifier,
use only cleaners specifically
recommended for humidifiers.
Never use flammable, combustible
or poisonous materials to clean your
humidifier. To reduce the risk of
scalds and damage to humidifier,
never put hot water in humidifier.
Step 1
To make cleaning easier, the humidifier base should be empty and completely
dried out. To accomplish this, use the following method:
a. Allow the humidifier to run until the REFILL message “F” illuminates and
the automatic shutoff has stopped the humidifier fan.
b. Unplug humidifier.
Step 2
a. Remove humidifier parts. See “Replacement and Care of Filter” page 10.
b. NOTE: There may be a little water still in the base. Carefully dump the
water out or remove with a sponge.
WARNING: To reduce the risk
of shock, always unplug
humidifier before cleaning or
servicing. If humidifier is not
unplugged, fan could start after
housing is removed.

11
Cleaning and Maintenance (Con’t.)
CAUTION: Local water purity
varies from area to area and
under certain conditions water
impurities and airborne bacteria
may promote the growth of
microorganisms in the reservoir
of the humidifier. To retard
bacteria growth that may cause
odors and be harmful to your
health, use only recommended
replacement filters. Also use
EPA registered Bacteriostat.
Step 3
Bi-Weekly Maintenance
Removing Scale
1. Fill the humidifier base with water and add one 8-ounce cup of white
vinegar. Let solution stay 20 minutes.
2. Clean all interior surfaces with a soft brush. Dampen a soft cloth with
white vinegar and wipe out the base to remove scale.
3. Rinse thoroughly with clean warm water to remove scale and cleaning
solution.
Disinfecting Base
1. Pour 1/2 gallon of water and 1/2 teaspoon chlorine bleach into the
base. Let solution stay for 20 minutes, carefully swishing every few
minutes. Wipe all surfaces normally exposed to water.
2. Empty base after 20 minutes. Rinse with water until bleach smell is
gone. Allow unit to dry out completely.
NOTE: The water bottle should be cleaned in the same manner as the
base. Rinse thoroughly with clean water after all steps are complete.
End of Season Maintenance
1. Follow “Bi-Weekly Maintenance” instructions at end of humidification
season.
2. Remove filter.
3. Let humidifier dry completely before storing.
4. Store in cool, dry location.
5. Install a new filter in clean humidifier before next season begins.
NOTE: “Bi-Weekly Maintenance” procedure
is also recommended if you do not plan to
run the humidifier for one week or more.

12
Troubleshooting
Trouble
Probable Cause
Remedy
Digital display not
illuminated.
•No Power
Power button hasnot been
depressed.
• Check 120 volt power source .
•Press power button once to turn
on.
Fan notoperating (digital
display is illuminated).
•ROOM humidity level is not 3%
more below SET humidity level.
•Reservoir is empty.
•Raise SET humidity level if
desired.
•Increase fan speed.
•Fill humidifier with water.
Fan running
continuously.
•SET humidity level is 65%.
•ROOM humidity level has not
reached 1% or more aboveSET
humidity level.
•A Set humidity percentage of 65%
operates fan continuously. Adjust
SET level between 25%-60%.
•Continue to rununtil desired
humidity level is achieved. This
may takeup to 48 hours initially.
Poor evaporation of
water.
•CHECK FILTER message
flashing.
•Mineral buildup on filter.
•Change to a freshnew filter.
•NOTE: Local water purity varies
from area to area.
Bottleempties
completely.
•This is normal for
initial filling.
• Refill bottle for maximum run time .
Bottle continuesto empty
after complete filling.
•Air is entering water bottle. •Checkfor leak in water bottle.
Bottle not emptying.
•Spring Valve Assemblydamaged
or missing post in bottom of base.
•Base full of water.
•Checkorientation of bottle.
Reposition so that fill valve on
bottom of bottle is depressed by
post in bottom of base.
The base will hold the contents of
water bottle (1.25 gallons).
Continue to runhumidifier to
deplete water from base.
Display blinks or fan
movesslightlywhen
humidifier is plugged in.
•Normal •No action required.
Fan operating slower
than speed registered on
digitaldisplay •Humidifier in “DRY OUT MODE”.
•Humidifier automatically switches
fan to (LOW)F1 when “F”and
alternating room humidityis
displayed.
Humidifier not shutting off
during “DRY OUT MODE” •Filter not dry.
•During “DRY OUTMODE” the
humidifierwill continue to run on
“LOW” speed as required forup to
2 hours or until the filter is
completelydry.
Alternating “F”and room
humiditydisplayed.
•Reservoir is empty. •Fill humidifier with water.
Alternating “CF”and
roomhumiditydisplayed. •Filter may be dirty.
•Replace filter.
•Unplug unit for 30 seconds and
replug in to clear.

13
Parts List for MoistAir Humidifier Model No. MA0601
Always order by part number - Not by key number
Key No.
Part No.
Description
1
MA0601
* Housing, Upper Assembly (includes all parts 1-7)
2
MAF-2
± Filter
3
831188-1
Support, Float
4
831189
Float, Reservoir
5
1B71761
Base
6
1B71763
Bottle Assembly
7
1B71940
Operator’s Manual (not shown)
±Stock item - May be secured through the Hardware Department of most retail
stores.

14
Moist AIR®PRODUCTS
HUMIDIFIER WARRANTY POLICY
EFFECTIVE APRIL 1, 2008
SALES RECEIPT REQUIRED AS PROOF OF PURCHASE
FOR ALL WARRANTY CLAIMS.
This product is warranted against defects in workmanship and materials for one year
from the date of sale except for motors, which are warranted for two years. This warranty
does not apply to filters or wicks which are customer replaceable parts.
This warranty applies only to the original purchaser of the product when it is purchased
from a reputable retailer/dealer.
This warranty does not apply to damage from accident, misuse, alterations, unauthorized
repairs, unauthorized use, mishandling, unreasonable use, abuse, including failure to
perform reasonable maintenance, normal wear and tear, nor where the connected
voltage is more than 5% above the nameplate voltage, nor to the equipment or products
being improperly installed or wired or maintained in violation of this Owner’s Manual.
Alterations include the substitution of name brand components including, but not limited
to wicks and bacteria treatment.
THIS PRODUCT IS NOT INTENDED FOR COMMERCIAL USE. THIS IS THE SOLE
AND EXCLUSIVE WARRANTY GIVEN BY MANUFACTURER WITH RESPECT TO THE
PRODUCTS AND, TO THE MAXIMUM EXTENT PERMITTED BY LAW, IS IN LIEU OF
AND EXCLUDES ALL OTHER WARRANTIES AND CONDITIONS, EXPRESS OR
IMPLIED, ARISING BY OPERATION OF LAW OR OTHERWISE. INCLUDING
WITHOUT LIMITATION, MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR
PURPOSE.
No employee, agent, dealer or other person is authorized to give any warranties or
conditions on behalf of the manufacturer. The customer shall be responsible for all costs
incurred in the removal or reinstallation and shipping of the product for repairs.
Within the limitations of this warranty, purchaser with inoperative units should
contact customer service @ 800-547-3888 for paperwork and instructions on the
return of the unit for repair. A copy of the sales receipt is required before authorization
to return a unit for repair is approved. The manufacturer will repair or replace the product,
at its discretion, at no charge to the customer with return freight paid by the manufacturer.
It is agreed that such repair or replacement is the exclusive remedy available from the
manufacturer and that TO THE MAXIMUM EXTENT PERMITTED BY LAW, THE
MANUFACTURER IS NOT RESPONSIBLE FOR DAMAGES OF ANY KIND,
INCLUDING INCIDENTAL AND CONSEQUENTIAL DAMAGE OR LOSS OF PROFITS
OR REVENUES.
This warranty will be null & void if purchaser attempts to repair or replace any
parts which are mechanical or electrical.
The warranty gives the customer specific legal rights, and the customer may also have
other rights which vary from province to province, or state to state.

15
LEA Y GUARDE ESTAS INSTRUCCIONES
Guía de uso y cuidado
HUMIDIFICADOR TIPO TORRE
Rendimiento de 6 galones con
lector digital
Modelo MA0601
PRECAUCIÓN: antes de usar
este producto, lea este manual
y siga todas las Reglas de
seguridad y las Instrucciones de
funcionamiento.
•Seguridad
•Ensamblaje
•Funcionamiento
•Mantenimiento
•Partes
Essick Air Products
5800 Murray St. Little Rock, AR 72209
www.moistair.com
Part No. 1B71940 08/09 Printed in China

16
INSTRUCCIONES GENERALES DE SEGURIDAD
Palabras indicadoras de seguridad
PELIGRO: significa que si no se respeta la
información de seguridad, alguien puede
resultar seriamente herido o muerto.
ADVERTENCIA: significa que si no se
respeta la información de seguridad,
alguien podría resultar seriamente herido o
muerto.
PRECAUCIÓN: significa que si no se
respeta la información de seguridad,
alguien puede resultar herido.
1. Para reducir el riesgo de incendio o el
peligro de descarga eléctrica, enchufe
el humidificador directamente a un
tomacorriente eléctrico de 120 V de
CA. No utilice extensiones.
2. Mantenga el cable fuera de las áreas
de tránsito. Para reducir el riesgo de
peligro de incendio, nunca coloque el
cable debajo de alfombras, cerca de
fuentes de calor, radiadores, cocinas o
calentadores.
3. Siempre desenchufe el humidificador
antes de moverlo, antes de limpiarlo o
cada vez que el humidificador no esté
funcionando.
Tabla de contenidos
Información general de
seguridad ...................................16
Sobre su humidificador................17
Funcionamiento de su
humidificador...............................18
Encendido de su humidificador 18
Ubicación .................................18
Conexión eléctrica....................19
Llenado con agua.....................20
Configuración de los controles.21
Funcionamiento de los controles.21
Uso de su humidificador..............22
Reemplazo y cuidado del filtro ....23
Limpieza y mantenimiento...........24
Solución de problemas................26
Lista de repuestos para MoistAir
MA0601.......................................27
Información sobre la garantía......28
ADVERTENCIA: para reducir el
riesgo de incendio, descargas
eléctricas o lesiones siempre
desenchúfelo antes de efectuar
reparaciones o de limpiarlo.
4. Mantenga el humidificador
limpio
5. No coloque objetos extraños
dentro del humidificador.
6. No permita que lo utilicen como
un juguete. Se debe prestar
atención cuando lo utilizan niños
o cuando se lo utiliza cerca de
niños.
7. Nunca utilice su humidificador
cuando le falte una parte o una
parte esté dañada en alguna
forma.
8. Para reducir el riesgo de peligro
eléctrico o daño al
humidificador, no lo mueva,
sacuda ni incline mientras la
unidad esté en funcionamiento.
9. Para reducir el riesgo de daños
en el humidificador,
desenchúfelo cuando no lo esté
utilizando.
10. Para reducir el riesgo de
descargas eléctricas
accidentales, no toque el cable
ni los controles con las manos
húmedas.
11. Para reducir el riesgo de
incendio, no lo utilice cerca de
una fuente de fuego abierta,
como una vela u otra fuente.
12. Preste atención a la etiqueta de
advertencia que aparece
adjunta.

17
SOBRE SU HUMIDIFICADOR
*Basado en una superficie con aislamiento promedio y una
altura de cielorraso de 8 pies.
Descripción
* Rendimiento de galones
durante 24 horas
Capacidad de la botella
Capacidad de la base
*Cobertura en pies cuadrados
Velocidades del ventilador
Velocidad del ventilador
automático
Filtro de reemplazo
Humidistato automático
Apagado automático
Controles
Registrado por ETL/CETL
Voltios
Hertz
Amperes (velocidad máxima)
Vatios (velocidad máxima)
MA0601
6 galones
1.25 galones
1.25 galones
1300
3
Sí
MAF-2
Sí
Sí
Electrónico (botón pulsador)
Sí
120 CA
60
1.2
81

18
PRECAUCIÓN: Para reducir el riesgo
de lesiones, incendios o daños al
humidificador, utilice solamente
limpiadores recomendados
específicamente para humidificadores.
Nunca utilice materiales inflamables,
combustibles ni venenosos para
limpiar su humidificador. Para reducir
el riesgo de quemaduras y daños al
humidificador, nunca coloque agua
caliente en el humidificador.
Funcionamiento de su humidificador
Su nuevo humidificador está diseñado para satisfacer los requisitos de
humedad del hogar por medio del principio de evaporación de agua en el aire.
Una vez que el filtro se satura, el aire ingresa, pasa a través del filtro y la
humedad es absorbida y liberada en el aire. Toda la evaporación se produce
en el humidificador para que cualquier residuo permanezca en el filtro. Este
proceso natural de evaporación elimina prácticamente todo el polvo blanco.
Una vez que lo saque de la caja, retire
todos los materiales de embalaje.
Verifique que el filtro esté instalado
adecuadamente (Consulte la página 24).
Paso 1. Ubicación
Selección de una ubicación
Coloque el humidificador sobre una
superficie plana, preste especial
cuidado de que quede nivelado
cuando se coloca la unidad sobre una
alfombra. Ubique el humidificador
donde se requiera la mayor cantidad
humedad o donde circulará la mayor
parte de aire en la casa, como cerca
de un conducto de aire frío.
El aire húmedo (humedad)
producido se dispersará por toda la
casa, pero el área más cercana a la
unidad tendrá la humedad más alta.
Si se coloca la unidad cerca de una
ventana, se puede formar
condensación en el vidrio de la
ventana. Si esto ocurre, se debe
colocar la unidad en otro lugar.
Encendido de su
humidificador
ADVERTENCIA: Por su propia seguridad, no utilice el humidificador si
están dañadas o faltan algunas de las partes.

19
Si el enchufe no encaja
completamente en el tomacorriente,
inviértalo. Si aún así no encaja,
contacte a un electricista calificado
para que instale el tomacorriente
adecuado. No cambie el enchufe de
ninguna manera.
OBSERVACIÓN: debido a que el humidificador libera aire húmedo frío, es mejor
dirigir el flujo de aire lejos del termostato y de las fuentes de calor, y colocar los
humidificadores junto a una pared interior. La unidad no se debe colocar donde
el aire frío proveniente de paredes externas o el aire tibio proveniente de una
fuente de aire caliente la alcancen directamente.
Para reducir el riesgo de descarga
eléctrica, este humidificador posee un
enchufe polarizado (una espiga es
más ancha que la otra). Este enchufe
encajará en un tomacorriente
polarizado de una sola forma.
ADVERTENCIA: Para reducir el riesgo de incendio o peligro de descarga
eléctrica, el humidificador debe estar enchufado a un tomacorriente de 120
V de CA No utilice extensiones
Ubicación de la unidad
Se debe colocar el humidificador con la
parte trasera (lado de salida del cable) y
los lados al menos a 2 pulgadas de la
pared. El aire tiene que ingresar por
todos los respiraderos en el conjunto del
alojamiento para que el humidificador
funcione con la mayor eficacia.
OBSERVACIÓN: Asegúrese de que el
humidistato (ubicado aproximadamente a
4 pulgadas fuera del cuerpo del
humidificador en el cable de energía) no
tenga obstrucciones y esté lejos de
cualquier fuente de aire caliente.
Paso 2. Conexión eléctrica
Ubíquelo lo más cerca posible de un tomacorriente de pared de 120 V de CA en
el lugar deseado, preferentemente en una pared interna. Con el humidificador en
la ubicación deseada, coloque el cable de manera segura para que nadie tropiece
ni moleste el funcionamiento del humidificador. Enchufe el cable.

20
Paso 3. Llenado con agua
ADVERTENCIA: para reducir el riesgo de
incendio o el peligro de una descarga
eléctrica, no deje caer agua dentro del
área de los controles o del motor. Si los
controles se humedecen, deje que se
sequen por completo y haga que el
personal de servicio autorizado revise la
unidad antes de enchufarla.
Después de ubicar el humidificador en el
lugar donde funcionará, usted está listo
para llenarlo. La botella se inclina y se
saca de la base. Tenga cuidado de no
golpear ni dañar el conjunto de válvula
de llenado en la parte inferior de la
botella.
Invierta la botella. Presione el botón del
eje de la válvula en la botella y gírelo en
sentido de las agujas del reloj para
bloquearlo en la posición abierta.
Coloque la botella debajo del grifo. Llene
la botella, con cuidado para evitar que
cualquier residuo ingrese en el asiento
de la válvula. Una vez que la botella esté
llena, presione el botón del eje de la
válvula y gire en sentido contrario a las
agujas del reloj para soltar y cerrar.
Coloque de nuevo la botella de agua en
la base del humidificador. Cuando se lo
coloca apropiadamente, el émbolo se
abrirá y el agua fluirá en la base. La base
tendrá la capacidad para el contenido
completo de la botella de agua. Una vez
que la botella se vacíe, retírela y repita el
proceso de llenado. El humidificador está
lleno hasta su capacidad máxima. Para
llenarlo con menos frecuencia, deje que
el humidificador termine el agua de la
botella y de la base antes de llenarlo.
PRECAUCIÓN: Utilice solamente el
bactericida registrado 1970 EPA. Bajo
ninguna circunstancia, utilice
productos de tratamiento de agua
diseñados para humidificadores
Rotobelt o Ultrasonic.
