MoJack PRO Installation instructions

Ver. 111716

MoJack PRO Lift
2
Introduction
This manual contains assembly, parts, operating,
maintenance, adjustment and safety instructions for
your MoJack PRO lift.
BEFORE USING YOUR MOJACK PRO, CAREFULLY
READ THIS MANUAL IN ITS ENTIRETY.
By following these operating, maintenance and safety
instructions, you will prolong the life of your MoJack lift
and promote safe operation.
If additional information is needed, or should you
require a trained service mechanic, contact your
authorized MoJack equipment dealer or distributor.
All MoJack parts are thoroughly tested and inspected
before leaving the factory to ensure that they comply
with all relevant safety standards.
NOTE: Please save this manual for future reference.
NOTE: Location of unit Serial Number.
Patent No. 7,823,861 and No. 7,789,375.
© 2011 MoJack Distributors, LLC.
MoJack and the MoJack logo are registered trademarks of MoJack Distributors, LLC.
MoJack PRO is a trademark of MoJack Distributors, LLC. All rights reserved.
Submit your questions online at:
Envie sus preguntas por Internet a:
Vous pouvez également transmettre votre question en ligne à l’adresse suivante :
www.theMoJack.com
Need
Assistance?
Please DO NOT return this
product to the store.
Our Customer Service
Department is ready to help!
1-877-575-3173
¿Necesita
ayuda?
¡NO devuelva este producto
a la tienda!
¡Nuestro Departamento de
Servicio de Atención al Cliente
está listo para ayudarle!
1-877-575-3173
Besoin
d’assistance ?
NE renvoyez PAS ce produit
au magasin .
Notre service clientèle est là
pour vous aider !
1-877-575-3173

MoJack PRO Lift
3
Warnings and Safety Instructions
IMPORTANT: The MoJack PRO is intended for use with riding lawn mowers and riding lawn tractors only. Do not
exceed 750 lbs. It should never be used to service other types of machinery unless there is an approved MoJack
accessory tted for the type of machinery. Please consult your local MoJack dealer or distributor.
Read and understand all safety and operating instructions before using the MoJack PRO.
Never allow anyone unfamiliar with the safety or operating instructions to use the MoJack PRO.
Follow all safety and servicing instructions provided by the lawn mower’s manufacturer before using
the MoJack PRO.
Do not modify the MoJack in any way. Any modications will void any and all warranties and could
compromise your personal safety.
When using the MoJack PRO, keep ALL bystanders at a safe distance away from the MoJack PRO.
The MoJack PRO must be used on a solid level surface.
Do not lift the front end and the back end of the mower at the same time.
Do not use MoJack PRO lift for anything other than a mower, unless the proper accessory is used.
Always stop engine and remove key before beginning any work on the mower.
Never operate the mower’s engine while using the MoJack PRO.
Do not exceed the lifting capacity of 750 lbs.
If the MoJack PRO Tower is leaning while lifting or lowering the mower, this indicates an overload
condition. Remove the mower immediately.
Tower must be locked in place with the Tower Locking Pin before using the MoJack PRO.
Do not remove safety warnings or decals from MoJack PRO.
Before each use, always check for any worn, loose or damaged parts on the MoJack PRO. If any
damaged parts are present, do not use the MoJack PRO and contact MoJack at 1-877-575-3173.
Do not climb on mower while it is lifted, being lifted or being lowered.
No one should be on the mower while it is lifted, being lifted or being lowered.
After the mower is raised to a working height, always place wheel chocks (not included) behind the back tires
of the mower.
Wheel Pads must be equal distance from the Lift Arm to maintain proper balance.
Remove all mower attachments before using the MoJack PRO.
Failure to follow these warnings may result in property damage and serious bodily injury or death.

MoJack PRO Lift
4
LIMITED WARRANTY
This warranty protects the lift frame against failure due to defect in material or workmanship when product is used properly for two
years of residential use and one year of commercial use. The lift winch is warrantied against failure due to defect in material or work-
manship for one year of proper use. MoJack will replace any defective part at no cost. This warranty does not cover any product that
has been altered or adjusted, or any product that has been misused or abused. THIS IS THE CUSTOMER’S SOLE AND EXCLUSIVE
REMEDY. MOJACK DISCLAIMS ALL IMPLIED WARRANTIES, INCLUDING THE WARRANTY OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE. MOJACK SHALL NOT BE LIABLE FOR ANY INCIDENTIAL OR CONSEQUENTIAL DAMAGES. SOME
STATES OR PROVINCES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF THE IMPLIED WARRANTIES OR THE REMEDIES
FOR BREACH OF THE IMPLIED WARRANTIES, SO THESE EXCLUSIONS MAY NOT APPLY TO YOU. THIS LIMITED WARRANTY
GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE OR
PROVINCE TO PROVINCE.
What does this warranty cover?
This warranty covers against a failure due to a defect in material or workmanship. It includes a one-year warranty on the lift winch from
the date of puchase. The lift frame includes a two-year warranty from date of purchase for residential use, and a one-year warranty from
date of purchase for commercial use.
What does this warranty NOT cover?
This warranty does not cover any MoJack which has been altered or adjusted in any way from its original model.
It will not cover any MoJack which has been damaged due to misuse, abuse, accident or negligence. This warranty does not cover
incidental or consequential damages.
What is the period of coverage?
One-year warranty on lift winch from date of purchase for the original owner. Two-year warranty on lift frame for residential use, one-year
warranty on lift frame for commercial use from date of purchase for the original owner.
What will MoJack do to correct problems?
We will replace any defective part (within the coverage period) at no charge.
How can I get service?
In order to be eligible for service under this warranty you MUST register your MoJack within thirty (30) days of
purchasing. You must keep your receipt as proof of date of sale. You can register your new MoJack on our website at
www.themojack.com or by calling our toll-free number 1-877-575-3173.
How do I contact MoJack about a warranty issue?
You can contact us from our website at www.themojack.com or by calling our toll-free number 1-877-575-3173.
Do I have other rights under State Law?
This warranty gives you specic legal rights, and you may also have other rights which vary from state to state.
What is the return policy?
Within thirty (30) days of the date that you receive your MoJack. Please contact MoJack for return policies and
procedures at our toll-free number 1-877-575-3173 or by email at [email protected].
How do I make a return?
Contact us within the return period. We will issue you a Return Merchandise Authorization (RMA) to place on the outside of the box.
All merchandise must be shipped back in its original packaging. We will make arrangements for the MoJack to be picked up by a
national carrier.
In what form will I receive my refund?
This is at our discretion. If receiving a refund, please allow four weeks for the credit to process to your account. Return service fees will
be deducted from the amount of the refund.
Are shipping charges refundable?
No.
Does MoJack have a return service fee policy?
Yes. Returns and refunds impose an extra workload on our parts. Rather than pass this cost on to the customer through higher product
prices, we are consistent with others within our industry by requiring nominal service fees in the event of returns. The service fee is 20%.
How do I contact MoJack?
You can call our toll-free number 1-877-575-3173 or by email at [email protected].
Warranty and Returns

MoJack PRO Lift
5
Parts List
1
Item
No. Qty. Description
Tower
Lift Arm
Base
Wheel
Wheel Pad
Lift Arm Insert
1
1
1
2
2
2
2
3
4
5
6
7
Item
No. Qty. Description
Grip Handle
Ratchet Release Handle
Winch
Winch Handle
Support Rod
Safety Strap
1
1
1
1
2
2
8
9
10
11
12
4
12
5
7
12
6
6
1
4
3
5
9
8
211
11
10

MoJack PRO Lift
6
Hardware List
13
Item
No. Qty. Description
Cap Screw – M12-1.75 x 85
Nylock Nut – M12-1.75
Cap Screw – M12-1.75 x 95
Cap Screw – M10-1.5 x 30
Nylock Nut – M10-1.5
Winch Washer – 10mm
2
4
1
3
5
3
14
15
16
17
18
13 Cap Screw – M12-1.75 X 85
19
Item
No. Qty. Description
Winch Handle Washer – 12mm
Clevis Pin
Push Pin
Hair Pin
Cap Screw – M14-2.0 x 100
Nylock Nut – M14-2.0
1
1
4
3
1
1
20
21
22
23
24
14 Nylock Nut – M12-1.75
15 Cap Screw – M12-1.75 X 95 16 Cap Screw –
M10-1.5 X 30 17 Nylock Nut –
M10-1.5
23 Cap Screw – M14-2.0 X 100
24 Nylock Nut – M14-2.0
19 Winch Handle
Washer – 12mm 20 Clevis Pin
21 Push Pin 22 Hair Pin
18 Winch Washer –
10mm
Tools Needed for Assembly
(2) 22mm Wrench (2) 17mm Wrench(2) 19mm Wrench

MoJack PRO Lift
7
Assembly Instructions
STEP 1
Remove MoJack PRO from package.
Inventory items to be certain all parts and hardware
are present. If any parts or hardware are missing,
please contact MoJack at 1-877-575-3173 or
email us at [email protected].
STEP 2
Assemble the Wheel to the Base
by inserting Cap Screw and Nylock Nut
and tighten. Repeat with second Wheel.
Note: Do not over tighten Nylock Nut.
Base 3
4 3
13 14
Wheel 4Nylock Nut
14
Cap Screw 13
Attach the Tower to the Base
using Cap Screw and Nylock
Nut as shown.
Note: Do not over tighten Nylock Nut.
STEP 3
Cap Screw 15
1 3
15
14
Base 3
Nylock Nut
14
Tower 1
Cap
Screw
Hole

MoJack PRO Lift
8
Assembly Instructions
STEP 6
Attach the Ratchet Release Handle to the top
of the Tower using Nylock Nuts and tighten
as shown.
8
117
Ratchet Release Handle 8Nylock Nuts
17
Winch Handle 10
STEP 7
Attach Lifting Strap from Winch Spool to the
Carrier using Cap Screw and Nylock Nut
and tighten as shown.
Note: Do not over tighten Nylock Nut.
23 24 Hex Nut 24 Cap Screw
23
Lifting StrapCarrier
Attach the Winch and Grip Handle
to the Tower using Cap Screws ,
Nylock Nuts and Winch Washers ,
and tighten as shown.
STEP 4
9
1
7
16
17
Nylock Nuts 17
Cap Screws 16
Grip Handle 7
Winch 9
Tower
1
Nylock Nut
17
STEP 5
Attach Winch Handle to Winch using
Nylock Nut and Winch Handle Washer
and tighten as shown.
10 9
14
Winch 9
Winch Handle Washer
19
Winch Handle
10
Tower 1
Nylock Nut
14
19
18 Winch Washer 18
Winch Washers
18

MoJack PRO Lift
9
Assembly Instructions
THIS COMPLETES ASSEMBLY.
Wheel Pad
STEP 10
Ready the Wheel Pads for installation by adding Sup-
port Rods and Hair Pins .
5
11 22
Hair Pin 22
Support Rod 11
Push Pin
21
STEP 11
Slide the Wheel Pads onto both sides of the
Lift Arm Inserts and secure with Push Pins .
Note: The Wheel Pads can be moved in or out to t dif-
ferent mower widths. Use the conguration that works
best with your model of lawn mower.
5
621
Lift Arm Insert 6
Wheel Pad
5
Lift Arm 2
Push Pin
21
Slide Lift Arm Inserts into both sides of the
Lift Arm and secure with Push Pins as shown.
STEP 9
6
221
Lift Arm Insert 6
Lift Arm Insert 6
Push Pin 21
STEP 8
Hang the Lift Arm on the Carrier by hooking
the slotted area of the Lift Arm under the top bar
of the Carrier. Lift Arm must be inserted from the
front and then lowered which fastens Lift Arm into
place. Insert Clevis Pin through the hole in the
Carrier and lock by fastening the Hair Pin to
the Clevis Pin.
2
20
22
Lift Arm 2
Top Bar of Carrier
Clevis Pin
20
Hair Pin
22
Carrier

MoJack PRO Lift
10
Operating Instructions
Preparing the MoJack PRO for Use (Steps 1 - 8)
STEP 1
Unfolding MoJack PRO
• Pull locking pin out to unlock.
• Raise the Tower by pulling up on the Grip Handle.
Once the Tower is in the vertical position, lift up on
the Grip Handle and drop the Tower into the Base.
• The tower will be securely locked in place when the
locking pin retracts and the tower is snug in the
channel behind the crossbar.
Some steps of the Operating Instructions are repeated from the
Assembly Instructions. The Operating Instructions will show a full
working cycle of the MoJack PRO.
Before using the MoJack PRO, carefully read this manual in its entirety.
Tower Locking Pin
(unlocked position)
Tower Locking
Pin
(locked position)
Tower Locking Pin
(unlocked position)
Crossbar in
channel
Crossbar
Drop Tower into Base
When Tower is
above the bar,
unit is NOT
locked and
UNSECURE.
When Tower sits
behind the bar,
unit is locked
and fully secure.

MoJack PRO Lift
11
Push Pin
Lift Arm Insert
Wheel Pad
Lift Arm
Push Pin
Lift Arm Insert
Lift Arm Insert
Push Pin
STEP 4
Installing Wheel Pads
• Slide Wheel Pads onto Lift Arm Inserts and
temporarily secure with Push Pins.
STEP 3
Installing Lift Arm Inserts
• Slide Lift Arm Inserts into both sides of the
Lift Arm and secure with Push Pins.
STEP 2
Installing Lift Arm
• Hang the Lift Arm on the Carrier by hooking the slotted area
of the lift Arm under the top bar of the Carrier. Lift Arm must
be inserted from the front and then lowered which fastens
Lift Arm into place.
• Secure Lift Arm to Carrier with Clevis Pin and Hair Pin.
Clevis Pin
Hair Pin
Lift Arm
Top Bar of Carrier
Slotted Area
Operating Instructions

MoJack PRO Lift
12
Operating Instructions
STEP 7
Adjusting Support Rods for Proper Tire Size
• Adjust Support Rods on Wheel Pads to accommodate the front
tire size of the mower. Please refer to the chart below for proper
Support Rod placement based on the diameter of the mower’s
front tires.
• Secure Support Rods to Wheel Pads with Hair Pins.
Support Rod
Hair Pin
See page 19 for more more detailed guide.
10” - 11.5” (25cm - 29cm)
12” - 15” (30cm - 38cm)
15.5” - 17” (39cm - 44cm)
SUPPORT ROD GUIDE FOR TIRE SIZES
STEP 6
Aligning Wheel Pads to Fit the Mower
• Place the front tires of mower 6” in front of
the Wheel Pads.
• Remove Push Pins and align the Wheel
Pads so that the front mower tires will be
centered on the Wheel Pads.
• Replace the Push Pins to lock the Wheel
Pads to the Lift Arm.
Wheel Pads must be equal distance from
the Lift Arm to maintain proper balance.
STEP 5
Familiarize Yourself with the MoJack PRO
• Practice raising and lowering the Lift Arm before
attempting to lift the mower. (see Steps 9-16 on
how to raise and lower the Lift Arm)
• Practice Step 21 if you intend to raise or lower the
mower with the drill attachment.

MoJack PRO Lift
13
STEP 10
Strapping Front Mower Tires to Wheel Pads
• Secure the front mower tires to the Wheel Pads using the
Safety Straps . Secure the hook on the Safety Strap to
the Wheel Pad Cross Bar and insert the Support Rod into
the loop on the Safety Strap by detaching the Support
Rod and then sliding the Safety Strap Loop through and
reattaching the Support Rod.
• Tighten the Safety Straps over the top of the tires to
secure mower to Wheel Pads.
14
Wheel Pad Cross Bar
Support Rod
Safety Strap
Operating Instructions
Using the MoJack PRO (Steps 9 - 16)
STEP 9
Move Mower onto MoJack PRO
The MoJack PRO must be used on a solid
level surface.
• Drive or roll the mower onto the Wheel Pads.
Stop engine and remove the key.
STEP 8
Reverse Front Tires of Mower (optional – if not applicable, skip to Step 9)
• In some cases, the mower deck or anti-scalping wheels will hit the
Lift Arm while the mower is being raised. This is often the case if
part of the deck (including the anti-scalping wheels) protrudes past
the center line of the front wheels of the mower.
• Rotate the front tires 180° so that they are in the reverse position.
• Remove the Support Rods from the Wheel Pads and slide the
MoJack PRO underneath the mower.
• Secure the Support Rods to Wheel Pads with Large Hair Pins.
Reverse
Wheel
Position
Forward
Wheel
Position

MoJack PRO Lift
14
Operating Instructions
STEP 13
Locking Carrier into the Safety Ratchet
• As the Carrier raises, the clicking sound indicates that the
Safety Ratchet is functioning properly. Once the mower is
at the desired working height, rotate the Winch Handle
counterclockwise 1/2 turn to release the tension off of the
Lifting Strap and allowing the Carrier to rest rmly on the
Safety Ratchet.
STEP 12
Raising the Mower
• Raise the mower by rotating the Winch Handle clockwise.
• See Step 21 for raising the mower with drill attachment.
Do not attempt to lift more than 750 lbs.
The MoJack PRO must be used on a solid level surface.
The engine must be turned off and key removed.
The mower must be in neutral.
The parking brake must be off when raising and/or lowering
the mower.
The Safety Straps must be rmly tightened.
Safety Ratchet
Carrier Lifting Strap
1/2 Turn
STEP 11
Adjusting the Winch Handle (optional)
• The optimal Winch Handle length is in the longer setting.
Some mowers have brush guards or larger hoods that
interfere with the longer Winch Handle. The Winch Handle
can be adjusted by removing the Nylock Nut and
Winch Handle Washer
and re-attaching
in the shorter setting.
Longer Setting – 12” Radius
Shorter Setting – 10” Radius
Winch Handle Washer
Nylock Nut

MoJack PRO Lift
15
STEP 16
Removing the Mower from the MoJack PRO
• Remove the Safety Straps from front mower tires.
• Removing Support Rods is optional during this step.
• Drive or roll the mower off of the Wheel Pads.
Operating Instructions
STEP 15
Lowering the Mower
• Remove wheel chocks.
• Release the parking brake.
• Mower must be in neutral.
• Rotate the Winch Handle 1/2 turn clockwise while squeezing the
Grip Handle and Ratchet Release Handle together. Keeping the
Grip and Ratchet Release Handles squeezed together, turn the
Winch Handle counterclockwise until the Wheel Pads are rmly
on the ground.
Grip Handle
Ratchet
Release
Handle
1/2 Turn
STEP 14
Preparing the Mower for Service
• Place wheel chocks (not included) behind the back tires of the mower.
• Now apply the parking brake on the mower.
Wheel Chock

MoJack PRO Lift
16
Clevis Pin
Hair Pin
Lift Arm
Push Pin
Lift Arm Insert
Lift Arm Insert
Push Pin
Operating Instructions
STEP 18
Removing LIft Arm Inserts
• Remove Lift Arm Push Pins and pull Lift Arm Inserts
from the Lift Arm.
• Store the Push Pins in the Lift Arm.
STEP 19
Unhooking the Lift Arm
• Remove Small Hair Pin and Clevis Pin from Lift Arm.
• Unhook the Lift Arm from the Carrier by lifting up on the
front of the Lift Arm and pulling out.
• Store the Clevis Pin and Hair Pin in the Lift Arm.
Lift Arm
Top Bar of Carrier
Slotted Area
Preparing the MoJack PRO for Storage (Steps 17 - 20)
STEP 17
Removing the Wheel Pads
• Remove Wheel Pad Push Pins and pull
Wheel Pads out from the Lift Arm Inserts.
• Store the Push Pins in the Wheel Pads.
Push Pin
Lift Arm Insert
Wheel Pad

MoJack PRO Lift
17
Operating Instructions
STEP 21
Raising the MoJack PRO with a power drill (optional)
• The MoJack PRO can be raised or lowered by using a
variable speed corded drill (7 amp minimum) or variable
speed cordless drill (18V minimum).
• The drill will require a 7/16” socket (not provided).
• Remove the Winch Handle by removing the
Nylock Nut and Winch Handle Washer.
• Firmly place the 7/16” socket on the Drill Reducer.
Rotate the drill in reverse (counterclockwise) to raise
the Lift Arm and rotate the drill forward (clockwise) to
lower the Lift Arm.
• Ratchet Release Handle and Grip Handle must be
squeezed together when lowering the Lift Arm.
• Follow all other operating instructions while using the drill attachment.
• Replace the Winch Handle for future use.
Operator must have a rm grip on the drill before
raising or lowering the Lift Arm.
Drill Reducer
7/16” Socket
Remove Winch Handle
STEP 20
Folding the MoJack PRO
• Pull locking pin out to unlock.
•Raise the Tower out of the Base by pulling up on
the
Grip Handle and then lower the Tower.
•The tower will be securely locked in place when the
locking pin retracts.
THE MOJACK PRO IS NOW READY FOR STORAGE OR TRANSPORT.
Tower Locking
Pin
(unlocked position)
Lift Tower
out of Base
Tower Locking
Pin
(locked position)

MoJack PRO Lift
18
Maintenance Schedule
• Before each use, always check for any worn, loose or
damaged parts on the MoJack PRO. If any damaged parts
are present, do not use the MoJack PRO and
contact MoJack at 1-877-575-3173.
• Check the Lifting Strap before every use. Make sure
the Lifting Strap is not damaged or torn and the
stitching on the loop is secure. If any of these issues
are present, do not use the MoJack Pro and call MoJack at
1-877-575-3173.
• Check that the Safety Ratchet is working properly.
As the Carrier raises, the clicking sound indicates that
the Safety Ratchet is functioning properly. Raise the Carrier
to the working height and rotate the Winch Handle counter-
clockwise 1/2 turn to release the tension
off of the Lifting Strap. If the Carrier does not rest rmly into
the Safety Ratchet and tension remains on the
Lifting Strap, do not use the MoJack Pro and call MoJack at
1-877-575-3173.
• Place lithium grease on the small cog of the winch and be-
tween the small cog on the winch and the braking mecha-
nism, and teeth and bolt of safety bar once a year or every
50 uses.
Check entire
length of
Lifting Strap
Winch
Small Cog
Winch
Carrier
Safety
Ratchet
Braking
Mechanism
Place Lithium
Grease
Carrier
Lifting Strap Loop

MoJack PRO Lift
19
10” – 11.5” (25cm – 29cm) Tire Size
12” – 15” (30cm – 38cm) Tire Size
15.5” – 17” (39cm – 44cm) Tire Size
Support Rod Guide for Tire Sizes
Not for use with tires over 17” (44cm) in size

Elevador MoJack PRO
20
Introducción
Este manual contiene instrucciones sobre montaje,
partes, funcionamiento, mantenimiento, ajuste y
seguridad del elevador MoJack PRO.
ANTES DE UTILIZAR EL ELEVADOR MOJACK PRO,
LEA CON ATENCIÓN TODO EL MANUAL.
Si sigue estas instrucciones de funcionamiento,
mantenimiento y seguridad, prolongará la vida del eleva-
dor MoJack y favorecerá su funcionamiento seguro.
Si necesita información adicional o un mecánico
de servicio especializado, póngase en contacto
con su vendedor o distribuidor autorizado de
equipos MoJack.
Todas las partes MoJack han sido rigurosamente pro-
badas e inspeccionadas en fábrica para garantizar el
cumplimiento de las normas de seguridad
pertinentes.
NOTA: guarde este manual para referencia futura.
NOTE: Emplazamiento de la unidad número de
serie.
Patente No. 7,823,861 y No. 7,789,375
© 2011 MoJack Distributors, LLC.
MoJack es una marca registrada de MoJack Distributors, LLC.
MoJack PRO es una marca registrada de MoJack Distributors, LLC.
Submit your questions online at:
Envie sus preguntas por Internet a:
Vous pouvez également transmettre votre question en ligne à l’adresse suivante :
www.theMoJack.com
Need
Assistance?
Please DO NOT return this
product to the store.
Our Customer Service
Department is ready to help!
1-877-575-3173
¿Necesita
ayuda?
¡NO devuelva este producto
a la tienda!
¡Nuestro Departamento de
Servicio de Atención al Cliente
está listo para ayudarle!
1-877-575-3173
Besoin
d’assistance ?
NE renvoyez PAS ce produit
au magasin .
Notre service clientèle est là
pour vous aider !
1-877-575-3173
