Mojawa MOJO2 User manual

MOJAWA Bone Conduction Headphones
User Guide
2021/11/24
MOJO2
User Guide

1 2
Product Composition
Noise-Cancelling Microphone
Microphone
Volume control
touchpad
Magnetic charging port
Power button/Multi-function button

3 4
Identify the Left and Right of the headset
by the volume Control touchpad and
LED indicator. They should be on the Right
Side. Wear the headset by wrapping it around
your head and letting it rest on your ears.
Slide your finger upward to
increase volume
Slide your finger downward to
decrease volume
Power On
Press and hold the power button for 2 seconds until you hear “ power on ”.
Release the power button when the indicator light is turned on.
Power Off
Volume Control
The volume control touchpad is located on the right. Slide your finger up to
increase the volume and slide down to decrease the volume; increase or decrease
the sliding speed for larger adjustments.
Press and hold the power button for 2 seconds until you hear “ power off ”.
Release the power button when the indicator light is turned off.
How to Wear

5 6
When the headset is powered off, press and hold the power
button for 5 seconds, listen for “power on” and a pairing tone.
The indicator light will flash to indicate. It is in pairing mode.
In your Bluetooth settings, search for “MOJO2” and tap to
connect. Listen for an indicator sound to indicate successful
pairing. The indicator light will be turned off after successful
pairing.
Choose “MOJO2” from your device’s Bluetooth settings and
select unpair. Wait for an indicator sound to indicate successful
unpairing. After unpairing, the indicator light will flash to
indicate it is ready to be paired with another device.
When the headset is powered on, it will automatically connect
to the last connected device. You can also manually connect it
to another device via Bluetooth settings. Once the headset is
connected, the indicator light will be turned off. If connection is
unsuccessful, the indicator light will keep on flashing.
Pairing
Unpair
Connect
In your Bluetooth settings, search for “MOJO2” and select to
disconnect. Listen for an indicator sound to indicate successful
disconnect.
Disconnect
In the connected state, if the distance between the headset and
the connected device exceeds the Bluetooth communication
range, the connection will be disconnected. The headset will
enter into pairing mode with the indicator light flashing. If the
distance between the headset and the connected device returns
to the Bluetooth communication range within 10 minutes, the
headset will automatically be connected again. If the headset is
not reconnected within 10 minutes, the headset will shut down
automatically.
Reconnect
automatically

7 8
2021/11/24
Play/Pause Music Press 1x indicator light on power on
indicator light off power off
indicator light flashing slowly not connected
indicator light flashing quickly pairing
indicator light stops flashing and turns off connected
indicator light flashing slowly charging, battery at medium
capacity
indicator light flashing quickly charging, low battery
quick-charging
indicator light on for 3 minutes then turns off
Battery Low - white light
flashes 3 times quickly
Very low battery - white light
flashes slowly 3 times;
Battery fully charged
low battery
Skip to next track Press 2x
Back to previous track Press 3x
Answer a call Press 1x to answer
Decline a call Press 2x to decline
Cancel an outgoing call Press 1x while calling
Hang up a call Press 1x during the call
Voice Assistant Click 2x the touchpad
Hold A's call and answer
incoming call from B
During a call with A, press 1x to answer incoming call
from B
End call with A and answer
incoming call from B
During a call with A, press 2x to end call with A and
answer incoming call from B
Multi-function button & volume control touchpad LED Light

9 10
2021/11/24
Model：
MOJO2
Speaker：Bone Conduction Speaker
Frequency Response：2.4GHz Bluetooth Range：
10m
Bluetooth Version：BT5.2 Protocol：A2DP 1.3 ( HFP ) AVRCP
1.5
Battery：Lithium Ion Battery Battery：130mAh
Charging：Charging Time：<=80 min
Playtime：8 hours Standby Time：130 hours
Microphone Sensitivity：-38dB Waterproof：IP67
Weight：26g Warranty：1 Year
5V 500mA
Specifications Charging
Restore to factory settings
Connect the USB-A end of the charging cable to a 5V power adapter. To charge the headset,
attach the magnetic charging head to the charging port of the headset.
The indicator light will flash during the charging process. When the battery is low, the light
will flash slowly; when it is charged to medium battery capacity, it will flash at a normally
speed. After charging is completed, the indicator light will stay on for 3 minutes, then turn
off .
Turn on the power, press and hold the power button for 8 seconds, the headset will be
restored to factory settings. All pairing information will be deleted, and it will enter into
pairing mode after automatic restart.
*Please charge the headset before using it for the first time. Make sure the charging port
is dry.

11 12
2021/11/24
Storage and Maintenance
The headset should be stored in a cool and dry place. It should be used at an ambient
temperature between 0°C(32℉) and 55°C(131℉), and charged at an ambient temperate between 0°C
and 40°C. Working in extremely cold, hot or humid environments may shorten the battery
life.
When left unused for a long time, please recharged the headset before use.
The headset can be cleaned regularly. Do not use high-pressure water to wash the
microphone or immersed the product in water for an extended period of time. Doing
so may damage the microphone or waterproof performance.If the charging port is wet,
dry it with a soft dry cloth before charging.

13 14
2021/11/24
Important Safety Instructions
Use manufacturer-designated accessories and supplies only.
Warning/Caution
When not in use, keep the headset away from children and pets.
This product contains lithium batteries which can be dangerous
if swallowed. If swallowed, seek immediate medical attention.
For use of the headset during activities that require concentration, such as cycling,
walking on or near roads, construction sites or railways, pay attention to your own
safety and that of others. Follow relevant laws regarding the use of headphones.
This product contains small parts which may be a choking hazard. It is not suitable
for children under age 3.
This product contains magnetic material. Consult your physician on whether this will
affect your implanted medical device.
Do not make unauthorized alterations to the product.
Use this product with power sources approved by relevant authorities and meet local
regulatory requirements (Ie. UL, CSA, VDE, CCC).
Do NOT expose the product to excessive heat (Ie. Avoid direct sunlight and keep away
from fire).
Do not expose the product to high temperature, smoke, or fume. Doing so may cause
it to catch on fire.
Do not charge the headset during thunder and lightning.
Do not throw the headset into fire. Doing so may cause the battery to explode under
high temperature.
Do NOT use the headset at a high volume for extended periods of time.
For use of the headset during driving, use with caution and follow applicable
laws regarding the use of mobile phones and headsets. Some jurisdictions
impose specific limitations on the use of such products while driving.
Do not use the headset for any other purposes while driving.
To avoid hearing damage, use the headset at a moderate volume.
Listening to music at high volume levels may damage your hearing
and the sound may be distorted.
-
-
Please turn the volume down before placing the headset on your ears ,
then gradually turn the volume up to a comfortable listening level.
•
•
•
•
•
•
•
•
•
•
•
•

15 16
2021/11/24
•
•
Do not expose this product to hot temperature, smoke, or fume least it may catch fire.
Do not charge this product during thunder and lightning.
The Bluetooth word mark and logos are regis tered traddemarks owned by Bluetooth
SIG, Inc.
Apple, the Apple logo, iPad, iPhone, and iPod are trademarks of Apple Inc, registered in
the U.S. and other countries/regions. App Store is a service mark of Apple Inc. Use of the
veloper to meet Apple performance standards. Apple is not responsible for the opera-
tion of this product or its compliance with safety and regulatory standards. Please note
that the use of this accessory with an Apple product may affect wireless performance.
Android, Google Play, and the Google Play logo are trademarks of Google LLC.
•
®
.
-
-
Accessories
Earplugs
For a more focused listening experience in noisy environments, please use the earplugs
including in the package to block out any background noises. Roll the earplugs to fit into
your ears.
Charging cable
Please only use the MOJO2 charging cable for charging. If the charging cable is damaged,
please replace it in time. Please follow 5V-500mA specifications for the power adapter.
Storage Bag
When not in use, keep the headset in the storage bag to avoid damages.

Contact us
If you have any other questions,
visit https://mojaverse.com
or mail to: [email protected]
Product specifications, designs, and the content of these
operating instructions are subject to change without notice.
For an update on MOJAWA, please visit our website: www.mojaverse.com
2021/11/24
17 18
USER GUIDE .indd 17-18

19 20
2021/11/24
Caution!
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment and receiver.
— Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
— Consult the dealer or an experienced radio/TV technician for help.
FCC Statement
This device complies with FCC radiation exposure limits set forth for an
uncontrolled environment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
FCC Statement
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
