A.S.04.03.15/ISSUE D
FILENAME: SD-69020-0500
ARBOR PRESS FIXTURE
PART No. 69020-0500
FOR MOLEX PRODUCT ENG. No. 90075 4 & 6 way
DESCRIPTION
This fixture is used to terminate 90075 4/4,6/4 & 6/6 way
connectors onto pre-cut and stripped cable.
FEATURES
1. This fixture can only be used in a standard Arbor Press part
No. 69020-0660.
2. For loose piece terminals only.
SPECIFICATION
SIZE: 100mm x 100mm x 20mm
WEIGHT: 3Kg
WORKING SERVICES: None

A.S.04.03.15/ISSUE D
FILENAME: SD-69020-0500
SET-UP
1) Fix upper block onto Arbor Press spindle and tighten locking
screw.
2) Place lower termination fixture onto mounting platform of
Arbor Press.
3) Make a few samples following the next section (operation)
and then check termination heights. If adjustment is
required see adjustments section.
OPERATION
1) Prepare cable in accordance with product specification
(e.g.: PS-90075).
2) Push pre-stripped cable into connector.
3) Insert connector into lower termination block.
4) Pull handle of Arbor Press down fully to terminate
connector.
5) Return handle to start position.
6) Release connector latch and remove cable assembly from
fixture.

A.S.04.03.15/ISSUE D
FILENAME: SD-69020-0500
ADJUSTMENTS
1) If termination height is incorrect then follow the procedure
below.
2) Loosen the stud nuts in the centre of the Arbor Press.
3) Loosen clamp bolt to column at the rear of the Arbor Press.
4) Adjust upper part of Arbor Press up or down using the nuts
on the central stud.
5) Re-tighten nuts and clamp bolt.
6) Recheck termination height.
MAINTENANCE
1) Keep fixture clean at all times.
2) Clean fixture with brush.
3) Oil moving parts weekly, when in use.
4) Store in a clean dry environment.
SPARE PARTS
Insertion Punch 4 way 69020-0505
Insertion Punch 6 way 69020-0506
Latching Punch 4 way 69020-0511
Latching Punch 6 way 69020-0512

A.S.04.03.15/ISSUE D
FILENAME: SD-69020-0500
QUALITY
Check termination quality against the Molex wire
termination specification for relevant product being
terminated e.g.: PS-90650.
A quality procedure should be in place to monitor output
from this fixture.
LIMITATIONS
This Arbor Press can only be used for product stated in
the description section of this leaflet.
