molex 207129 Series User manual

Air Crimp Tool Head
Doc No. ATS-640056300 Release Date: 03-13-06 UNCONTROLLED COPY Pa e 1 of 7
Revision: C Revision Date: 11-19-12
Air Powered
Crimp Tool Head
Insulkrimp


Application Toolin
Specification Sheet Order No. 64005-6300
FEATURES
 Quick chan e tool head for the 19279-0001 (AT-200)
 Toolin kit is interchan eable with other kits in the 64001 and 64003 Series
 A precision user-friendly terminal locator wire stop holds terminals in the proper crimpin position for each of
the three nests
 3-nested tool eliminates the need for additional tools
 Pneumatic powered crimp tools help reduce fati ue and discomfort from repetitive manual crimpin
SCOPE
Products: InsulKrimp™ Pi yback Quick Disconnects Terminals 10–22 AWG. This tool head is intended for
use in the 19279-0001 (AT-200) either hand held or with optional bench adapter 19078-0307 (ATBA)
and foot switch.
Testin
Mechanical
The tensile test, or pull test, is a means of evaluatin the mechanical properties of the crimped connections.
The followin charts show the UL specifications for various wire sizes. The tensile stren th is shown in
pounds and indicates the minimum acceptable force to break or separate the terminal from the conductor.
Wire Size (AWG)
*UL
-
310
22
8
20
13
18
20
16
30
14
50
12
70
10
80
*UL – 310 – Quick Disconnects
The followin is a partial list of the product part numbers and their specifications that this tool is desi ned to
run. We will be addin to this list and an up to date copy is available on www.molex.com.
Wire Size: 14
–
16 AWG 2.00
–
1.30mm²
Terminal No.
Terminal
En No. (REF)
Terminal No.
Mylar Tape
Wire Strip Len th
Insulation Diameter Maximum
In.
mm
In.
mm
19013
-
0005
BB
-
2318
19013
-
0006
.313
7.94
.16
5
4.19
19013
-
0007
BB
-
2318X
19013
-
0008
.313
7.94
.165
4.19
19013
-
0029
BB
-
2318
19013
-
0030
.313
7.94
.165
4.19
19013
-
0031
BB
-
2318X
19013
-
0032
.313
7.94
.165
4.19

Air Crimp Tool Head
Doc No. ATS-640056300 Release Date: 03-13-06 UNCONTROLLED COPY Pa e 2 of 7
Revision: C Revision Date: 11-19-12
SHORTER
TAB LOCATOR
CONDUCTOR
ANVIL
TERMINAL
Fi ure 2
WIRE
TERMINAL
BARREL
TERMINAL TAB
WIRE
PUNCH INSERT
ANVIL INSERT
Fi ure 3
CONDUCTOR
PUNCH
LOCATOR
WIRE STOP BUILT
INTO TERMINAL
TAB LOCATOR
Wire Size: 18
–
22 AWG 0.80
–
0.35mm²
Terminal No. Terminal En No. (REF)
Terminal No.
Mylar Tape
Wire Strip Len th
Insulation Diameter Maximum
In.
mm
In.
mm
19013
-
0001
AA
-
2317
19013
-
0002
.313
7.94
.140
3.56
19013
-
0003
AA
-
2317X
19013
-
0004
.313
7.94
.140
3.56
19013
-
0025
AA
-
2317
19013
-
0026
.313
7.94
.140
3.56
19013
-
0027
AA
-
2317X
19013
-
002
8
.313
7.94
.140
3.56
OPERATION
Refer to the instruction manual for the 19279-0001 (AT-200) for
mountin this crimp tool head.
Crimpin Terminals
1. Push the terminal onto the tab locator all the way to the stop
in the proper color-coded nest. The male tab of the terminal
should be up. See Fi ure 1.
2. The hei ht of the locator may need to be adjusted when
chan in from one terminal size to another. To do this,
loosen the locator lock nut, (See Fi ure 3), and adjust hei ht
so the tab ali ns with the female locator tab. Ti hten the lock
nut.
3. Insert the wire into the terminal. Push the terminal and wire onto the tab locator all the way to the stop in
the proper color-coded nest. The barrel of the terminal should be up. See Fi ure 2.
4. In some cases, the overall size of the terminal prohibits it from bein loaded throu h the crimp dies and
into the locator. If so, the shorter tab locator, included with this tool, must be installed and then the
terminal can be loaded from the end or opposite side. Then the terminal can be crimped while holdin in
place with the wire. The shortened tab locator is stored underneath the locator. See fi ure 3.
MALE TAB
FACING UP
SAFETY
SHIELD
TAB LOCATOR
Fi ure 1
LOCATOR
JAWS
OPEN

Air Crimp Tool Head
Doc No. ATS-640056300 Release Date: 03-13-06 UNCONTROLLED COPY Pa e 3 of 7
Revision: C Revision Date: 11-19-12
CAUTION: Never operate this tool without the supplied safety shield in place. Never place fin ers in
the tool nests.
5. Push on the wire to assure it is still fully seated in the terminal. The wires end should butt a ainst the wire
stop stamped into each terminal. See Fi ure 2 and 3. Cycle the tool.
6. Remove the crimp and inspect for proper crimp location. Molex offers a Crimp Inspection Handbook for
closed barrel industrial product. See our website or contact your sales en ineer.
Note: Whenever crimpin without the locator, make sure the seam of the terminal is oriented up or down
in the tool if usin un-brazed product, as this will provide hi her pull force values.
7. If the insulation part of the crimp needs to be adjusted, first loosen the M4 screw on the bottom tool jaw,
then insert a 3/32 hex wrench (supplied) into the bottom of the lower die. See Fi ure 4. A clockwise
(CW) rotation decreases insulation crimp while a counter-clockwise (CCW) rotation increases insulation
crimp. After adjustin reti hten the M4 screw.
Maintenance
It is recommended that each operator of the tool be made aware of, and responsible for, the followin
maintenance steps:
1. Remove dust, moisture and other contaminants with a clean brush, or soft, lint-free cloth.
2. Do not use any abrasive materials that could dama e the tool.
3. Make certain all pins; pivot points and bearin
surfaces are protected with a thin coat of hi h
quality machine oil. Do not oil excessively. This
tool was en ineered for durability, but like any
fine piece of equipment it needs cleanin and
lubrication for a maximum service life of trouble-
free crimpin . Use a li ht oil such as 30 wei ht
automotive oil at the oil points shown in Fi ure
4, every 5,000 crimps or monthly will
si nificantly enhance the tool life and ensure a
stable calibration.
4. When tool is not in use store the tool in a clean,
dry area.
LUBRICATION POINTS
(BOTH SIDES)
LIGHT OIL (EVERY MONTH
OR 5,000 CRIMPS)
LOOSEN
M4 SCREW
Fi ure 4
3/32” HEX
WRENCH

Air Crimp Tool Head
Doc No. ATS-640056300 Release Date: 03-13-06 UNCONTROLLED COPY Pa e 4 of 7
Revision: C Revision Date: 11-19-12
Tool Calibration
A Certificate of Calibration (see last pa e) was supplied with the tool. To
recalibrate this tool, pin au e measurements should be taken in each
conductor nest and compared to this chart. The tool should be lubricated
prior to recalibration to ensure consistent measurements.
Nest Color Code
Wire Ran e
“X” Dimension
Conductor Crimp
Crimp InspectionMarkin
AWG
mm²
Mean
Go
No Go
Red
18
-
22
0.35
-
0.80
.072
.068
.076
N/A
Blue
14
-
16
1.30
-
2.00
.090
.086
.094
N/A
Yellow
10
-
12
3.30
-
5.00
.134
.130
.138
N/A
CAUTION: Repetitive use of this tool should be avoided.
Warranty
This tool is for electrical terminal crimpin purposes only. This tool is made of the best quality materials. All
vital components are lon -life tested. All tools are warranted to be free of manufacturin defects for a period
of 30 days. Should such a defect occur, we will repair or exchan e the tool free of char e. This repair or
exchan e will not be applicable to altered, misused or dama ed tools. This tool is desi ned for hand use
only. Any clampin , fixturin , or use of handle extensions voids this warranty.
CAUTION: Molex crimp specifications are valid only when used with Molex terminals, applicators and toolin .
PIN GAUGE IN
CONDUCTOR CRIMP
“Confinin ” Crimp
X

Air Crimp Tool Head
Doc No. ATS-640056300 Release Date: 03-13-06 UNCONTROLLED COPY Pa e 5 of 7
Revision: C Revision Date: 11-19-12
3
2
1
Fi ure 5
M4 LOCKNUT W/HEX
NYLON INSERT
M4 FLAT WASHER
4
5
6
7
8
(2)
PARTS LIST
Item
Order
No
Description
Quantity
64005
-
6300
Crimp Tool Head
Fi
ure
5
1
64005
-
0000
Basic Air Tool Head
1
2
64001
-
6275
Locator Assembly
1
3
64001
-
6370
Toolin Kit
1
Toolin Kit Only
4
64001
-
6301
Conductor Punch
1
5
64001
-
6302
Conductor Anvil
1
6
64001
-
0312
Insert Punch
1
7
64001
-
0311
Insert Anvil
1
8
N/A
4mm Dia
meter
by 5.0mm L
on
Roll Pins
2**
**
A
vailable from an Industrial supply company such as (MSC 1
-
800
-
645
-
7270).

Air Crimp Tool Head
Doc No. ATS-640056300 Release Date: 03-13-06 UNCONTROLLED COPY Pa e 6 of 7
Revision: C Revision Date: 11-19-12
Fi ure 6
3
4
2
2
2
5
1
(4)
(4)
(2)
(4)
2
2
(2)
(2)
2
Parts List (Continued)
Item
Order No.
Description
Quantity
64005
-
0000
Basic Air Tool Head
Fi ure 6
1
64005
-
0103
Nose Guard
1
2
64000
-
0077
Repair Kit (Sprin s, Rods Pivots ,Rin s, and Washers)
1
3
N/A
M4 by 12 Lon Freedrive Pan Head Screw
1**
4
N/A
M4 by 30 Lon Freedrive Pan Head Screw
1**
5
N/A
3
/16” by 3/8” Lon Dowel Pin
1**
** Available from an industrial supply company such as MSC (1
-
800
-
645
-
7270).

Air Crimp Tool Head
Doc No. ATS-640056300 Release Date: 03-13-06 UNCONTROLLED COPY Pa e 7 of 7
Revision: C Revision Date: 11-19-12
Air Powered
Crimp Tool Head
Insulkrimp


Certificate of Calibration
Order No. 64005-6300
Tool Order Number __________________
Tool En . Number___________________
Tool Revision______________________
Serial Number_____________________
Date of Manufacture
Pin Gau e of Conductor Nest/Nests or Slu hei ht if the nest is the “F” Crimp style.
Ran e Conductor Nest # 1 = ____________- Actual = ____________-
Ran e Conductor Nest # 2 = ____________- Actual = ____________-
Ran e Conductor Nest # 3 = ____________- Actual = ____________-
Technician _______________________-
Date of Calibration __________________-
Calibration should be done every 5,000 cycles or 3 months.
Tools should be lubricated durin this operation.
Visit our Web site at http://www.molex.com
