molex 207129 Series User guide

Hand Crimp Tool for .54mm (.100") Pitch MX64™ Crimp Terminals
Doc No: ATS-6381142HM Release Date: 04-08-03 UNCONTROLLED COPY Page 1 of 6
Revision: G Revision Date: 07-27-23
Order Number
63811-4200
Application Tooling
Specification Sheet
FEATURES
A full-cycle ratcheting hand tool ensures complete crimps
Ergonomically designed soft handles
Precisely designed crimping profiles with simple contact positioning
Easy handling due to outstanding force ratio
This tool is IPC/WHMA-A-620 compliant
Modular Crimp Head is removable and can be used in the Electric Crimp Machine (Order No. 63816-1900),
accompanied by Crimp Adapter (Order No. 63816-1950)
Can also be used in the Battery Powered Tool Order No. 63816-0270 (110 V) or 63816-0280 (220 V),
accompanied by Crimp Adapter (Order No. 63816-1950)
SCOPE
Products: .54mm (.100") Pitch MX64™ Crimp Terminals, 18-22 AWG.
Terminal Series No.
Terminal Order No.
Wire Size
Insulation Diameter
Maximum
Strip Length
●Reel Form Only
AWG
mm²
mm
In.
mm
In.
33467
33467-0005
33467-0006
18
0.83
1.91-2.06
.075-.081
2.70-3.50
.106-.138
20
0.58
1.70-1.85
.067-.073
2.70-3.50
.106-.138
33467-0003
33467-0004
22
0.36
1.50-1.65
.059-.065
2.70-3.50
.106-.138
33468
33468-0003
33468-0004
18
0.83
1.91-2.06
.075-.081
2.70-3.50
.106-.138
20
0.58
1.70-1.85
.067-.073
2.70-3.50
.106-.138
33468-0001
33468-0002
22
0.36
1.50-1.65
.059-.065
2.70-3.50
.106-.138
34736-
34736-1002
34736-2002
18
0.83
1.91-2.06
.075-.081
2.70-3.50
.106-.138
20
0.58
1.70-1.85
.067-.073
2.70-3.50
.106-.138
34736-1001
34736-2001
22
0.36
1.50-1.65
.059-.065
2.70-3.50
.106-.138
●Customer to cut off terminal from reel: 0.50mm (.020”) maximum Cut-off Tab.
Terminal will accommodate the following wire specification:
SAE: ESB-M1L123-A, WSS-M1L135-A1, and SAE-J1128 Metric: WSK-M1L126-A1
TYPE 4A

Hand Crimp Tool for .54mm (.100") Pitch MX64™ Crimp Terminals
Doc No: ATS-6381142HM Release Date: 04-08-03 UNCONTROLLED COPY Page 2 of 6
Revision: G Revision Date: 07-27-23
INSULATION
CRIMP HEIGHT
BRUSH
STRIP
LENGTH
BELL MOUTH
CONDUCTOR
CRIMP WIDTH
BEND
DOWN
BEND UP
ROLLING
TWISTING
●CUT-OFF TAB
INSULATION
CRIMP WIDTH
CONDUCTOR
CRIMP HEIGHT
DEFINITION OF TERMS
The above terminal drawing is a generic terminal representation. It is not an image of a terminal listed in the scope.
CRIMP SPECIFICATION
Terminal
Series No.
Bell mouth
Cut-off Tab Maximum
Conductor Brush
mm
In.
mm
In.
mm
In.
33467
33468
33468
0.25-1.25
.010-.049
0.50
.020
0.10-0.55
.004-.022
Not produced by this Hand tool
Terminal Series No.
Bend up Bend down
Twist Roll
Seam
Seam shall not be open
and no wire allowed out
of the crimping area
33467
33468
34736
Crimped samples must pass thru and cutoff tab must
freely fit in the Checking Aid, Part No. 63867-3008
Order Separately
After crimping, the conductor profile should measure the following.
Terminal
Series No.
Wire Size
Conductor Crimp
Insulation Crimp
Pull Force
Minimum
Profile
AWG
Height
Width
Height
Width
AWG
mm2
mm
In.
mm
In.
mm
In.
mm
In.
N
Lb.
22
18
20
33467
18
0.83
1.10-1.20
.043-.047
1.75-1.85
.069-.073
2.00-2.20
.079-.087
1.85-2.05
.073-.081
90.0
20.25
X
20
0.58
1.05-1.15
.041-.045
1.75-1.85
.069-.073
1.85-2.05
.073-.081
1.85-2.05
.073-.081
75.0
17.00
X
22
0.36
0.90-1.00
.035-.039
1.40-1.50
.055-.059
1.50-1.70
.059-.067
1.70-1.90
.067-.075
50.0
11.25
X
33468
18
0.83
1.10-1.20
.043-.047
1.75-1.85
.069-.073
2.00-2.20
.079-.087
1.85-2.05
.073-.081
90.0
20.25
X
20
0.58
1.05-1.15
.041-.045
1.75-1.85
.069-.073
1.85-2.05
.073-.081
1.85-2.05
.073-.081
75.0
17.00
X
22
0.36
0.90-1.00
.035-.039
1.40-1.50
.055-.059
1.50-1.70
.059-.067
1.70-1.90
.067-.075
50.0
11.25
X
34736
18
0.83
1.10-1.20
.043-.047
1.75-1.85
.069-.073
2.00-2.20
.079-.087
1.85-2.05
.073-.081
90.0
20.25
X
20
0.58
1.05-1.15
.041-.045
1.75-1.85
.069-.073
1.85-2.05
.073-.081
1.85-2.05
.073-.081
75.0
17.00
X
22
0.36
0.90-1.00
.035-.039
1.40-1.50
.055-.059
1.50-1.70
.059-.067
1.70-1.90
.067-.075
50.0
11.25
X
Pull Force should be measured with no influence from the insulation crimp. The above specifications are guidelines
to an optimum crimp.

Hand Crimp Tool for .54mm (.100") Pitch MX64™ Crimp Terminals
Doc No: ATS-6381142HM Release Date: 04-08-03 UNCONTROLLED COPY Page 3 of 6
Revision: G Revision Date: 07-27-23
CONDUCTOR
PUNCH
WIRE
LOCATOR
TERMINAL
INSULATION
PUNCH
INSULATION
ANVIL
CONDUCTOR
ANVIL
L
WIRE STOP
BLADES
Figure 2
RETAINER
SPACER
TERMINAL
PRE-STRIPPED
WIRE
LOCATOR
Figure 1
WIRE STOP
BLADES
NOTE:
Straightness:
A Crimped terminal lead must be
able to pass freely through the
Checking Aid **, Part No.63867-
3008 (ordered separately if
required)
B Wire on the crimped lead must
meet all specification above.
OPERATION
Open the tool by squeezing the
handles together, at the end of the
closing stroke, the ratchet mechanism
will release the handles, and the hand
tool will spring open.
Crimping Terminals
1. Lift the wire stop blades up.
2. Insert the terminal fully into the correct die profile and
the locator slot until the terminal is fully seated and
stops.
3. Bring down the wire stop blades. Make sure the wire stop blades are fully seated on the terminal behind
the conductor grip section.
4. Slide the pre-stripped wire into the terminal; make sure to aim the wire brush towards the tip point on the
wire stop blade. See Figure 1. Align the wire so that it is parallel and sitting into the terminal. Maintain a
light and constant pressure on the wire that is seated in the terminal at all times. (Do not let go of the
wire.) Be sure to hold the wire and terminal in place until the terminal is fully crimped. See Figure 2.
5. Close the tool until the ratchet releases.
Flush to below Insulation Crimp Typ.
R 1.50
The Cut-Off Tab length shall not exceed 0.5mm,
No Burrs may result from removal of Cut-Off Tab
Wire Brush to be Visible
but not to exceed 0.55mm
Wire Brush to be Below Conductor Crimp
22.0 Minimum
See Note Below
0.18mm Max. All around
Conductor Crimp
Insulation Crimp
3Max.
See Note Below
3Max.
See Note Below

Hand Crimp Tool for .54mm (.100") Pitch MX64™ Crimp Terminals
Doc No: ATS-6381142HM Release Date: 04-08-03 UNCONTROLLED COPY Page 4 of 6
Revision: G Revision Date: 07-27-23
6. Lift the wire stop blades up.
7. Carefully remove the crimped terminal.
Note: The tamper proof ratchet action will not release the tool until it has been fully closed.
Note: To maintain good brush control and a consistent bell mouth the crimping instructions must be followed.
Maintenance
It is recommended that each operator of the tool be made aware of, and responsible for, the following
maintenance steps:
1. Remove dust, moisture, and other contaminants with a clean brush, or soft, lint free cloth.
2. Do not use any abrasive materials that could damage the tool.
3. Make certain all pins; pivot points and bearing surfaces are protected with a thin coat of high quality machine
oil. Do not oil excessively. The tool was engineered for durability but like any other equipment it needs
cleaning and lubrication for a maximum service life of trouble free crimping. Light oil (such as 30 weight
automotive oil) used at the oil points, every 5,000 crimps or 3 months, will significantly enhance the tool life.
4. Wipe excess oil from hand tool, particularly from crimping area. Oil transferred from the crimping area onto
certain terminations may affect the electrical characteristics of an application.
5. When tool is not in use, keep the handles closed to prevent objects from becoming lodged in the crimping dies,
and store the tool in a clean, dry area.
Miscrimps or Jams
Should this tool ever become stuck or jammed in a partially closed position, Do Not force the handles open or
closed. The tool will open easily by lifting the ratchet release lever. See Figure 6.
Warranty
This tool is for electrical terminal crimping purposes only. This tool is made of the best quality materials. All vital
components are long life tested. All tools are warranted to be free of manufacturing defects for a period of 30
days. Should such a defect occur, we will repair or exchange the tool free of charge. This repair or exchange will
not be applicable to altered, misused, or damaged tools. This tool is designed for hand use only. Any clamping,
fixturing, or use of handle extensions voids this warranty.
CAUTION: Repetitive use of this tool should be avoided.
CAUTIONS:
1. Manually powered hand tools are intended for low volume or field repair. This tool is NOT intended for
production use. Repetitive use of this tool should be avoided.
2. Insulated rubber handles are not protection against electrical shock.
3. Wear eye protection at all times.
4. Use only the Molex terminals specified for crimping with this tool.
Notes:
1. This tool should only be used for the terminals and wire gauges specified on this sheet.
2. This tool is not adjustable for crimp height; however crimp force is adjustable (See instructions above).
Variations in tools, terminals, wire stranding, and insulation types may affect crimp height.
3. This tool is intended for standard conductor sizes. It may not give a good insulation crimp support for all
insulation sizes.

Hand Crimp Tool for .54mm (.100") Pitch MX64™ Crimp Terminals
Doc No: ATS-6381142HM Release Date: 04-08-03 UNCONTROLLED COPY Page 5 of 6
Revision: G Revision Date: 07-27-23
MODULAR
CRIMP
HEAD
CRIMP
ADAPTER
LOCKING
PINS
LOCKING PINS
BATTERY
POWERED
TOOL
4. Molex does not repair hand tools (see warranty above). The replacement parts listed are the only parts
available for repair. If the handles or crimp tooling is damaged or worn, a new tool must be purchased.
5. Pull force should be used as the final criteria for an acceptable crimp. Pull force is measured with no
influence from the insulation crimp. The insulation should be stripped long (1/2 in.) so the insulation grips
on the terminal do not grip the wire insulation or the conductor. Refer to Molex Quality Crimping
Handbook 63800-0029 for additional information on crimping and crimp testing.
6. Molex does not certify crimp hand tools.
CAUTION: Molex crimp specifications are valid only when used with Molex terminals and tooling.
APPLICATIONS FOR THE MODULAR CRIMP HEAD
WARNING: NEVER operate, service, install, or adjust this Modular Crimp Head without proper instruction
and without first reading and understanding the instructions in the proper Manual or Specification Sheet.
See Chart below for the correct Manual or Specification Sheet.
WARNING: NEVER install tooling or service this tool while it is into any power source. Disconnect the
power by unplugging or turn off the Actuator from its power source.
CAUTION: Keep fingers away from the crimping area when operating this tool. It may cause severe injury.
CAUTION: Wear safety glasses when operating or serving this tool.
Tool
Order no.
Tool
Description
Adapter
Order No.
Adapter
Description
Figure
No.
63816-0270
Battery Power Tool (110 V)
63816-1950
Crimp Adapter
3
63816-0280
Battery Power Tool (220 V)
63816-1950
Crimp Adapter
3
63816-1900
Electric Crimp Machine
63816-1950
Crimp Adapter
4
Applications for the Modular Crimp Head
Hand Crimp Tool
Battery Powered Tool
Electric Crimp Machine
Figure 3
Figure 4
MODULAR
CRIMP
HEAD
LOCKING
PINS
HAND CRIMP
FRAME LONG
OR SHORT
ELECTRIC
CRIMP
MACHINE
INSTALL CRIMP ADAPTER
WITH CRIMP HEAD HERE

Hand Crimp Tool for .54mm (.100") Pitch MX64™ Crimp Terminals
Doc No: ATS-6381142HM Release Date: 04-08-03 UNCONTROLLED COPY Page 6 of 6
Revision: G Revision Date: 07-27-23
RATCHET
RELEASE LEVER
HANDLE
SPRING
CRIMPING
SPRING (2)
2
5
3
Figure 5
M4 X 12mm
LONG BHCS
1
4
PARTS LIST
Item
Order Number
Description
Quantity
1
---
Hand Crimp Frame
1
2
63811-4275
Terminal Locator
1
3
63816-0001
Locking Pin
2
4
63600-0525
Handle Spring
1
5
63600-0520
Crimping Spring
2
Application Tooling Support
E-Mail: [email protected]
Website: www.molex.com/applicationtooling
Molex is a registered trademark of Molex, LLC in the United States of America and may be registered in other countries; all other
trademarks listed herein belong to their respective owners.
