RHT-5771 Hand Crimp Tool
Doc No. 64001-4500 Release Date: 10-24-03 UNCONTROLLED COPY Page 1 of 6
Revision: B Revision Date: 07-05-06
Hand Crimp Tool
Operating Instruction Sheet and Specifications
Part No. 64001-4500
Eng. No. RHT 5771
(Replaces 19285-0051)
FEATURES
 A full cycle ratcheting hand tool ensures complete crimps
 An economical tool for portable crimping and field repair
 3-nested tool eliminates the need for additional tools
SCOPE
Perma-SealStep Down Butt Splices for 14-16 to 18-22 AWG and 10-12 to 14-16 AWG. FIQD Couplers Male and Female for
14-22 AWG.
Testing
Mechanical
The tensile test, or pull test, is a means of evaluating the mechanical properties of the crimped connections. The following charts
show the UL specifications for various wire sizes. The tensile strength is shown in pounds, and it indicates the minimum acceptable
force to break or separate the terminal from the conductor.
UL – 486 A* UL – 486 C** UL*310***
Wire Size (AWG) Min. Pull Min. Pull Min. Pull
22 8 8 8
20 13 10 13
18 20 10 20
16 30 15 30
14 50 25 50
12 70 35 70
10 80 40 80
*UL - 486 A - Terminals (copper conductors only).
**UL - 486 C - Butt Splices
***UL – 310 – Couplers
The following is a partial list of the product part numbers and their specifications that this tool is designed to run. We will be adding to
this list and an up to date copy is available on www.molex.com.

RHT-5771 Hand Crimp Tool
Doc No. 64001-4500 Release Date: 10-24-03 UNCONTROLLED COPY Page 2 of 6
Revision: B Revision Date: 07-05-06
Figure 2
WIRE
TERMINAL
TERMINAL
WIRE
CONDUCTOR
PUNCH
CONDUCTOR
ANVIL
Figure 3
LOCATOR
Wire Size: 18 – 22 AWG 0.80 –0.35mm²
Wire Strip Length Insul. Dia. Max.
Terminal No. Terminal Eng No. (REF) In mm In mm
19164-0015 SAA-9260 .313 7.94 .145 3.68
19164-0017 SAA-9261 .313 7.94 .165 4.19
Wire Size: 14 –16 AWG 2.00 –1.30mm²
Wire Strip Length Insul. Dia. Max.
Terminal No. Terminal Eng No. (REF) In mm In mm
19164-0048 SBB-9262 .313 7.94 .170 4.32
19164-0050 SBB-9263 .313 7.94 .170 4.32
STEP DOWN BUTT SPLICE
Wire Size: 14 –16 AWG 2.00 –1.30mm²to
18 - 22 AWG .080-0.35 mm²
Wire Strip Length Insul. Dia. Max.Terminal No. Terminal Eng No. (REF)
In mm In mm
19164-0043 SBA-631 .281 7.14 .230 5.84
STEP DOWN BUTT SPLICE
Wire Size: 10 –12 AWG 5.00 –3.30mm²to
14 - 16 AWG 2.00-1.30 mm²
Wire Strip Length Insul. Dia. Max.Terminal No. Terminal Eng No. (REF)
In mm In mm
19164-0077 SCB-646 .281 7.14 .300 7.62
OPERATION
Crimping Terminals
Open the tool by first closing the jaws sufficiently for the ratchet mechanism to release.
1. Adjust the locator up or down until the terminal being run sits flat and straight in
the tool.
2. Position the locator for the proper color-coded nest by removing the #4-40 X
3/8”Lg. BHSCS under the bracket of the locator. Place it in the desired position that
corresponds with the color-coded nest being used. Tighten the BHSCS.
3. Place the terminal into the locator and push until the terminal is flush against the
locator face shown in Figure 1.
4. Partially close the hand tool jaws until the connector is held snug in place, See Figure 2.
5. Insert the properly stripped wire into the terminal barrel (See Figure 2 and 3).
6. Complete the crimp by closing the hand tool handles until they release.
Note: The tamper proof ratchet action will not release the tool until it has been fully closed.
TERMINAL
JAWS
OPEN
Figure 1
LOCATOR

RHT-5771 Hand Crimp Tool
Doc No. 64001-4500 Release Date: 11-06-03 UNCONTROLLED COPY Page 3 of 6
Revision: B Revision Date: 07-05-06
7. Remove the crimp and inspect for proper crimp. Molex offers a Crimp Inspection Handbook for closed barrel industrial product.
See our website or contact your sales engineer.
Crimping Butt Splices
When crimping butt splices, the locator must be removed.
1. Position the splice into the proper color-coded nest.
2. Partially close the tool to hold the splice in place.
3. Insert the properly stripped wire into the splice. The wires end
should butt against the tab in the terminal (See Figure 4). Cycle the
tool.
4. Remove the crimped splice. Inspect for proper crimp location.
5. Rotate the butt splice terminal 180°, so that the opposite end of
splice is in the nest.
6. Repeat steps 2 thru 4.
Note: Whenever crimping without the locator, make sure the seam of the terminal is oriented up or down in the tool if using
unbrazed product, as this will provide higher pull force values.
Maintenance
It is recommended that each operator of the tool be made aware
of, and responsible for, the following maintenance steps:
1. Remove dust, moisture and other contaminants with a clean
brush, or soft, lint-free cloth.
2. Do not use any abrasive materials that could damage the
tool.
3. Make certain all pins; pivot points and bearing surfaces are
protected with a thin coat of high quality machine oil. Do not
oil excessively. The 64001-4500 (RHT-5771) was
engineered for durability, but like any fine piece of
equipment, it needs cleaning and lubrication for a maximum
service life of trouble-free crimping. A light oil, such as 30
weight automotive oil used at the oil points shown in Figure 5, every 5,000 crimps or 3 months will significantly enhance the tool
life and ensure a stable calibration.
4. When tool is not in use, keep the handles closed to prevent objects from becoming lodged in the crimping dies, and store the tool in
a clean, dry area.
Miscrimps or Jams
Should this tool ever become stuck or jammed in a partially closed position, Do Not force the handles open or closed. The tool will
open easily by pressing the ratchet release lever, (See Figure 6).
WIRE
Figure 4
CONDUCTOR
ANVIL
CONDUCTOR
PUNCH
TAB OF
TERMINAL
STEP DOWN BUTT
SPLICE TERMINAL
LUBRICATION POINTS
(BOTH SIDES) LIGHT OIL
(EVERY 3 MONTHS OR
5,000 CRIMPS)
Figure 5

RHT-5771 Hand Crimp Tool
Doc No. 64001-4500 Release Date: 11-06-03 UNCONTROLLED COPY Page 4 of 6
Revision: B Revision Date: 07-05-06
How to Adjust Tool Preload (See Figure 6)
Over the life of the tool, it may be necessary to adjust tool
handle preload force. Listed below are the steps required to
adjust the crimping force of the hand tool to obtain proper
crimp conditions:
1. Remove the screw and plastic cover washer. Note the
setting wheel position.
2. Lift the setting wheel off the axle. Turn the eccentric
axle with a screwdriver.
3. Turning the eccentric axle counter-clockwise will increase
handle force.
4. Replace the setting wheel to the axle, aligning the
nearest notch in the setting wheel to the dowel pin.
5. Replace the plastic cover washer and screw.
6. Check the crimp specifications after tool crimp force is adjusted.
Tool Calibration
A Certificate of Calibration (see last page) was supplied with the tool. To
recalibrate this tool, pin gauge measurements should be taken in each
conductor nest and compared to this chart. The tool should be lubricated
before recalibration to ensure consistent measurements. Handle preload is
factory set to 25-45 LBS. See How to Adjust Tool Preload (See Figure 5) to
recalibrate.
Wire Range “X”Dimension Conductor Crimp
Nest Color Code AWG mm²Mean Go No Go
Crimp Inspection
Marking
Red 18 - 22 0.35 - 0.80 .094 .090 .098 ---
Blue 14 - 16 1.30 - 2.00 .115 .110 .119 ---
Yellow 10 - 12 3.30 - 5.00 .161 .156 .167 ---
Warranty
This tool is for electrical terminal crimping purposes only. This tool is made of the best quality materials. All vital components are long
life tested. All tools are warranted to be free of manufacturing defects for a period of 30 days. Should such a defect occur, we will
repair or exchange the tool free of charge. This repair or exchange will not be applicable to altered, misused or damaged tools. This
tool is designed for hand use only. Any clamping, fixturing, or use of handle extensions voids this warranty.
Caution: Repetitive use of this tool should be avoided.
Hand held crimping tools are intended for low volume, prototyping, or repair requirements only.
CAUTION: Molex crimp specifications are valid only when used with Molex terminals, applicators and tooling.
Figure 5
PRELOAD
ADJUSTMENT
LOCKING SCREW
1.00
1.00
PRELOAD
TEST POINT
PRELOAD
TEST POINT
RATCHET
RELEASE LEVER
PUSH UP
PIN GAUGE IN
CONDUCTOR CRIMP
“Confining ”Crimp
“X ”

RHT-5771 Hand Crimp Tool
Doc No. 64001-4500 Release Date: 11-06-03 UNCONTROLLED COPY Page 5 of 6
Revision: B Revision Date: 07-05-06
Figure 6
M4 X 25LG
PAN HEAD SCREW
FOR SPRING
ACCESS SWING
OPEN COVER
6
SCREW AND PLASTIC
COVER FOR HANDTOOL
PRELOAD ADJUSTMENT
RATCHET
RELEASE LEVER
3
1
2
M4 X 12LG
PAN HEADSCREW
M4 LOCKNUT W/
HEX NYLON INSERT
M4 FLAT WASHER
5
4 REPAIR KIT. ALL PARTS REQUIRED FOR
REPAIR. (ONLY MAIN SPRING SHOWN)
#4-40 X 3/8”LG
SHCS
PARTS LIST
Item Order No Description Quantity
64001-4500 Hand Crimp Tool (Fig. 6)
1 64000-0076 Repair Kit (Springs, Pins and E-Rings) 1
2 63810-0000 Handle 1
3 64001-4575 Locator Assembly 1
4 64001-4570 Tooling Kit 1
Tooling Kit Only
5 64001-4502 Conductor Punch 1
6 64001-4501 Conductor Anvil 1

RHT-5771 Hand Crimp Tool
Doc No. 64001-4500 Release Date: 11-06-03 UNCONTROLLED COPY Page 6 of 6
Revision: B Revision Date: 07-05-06
Certificate of Calibration
Tool Order Number ____________________________
Tool Eng. Number_____________________________
Tool Revision________________________________
Serial Number_______________________________
Date of Manufacture___________________________
Handle Load Range at 1 inch from the Tips =_______________
Actual =_______________
Pin Gage of Conductor Nest/Nests or Slug height if the nest is the “F”Crimp style.
Range Conductor Nest # 1 =______________Actual =_____________
Range Conductor Nest # 2 =______________Actual =_____________
Range Conductor Nest # 3 =______________Actual =_____________
Technician________________________
Date of Calibration ___________________
Calibration should be done every 5,000 cycles or 3 months.
Tools should be lubricated during this operation.
