MONARCH INSTRUMENT RLS User manual

Instruction Manual
RLS and RLS24
Rugged Laser Sensors
15 Columbia Drive
Amherst, NH 03031 USA
Phone: [phone] • Fax: [phone]
E-mail: [email protected]
Website: www.monarchinstrument.com

In order to comply with EU Direcve 2012/19/EU on Waste Electrical
and Electronic Equipment (WEEE): This product may contain material
which could be hazardous to human health and the environment. DO NOT
DISPOSE of this product as unsorted municipal waste. This product needs to be
RECYCLED in accordance with local regulaons; contact your local authories for
more informaon. This product may be returnable to your distributor for recycling;
contact the distributor for details.
SAFEGUARDS AND PRECAUTIONS
Laser Hazards:
Eye injury from beam - Do not look into the direct or reected beam; can cause eye
injury up to 25  [7.5 m] away.
Visual interference (glare) with pilots and drivers - Interferes with vision up to 525
 (160 m) away. Can be a distracon up to 1 mile [1.6 km] away. NEVER point any
laser towards aircra or vehicles; it is unsafe and illegal.
Read and follow all instrucons in this manual carefully, and retain this
manual for future reference.
Do not use this instrument in any manner inconsistent with these operang
instrucons or under any condions that exceed the environmental specicaons
stated.
This instrument is not user serviceable. For technical assistance, contact the sales
organizaon from which you purchased the product.
Diode Laser
Max. Output Power: <1 milliwa
Wavelength: 650 nanometers (visible light)
Beam Divergence: <18 milliradian
Output: Connuous (CW)
Laser Hazard Classicaon: Class 2
Safe Use Guidance:
Class 2 lasers are considered safe
for accidental eye exposure. Do
not look or stare into beam. Do
not aim at aircra. This is not a
toy. Always supervise children.
Manufacturer:
Monarch Instrument
15 Columbia Drive
Amherst, NH 03031 USA
Country of Origin: USA
Contact info: www.monarchinstrument.com

Monarch Instrument’s Limited Warranty applies.
See www.monarchinstrument.com for details.
Warranty Registraon and Extended Warranty Coverage informaon is available
online at www.monarchinstrument.com.
Monarch Instrument holds the following US trademarks and registraons, all rights
reserved: illumiNova®, Nova-Pro®, Nova-Strobe™, DataChart™, Track-It™.
TABLE OF CONTENTS
1.0 OVERVIEW ...................................................................... 1
2.0 CONNECTION DETAILS .................................................... 2
3.0 OPERATING INSTRUCTIONS ........................................... 2
4.0 SPECIFICATIONS ............................................................. 5
4.1 Dimensions ............................................................... 6
4.2 Environmental ........................................................... 6
4.3 Compliance ................................................................ 6
5.0 ACCESSORIES .................................................................. 7

1
1.0 OVERVIEW
The RLS and RLS24 Rugged Laser Sensors are opcal reecve sensors
with a visible red laser light source and green LED on-target indicator. The
sensors are rated IP67 and are designed to survive accidental exposure to
water, dirt, oil, and other contaminants.
The Class 2 laser source acts as the aiming device during setup and can
accurately measure speeds from 1-250,000 RPM from a distance of up
to 25 feet with a maximum oset angle of 60 degrees from the rotang
object. The sensors are housed in an M20x1.5 threaded 316L stainless steel
tube and have a waterght M12 4 pin socket on the backend. A 90-degree
mounng bracket and 2 jam nuts are provided for mounng.
The RLS and RLS24 are supplied with a removable 3 m [9.8 .] cable with
a waterght M12 4 Pole Female connector on one end and a 3.5 mm [1/8
inch] male stereo plug (RLS-P or RLS24-P) or 4 nned wires (RLS-W or
RLS24-W) on the other end. An oponal 25 . [7.6 m] extension cable EC-
25P is available with a female socket for the plug on one end and a 3.5 mm
[1/8 inch] male stereo plug on the other (for RLS-P or RLS24-P).
The sensor can be powered by 4-15 V dc or 10-24 V dc and is available in
the following conguraons:
Model Power Requirement Removable 3 m Cable
RLS-P 4 – 15 V dc ±20% 0.5W M12 4 Pole Female connector to
1/8 in. [3.5 mm] male stereo plug
RLS-W 4 – 15 V dc ±20% 0.5W M12 4 Pole Female connector to
nned wires
RLS24-P 10 – 24 V dc ±20% 0.5W M12 4 Pole Female connector to
1/8 in. [3.5 mm] male stereo plug
RLS24-W 10 – 24 V dc ±20% 0.5W M12 4 Pole Female connector to
nned wires

2
2.0 CONNECTION DETAILS
Connecon to the sensor is via the waterght M12 connector on the end
of the sensor. The sensor may be ordered with one of two cables: the -P
with a 3.5 mm stereo connector or the -W with nned wires as shown
below.
RLS-W with wires RLS-P with plug

3
3.0 OPERATING INSTRUCTIONS
Plug the sensor into an appropriate power source (RLS = 4-15 V dc,
RLS24 = 10-24 V dc). The RLS-P will work directly with all Monarch
handheld tachometers and stroboscopes that accept pulse input through
an input jack (e.g., PLT200, PLS, dax, dbx, DBL, pbx, PBL, Nova-Pro® 300,
Nova-Pro® 500). The RLS-W and RLS24-W will work with all Monarch panel
instruments that accept pulse inputs (e.g., ACT series, Frequency to Analog
Converters, DataChart™ 1250, DataChart™ 6000) and vibraon data
collectors. A sensor power supply (SPSR-IM) with BNC output is available
for those applicaons that require a separate power source for the sensor
(RLS-P only).
The RLS Rugged Laser Sensor can detect a reected pulse from a target
consisng of T-5 Reecve Tape or high-contrast color dierences (such
as black and white) at distances up to 25 feet [7.6 m] from the rotang
object and angles up to 60 degrees. For most applicaons, a ½" [12 mm]
square piece of T-5 Reecve Tape should be applied to a clean area on
the rotang object as a target. At slow speeds (<500 RPM) best results will
be obtained by aiming the laser perpendicular (90°) to the target using a
narrow piece of reecve tape – typically 0.2 inch [5 mm] wide.

4
The RLS should be opcally aligned to illuminate the On-Target Indicator
once per revoluon. It is recommended that the opcal sensor be placed
at a slight angle (15 degrees) from perpendicular so that the sensor will
receive only pulses from the reecve marker. Triggering from contrasng
colors should be done perpendicular to the target. The RLS should be at
least 1 inch from the reecve target to avoid false triggering. The green
LED On-Target Indicator will blink at the input frequency rate when the RLS
is properly aimed.
Note: The green LED On-Target Indicator will blink (on/o) at slow speeds
and remain on steady at high speeds.
Note: Opcal speed sensors require environments that are clean and free
of mist, steam, dirt, oil, and other contaminants to funcon properly. The
RLS can survive these condions, but it will not funcon properly if the
opcs are contaminated. Carefully cleaning or drying the opcs will restore
normal operaon.

5
4.0 SPECIFICATIONS
Specicaons* RLS Rugged Laser
Speed Range 1 - 250,000 RPM
Illuminaon Visible red laser
Laser Specicaons:
Classicaon
Class 2 (per IEC 60825-1:2014)
This product complies with IEC60825-1 Ed. 3 and 21 CFR
1040.10 and 1040.11 except for deviaons pursuant to
Laser Noce No. 50 of June 2007.
Laser Output 1 mW max
Laser Operaon Connuous
Laser Wavelength 650nm (visible red)
Beam Divergence <18 mrad
Beam Diameter 4 x 7 mm typical at 2 m
Laser Diode Life 8,000 operang hours MTBF (1-year warranty)
On-Target Indicator Green LED on tube body - acve when pulse present
Operang Range Up to 7.6 m [25 .] and 60° oset from target
Power
Requirements
RLS-W and RLS-P: 4 - 15 V dc ±20% 0.5W
RLS24-W and RLS24-P: 10 - 24 V dc ±20% 0.5W
Output
Standard: Open Collector with internal pull up resistor
(5600 ohm) to supply voltage; posive pulse when
target present
Note: On 24 V unit output voltage = input voltage – 5 V.
Oponal: Negave pulse, true open collector,
3.3 V output (TTL); contact factory
Material Tube: 316L stainless steel Nosepiece: ABS
*Specicaons are subject to change without noce.

6
4.1 Dimensions
4.2 Environmental
This product is rated IP67 when used with supplied cables.
Operang Temperature: -10 °C to +50 °C (14 °F to 122 °F)
Storage Temperature: -40 °C to +80 °C (-40 °F to 170 °F)
4.3 Compliance
• CE Compliant
• Low Voltage Direcve (LVD) 2014/35/EU
• Electromagnec Compability Direcve (EMC) 2014/30/EU
• Restricon of Hazardous Substances (RoHS 3) Direcve 2015/863/EU

7
5.0 ACCESSORIES
See Accessories webpage for details.
SPSR-IM: Self-Powered Sensor
Interface module
PN: 6150-021
EC-25P: Extension Cable
PN: 6180-028
RLS-P Cable: 3 m cable
with M12 connector to 3.5 mm [1/8 in.]
male stereo plug
PN: 6180-085
RLS-w Cable: 3 m cable
with M12 connector to nned leads
PN: 6180-084
RLS-Nut: Jam Nut M20 x 1.5 x 10 mm
Two required to secure to Mounng Bracket
PN: 1053-0189-001
RLS-Mount: Mounng Bracket
90° sloed
PN: 1052-4350-112
Reecve Tape
T-5 (single pack), 5 feet - PN: 6180-070
T-5 (2-pack), 5 feet each - PN: 6180-069
T-50, 50 feet - PN: 6180-072
T-5WP (waterproof), 5 feet - PN: 6180-079

8
