MONARCH INSTRUMENT SPSR-115/230 Series User manual

Instruction Manual
SPSR-115/230
Self-Powered Sensor
TTL Pulse Output
15 Columbia Drive
Amherst, NH 03031 USA
Phone: [phone] • Fax: [phone]
Email: suppor[email protected]
Website: www.monarchinstrument.com

In order to comply with EU Direcve 2012/19/EU on Waste Electrical
and Electronic Equipment (WEEE): This product may contain material
which could be hazardous to human health and the environment. DO NOT
DISPOSE of this product as unsorted municipal waste. This product needs to be RE-
CYCLED in accordance with local regulaons; contact your local authories for more
informaon. This product may be returnable to your distributor for recycling; con-
tact the distributor for details.
SAFEGUARDS AND PRECAUTIONS
Read and follow all instrucons in this manual carefully, and retain this manual for
future reference.
Do not use this instrument in any manner inconsistent with these operang
instrucons or under any condions that exceed the environmental specicaons
stated.
This instrument is not user serviceable. For technical assistance, contact the sales
organizaon from which you purchased the product.
Monarch Instrument’s Limited Warranty applies.
See www.monarchinstrument.com for details.
Warranty Registraon and Extended Warranty Coverage informaon is
available online at www.monarchinstrument.com.

TABLE OF CONTENTS
1.0 INTRODUCTION .......................................................... 1
2.0 FUNCTIONS AND OPERATION .......................................... 1
2.1 SPSR Interface Module ............................................. 1
 
 
 
 
3.1 ROS-P ........................................................................ 3
 
 
 
 AND ACCESSORIES .............................. 8

1
1.0 INTRODUCTION
The SPSR-IM Self Powered Sensor Interface Module
is a self-contained, rechargeable baery powered
device for developing a TTL compable one pulse
per revolution output for triggering external
equipment such as vibraon analyzers, spectrum
analyzers, stroboscopes, data acquision equipment,
tachometers, balancers, waveform analyzers and
magnec tape recorders.
The SPSR-115/230 is comprised of the SPSR-IM Interface Module, which
provides power to a sensor and couples the sensor to a BNC output; an input
sensor with a visible red LED light source (ROS-P); and a baery recharger.
Oponal sensors such as an opcal laser
sensor (ROLS-P-not shown), infrared
sensor (IRS-P), or an amplied magnec
sensor (MT-190P) may also be combined
with the SPSR-IM Interface Module when
appropriate. (See separate instrucons for these conguraons.)
2.0 FUNCTIONS AND OPERATION
2.1 SPSR Interface Module
The SPSR Interface Module (SPSR-IM) provides power to the input sensor,
receives and oponally inverts the return pulse signal, and provides a
switch selectable posive going 0 to 5 V dc or negave going 5 to 0 V dc
pulse train trigger output on a BNC connector. Connecons and operaon
are common to all SPSR models. Fully charged internal NiMH baeries
will typically provide greater than 40 hours of connuous operaon. In
addion, the SPSR system can be operated connuously on external
power by use of the recharger/power supply provided.
MT-190P
Magnec Trigger Sensor
IRS-P
Infrared Sensor
SPSR-115/230
SPSR-IM, ROS-P and
Universal Recharger

2
 
Connect the input sensor via the 1/8” [3.5 mm] phone plug to the
mang connector on the SPSR-IM. This sensor may remain connected
even when recharging the internal baeries of the SPSR-IM.
NOTE: Do not plug an input sensor into the SPSR with the Power
switch in the ON posion. Before plugging the sensor in,
switch the power to OFF and unplug any external power
supply.
Connect the output signal cable to the BNC connector on the
opposite end of the SPSR-IM and to the external equipment to be
triggered.
If operang from the recharger/power supply, connect the recharger
to the connector marked EXTERNAL DC on the SPSR-IM and connect
the wall unit to the appropriate power source.
 
The  switch on the SPSR-IM controls both the operaon and
the charging of the system. The unit will only charge from external
power in the power OFF posion. In the power ON posion, the unit
will operate directly from external power any me that it is being
supplied. Otherwise, it funcons on internal baery power.
The OUTPUT SELECTION switch determines the polarity of the
leading edge of the TTL compable output signal. In the NON-
INVERTING posion, the output signal on the BNC connector will be a
negave going 5 to 0 V dc pulse derived directly from the condioned
sensor output. When the INVERTING posion is switch selected, the
BNC output signal will be a posive going 0 to 5 V dc, TTL compable.

3

Unit operaonal = solid green
Unit charging = blinking red
Charging done = solid red
NOTE: Short red blinks followed by long blink = charge error; contact
factory.
 
To recharge the SPSR-IM Interface Module baeries:
1. Connect the recharger/power supply to the EXTERNAL DC input
connector.
2. Connect the recharger/power supply into a working ac outlet.
3. Be sure the  switch is in the OF posion. The
red  LED will indicate that the baeries are being charged.
Allow up to 4 hours to fully charge.
 
The SPSR-115/230 consists of the SPSR-IM Interface Module described
above, an ROS-P Remote Opcal Sensor with eight foot cable and mounng
bracket, and an SPSR-U (115/230 V ac) external power connecon. One foot
of T-5 Reecve Tape is also supplied.
3.1 ROS-P
When connected to the SPSR-IM as described above, the ROS-P
illuminates the target with a visible red light from a high intensity LED
and detects the reected pulses from the rotang reecve tape target
with an internal photo-detector. The ROS-P Remote Opcal Sensor is
capable of detecng a reected pulse from T-5 Reecve Tape targets
at distances of up to 3 feet and angles up to 45 degrees from the target.
The sensor is supplied with a set of two M16 jam nuts and a 90° angle
sloed aluminum mounng bracket.

4
For most applicaons, a 1/2" square piece of T-5 Reecve Tape should
be applied to a clean area on the rotang object. The sensor should be
mounted and opcally aligned to illuminate the reecve target once
per revoluon. 


The sensor should be at least 2 inches and no more than 3 feet from the
target. The green LED On-Target Indicator on the ROS-P will blink at the
input frequency or be connuously illuminated when properly aimed.
 
Once the ROS-P input sensor is properly mounted and aligned, further
connecons and operaon should proceed in accordance with the
funcons and descripons under the SPSR Interface Module secons
entled Connecons and Controls.
The pulse signal on the connector marked OUTPUT provides a sharp
leading edge for reliable and repeatable triggering of the connected
device. This output is capable of driving a hundred feet of coax cable.
Be sure to select the direcon (0 to 5 V dc or 5 to 0 V dc) of this signal
to provide the required polarity of the leading edge to properly trigger
the connected equipment.
 
Prior to disposing of the SPSR-IM, the user must remove the Nickel Metal
Hydride baeries. To do this, remove the four (4) rubber feet on the
boom of the unit. This will expose four (4) screws that must be removed
to dismantle the boom case piece, exposing the baeries. Remove the
baeries and place tape over the baery terminals to prevent them from
shorng. The baeries should be sent to a recycling center or returned to
the factory. The rest of the parts may now be disposed of.
NOTE: This product contains nickel metal hydride (NiMH) baeries. Replace
only with the same type of baery – Rechargeable NiMH.

5
 SPSR-IM Interface Module
 Nickel metal hydride (NiMH) baery pack, 4.8 V dc
 >40 hours typical with ROS-P (~40 mA load)
 Up to 4 hours
Output
TTL compable pulse, INVERTED or NON-INVERTED
switch selectable
With ROS (negave pulse) input, output will be a
posive pulse when set to inverted or negave pulse
when set to non-inverted; oponally, the output can
be open collector (external pull-up required)
 0 to 100 kHz
 12 mA with kΩ load (operational)
 14 mA with kΩ load (operational)
 SPSR-U (operaonal/charge)
LED Indicator Status indicaon; see LED Indicaon secon
Output Connector BNC connector (female)
 32 °F to 122 °F (0 °C to 50 °C)
 8.3 oz. (235 g)
 5.0 in. x 2.5 in. x 1 in. [127 mm x 64 mm x 25 mm]
*Specicaons are subject to change without noce.
SPSR-IM Dimensions
 
Remote Sensor Input Jack
Recharger Jack

6
 
 Up to 3 . [0.9 m] and 45° from reflective target
Speed Range 1 to 250,000 RPM
 Visible red LED, 5 V dc @ 30 mA
 14 °F to 158 °F (-10 °C to 70 °C)
Output Signal 5 to 0 V dc TTL compatible pulse
On-Target Indicator Green LED on end cap
Material 303 Stainless steel
 Acrylic plasc
 8 . [2.5 m] Standard

Threaded Tube: 2.90 in. L x 0.625 in. diameter [M16
x 1.5 x 74 mm] supplied with two M16 jam nuts
and mounng bracket
*Specicaons are subject to change without noce.
ROS-P and mounng bracket Dimensions
M16 x 1.5
Green
On Target LED
0.62” [15.9mm] 2.90” [74.0mm]
-" "

7
 
Both the SPSR-IM and ROS-P units are CE compliant.
• Low Voltage Direcve (LVD) 2014/35/EU
• Electromagnec Compability Direcve (EMC) 2014/30/EU
• Restricon of Hazardous Substances (RoHS) Direcve 2011/65/EU

8
 
ROS-P Remote Opcal Sensor with 8 . [2.5 m] cable
and mounng bracket
ROS-P-25 Remote Opcal Sensor with 25 . [7.6 m] cable
and mounng bracket
ROLS-P Remote Opcal Laser Sensor with 8 . [2.5 m]
cable and mounng bracket
IRS-P Infrared Sensor with 8 foot [2.5 m] cable for use
without reecve target at 0.5 inch [12.7 mm]
gap (5 to 500,000 RPM)
MT-190P Magnec Trigger Sensor/Amplier with 8 . [2.5
m] cable - 0.250" [6.4 mm] operang gap from
target, 2" (L) x 5/8" [50.8 x 15.9 mm]
EC-25P 25 foot [7.6 m] Extension Cable for remote
sensors with male 1/8" [3.5 mm] phone plug to
female 1/8" [3.5 mm] connector
T-5 Reecve Tape 5 . [1.5 m] roll, ½ inch [13
mm] wide
T-5WP Reecve Tape, waterproof, honeycomb paern,
5 . [1.5 m] roll, 1-inch [25 mm] wide
BP-R Replacement NiMH Baery Pack (for SPSR-IM ONLY)
SPSR-U Universal Recharger with plugs, 115/230 V ac -
50/60 Hz
PN: 6180-057
PN: 6180-057-25
PN: 6180-029
PN: 6180-020
PN: 6180-036
PN: 6180-028
PN: 6180-070
PN: 6180-079
PN: 6180-066
PN: 6180-059

15 Columbia Drive, Amherst NH 03031 USA
Tel.: [phone] // Fax: [phone]
Email: [e-mail]
Website: www.monarchinstrument.com
Monarch Instrument is commied to excellence and quality in
