QUICK INSTALL GUIDE
MONITECH MB1700P
New Backlight Inverter for Allen Bradley Versa View 1700P

INSTALL GUIDE
CANADA OFFICE: 20 Howard Place, Kitchener, Ontario, Canada, N2K 2Z4 | US OFFICE: 8955 US-301 Parrish, FL. 34219 |monitech.com
PRECAUTIONS
Disconnect power from the terminal
before installing or replacing any
components. Take care not to touch any
of the exposed electronic components
during installation.
Work in a static free environment and
wear a properly grounded electrostatic
discharge (ESD) wristband. Be careful
when touching any of the exposed
electronic components to prevent
damage from ESD.
KIT CONTENTS:
Part Number
Item
QTY
MPCBCPC1151
Inverter PCB Board
1
MPCB17-08370AB, 8mm
LED Strip
2
HARDWARE
M3 Pan Head Screws
2

INSTALL GUIDE
CANADA OFFICE: 20 Howard Place, Kitchener, Ontario, Canada, N2K 2Z4 | US OFFICE: 8955 US-301 Parrish, FL. 34219 |monitech.com
REFERENCE
REMOVAL
•Turn off the main power, then turn off the machine.
•Remove the unit from the main Machine.

INSTALL GUIDE
CANADA OFFICE: 20 Howard Place, Kitchener, Ontario, Canada, N2K 2Z4 | US OFFICE: 8955 US-301 Parrish, FL. 34219 |monitech.com
•Remove the LCD front panel from the unit.

INSTALL GUIDE
CANADA OFFICE: 20 Howard Place, Kitchener, Ontario, Canada, N2K 2Z4 | US OFFICE: 8955 US-301 Parrish, FL. 34219 |monitech.com
•Disconnect the LVDS connector from LCD panel, then disconnect the touchscreen
connector.

INSTALL GUIDE
CANADA OFFICE: 20 Howard Place, Kitchener, Ontario, Canada, N2K 2Z4 | US OFFICE: 8955 US-301 Parrish, FL. 34219 |monitech.com
•Unplug the CCFL bulb cables from the inverter, then disconnect the inverter power
cable.
•Remove the old inverter by unscrewing the 2 screws as shown.

INSTALL GUIDE
CANADA OFFICE: 20 Howard Place, Kitchener, Ontario, Canada, N2K 2Z4 | US OFFICE: 8955 US-301 Parrish, FL. 34219 |monitech.com
•Unscrew the 5 screws to remove the PCB board and the metal shield.
•Remove the LCD panel by unscrewing the 4 screws, then pull up the LCD panel from
the metal frame.

INSTALL GUIDE
CANADA OFFICE: 20 Howard Place, Kitchener, Ontario, Canada, N2K 2Z4 | US OFFICE: 8955 US-301 Parrish, FL. 34219 |monitech.com
•The LCD panel and the metal frame with the touchscreen.

INSTALL GUIDE
CANADA OFFICE: 20 Howard Place, Kitchener, Ontario, Canada, N2K 2Z4 | US OFFICE: 8955 US-301 Parrish, FL. 34219 |monitech.com
•Remove the CCFL bulb from the LCD panel by unscrewing the 2 screws as illustrated
below.
•Pull up the CCFL bulbs from the LCD housing.
•The new Inverter with LED strips.

INSTALL GUIDE
CANADA OFFICE: 20 Howard Place, Kitchener, Ontario, Canada, N2K 2Z4 | US OFFICE: 8955 US-301 Parrish, FL. 34219 |monitech.com
•Take the LED strips and slide them into the LCD housing all the way.
•Continue sliding the LEDs all the way until they fit completely as shown in the picture
below.

INSTALL GUIDE
CANADA OFFICE: 20 Howard Place, Kitchener, Ontario, Canada, N2K 2Z4 | US OFFICE: 8955 US-301 Parrish, FL. 34219 |monitech.com
•Place the LCD panel ack into the metal fame by screwing the 4 screws.
•Put back the PCB board with the metal shield by screwing the 5 screws, reconnect the
touchscreen connector and then reinsert the LVDS connector.

INSTALL GUIDE
CANADA OFFICE: 20 Howard Place, Kitchener, Ontario, Canada, N2K 2Z4 | US OFFICE: 8955 US-301 Parrish, FL. 34219 |monitech.com
•Insert the new inverter where the old inverter was located and secure it by using 2
screws as shown.
•Insert the LED strips cable to the connectors of the inverter and then insert the power
harness to the power connector of the inverter.

INSTALL GUIDE
CANADA OFFICE: 20 Howard Place, Kitchener, Ontario, Canada, N2K 2Z4 | US OFFICE: 8955 US-301 Parrish, FL. 34219 |monitech.com
•The new inverter after it has been installed.
•After you install the front panel that has the new inverter to the main unit, and before you
power up the unit, make sure everything is connected properly and safely to power up.
