Mono AZTEC PLC User manual

FILE 7 FG059 Aztec plc Quickstart RevA19 29-01-19
COMPLETE OPERATION AND MAINTENANCE INSTRUCTIONS
ARE AVAILABLE AT www.monoequip.com
AZTEC (PLC)
DOUGHNUT FRYER
IMPORTANT INFORMATION
and
INSTALLATION INSTRUCTIONS
MONO EQUIPMENT
Queensway
Swansea West Industrial Estate
Swansea. SA5 4EB UK
Tel. [phone]
email:[e-mail]
Spares Tel.[phone]
Fax. [phone]
FILE 7
Enter Serial No. here._____________________________________
In the event of an enquiry please quote this serial number.
www.monoequip.com

FILE 7 FG059 Aztec plc Quickstart RevA19 29-01-19

FILE 7 FG059 Aztec plc Quickstart RevA19 29-01-19
SAFETY SYMBOLS
The following safety symbols are used throughout this product documentation and manual
(available at www.monoequip.com).
Before using your new equipment, read the instruction manual carefully and pay special
attention to information marked with the following symbols.
ELECTRICAL SAFETY AND ADVICE REGARDING
SUPPLEMENTARY ELECTRICAL PROTECTION:
Commercial bakeries, kitchens and foodservice areas are environments where electrical
appliances may be located close to liquids or operate in and around damp conditions or
where restricted movement for installation and service is evident.
The installation and periodic inspection of the appliance should only be undertaken by a
qualified, skilled and competent electrician, and connected to the correct supply suitable for
the load as stipulated by the appliance data label.
The electrical installation and connections should meet the necessary requirements of the
local electrical wiring regulations and any electrical safety guidelines.
We Recommend:
−Supplementary electrical protection with the use of a residual current device (RCD)
−Fixed wiring appliances incorporate a locally situated switch disconnector to connect
to, which is easily accessible for switching off and safe isolation purposes. The switch
disconnector must meet the specification requirements of IEC 60947.
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
will result in electric shock.
Indicates a hazardous situation which, if not avoided,
will result in minor or moderate injury.
WARNING
WARNING
CAUTION
The supply to this machine must be protected by a 30mA RCD

FILE 7 FG059 Aztec plc Quickstart RevA19 29-01-19
Thank you for purchasing the MONO AZTEC FRYER.
A combination of clean industrial design and the latest technology.
The following information should get your purchase running without any problems
If you have a problem with your purchase please contact MONO EQUIPMENT at:
MONO EQUIPMENT
Queensway
Swansea West Industrial Estate
Swansea. SA5 4EB UK
Tel. [phone]
1Never use the fryer in a faulty condition and always report any damage.
2No-one under the age of 16 may operate this machine.
3No-one under the age of 18 may clean this machine under any circumstances.
4Only trained personnel may remove any part from this fryer that requires a tool to do so.
5Always ensure hands are dry before touching any electrical appliance (including cable, switch
and plug).
6All operatives must be fully trained.
7People undergoing training on the machine must be under direct supervision.
8Do not operate the machine with any panels removed.
9All guards must be fixed in place with bolts or screws unless protected by a safety switch.
10 No loose clothing or jewellery to be worn while operating the fryer.
11 The Bakery Manager or the Bakery Supervisor must carry out daily safety checks on the fryer.
11112 Switch off power at the mains isolator when fryer is not in use and before carrying out any
cleaning or maintenance.
13 Please read the H.S.E. information sheet contained on the CD manual.(see pages 4,5)
SAFETY
Special attention should be given to the bottom of the top
tank so that a layer of sediment is not allowed to build up.
If the sediment does build up the temperature safety sensors
will not be able to function correctly.

FILE 7 FG059 Aztec plc Quickstart RevA19 29-01-19
1It is recommended that the Aztec Doughnut Fryer should be sited away from
any main thoroughfare and that the surrounding floor area should be covered
with an appropriate brand of non-slip surfacing.
2VENTILATION should be provided with an extraction canopy to ensure that convected
heat and cooking smells are removed from the building. The canopy should extend a
minimum of 300mm (12”) beyond each edge of the fryer and have its lowest point
between 1980mm (70”) and 2740mm (108”) above the floor.
The extraction canopy should be fitted with a cleanable grease trap.
3Fittings are provided for the attachment of the draining board.
4ELECTRICAL CONNECTION
The fryer should be connected to a 25 Amp, 3 phase plus neutral isolator at 25 Amp
with a BS 88 fuse.
5. Aztec doughnut fryers are dispatched with the carrier (1) in the mid way
position to avoid damage during the following check procedure:
When turning the main power switch (4) on, watch if carrier (1) moves up or down.
Turn power off immediately before the carrier reaches top or bottom positions.
If carrier moves UP, this is CORRECT.
If carrier moves DOWN, this is NOT CORRECT.
Transpose any two of the phase carrying wires at main isolator feeding the fryer.
INSTALLATION
(5)
(5)
(6)
(4)
(1)
CORRECT
NOT
CORRECT
CARRIER START
UP DIRECTION
VERY IMPORTANT
VERY IMPORTANT
DO NOT TURN POWER ON UNTIL THIS IS UNDERSTOOD
The supply to this machine must be protected by a 30mA RCD

FILE 7 FG059 Aztec plc Quickstart RevA19 29-01-19
6. FILLING WITH FRYING OIL.
•Fill tank with cooking oil until oil is flowing into the bottom tank via the overflow
slot at the back of the main tank. Allow flow to stop then pull out lower tank.
•Fill bottom tank with oil to level shown on the back wall of the tank
Do not overfill or spillage will occur during filtering.
7Turn main isolator switch (4) to ‘OFF’(horizontal position).
8Remove two screws (5).
9Remove cover (6).
10 Switch breakers (top right in control box) to on position.
11 Replace cover (6) and screws (5)
12 Switch on main control switch (4)
OIL LEVEL LINE
BOTTOM TANK
Do not mix different makes or types of frying oil as a reaction can result in a thick
flour-like sediment forming in the lower tank which can block the filtering system.

FILE 7 FG059 Aztec plc Quickstart RevA19 29-01-19
OPERATING INSTRUCTIONS
OIL LEVEL
CONFIRMATION
BUTTON.
ONLY PRESS WHEN
BUZZER IS HEARD
AND LIGHT FLASHES
AND ONLY IF OIL IS
IN THE TOP TANK.
TURN OFF.
STARTS THE FILTER
OPERATION AND
THEN TURNS OFF
TURN ON.
STARTS HEAT UP
AFTER OIL
CONFIRMATION
BUTTON PRESSED.
OPERATION
BUTTON.
STARTS THE FRY
AND TURNOVER
OPERATION
LIGHTS WHEN POWER
SUPPLY CONNECTED
LIGHTS WHEN
ELEMENTS ARE
HEATING
CONTROL PANEL
IF A TRAY IS NOT PLACED
IN THE CORRECT
POSITION, AS SHOWN
DURING TRAINING, THE
CARRIER MAY JAM IN
POSITION.
IF THIS HAPPENS PRESS
CARRIER RETURN SWITCH
ONCE AND THE CARRIER
WILL RETURN TO THE
START POSITION.

FILE 7 FG059 Aztec plc Quickstart RevA19 29-01-19
•HEATING UP
1 Ensure the top control panel switch is in “ON / HEATERS” position
2Turn on main power supply.
***Buzzer sounds***
3If there is enough oil in the top tank press “CONFIRM OIL “ button.
Oil will now heat to set cooking temperature.
NOTE
Until the oil is heated to cooking temperature, the up and down operation will not work.
•SHUT DOWN FILTERING
1Ensure lower tank is pushed fully back on runners.
2Turn top switch to “OFF FILTER” position.
3After 30 seconds the drain valve will open and the return pump will be heard operating.
4After about 9 minutes the valve will close and the top tank will start to fill up again.
When the pump stops the main power can be switched off.
DO NOT…….
DO NOT TURN POWER OFF WHILST PUMP IS OPERATING
DO NOT TURN POWER OFF UNTIL FULL FILTER CYCLE HAS FINISHED.
DO NOT LEAVE MACHINE WITH ALL THE OIL IN THE BOTTOM TANK, (ALWAYS
MAKE SURE THE OIL HAS PUMPED BACK TO THE TOP TANK BEFORE LEAVING
THE MACHINE.)
CAUTION!!
ELEMENT HEATING WILL STOP WHILE PUMP IS IN OPERATION. ENSURE OIL IS IN
THE TOP TANK AT ALL OTHER TIMES. I.E WHEN TURNING MAIN POWER ON.
DO NOT PRESS UNLESS THERE IS THE CORRECT AMOUNT OF OIL IN THE TOP TANK

FILE 7 FG059 Aztec plc Quickstart RevA19 29-01-19
•MACHINE OPERATION
1Slide a loaded tray into the cradle.
Ensure that the tray is pushed up against the cradle end stops.
(This must be correct or the machine will jam).
2Press the black button to start the frying sequence.
The cradle will lower the tray into the first position and wait before lowering again
and turning the doughnuts over. After the preset time the cradle will lift to the top
position allowing the doughnuts to drain.
3Slide the tray onto the drainer and insert a fresh tray into the cradle.
•ADJUSTMENT OF TURNOVER DEVICE
Depending on the size or shape of the doughnut being fried, the separator unit must be adjusted
for the turnover device to work correctly.
1Turn Knob (1) on right hand side of tank, clockwise or anticlockwise.
2Read off scale (2) on left until required position is found.
3The positions required will have to be determined and recorded for future
reference.
(Generally position 1is for large products and position 4is for very small or finger doughnuts)
NOTE
IF A TRAY IS NOT PLACED IN THE CORRECT POSITION, AS SHOWN
DURING TRAINING, THE CARRIER MAY JAM IN POSITION.
IF THIS HAPPENS A CARRIER RETURN SWITCH CAN BE FOUND ON
THE FRONT PANEL OR AT THE BACK OF THE CONTROL BOX
(DEPENDING ON MODEL). PUSH ONCE AND THE CARRIER WILL
RETURN TO THE START POSITION.
(2)
(1)
FRONT
REAR

FILE 7 FG059 Aztec plc Quickstart RevA19 29-01-19
CLEANING INSTRUCTIONS
WARNING:
ISOLATE FROM MAINS SUPPLY BEFORE CLEANING AND ALLOW TO COOL.
HOT OIL IS DANGEROUS
DAILY
Wipe down exterior bodywork with a damp cloth and cleaning fluid.
•TO CLEAN OIL FILTER
ALLOW OIL TO COOL BEFORE ATTEMPTING TO REMOVE FILTER
1Open front doors.
2Pull lower tank towards you.
3Unclip poppers around top edge and remove filter.
4 Only use hot water to clean filter. Do not use soap or detergent. Do not clean in
a dishwasher.
5Ensure filter is dry and replace on to filter holding bars, ensuring all poppers are done
up.
6Push lower tank back under machine. Close doors.

FILE 7 FG059 Aztec plc Quickstart RevA19 29-01-19
•REMOVAL OF TURNOVER DEVICE AND
SEPARATOR UNIT FOR CLEANING
Before proceeding with the following,
the fryer must be allowed to cool and
oil drained
1Lift turnover device off rear bars as shown
in photo. (CAUTION UNIT IS HEAVY).
(This may require two people)
2Turn separator unit adjuster to position 1.
3Lift separator unit carefully and remove from
tank. (CAUTION UNIT IS HEAVY).
(This may require two people)
4After cleaning replace all parts in reverse order.
Pay particular attention to the separator unit
engagement with its adjuster.
NOTE
Special attention should be
given to cleaning the bottom of the
top tank so that a layer of sediment
is not allowed to build up. If the
sediment does build up, a fire could
result as the temperature sensors
will not be able to function correctly.
POSITION 1
1
