Monogram Monogram ZIRS360NX Manual

For answers to your Monogram,® GE Profile™
or GE®appliance questions, visit our website
at ge.com or call GE Answer Center®service,
800.626.2000.
110163
Specification Created 6/08
Listed by
Underwriters
Laboratories
ZIRS360NX
GE Monogram® 36" Built-In Integrated All-Refrigerator
Dimensions and Installation Information
ZIRS360NXRH, Refrigerator
Handle on the left side, the door swings left to right.
ZIRS360NXLH, Refrigerator
Handle on the right side, the door swings right to left.
Caution
*Shipping height. The refrigerator can be adjusted to fit
into a cutout 83-1/2" min. to 84-1/2" max. height. Note: the
top case trim at the front is 1/2" higher and will overlap
upper cabinetry or soffit. Use leveling legs and wheels for a
maximum 1" height adjustment.
The water and electrical supply must be located as shown.
The finished cutout width must be 35-1/2".
Note: The case trim overlaps cabinets at the top and
sides. Frameless cabinets may require filler strips to
prevent interference with cabinet door swing. The opening
width must allow for filler strips.
36" Frame to
Frame Width
*84" From
Floor to
Top Frame
35"
Case Width
*83-1/2"
at
Rear
25-3/4" Stainless Steel Models
Case Depth
Depth Including Handles:
27-3/4" Stainless Steel Models
28-11/16" Professional Models
Product Clearances
These units are equipped with a 2-position door stop. The fac-
tory set 130˚ door swing can be adjusted to 90˚ if clearance
to adjacent cabinets or walls is restricted. Order WX14X99
door stop for precise settings between 90˚and 130˚.
251Dia59
25"
Minimum
to Wall
130ϒDoor Swing
36-3/4"
23-7/8"
Behind Frame
251Dia60
4" Min.
to Wall
90ϒDoor Swing
Corner Installation
Allow 25" minimum clearance for a full 130˚ door swing.
Allow 15" for pan removal. for a 90˚ door swing, allow 4"
minimum clearance for professional models. If the 90˚
doorstop position is used, pan access is maintained but
pan removal is restricted.
These units are top-heavy and must be secured to prevent the
possibility of tipping forward. Anti-Tip protection is required.

For answers to your Monogram,® GE Profile™
or GE®appliance questions, visit our website
at ge.com or call GE Answer Center®service,
800.626.2000.
110163
Specification Created 6/08
Listed by
Underwriters
Laboratories
ZIRS360NX
GE Monogram® 36" Built-In Integrated All-Refrigerator
Dimensions and Installation Information
Cutout and Clearances for Multiple Product Installations
If you are installing two units, side by side, the installation
space must be 71-1/2" wide. Additional cutout width may be
required when side panels are used. Add side panel thickness
to the finished cutout to calculate rough-in width.
• The water and electrical locations for each product must be
located as shown.
• A separate 115V, 60Hz., 15 or 20 amp power supply is
recommended for each product.
251Dia35
251Dia61
25"
Min. to
Wall
0" 25"
Min. to
Wall
130ϒDoor Swing 130ϒDoor Swing
Clearances for two products installed side-by-side with
right and left side hinges together
Allow 5" minimum between the two products to prevent
one door from striking the other. Use the WX14X99
adjustable door stop to reduce the factory set 130˚ door
swing and to allow pan removal. NOTE: A unified grille
panel kit will NOT fit this installation.
Clearances for Multiple Single Door Installations
In a side-by-side installation of a left and right door swing
product, the inside trims touch at the front, with a 1" clearance
between the units at the rear. Order ZUGSS2 Unified Grille Panel
Kit for one continuous grille panel.
ZUGSS2: For side-by-side installation of two stainless
steel wrapped models. This kit provides a unified
stainless steel grille panel to span the width of two units.
For a complete food storage center, install a Monogram
All-Refrigerator and All Freezer side-by-side. For even
more capacity, install two refrigerators or two freezers.
5"

For answers to your Monogram,® GE Profile™
or GE®appliance questions, visit our website
at ge.com or call GE Answer Center®service,
800.626.2000.
110163
Specification Created 6/08
ZIRS360NX
GE Monogram® 36" Built-In Integrated All-Refrigerator
ZIFS360NXRH
ZIRS360NXRH
Features and Benefits
• Integrated appearance with Premium-Grade 304 Stainless
Steel - Extending across the door and wrapping beautifully
around the edges; A Monogram signature, slim tubular
handle enhances the overall look
• Enhanced Temperature Management System - With precise
electronic controls and thermistors, maintains ideal storage
conditions for fresh foods
• Concealed Halogen Lighting System - Illuminates contents
without compromising space
• ENERGY STAR® Qualification - As an ENERGY STAR partner,
GE has determined that Monogram all-refrigerators meet the
ENERGY STAR guidelines for energy efficiency
• Humidity-Controlled Compartments and Sealed Snack
Drawers - Help preserve the freshness of foods
• Adjustable Spillproof Glass Shelves - Easily accommodate
party trays and platters
• Gallon-Size Door Bin - Holds milk containers, two-liter bottles
and pitchers
• Sealed Dairy Compartment - Locks in freshness
• Model ZIRS360NXRH – Stainless steel wrap (right-handed
door swing)
• Model ZIRS360NXLH – Stainless steel wrap (left-handed door
swing)
