Monoprice 43394 User manual

1x2 VGA Splitter with Audio
P/N 43394
User's Manual

2
SAFETY WARNINGS AND GUIDELINES
Please read this entire manual before using this device, paying extra
attention to these safety warnings and guidelines. Please keep this
manual in a safe place for future reference.
•This device is intended for indoor use only.
•Do not expose this device to water or moisture of any kind.
Do not place drinks or other containers with moisture on or
near the device. If moisture does get in or on the device,
immediately remove it from its power source and allow it to
fully dry before reapplying power.
•Do not touch the device, the power cord, or any other
connected cables with wet hands.
•Do not expose this device to excessive vibration, extreme
force, shock, or fluctuations in temperature or humidity.
•Do not expose this device to excessively high temperatures.
Do not place it in, on, or near a heat source, such as a
fireplace, stove, radiator, etc. Do not leave it in direct sunlight.
•Clean using a soft, dry cloth only. Do not use chemical
cleaners, solvents, or detergents. For stubborn deposits,
moisten the cloth with warm water.
•This device has no user serviceable parts. Do not attempt to
open, service, or modify this device.

3
INTRODUCTION
This 1x2 VGA Splitter with Audio allows you to connect two VGA
displays to a single VGA source. It supports resolutions up to
1900x1200 and features up to 500MHz video bandwidth. It features
audio support using a single 3.5mm audio input and two 3.5mm audio
outputs. It includes a video amplifier, which allows the output cables
to be to be extend to up to 49 feet (15 meters) long.
FEATURES
•Connect two VGA displays to a single VGA source
•Includes audio support
•Supports resolutions up to 1900x1200
•500MHz video bandwidth
•Video amplifier allows output cables to extend to up to 49
feet (15 meters) long

4
CUSTOMER SERVICE
The Monoprice Customer Service department is dedicated to
ensuring that your ordering, purchasing, and delivery experience is
second to none. If you have any problem with your order, please give
us an opportunity to make it right. You can contact a Monoprice
Customer Service representative through the Live Chat link on our
website www.monoprice.com or via email at
[e-mail]. Check the website for support times and
links.
PACKAGE CONTENTS
Please take an inventory of the package contents to ensure you have
all the items listed below. If anything is missing or damaged, please
contact Monoprice Customer Service for a replacement.
1x VGA Splitter
1x AC Power Adapter
1x User's Manual

5
PRODUCT OVERVIEW
SAMPLE CONNECTION DIAGRAM

6
CONNECTION
Perform the following steps to connect the splitter to your system.
1. Ensure that all devices to be connected are powered off and
disconnected from their power sources.
2. Using a VGA cable (available separately), plug one end into
the VGA input on your first display, then plug the other end
into the VGA 1 OUT port on the splitter. Repeat for your
second display and the VGA 2 OUT port.
3. (Optional) Using a 3.5mm audio cable (available separately),
plug one end into the 3.5mm audio input on your first display,
then plug the other end into the AUDIO 1 OUT jack on the
splitter. Repeat for your second display and the AUDIO 2 OUT
port.
4. Using a VGA cable (available separately), plug one end into
the VGA-IN port on the splitter, then plug the other end into
the VGA output on your computer.
5. (Optional) Using a 3.5mm audio cable (available separately),
plug one end into the AUDIO-IN jack on the splitter, then plug
the other end into the audio output on your computer.
6. Plug one end of the included AC Power Adapter into the
DC5V connector on the splitter, then plug the other end into
a nearby AC power outlet. The POWER LED will illuminate to
indicate that power is applied.

7
7. Plug in and power on all connected equipment. Verify that
you can see video on each display. If you connected audio,
verify that you can hear audio on each display.
SPECIFICATIONS
P/N
43394
Input
1x VGA + 3.5mm audio
Outputs
2x VGA + 3.5mm audio
Maximum Video Resolution
1900x1200
Video Bandwidth
500MHz
Input Power
5 VDC
AC Power Adapter Input
Power
100 ~ 240 VAC, 50/60 Hz
Maximum Power
Consumption
1 watt
Operating Temperature
+32 ~ +158°F (0 ~ +70°C)
Operating Humidity
10 ~ 85% RH, noncondensing
Storage Temperature
+14 ~ +176°F (-10 ~ +80°C)
Storage Humidity
5 ~ 90% RH, noncondensing

8
TECHNICAL SUPPORT
Monoprice is pleased to provide free, live, online technical support to
assist you with any questions you may have about installation, setup,
troubleshooting, or product recommendations. If you ever need
assistance with your new product, please come online to talk to one
of our friendly and knowledgeable Tech Support Associates. Technical
support is available through the online chat button on our website
www.monoprice.com or through email by sending a message to
[e-mail]. Check the website for support times and links.
To download the latest drivers, firmware, manuals, etc., go to
www.monoprice.com and type the P/N into the search bar. If
available, support files are linked at the bottom of the product page.
REGULATORY COMPLIANCE
Notice for FCC
This device complies with Part 15 of the FCC rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Modifying the equipment without Monoprice's authorization may
result in the equipment no longer complying with FCC requirements

9
for Class B digital devices. In that event, your right to use the
equipment may be limited by FCC regulations, and you may be
required to correct any interference to radio or television
communications at your own expense.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for
help.

10
Notice for Industry Canada
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-
003 du Canada.
Monoprice™ and all Monoprice logos are trademarks of Monoprice
Inc.
