Monoprice 12520 User manual

CONTENTS
SAFETY WARNINGS AND GUIDELINES..................................................................................3
FEATURES ................................................................................................................................4
PACKAGE CONTENTS..............................................................................................................4
CONNECTIONS.........................................................................................................................5
CONTROLS................................................................................................................................6
SETUP........................................................................................................................................7
MONITOR STAND & BASE........................................................................................................7
VIEWING ANGLE ADJUSTMENT..............................................................................................9
MAIN INPUT SELECTION..........................................................................................................9
ON-SCREEN DISPLAY (OSD) MENU .....................................................................................10
Basic Menu Operation...........................................................................................................10
BRIGHTNESS MENU...........................................................................................................11
IMAGE MENU.......................................................................................................................12
COLOR TEMP MENU...........................................................................................................13
OSD SETTING MENU..........................................................................................................14
RESET MENU ......................................................................................................................15
MISC MENU .........................................................................................................................16
TECHNICAL SUPPORT...........................................................................................................17
WARRANTY.............................................................................................................................17
TROUBLESHOOTING..............................................................................................................18
SPECIFICATIONS....................................................................................................................19
Compliance Information............................................................................................................20

SAFETY WARNINGS AND GUIDELINES
•Do not place the monitor on an unstable surface where it could fall and cause either
personal injury or damage to the monitor and/or other equipment.
•Do not expose the monitor to water or moisture of any kind. Do not place objects
containing moisture, such as a glass or vase, where it could tip over and spill into or
onto the monitor.
•If the monitor is exposed to water or moisture, immediately unplug it from its power
source and allow it to completely dry out before reapplying power.
•Do not block the ventilation holes in the monitor's casing. Do not place the monitor in a
confined space with inadequate ventilation.
•Do not place the monitor near a heat source, such as a fireplace, heating vent, radiator,
etc.
•The power supply for this monitor uses a NEMA 5-15 three prong, grounded plug. Do
not use a "cheater" plug or otherwise bypass the grounding pin.
•The power supply for this monitor accepts a wide range input voltages, from 100 to 240
VAC, 50 or 60 Hz, with a current at least 1.75A. Ensure that your power source is within
these limits. If not, consult a professional electrician or your power company for a
resolution.
•Unplug the monitor if it will go unused for a long period of time.
•This monitor has no user serviceable parts. Do not open the case or otherwise attempt
to modify this monitor.
•Clean only using a soft, dry cloth. Do not use chemical cleaners, solvents, or
detergents. For stubborn deposits, moisten the cloth with warm water.
•Do not leave a single image on the display for a long period of time. Doing so could
cause "burn-in" of the image. It is recommended to use a variable desktop background
and to use a screen saver to prevent "burn-in". Alternatively, ensure that the monitor is
power off for at least 2 hours out of every 12.
3

FEATURES
•27" WQHD monitor with LED backlighting
•16:9 aspect ratio
•2560 x 1440 @ 60Hz maximum resolution
•1 DisplayPort input
•1 HDMI input
•1 Dual Link DVI-D input
•1 VGA input
•Detachable stand allows for tilt and swivel, plus rotation for easy portrait/landscape
orientation changes
•Built-in stereo speakers with 2 watts/channel amplifier
•100 x 100 VESA mounting pattern
PACKAGE CONTENTS
Please take an inventory of the package contents to ensure you have all the items listed
below. If anything is missing or damaged, please contact Monoprice Customer Service for a
replacement.
1x 27" WQHD LED monitor
1x Adjustable stand
1x Stand base
4x M4x8 stand mount screws
1x AC power adapter
1x AC power cord
1x 3.5mm TRS audio cable
1x Dual Link DVI-D video cable
1x User's manual
4

CONNECTIONS
1 2 3 4 5 6
1
DP
DisplayPort 1.2 video input
2
VGA
Analog D-Sub video input
3
DVI
Dual Link DVI-D video input
4
HDMI
HDMI video input
5
Line In
3.5mm TRS stereo audio input
6
DC In
DC power input
DVI Note: This monitor features a Dual Link DVI-D input port. Your DVI source must support
Dual Link DVI-D and you must use a Dual Link DVI-D cable (included), which has a pinout that
looks like this:
5

CONTROLS
1. VOL+: If the OSD menu is displayed and an entry has been opened for editing, pressing
the VOL+ button increases the selected value. If the OSD is not displayed, pressing the
VOL+ button opens the volume adjustment control. With either the brightness or volume
adjustment control displayed, pressing the VOL+ button increases the brightness or
volume.
2. VOL-: If the OSD menu is displayed and an entry has been opened for editing, pressing the
VOL- button decreases the selected value. If the OSD is not displayed, pressing the VOL-
button opens the brightness adjustment control. With either the brightness or volume
adjustment control displayed, pressing the VOL- button decreases the brightness or
volume.
3. UP:If the OSD menu is displayed, pressing the UP button moves the selection highlight up.
If the OSD menu is not displayed, the button is ECO function hotkey.
4. DOWN:If the OSD menu is displayed, pressing the DOWN button moves the selection
highlight down. If the OSD menu is not displayed, the button is DCR function hotkey.
5. SELECT: If the OSD menu is displayed, pressing the SELECT button enters the OSD
highlighted entry. If the OSD menu is not displayed, the button displays the source list.
6. MENU: If the OSD menu is not displayed, pressing the MENU button opens the OSD menu.
If the OSD menu is displayed pressing the MENU button will back out of a submenu or close
the OSD menu if already at the top menu level.
7. POWER: Press the POWER button to toggle the monitor ON or OFF. When the monitor is
powered on and a video signal is present, the power indicator will glow blue. When the monitor
is powered on but no video signal is present, the power indicator will glow yellow/orange.
6

SETUP
1. Install the stand and base, using the instructions in the following section, or mount the
monitor to a wall or desk mount using the included M4x8screws.
2. Connect video cable(s) from your source device(s) to the monitor's input(s). The monitor has
4 video inputs (1x DVI, 1x HDMI, 1x DisplayPort, 1x VGA) and can simultaneously display
up to four video sources.
3. Use the included 3.5mm TRS audio cable to connect the audio output of your computer to
the audio input on the monitor.
4. Plug the DC power connector on the AC power adapter into the DC IN port on the back of
the monitor.
5. Plug the included AC power cord into the AC power adapter. Plug the other end into a
nearby power outlet.
MONITOR STAND & BASE
To install the stand, perform the following steps:
1. Place a blanket or towel on a flat surface, such as a table or the floor.
2. Place the monitor face down on the blanket or towel.
3. Install the stand on the VESA mount using the four included M4x8screws.
4. Fit the base on the bottom of the stand and press it until it clicks into place.
7

To remove the base, perform the following steps:
1. Place a blanket or towel on a flat surface, such as a table or the floor.
2. Place the monitor face down on the blanket or towel.
3. Squeeze the plastic clip on the bottom of the base and pull the base off the stand.
Note that the stand can be removed from the back of the monitor so that the monitor can be
attached to a desk or wall mount. To remove the stand, perform the following steps:
1. Place a blanket or towel on a flat surface, such as a table or the floor.
2. Place the monitor face down on the blanket or towel.
3. Remove the four M4x8screws attaching the stand to the back of the monitor.
4. Follow the mounting instructions for your wall/desk mount to attach the monitor to the
mount.
5. Store the stand and mount screws in a safe place for future use.
Note: The monitor uses a VESA mounting size of 100x100mm.
8

VIEWING ANGLE ADJUSTMENT
The included monitor stand supports tilt adjustment from -5° (down) to +20° (up). To adjust the
angle, grasp the bezel at both the top and bottom of the monitor and move it as desired. Use
soft cloth gloves or a soft, dry cloth to grasp the monitor without touching the screen.
MAIN INPUT SELECTION
To change the main input, perform the following steps:
1. Press the SELECT button to display the Input Selection menu.
2. Use the UP or DOWN buttons to move the highlight to the desired input.
3. Press the SELECT button to select the highlighted input.
9

ON-SCREEN DISPLAY (OSD) MENU
Press the MENU button to access the OSD menu.
Basic Menu Operation
VOL+: When the OSD menu is displayed and an item has been opened for editing, pressing
the VOL+ button increases the selected value.
VOL-: When the OSD menu is displayed and an item has been opened for editing, pressing
the VOL- button decreases the selected value.
UP:When the OSD menu is displayed, pressing the UP button moves the selection highlight
up.
DOWN:When the OSD menu is displayed, pressing the DOWN button moves the selection
highlight down.
SELECT: When the OSD menu is displayed, pressing the SELECT button either selects the
currently highlighted menu option or opens the currently highlighted menu entry for editing. If
the OSD menu is not displayed, pressing the SELECT button opens the INPUT
SELECTION menu and selects the currently highlighted video input.
MENU: If the OSD menu is not displayed, pressing the MENU button opens the OSD menu.
When the OSD menu is displayed pressing the MENU button will back out of a submenu or
close the OSD menu if already at the top menu level.
10

BRIGHTNESS MENU
BRIGHTNESS: Adjusts the image brightness. The adjustment range is 0 to 100.
CONTRAST:Adjusts the image contrast. The adjustment range is 0 to 100.
ECO:Preset display mode selection. Four display modes: Standard, Text, Movie, Game
DCR: DCR stands for Dynamic Contrast Ratio, which is a circuit that increases the effective
picture contrast by changing the light intensity of the LED backlighting. DCR tends to cause
too much contrast fluctuation when dealing with swiftly moving images and is usually better
suited to applications use than for use with games. DCR can be turned On or Off.
11

IMAGE MENU
H. POSITION: Adjusts the horizontal position of the image. The adjusting range is from 0 to
100. (Only available for VGA input.)
V. POSITION: Adjusts the vertical position of the image. The adjusting range is from 0 to 100.
(Only available for VGA input.)
CLOCK:Adjusts the clock frequency The adjusting range is from 0 to 100. (Only available for
VGA input.)
PHASE:Reduces image noise by adjusting Phase. The adjusting range is from 0 to 100. (Only
available for VGA input.)”
ASPECT:Adjusts the aspect ratio to “WIDE” or “4:3”
12

COLOR TEMP MENU
COLOR TEMP.:Contains four color modes: “Warm”, “Normal”, “Cool”, and “User”
RED: The color of Red is user-configurable; the adjusting range is from 0 to 100.
GREEN:The color of Green is user-configurable; the adjusting range is from 0 to 100.
BLUE:The color of Blue is user-configurable; the adjusting range is from 0 to 100.
13

OSD SETTING MENU
LANGUAGE:This menu allows you to set the language to be used in the OSD. The possible
options are English, French, Deutsche, Italiano, Espanol, Nederlands.
OSD H. POS.:Adjusts the horizontal position of the OSD menu. The adjustment range is 0 to
100
OSD V. POS.:Adjusts the vertical position of the OSD menu. The adjustment range is 0 to 100
OSD Timer:Sets the amount of time in seconds that the OSD menu will display without any
input before it automatically closes. The possible options are 5s, 10s, 15, 20s, 25s, 30s, 35s,
40s, 45s, 50s, 55s and 60s.
TRANSPARENCY:Adjusts how transparent or opaque the OSD menu will appear on screen.
The possible options are 0, 25, 50, 75, and 100.
14

RESET MENU
IMAGE AUTO ADJUST:Adjusts H/V Position and Clock/Phase automatically. (Only available
for VGA input.)
COLOR AUTO ADJUST: Adjusts red, green, and blue colors gain automatically. (Only
available for VGA input.)
RESET: Resets the display to its default values.
15

MISC MENU
HOTKEY TYPE:Contains ECO+DCR, BRI+CON and ASP+ECO hotkey combinations. (UP
and DOWN will be the hotkey buttons while OSD menu is not displayed)
SIGNAL SOURCE: Selects the input source. You can select VGA, DVI, HDMI and DP.
AUDIO SELECT: Selects the audio input source (Analog or Digital).
VOLUME: Sets the volume level. The adjustment range is 0 to 100
16

TECHNICAL SUPPORT
Monoprice is pleased to provide free, live, online technical support to assist you with any
questions you may have about installation, setup, troubleshooting, or product
recommendations. If you ever need assistance with your new product, please come online to
talk to one of our friendly and knowledgeable Tech Support Associates. Technical support is
available through the online chat button on our website (www.monoprice.com) during regular
business hours, 7 days a week. You can also get assistance through email by sending a
message to [email protected]om.
WARRANTY
MONOPRICE will replace defective monitors with a new monitor if the RMA is issued within
thirty (30) days of the original date of purchase, as shown on the original invoice. Monitors
identified as defective after 30 days, but within the twelve (12) month warranty period, will be
replaced with refurbished, reconditioned, or used monitors at MONOPRICE'S discretion. All
returned products are the property of MONOPRICE and must be returned to MONOPRICE for
a replacement to be issued.
17

TROUBLESHOOTING
Following are some common problems and possible solutions. If you cannot solve a problem
yourself, please contact Monoprice Technical Support for assistance.
Q: The power LED is off.
A: Verify that the power adapter is plugged into the monitor. Verify that the power cord is
plugged into both the AC adapter and the power outlet. Verify that the power outlet is live
by plugging something else into it, such as a lamp.
Q: The picture is weak, washed out, or over saturated.
A: Adjust the Brightness and/or Contrast.
Q: The image flashes or distorts.
A: Verify that there are no nearby sources or Radio Frequency or Electromagnetic
Interference (RFI or EMI).
Q: The power LED is glowing blue, but the display is blank.
A: Press a key on the keyboard to ensure the computer is not asleep or that a screen saver
is active. Verify that the proper input is selected. Verify that the display cable is securely
attached to both the display and the video source. Replace the cable with another of the
same type to verify that it is not faulty.
Q: One of the primary colors (red, green, or blue) is missing.
A: Replace the video cable with another of the same type. Connect to a different video
source to verify that there are no problems with the video card or source device.
Q: The colors are not correct.
A: Adjust the color temperature or the individual mix or red, green, and blue picture
elements.
Q: No picture using the DVI input.
A: Verify that you are using a Dual Link DVI-D cable. Verify that your video card is capable
of delivering a Dual Link DVI-D signal. A Dual Link DVI-D cable will have a pinout that
looks like this:
18

SPECIFICATIONS
Display Type
AH-IPS panel with LED backlight
Screen Size
27" (685mm)
Dot Pitch
0.2331 x 0.2331 mm
Maximum Resolution
2560 x 1440 @ 60Hz (WQHD)
Brightness
350cd/m
2
Viewing Angle
178° left/right, 178° up/down
Video Inputs
1x Dual Link DVI-D, 1x DisplayPort v1.2,
1x HDMI, 1x VGA
Audio Inputs
1x 3.5mm TRS Line In
Horizontal Frequency (HFR)
30 ~ 158 kHz
Vertical Frequency (VFR)
60 ~ 75Hz
Pixel Clock Frequency
300 MHz
PNP Standard
VESA DDC2BTM
Power Consumption
Operation: < 50W
Standby: < 1W
Monitor Input Power
12 VDC, 5.42A
AC Adapter Input Power
100 ~ 240 VAC, 50-60 Hz
Operating Temperature
+32 ~ +122°F (0 ~ +50°C)
Storage Temperature
-4 ~ +140°F (-20 ~ +60°C)
Operating Humidity
10 ~ 85%, non-condensing
VESA Mount Size
100 x 100
Dimensions
25.8" x 9.6" x 21.7" (658 x 245 x 552 mm)
Weight
16.7 lbs. (7.6 kg)
Certifications
ETL, FCC, CE
19

Compliance Information
FCC Class B Notice
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
•Consult the dealer or an experienced radio/television technician for help.
Modifications: Any modifications made to this device that are not approved by Monoprice, Inc.
may void the authority granted to the user by the FCC to operate this equipment.
CE Compliance Statement:
This product is in compliance with CE directives and bears the CE mark. For detailed information
on specific directives please contact Customer Service or sales office or distributor.
WEEE Directive Compliance Statement:
This symbol on the product or on its packaging indicates that the product must not be disposed
of with normal household waste. Instead, it is your responsibility to dispose of your waste
equipment by arranging to return it to a designated collection point for the recycling of waste
electrical and electronic equipment. By separating and recycling your waste equipment at the time
of disposal you will help to conserve natural resources and ensure that the equipment is recycled
in a manner that protects human health and the environment.
ETL Compliance Statement:
This product has been thorough tested by Intertek – ETL, a nationally recognized independent
third-party testing laboratory. The North American ETL Listed mark signifies that the device has
been tested to and has met the requirements of a widely recognized consensus of U.S. and
Canadian device safety standards, that the manufacturing site has been audited, and the that
manufacturer has a agreed to a program of quarterly factory follow-up inspections to verify
continued conformance.
20
