Monoprice 38070 User manual

Monoprice Bluetooth 5 Transmitter & Receiver
with AptX, AptX-Low Latency, SBC
P/N 38070
User's Manual

SAFETY WARNINGS AND
GUIDELINES
Please read this entire manual before using this
device, paying extra attention to these safety
warnings and guidelines. Please keep this manual
in a safe place for future reference.
•Do not expose this device to water or
moisture of any kind. Do not place drinks or
other containers with moisture on or near the
device. If moisture does get in or on the
device, immediately power it off and allow it
to fully dry before reapplying power.
•Do not touch the device, the power cord, or
any other connected cables with wet hands.
•If operating in a humid environment, ensure
that no condensation occurs. Condensation
could cause damage and could cause a short

in the electrical components, which in turn
could cause fire or severe electric shock.
•Do not expose this device to excessively high
temperatures. Do not place it in, on, or near a
heat source, such as a fireplace, stove,
radiator, etc. Do not leave it in direct sunlight.
•Do not place or install this device in an area
where it can be exposed to excessive amounts
of dust, humidity, oil, smoke, or combustible
vapors.
•Prior to operation, check the unit and power
cord for physical damage. Do not use if
physical damage has occurred.
•Before charging the unit, ensure that the
output device provides the same type and
level of power required by the device.

•Ensure that power is turned off and
disconnected before making any electrical
connections.
•Clean using a soft, dry cloth only. Do not use
chemical cleaners, solvents, or detergents. For
stubborn deposits, moisten the cloth with
warm water.
•This device has no user serviceable parts. Do
not attempt to open, service, or modify this
device.
CUSTOMER SERVICE
The Monoprice Customer Service department is
dedicated to ensuring that your ordering,
purchasing, and delivery experience is second to
none. If you have any problem with your order,
please give us an opportunity to make it right. You
can contact a Monoprice Customer Service
representative through the Live Chat link on our

website www.monoprice.com or via email at
[email protected]. Check the website for
support times and links.
PACKAGE CONTENTS
Please take an inventory of the package contents
to ensure you have all the items listed below. If
anything is missing or damaged, please contact
Monoprice Customer Service for a replacement.
1x 38070 Bluetooth Transmitter and Receiver
1x USB Charging Cable
1x 3.5mm Audio Cable
1x Fiber Optic Cable
1x User’s Manual

PRODUCT OVERVIEW
1. TX/RX Switch
2. SPDIF/AUX Switch
3. AUX Audio Port
4. SPDIF Input
5. SPDIF Output
6. Micro USB Charging Port
7. Multi-function Button (MFB)
8. LED Indicator Light
OPERATION
Power On/Off

•Power On/Off: Press the
MFB button
for 3
seconds. (If the product had previously been
connected to another device it will
automatically reconnect to that device, if
available, when powered on)
•Play/Pause: A quick, single press of the
MFB
button
will play or pause the current playback.
•If no connection is made after 5 minutes, the
device will automatically power off.
Bluetooth
®
Pairing (Transmitter – TX Mode)
•Paring Mode: Make sure the device is off and
the TX/RX switch is set to “
TX
.” Press the
MFB
button
for 3 seconds to turn the product on,
then quickly press the
MFB
twice to enter
pairing mode. The LED indicator light will
quickly flash
blue.
Put your Bluetooth audio
device (speaker/headphones etc.) into pairing
mode. Once 38070 has paired with the

Bluetooth audio device the LED indicator will
slowly flash blue.
•Connect 38070 to your media player via the
3.5mm AUX cable and then you can use 38070
to connect to the paired speaker/ headphones
or other Bluetooth audio device.
*TVs and monitors can also connect to 38070 via the
Fiber Optic cable and ports.
Bluetooth Pairing (Receiver – RX Mode)
•Pairing Mode: Make sure the device is off and
the TX/RX switch is set to “
RX
.” Press the
MFB
button
for 3 seconds to turn the product on,

then quickly press the
MFB
twice to enter
pairing mode. The LED indicator light will
quickly flash
blue and red.
Open your device’s
Bluetooth settings, locate and select
“
MP38070.
” Once 38070 has paired with the
device the LED indicator will be solid blue.
•Connect a speaker, headphones or other audio
device to 38070 via the 3.5mm audio port to
play audio from your paired Bluetooth device.

Multi-device Pairing
•Pair the first device as you would normally,
then double press the
MFB
again to re-enter
pairing mode.
•Repeat the pairing steps for the second
device, the LED indicator light will be solid
green
when both devices are connected.
Charging
•When the battery reaches a low enough level
the LED indicator light with flash
red
.
•When charging the LED indicator light will be
blue
and supersede other LED light indications
such as the red and blue pairing flashes.
•To charge, please only use the included Micro-
USB cable to connect to a compatible charger,

computer, or outlet. A full charge will take
approximately 2 hours.
Status LED Indicator
Power On 2x Flash Blue
Power Off 2x Flash Red
Bluetooth Pairing
(TX) Flash Blue
(RX) Flash Red and Blue
Standby
(Disconnected)
Blue Flashes 1x/sec (TX)
Blue Flash 2x/3 sec (RX)
Standby (Connected) Solid Blue
Low Battery Red Flash
Charging Solid Red
Fully Charged LED off

SPECIFICATIONS
Model 38070
Bluetooth Version 5
Bluetooth Profiles A2DP, AVRCP
Codec (RX) aptX™low latency, aptX™, AAC,
SBC
Codec (TX) aptX™, low latency, aptX™,
SBC
Battery Capacity 350mAh/3.7V
Charging Time ≈2 hours
Standby Time ≈50 hours
Playback Time 12-15 hours

Operating
Temperature 14-131° F
Product
Dimensions
2.4 x 2.4 x 0.7 in (60 x 60
x 18mm)
Product Weight 1.4oz (38.6g)

TECHNICAL SUPPORT
Monoprice is pleased to provide free, live, online
technical support to assist you with any questions
you may have about installation, setup,
troubleshooting, or product recommendations. If
you ever need assistance with your new product,
please come online to talk to one of our friendly
and knowledgeable Tech Support Associates.
Technical support is available through the online
chat button on our website
www.monoprice.com
or through email by sending a message to
[email protected]
. Check the website for
support times and links.

REGULATORY COMPLIANCE
Notice for FCC
This device complies with Part 15 of the FCC rules.
Operation is subject to the following two
conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
Modifying the equipment without Monoprice's
authorization may result in the equipment no
longer complying with FCC requirements for Class
B digital devices. In that event, your right to use
the equipment may be limited by FCC regulations,
and you may be required to correct any

interference to radio or television
communications at your own expense.
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses and
can radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning
the equipment off and on, the user is encouraged
to try to correct the interference by one or more
of the following measures:

•Reorient or relocate the receiving antenna.
•Increase the separation between the
equipment and receiver.
•Connect the equipment into an outlet on a
circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced
radio/TV technician for help.
Radio Notice for FCC
Caution
This FCC Part 15 radio device operates on a non-
interference basis with other devices operating at
this frequency. Any changes or modification to

said product not expressly approved by
Monoprice, including the use of non-approved
antennas, could void the user’s authority to
operate this device.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two
conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
The Bluetooth® word mark and logos are registered
trademarks of Bluetooth SIG, Inc.
aptX™ is a trademark of Qualcomm Technologies
International, Ltd., registered in the United States and
other countries.
