Monoprice 14446 User manual

Deep Blue 10 Waterproof
Bluetooth Speaker (IPX-6)
User’s Manual
14446

2
SAFETY WARNINGS AND GUIDELINES
•This speaker is waterproof with an ingress protection rating of IPX6. This means that
speaker can withstand the application of "powerful water jets" consisting of a 1/4"
stream with a pressure of 30kPa, at a distance of 3 meters, at a rate of 12.5 liters per
minute, for 3 minutes. While this means that the speaker is protected from water
splashing or rain, it is not protected from more prolonged exposure or from being
immersed in water. Do not immerse this product in water.
•Note that this product is only waterproof when the cover for the auxiliary and
charging ports is properly secured. Water or moisture getting into either port can
cause damage to the product.
•After this device has been exposed to water, it should be thoroughly dried before
continued use.
•The device has a protective silicone sleeve, however this does not mean that it is
indestructible or drop-proof. Please take care to avoid physical damage to the
product.
•Do not subject the product to extreme force, shock, or fluctuations in temperature
or humidity.
•Clean using a soft, dry cloth only. Do not use chemical cleaners, solvents, or
detergents. For stubborn deposits, moisten the cloth with warm water.
•This device has no user serviceable parts. Do not attempt to open, service, or
modify this device.
•Keep away from corrosive materials.
•Charge the battery before first use and at least once every three months.
•This device contains a Lithium-ion battery. Dispose of this device only in accordance
with local, state, or federal regulations for electronic waste.

3
INTRODUCTION
Thank you for purchasing this Deep Blue Sea Waterproof Bluetooth® Speaker!
This speaker features a Bluetooth radio, allowing for wireless connections with your mobile
devices. It is waterproof with an IPX6 rating, making it safe for use in all weather
conditions. A built-in microphone allows it to be used as a hands-free communication
device for making and receiving phone calls.
FEATURES
•Built-in 5-watts (RMS) per channel amplifier driving two 2" speakers
•Waterproof with an IPX6 rating
•Bluetooth radio with A2DP and AVRCP profiles
•Up to 30 feet wireless range
•3.5mm auxiliary input for wired connections
•Built-in rechargeable Lithium-ion battery for up to 9 hours of audio playback
•90Hz ~ 20kHz frequency response
CUSTOMER SERVICE
The Monoprice Customer Service department is dedicated to ensuring that your ordering,
purchasing, and delivery experience is second to none. If you have any problem with your
order, please give us an opportunity to make it right. You can contact a Monoprice
Customer Service representative through the Live Chat link on our website
www.monoprice.com
during normal business hours (Mon-Fri: 5am-7pm PT, Sat-Sun: 9am-
6pm PT) or via email at
[e-mail]

4
PACKAGE CONTENTS
Please take an inventory of the package contents to ensure you have all the items listed
below. If anything is missing or damaged, please contact Monoprice Customer Service for a
replacement.
1x Deep Sea Blue Waterproof 10-Watt Bluetooth Speaker
1x Micro USB charging cable
1x 3.5mm TRS stereo audio cable
1x Carabiner clip
1x User's manual
PRODUCT OVERVIEW
1. Micro USB charging port
2. 3.5mm auxiliary audio input
3. Call/Play/Pause button
4. Volume decrease/previous track button
5. Power button
6. Volume increase/next track button

5
CHARGING
This device contains a rechargeable Lithium-ion battery, which can provide up to 9 hours
of audio playback. The battery should be fully charged prior to initial use and at least once
every 3 months. Perform the following steps to charge the battery in this speaker.
1. Open the cover seal on the side to reveal the charging port.
2. Using the included micro USB cable, plug one end into the micro USB port on the
speaker, then plug the other end into a USB power source, such as a computer port
or wall charger.
3. An LED under the front grille, next to the charging port, will glow
red
while charging
is in progress. When charging is complete, the LED will turn off. Depending on the
charging power of your USB power source, it takes 4-6 hours to perform a full
charge.
4. When charging is complete, remove the micro USB charging cable and close the
cover seal. Ensure that the seal is fully closed and properly seated to restore the
waterproof status.
POWER
•To power the speaker ON, press and hold the
Power
button for about 3 seconds.
The speaker will emit an ascending series of notes and the LED under the grille will
illuminate blue.
•To power the speaker OFF, press and hold the
Power
button for about 3 seconds.
The speaker will emit a descending series of notes and the LED under the grille will
turn off.

6
BLUETOOTH® PAIRING
Perform the following steps to pair this speaker with your Bluetooth® enabled mobile
device.
1. Press and hold the Power button for about 3 seconds to power the speaker on. The
speaker will emit an ascending series of notes and the LED inside the front grille will
start blinking blue, indicating that the speaker is in Bluetooth pairing mode.
If the speaker has been previously paired with a device, which is powered on,
has Bluetooth turned on, and is within range, it will automatically reconnect. If
you wish to pair the speaker with another device, press and hold the Power
button for about 2 seconds to clear the existing pairing and put the speaker into
Bluetooth pairing mode.
2. Open the settings on your mobile device, ensure Bluetooth is turned on, then
perform a search for nearby Bluetooth devices.
3. When the search is completed, select the
Deep Blue Sea
entry. If you are prompted
for a passcode, enter 0000 (four zeroes). The LED under the front grille will cease
blinking and the speaker will sound a tone. Depending on your device, it will
automatically connect. If it does not, select the entry on your mobile device to
connect with the speaker.
HANDLING PHONE CALLS
•When an incoming call is received, audio playback will automatically pause and the
speaker will sound a ringtone.
•Momentarily press the
Call/Play/Pause
button to answer the call.
•When the call is completed, momentarily press the
Call/Play/Pause
button to
terminate the call. Audio playback will automatically resume.
•To reject an incoming call, use your phone's call reject function.

7
OPERATION
•Press and hold the
Power
button for about 3 seconds to power the speaker on or
off.
•If the speaker is paired with an active device, press and hold the
Power
button for
about 2 seconds to delete the existing pairing and put the speaker in Bluetooth®
pairing mode.
•Momentarily press the
Call/Play/Pause
button to start or pause audio playback.
•When an incoming call is present, momentarily press the
Call/Play/Pause
button to
answer the incoming call. When the call is complete, momentarily press the
Call/Play/Pause
button to terminate the call.
•Momentarily press the
Volume decrease/previous track
button to skip back to
beginning of the current track. If already at the beginning of the track, press the
Volume decrease/previous track
button to skip back to the beginning of the
previous track.
•Momentarily press the
Volume increase/next track
button to skip forward to the
beginning of the next track.
•Press and hold the
Volume decrease/previous track
button to decrease the
speaker's volume level.
•Press and hold the
Volume increase/next track
button to increase the speaker's
volume level.

8
AUXILIARY INPUT
To use the speaker with non-Bluetooth® enabled devices, you can use the included audio
cable to connect the headphone output of your device to the auxiliary input on the
speaker. Perform the following steps to use a wired connection.
1. Open the cover seal on the side to reveal the 3.5mm auxiliary input.
2. Using the included 3.5mm audio cable, plug one end into the auxiliary input on the
speaker, then plug the other end into the headphone output on your mobile device.
The Bluetooth radio is disabled whenever a cable is plugged into the speaker's
auxiliary input.
3. When you are finished, unplug the audio cable from the speaker and close the cover
seal. Ensure that the seal is fully closed and properly seated to restore the
waterproof status.
TECHNICAL SUPPORT
Monoprice is pleased to provide free, live, online technical support to assist you with any
questions you may have about installation, setup, troubleshooting, or product
recommendations. If you ever need assistance with your new product, please come online
to talk to one of our friendly and knowledgeable Tech Support Associates. Technical
support is available through the online chat button on our website
www.monoprice.com
during regular business hours, 7 days a week. You can also get assistance through email by
sending a message to
[e-mail]

9
SPECIFICATIONS
Model
14446
Drivers
Two 2" drivers
Amplifier
5-watts RMS per channel
Frequency Response
90Hz ~ 20kHz
Bluetooth® Profiles
A2DP and AVRCP
Bluetooth Range
Up to 30 feet
Built-in Battery
2200mAh Lithium-ion
Full Charge Playback Time
Up to 9 hours
Charging Time
4-6 hours
Charging Source
Micro USB (5 VDC, 1A)

10
REGULATORY COMPLIANCE
Radio Notice for FCC
Caution
This FCC Part 15 radio device operates on a non-interference basis with other devices
operating at this frequency. Any changes or modification to said product not expressly
approved by Monoprice, including the use of non-approved antennas, could void the user’s
authority to operate this device.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
Radio Notice for Industry Canada
Caution
This IC RSS-210 radio device operates on a non-interference basis with other devices
operating at this frequency. Any changes or modification to said product not expressly
approved by Monoprice, including the use of non-approved antennas, could void the user’s
authority to operate this device.
This device complies with IC RSS-210. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
The Bluetooth word mark and logos are registered trademarks of Bluetooth SIG, Inc.
