monster tower HS1 Quick start guide

Monster Tower Phone: [phone]
5714 U.S. Hwy 411 S. www.monstertower.com
Maryville, TN 37801 [e-mail]
Copyright 2017 Monster Tower, Inc. Page 1
HS1
Installation Instructions and Owner’s Manual
Your HS1 uses many common parts and design features that make
it affordable, adjustable, and easy to install. There are four main
components: Top section, right leg, left leg, and cast mounting
bases. The top section has a larger inside diameter to allow the
legs to slide inboard and outboard adjusting to different boat
widths. An important part of the installation is drilling holes in the
tower to lock the legs into a position custom fit to your boat.
Quick Release Knobs allow you to fold the tower for storage.
Following all the installation instructions will give you a
professional look.
CAUTION
Important notes for installation, maintenance, and use of your new HS1!
For a High Quality, Trouble Free Installation, read the entire Installation Manual before you begin.
Monster Tower has documented forces on arches exceeding of 300 ft./lbs. under normal wakeboarding
conditions. Dynamic forces can exceed 10 G on “double-ups”. Towing forces are transferred into the deck of the
boat. Monster Tower REQUIRES reinforcement to be installed under the deck by a qualified installer who can
take your boat’s individual mounting situation into account. Every boat, mounting location, and configuration is
unique and needs to be assessed by a fiberglass professional to ensure the forces generated from towing do not
cause damage to the deck and other areas of your boat.
Monster Tower is not responsible for damages due to improper installation or reinforcement.
Leave the protective plastic wrap around the legs to prevent damage during installation.
Do not use power nut drivers to run bolts. Always turn by hand to prevent the bolts from heating up.
After drilling the locking bolts in the top section the width is permanently set and cannot be moved to another
boat unless the mounting width is the same. Be sure to measure twice before drilling!
The tower is silent by design. If you hear any rattling or noise please check all hardware for tightness. Please
call us at 877-778-6937 if rattling or noise persists.
USE PROVIDED ANTI-SEIZE (IN FOIL PACKET) ON ALL BOLTS!
If you are unfamiliar with these instructions please contact one of our many dealers listed under our dealer
locator on our website.

Page 2
Step 1: To ensure you are not missing any hardware layout all pieces
and verify you are not missing any hardware.
Supplied pieces
Tools Needed

Page 3
Step 2: Mounting Location
Determine where the tower will mount on your boat. The tower requires a 16x3 inch flat mounting surface on
top of the boat. Once you determine where you will mount the bases reinforce the back side of the boat with
the 3/8” marine grade plywood. 3M 5200 adhesive works well to hold the plywood in place.
Cut out the holes on the provided templates. The 5/8” diameter holes are where the studs will go through the
boat. The 13/16” hole is for your navigation light, speaker wires, etc...
Once you have cut out the template, use masking tape to hold the template in place and line up the starboard
template with the port.
Use a 5/8” drill bit to drill out the two stud holes for each base. Be sure to drill in reverse to get through the
gel coat, this will prevent spider cracks from forming. Once you are through the gel coat you can drill
normally. Determine which side of the boat the navigation light needs to run to and drill the 13/16” hole
according to the template.
Step 3: Base Installation
Remove the paper templates and place the correct rubber gasket over the mounting area. Note that there is a
port and starboard gasket. The male deck mount (pc.7) will go below the female deck mount (pc.6). Placing
these over the holes then placing the gasket on top will make base installation much easier.
Slowly place the cast base on the boat. Be careful not to let the studs
come in contact with the gelcoat. Once the base is sitting on the boat
you can place the backing plates (pc.9) against your marine grade
plywood and tighten them down with the brass nuts (pc.4).

Page 4
Step 4: Leg and Top Section Installation
Start with the starboard side and install the ½” x 4” bolt
The head of the bolt will face inside the boat. Before putting the bolt through the case base place the 1 ½”
fender washer (pc.1) against the leg so that it is between the cast base and the leg section. Before installing
the brass nut (pc.4) place the 1” black nylon washer (pc.3) between the brass nut and cast base. Install the
decorative cap (pc.10) over the brass nut.
Insert the quick release knob (Pc.5) into the rear
section of the leg and tighten all the way. Once the
quick release knob is secure install the set screw
(pc.14) into the brass insert. Tighten the set screw
all the way to prevent the knob from coming out
completely when lowering the tower.
Once the knob and set screws are installed you can
insert the header section onto the leg section. Do
not remove the protective wrap from the leg
section until the install is complete.
Insert the port leg completely into the header section and line it up with the port cast base. Install the ½” x 4”
bolt 1 ½” fender washer (pc.1), 1” black nylon washer (pc.3), brass nut (pc.4), quick release knob
assembly (pc.5), and set screw (pc.14) identical to the installation on the starboard side.
Step 5: Aligning the Top Section
Now that everything is installed align the top section so the holes for the locking bolts (pc.12) can be drilled.
Using an X pattern measure from the edge of the top section to a reference on the opposite side cast base.
Use the same reference on both sides. Some easy references are the welds on the front of the leg or the
bottom of the leg mounting plates.
Once the top section is centered and level use the provided 10mm drill bit (pc.16) to drill through the top
section into the leg sections. The center pilot holes on each side of the top section are for the sound bar
wiring harness. If you do not plan on installing a sound bar do not drill this hole! Be sure to drill from the top
down and the bottom up. This will prevent any misalignment with the bottom pilot hole thus preventing top
section movement. Once the first hole is drilled install the 3/8” x 3" BHCS bolt (pc.12) and use the provided
8mm allen wrench to tighten the bolt into the decorative header nut (pc.13). The decorative header nut will
sit flush against the top section. Continue this step for the remaining 3 bolts and install them accordingly.

Page 5
Step 6: Installing the LED Navigation Light
Use a wire fish to pull the wire through the tower to the side of the boat you drilled for the navigation light.
At the end of the leg, pull out the wire and run it into the wire slot of the leg mounting plate. In most cases,
the LED anchor light can be wired into the existing navigation light system.

Page 6
Step 7: Installing the cover panels
Install the base cover panels as the last step of your installation. The pegs should align with the white insert
holes on the cast base. Apply enough pressure so that the peg fits fully into the insert.
Using your new HS1 Wakeboard Tower –Operating Instructions
The HS1 tower easily folds for storage. To fold the tower, remove the quick release knobs and slowly guide the tower to
the folded position.
When the tower is folded, always use a vest or other cushion to protect your
boat where the tower and boat touch.
IMPORTANT –The tower cannot be towed when folded. The tower must be
in the upright position when being towed.
After towing and before every use, please check and tighten bolts and nuts
when necessary.
The HS1 tower is silent by design. If you hear any rattling or noise from the
tower, or see any movement in the tower, stop and check all hardware for
tightness. Call us at 877-778-6937 if this does not correct the problem.
Always understand and follow the warnings on the tower label!
