MONSTER TRAX 12 VOLT BLACKOUT SUV User manual

MONSTER
TRAX
12 VOLT BLACKOUT SUV

1
If a battery leak develops, avoid contact with the leaking acid and
place the damaged battery in a plastic bag. See information in
“Disposal of Battery” for proper disposal.
If acid comes in contact with skin or eyes,
flush with cool water for
at least 15 minutes and call a physician.
If acid is internally ingested,
give water, milk of magnesia or egg-
white immediately. Never give emetics or induce vomiting. Call a physician.
WARNING!
To reduce the risk of injury, adult supervision is required. Never use
in roadways, near motor vehicles, on or near steep inclines or steps,
swimming pools or other bodies of water. Always wear shoes and a helmet.
Never allow more than 2 riders.
TO PREVENT FIRE AND ELECTRIC SHOCK:
Only use battery and charger provided and specified by manufacturer. Use
of the wrong type of battery for charger could cause a fire or explosion.
DO NOT use the battery or charger for any other product.
Overheating, fire or explosion could occur.
NEVER modify the electric circuit system. Alterations could cause a shock,
fire or explosion.
DO NOT allow any type of liquid on the battery or its components.
Explosive gases are created during charging. DO NOT charge near heat
or flammable materials. Charge in a well ventilated area ONLY.
Charge the battery in a dry area ONLY.
DO NOT open the battery. Battery contains lead acid and other
materials that are toxic and corrosive.
DO NOT open the charger. Exposed wiring and circuitry inside case may
cause electric shock.
ONLY ADULTS may handle or charge the battery. NEVER allow child to
handle or charge the battery. Battery is heavy and contains lead acid
(electrolyte).
DO NOT drop the battery. Permanent damage to the battery could occur
or cause serious injury.
Before charging the battery, check for wear or damage to the battery,
charger and the connectors. DO NOT charge the battery if any damage
to parts has occurred. Replace with manufacturer’s parts ONLY.
DO NOT allow the battery to drain completely; recharge the battery after
each use or once a month if not used regularly.
DO NOT charge battery upside down.
Always secure the battery with the bracket. Battery can fall out and injure
a child if the vehicle tips over.
If you have any question, please call the Redman and Associates service phone #[phone]
instead of returning to the retailer where purchased.
Risk of fire. Do not bypass.

Charger Manual
Wrench
Spacer
Wheel cover Wheel cover cap
X1 X1
X1 X1
X1
X8
X1
X4 X4
X1
X2
X1
2
Tools required
Philips head screwdriver
Adjustable wrench
Component List
Pliers
1
4
8
5
2
6
10 11
14 15
16 17 18 19
12
13
9
7
3
If you have any question, please call the Redman and Associates service phone #[phone]
instead of returning to the retailer where purchased.
Steering wheel×1
5mm Lock nut×1
5mm×35mm
Steering fixing bolt×1
4mm×16mm
Flat self-tapping
screws×4
4mm×12mm
Flat self-tapping
screws×4
4mm×12mm 4mm×16mm
Circular self-tapping Circular self-tapping
screws×2 screws×6
wheel×4
12mm Washers×6
10mm Lock nut×4
Cover plate under
the seat×1
Gear box×2

4
12
16
15
11
17
4
4
17
15
17
15
17
11
15
16
12
12
16
15
11
17
4
17
18
12
18
16
15
11
17
17
1.
Assembly of your new car is simple, provided
you carefully follow the detailed diagram and refer to
component part numbers to ensure they are fitted in the
correct order as shown above.
IMPORTANT!
Before first time use, charge
the battery for at least 10 hours.
Never charge the battery longer
than 15 hours.
If you have any question, please call the Redman and Associates service phone #[phone]
instead of returning to the retailer where purchased.
3
19
19
9
5

3.
4
If you have any question, please call the Redman and Associates service phone #[phone]
instead of returning to the retailer where purchased.
Circular self-tapping screws×2
4mm×12mm
9
5
2.
A to A B to B
B to B
A to A
Connect the wire of the motor in accordance
with the instruction in the above drawing, and
insert plug-ins of the motor in place.

5.
5
If you have any question, please call the Redman and Associates service phone #[phone]
instead of returning to the retailer where purchased.
Flat self-tapping screws×2
4mm×16mm
9
1
9
4.
Circular self-tapping screws×2
4mm×16mm
9
3
9

6
If you have any question, please call the Redman and Associates service phone #[phone]
instead of returning to the retailer where purchased.
7.
Circular self-tapping screws×4
4mm×16mm
9
9
9
9
6.
Flat self-tapping screws×4
4mm×12mm
9
8
8
7

7
If you have any question, please call the Redman and Associates service phone #[phone]
instead of returning to the retailer where purchased.
8.
Flat self-tapping screws×2
4mm×16mm
9
6
9.
10

8
120
above.
If you have any question, please call the Redman and Associates service phone #[phone]
instead of returning to the retailer where purchased.
REVERSE
LOW SPEED
HIGH SPEED
REVERSE
LOW SPEED
HIGH SPEED
Input DC 12V 1000mA
ON
POWER
OFF
no less than
Prior to the first use of your vehicle, remove seat from vehicle and remove large flat battery
compartment cover and connect battery wires to battery(red to red & black to black) as the 2nd assembly
step in page 4. Please ensure colors are correct to avoid short circuiting.
Input DC 12V 1000mA
Your car is fitted with 2 gearboxes containing 2 forward speeds and 1 reverse speed. The operating speed of
your car can be controlled by the middle gear lever. Pushing it all the way forward will engage forward speed
on high speed. Central position of gear lever will engage forward speed at low speed. Pushing your gear lever
all the way back will operate reverse gear in low speed.
Your car is also fitted with an ON/OFF switch located behind the gear lever. Switch must be in the on position to
activate drive. In order to start your car, push gear lever forward into high speed position and place your foot onto
the accelerator.
To stop your car, simply release your foot from the accelerator and this will engage the auto brake system.
Your car is not fitted with a manually operated brake.
Your car has a large turning radius. To ensure unwanted collisions with obstacles, it is recommended that
you drive your car in a wide open area until you get fully used to its handling and steering capabilities.
OPERATING FEATURES

9
Disposal Of Battery
Disposal Of Battery
Battery safety information
Product Specification
Suitable age grading
Usage temperature range
Maximum user weight
Speed
Charger
Battery
Charger time
Battery life
3+yrs
0-40 degrees C
88 lbs
2.17-4.35/mph
Input AC 120V
Output DC 12V 1000mA
12V 7AH×1
8-12hrs
Appro×300 charges
If you have any question, please call the Redman and Associates service phone #[phone]
instead of returning to the retailer where purchased.

10
Safety warnings
1.Battery should only be charged by an adult.
2.Children should always be supervised when riding.
3.Product should only be assembled by an adult.
4.Car should not be ridden at night, near or around swimming pools, steep
slopes or near any public roads.
5.Always ensure that product is stationary before switching from forward to reverse.
6.To avoid suffocation, keep all bags away from children. Please dispose of all
plastic bags immediately.
7.Car should only be washed with a clean damp cloth.
8.Car should never be used in wet weather.
9.It is advisable to protect car from weather conditions when not in use.
Do not leave outside.
10.Never allow more than 2 riders at a time.
11.Always wear a helmet and protective clothing when riding.
Charging tips
1.Charging of battery should always be performed by an adult.
2.Never run battery flat as this will decrease battery life.
3.It is quite normal for battery and charger to become very warm during
charging cycle. Never charge battery while still warm after use.
4.To ensure proper life span of your battery while car is in storage,
it is strongly advised to charge battery fully every 3 months.
Trouble Shooting Guide
Car will not run of all.
Check all electrical connections and ensure there is no damage.
Car is running slower than normal.
Stop use immediately and recharge battery.
If you have any question, please call the Redman and Associates service phone #[phone]
instead of returning to the retailer where purchased.

Phone: [phone]
Fax: [phone]
Redman & Associates, LLC
9:00 am to 5:00 pm CST Monday through Friday.
!
Adult Assembly Required. To reduce the risk of injury,
adult supervision is required. Never use in roadways, near cars, on or near steep inclines or steps,
swimming pools or other bodies of water. Always wear shoes and never allow more than 2 riders,
or total of 88lbs. In unassembled state, contains potentially hazardous small parts, so please keep
out of baby’s reach.
WARNING
071813
Your Electric Vehicle has a Limited 90 Day Warranty from Redman & Associates,
LLC. from the date of original purchase against defects in materials or workmanship.
This warranty covers normal use and the coverage is not extended
if the unit was damaged by unreasonable use, neglect, accident,
abuse/misuse, improper service or other causes not arising out of
defects in material or workmanship. This warranty does not cover
any liability claims for breach of warranty
Please save your receipt from the original purchase in case of any warranty claims.
Save your box in the event the toy has to be returned. Should you need service or
assistance with your vehicle during the warranty period.
Do not return the vehicle to the store. Please call our Customer Care Center at:
Our products are suitable for the following standard:
GB6675,GB19865
ASTM-F963,CPSIA
EN71 AND EN62115
LIMITED 90 DAY WARRANTY
If you have any question, please call the Redman and Associates service phone #[phone]
instead of returning to the retailer where purchased.
Email: customersupport @ redmanandassociates.com
Website: www.redmanandassociates.com
