Monster JP 900 Installation guide

HOME THEATER SURGE PROTECTOR JP 900
Instructions and
Warranty Information

ENGLISH

ENGLISH
Fireproof MOV Technology Protects Your Equipment
and Your Home
Power surges can harm not only your valuable
home theater equipment but can also start a fire in
your home – even if you’re using a surge protector.
Ordinary surge protectors use plastic-coated MOVs
– metal oxide varistors – to absorb excess voltage. But powerful surges can overheat
and melt the plastic coating, potentially causing a fire.
This Monster Surge Protector features ceramic-encased MOVs for superior fire
protection. The ceramic enclosure is made of fireproof material similar to that used
on the space shuttle to give you peace of mind that your home theater and, more
importantly, your home is safe.

ENGLISH
MONSTER
®
HOME THEATER SURGE PROTECTOR
JP 900 FEATURES
1
32
4
6
5
7

ENGLISH
1. Power ON/OFF Switch
Turns the surge protector on and off.
2. “Protection ON” Diagnostic Light
Indicates that connected audio and video
equipment is protected
3. “Ground OK” Diagnostic Light
Indicates that the wall outlet that the surge
protector is plugged into is properly grounded
4. Labeled Outlets with Matching Cord Labels
Makes hook-up easy and eliminates unplugging
the wrong component
5. Ultra-Wide Spaced Outlets
Easily fit bulky power adapters without
blocking adjacent outlets
6. Surge-Protected Phone Connections
Provides surge protection for DVR, satellite
and modem lines
7. 2 Pair Surge-Protected Cable/Satellite
Connections
Provides surge protection for cable,
antenna and satellite lines

ENGLISH
CABLE/SATELLITE/ANTENNA CONNECTIONS HOOK-UP
Coaxial connections provide surge protection against damaging voltage surges
and spikes on the incoming cable TV, satellite and antenna lines.
PHONE CONNECTION HOOK-UP
Phone connections provide surge protection against damaging voltage surges and
spikes coming from the phone line. This surge protector also incorporates a splitter
for convenience. Protect Phone Line Connections as follows:
IN OUT
CABLE/SAT
OUTIN
PHONE
CABLE/SAT/ANT
To
TV/Cable
Box
IN OUT
CABLE/SAT
OUTIN
PHONE
Telephone
Wall Jack
To Satellite
Receiver,
Modem,
Digital Video
Recorder
(DVR) or
Telephone

ENGLISH
WALL-MOUNTING INSTRUCTIONS
The surge protector comes with keyholes for convenient wall-mounting.
1. Select the best location to mount the surge protector and mark
the position for the four mounting screws (screws not supplied).
2. Drive pan-head screws with spacer eyelets into the wall (use drywall anchors for
hollow walls) at the locations you marked, leaving the eyelet exposed.
3. Position the key-holes on the back of the unit over the screw/eyelets and slide
the surge protector down until it locks into position.
OFF
RESET

ENGLISH
SAFETY PRECAUTIONS
IMPORTANT SAFETY INFORMATION
Please read and observe the following safety points at all times.
WARNING – Power Sources
Do not plug this surge protector into a power outlet that differs from the source
indicated for safe use on the Surge protector. If you don’t know the type of electrical
power that is supplied to your home, consult your local power company
or a qualified electrician.
WARNING – Grounding and Polarization
A. Do not force your surge protector plug into an outlet that is not designed to
accept a three-wire grounded-type AC plug (a three-prong plug). This plug is
designed to be inserted into a grounded-type outlet only. If this plug doesn’t
fit directly inside your outlet, do not attempt to force it into the outlet. Never
attempt to dismantle the plug in any way (or to alter the power cord). Do not
attempt to defeat the grounding feature by using a 3-to-2 prong adapter.
If you have questions about grounding, consult your local power company
or a qualified electrician.

ENGLISH
B. If you use rooftop devices such as satellite dishes, antennas, or any other
component with wire that connects to your surge protector, be sure the wire(s)
is properly grounded. This protects against voltage surges and static charges.
C. Do not place any antenna near overhead power lines or any other power circuit.
Do not touch any power line or power circuit. Doing so may cause severe
physical injury or possibly death.
WARNING – Liquid: Avoiding Electrical Shocks
A. Do not operate your Monster Surge Protector if liquid of any kind is spilled onto
or inside the unit.
B. Do not operate your Monster Surge Protector near rain or water that’s spilled
or contained (e.g., bathtub, or kitchen sink).
WARNING – Power Cord Safety
A. When routing your surge protector’s AC power cord, do not place it near heavy
foot traffic areas (e.g., hallways, doorways, and floors). Do not create a trip
hazard with the power cord.
B. If your power cord’s protective jacket begins to rip or fray, exposing the internal
wiring, shielding, etc., disconnect it from the AC power source and discontinue
use of the surge protector immediately. See the Warranty Information section
of this owner’s manual for important details.

ENGLISH
WARNING – No User Serviceable Parts Inside
If, for any reason, your surge protector is not operating properly, do not remove
any part of the unit (cover, etc.) for repair. Unplug the unit and consult the Warranty
Information section of this owner’s manual for important details.
CAUTION – Exposure To Heat
Do not expose your surge protector to direct sunlight or place it near wall heaters,
space heaters, or any enclosed space prone to temperature increase.
CAUTION – Proper Cleaning
In general, the only cleaning necessary for your Monster Surge Protector is a light
dusting. Unplug your component from the wall outlet before cleaning it. Do not
use any type of liquid or aerosol cleaners.

ENGLISH

ENGLISH
SYMPTOM POSSIBLE CAUSE REMEDY
The surge protector is not
receiving power.
The surge protector is not turned On.
Too many devices are connected, causing an overload,
tripping the Circuit Breaker.
• Turn the surge protector switch on.
• Make sure the surge protector’s AC power plug is plugged into a properly grounded 120 volts (nominal)
wall outlet.
• In some households, a wall switch may need to be thrown to make the wall plug active. Try turning on the
light switches located near the wall unit.
• Press the surge protector main power switch to “OFF” and then again to “ON” to reset.
Component is not receiving power. The surge protector is plugged into a Switched outlet, but power
on the component is not On. In some instances, a component
plugged into a switched outlet won’t receive power when the
surge protector is turned On unless the component power is
also switched On.
• Turn the surge protector On.
• Turn On the component plugged into the Switched outlet.
Speakers emit a humming
or buzzing noise.
The surge protector is sharing AC power with equipment
that is not properly grounded.
• Connect your surge protector to a dedicated outlet.
• Try unplugging different components from the surge protector one at a time to see if the noise stops.
• Make sure all components are plugged into surge protector.
“Ground OK” Diagnostic Indicator Light
does not come on.
Make sure surge protector is plugged into grounded outlet. Contact a qualified electrician to check outlet(s) for proper grounding.
TROUBLESHOOTING
TROUBLESHOOTING

ENGLISH
SYMPTOM POSSIBLE CAUSE REMEDY
The surge protector is not
receiving power.
The surge protector is not turned On.
Too many devices are connected, causing an overload,
tripping the Circuit Breaker.
• Turn the surge protector switch on.
• Make sure the surge protector’s AC power plug is plugged into a properly grounded 120 volts (nominal)
wall outlet.
• In some households, a wall switch may need to be thrown to make the wall plug active. Try turning on the
light switches located near the wall unit.
• Press the surge protector main power switch to “OFF” and then again to “ON” to reset.
Component is not receiving power. The surge protector is plugged into a Switched outlet, but power
on the component is not On. In some instances, a component
plugged into a switched outlet won’t receive power when the
surge protector is turned On unless the component power is
also switched On.
• Turn the surge protector On.
• Turn On the component plugged into the Switched outlet.
Speakers emit a humming
or buzzing noise.
The surge protector is sharing AC power with equipment
that is not properly grounded.
• Connect your surge protector to a dedicated outlet.
• Try unplugging different components from the surge protector one at a time to see if the noise stops.
• Make sure all components are plugged into surge protector.
“Ground OK” Diagnostic Indicator Light
does not come on.
Make sure surge protector is plugged into grounded outlet. Contact a qualified electrician to check outlet(s) for proper grounding.

ENGLISH
LIMITED WARRANTY FOR CONSUMERS
Monster,LLC,7251LakeMeadBlvdWest,LasVegas,NV89128,USA(“Monster”)extendstoYouthisLimitedWarranty.Statutoryorcommonlawmay
provideYou with additional rights or remedies, which shall not be affected by this LimitedWarranty.
DEFINITIONS
“Adequate Use” means use of the Product and Connected Equipment (i) within a home or dwelling, (ii) for private (as opposed to commercial)
purposes,(iii)inconformance withall applicablelocal,stateorfederallaw,codeorregulations(includingwithoutlimitationbuildingand/orelectrical
codes),(iv) inaccordancewithmanufacturerrecommendationsand/orinstructionsinthematerialsanddocumentationthataccompanytheProduct
andanyConnectedEquipment,(v)withproperelectricalgrounding,(vi)withproperanddirectconnectionbetweentheProductandanACpower
sourcethat hasprotectivegrounding(excludinggasordieselpoweredgenerators), (vii) withcableortelephonelinestoany ConnectedEquipment
properly connected to the Product, and (viii) without a connection in a“daisy-chain”fashion to or with any extension cord, surge suppressor, power strip,
uninterruptible power supply (“UPS”) or other equipment.
“Authorized Dealer”means any distributor, reseller or retailer that (i) was duly authorized to do business in the jurisdiction where it sold the Product
toYou, (ii)waspermittedto sellYoutheProductunderthelawsofthejurisdictionwhereYouboughttheProduct,and(iii)soldYoutheProductnewand
in its original packaging.
“Connected Equipment”means any device that is (i) generally suited to be used with the Product or products of the same kind, (ii) meets the
requirements of all applicable laws and safety standards, (iii) contains only parts manufactured, sold or recommended by the original manufacturer of
theConnectedEquipment,and(iv)hasnotbeenaltered,tamperedwithormodifiedbyanypersonother thanitsmanufactureror servicepersonnel
authorized or recommended by the manufacturer of the Connected Equipment.
“Connected Equipment Damage”meansphysicaldamagetoConnectedEquipmentcausedbyaProductDefectbyatransient ACpower,cable,
telephone, or lightning surge while connected to a properly installed Product. Connected Equipment Damage (i) may not be caused by a defect or
unrelateddamagingoftheConnectedEquipment orasurge/spikeorlightningstrikethroughasource, mediumorconnectionotherthanthroughthe
Product, and (ii) does not extend to loss of data, or consequential, indirect or special damages resulting from the Connected Equipment Damage.
“Fair Market Value”(“FMV”) means the fair market value of the Connected Equipment at the time Connected Equipment Damage occurs.
“Formal Warranty Claim”means a claim made in accordance with the section“FormalWarranty Claims”herein.
“Maximum Coverage Amount” meansthe maximumamount thatMonster willpaytoYouunderthisLimitedWarrantyfor ConnectedEquipment
Damages and is defined in relation to each Product in the SpecificationsTable below.

ENGLISH
“Product” meansaProduct(i) thatislistedintheSpecificationsTablebelow,(ii)thatYoubought fromanAuthorizedDealernewandinitsoriginal
packaging, and (iii) whose serial number, if any, has not been removed, altered, or defaced.
“Product Defect”meansadefect,malfunction,non-conformance to thisLimitedWarrantyorotherinadequacyoftheProductthat existedat
thetimewhenYoureceivedtheProductfromanAuthorizedDealerandthatcausesafailureoftheProductto performinaccordancewithMonster’s
documentation accompanying the Product, unless such failure has been caused completely or partly by (a) any use other than Adequate Use, (b)
transportation, neglect, misuse or abuse by anyone other than Monster’s employees; (c) alteration, tampering or modification of the product by anyone
otherthanaMonster employee;(d)accident(otherthana malfunctionthatwouldotherwisequalifyasaProductDefect);(e)maintenance orservice of
the Product by anyone other than a Monster employee; (f) exposure of the Product to heat, bright light, sun, liquids, sand or other contaminants; or (g)
acts outside the control of Monster, including without limitation acts of God, fire, storms (excluding lightning surges), earthquake or flood.
“Warranty Period” means the time period during which Monster must have receivedYour FormalWarranty Claim.The differentWarranty Periods
related to Product Defects and Connected Equipment Damage are defined in the SpecificationsTable below.TheWarranty Period commences on the date
whenYoupurchasedorreceived(whicheveroccurslater)theProductfromanAuthorizedDealerasevidencedbytheAuthorizedDealer’sinvoice,sales
receiptorpackingslip.IfYoudonot have writtenproofofthe date ofpurchaseorreceipt,thentheWarrantyPeriod commencesthree(3)monthsafter
thedatewhentheProductleftMonster’sfactoryasevidencedbyMonster’srecords.TheWarrantyPeriodendsafterthetimedefinedintheSpecifications
Tablehasexpired,orafterYouhavetransferredownership oftheProduct,whicheveroccursearlier.Also,YoumustcallMonsterand obtainaReturn
AuthorizationNumber(as describedunder“HowtoMakeaClaim”)withintwo(2) monthsafterYoudiscoveraProductDefect(orshouldhave discovered
it, if such Product Defect was obvious).
“You”means thefirstindividualpersonthatpurchasedthe ProductinitsoriginalpackagingfromanAuthorizedDealer.ThisLimitedWarrantydoesnot
applytopersonsorentitiesthatboughttheProduct(i)inusedorunpackagedform,(ii)forresale, leaseorothercommercialuse,or(iii)fromsomeone
other than an Authorized Dealer.
SCOPE OFTHIS LIMITED WARRANTY
PRODUCTS. If a Product contained a Product Defect whenYou bought it from an Authorized Dealer and Monster receives a FormalWarranty Claim
fromYouwithintwo (2)monthsafterYoudiscoversuchProductDefect(orshouldhavediscoveredit, ifsuchProductDefectwas obvious)andbefore
the end of theWarranty Period for Product Defects applicable to the affected Product, then Monster will provideYou with one of the following remedies:
Monsterwill(1)repairor,at Monster’ssolediscretion,replace theProduct,or(2) refundtoYouthepurchasepriceYoupaidtotheAuthorizedDealerfor
the affected Product if repair or replacement is not commercially practicable or cannot be timely made.
CONNECTED EQUIPMENT DAMAGE. Monster will also provideYou with a remedy regarding Connected Equipment Damage if (i)You have a
claim under the LimitedWarranty for Products because of a Product Defect that causes Connected Equipment Damage despite Adequate Use, and (ii)
MonsterreceivesaFormalWarrantyClaim fromYoubeforethe endoftheWarrantyPeriodforConnectedEquipmentDamageapplicabletotheaffected

ENGLISH
Product.Iftheconditionslistedinthepreceding sentencearemet,Monster willprovideYouwithone ofthefollowingremediesprovidedthatMonster
maydecideatits solediscretionwhichofthethreeremediesitprovides:Monster will (1)replace thedamagedConnectedEquipment;(2)pay to
repair the damaged Connected Equipment; or (3) payYou the FMV of the Connected Equipment, provided that such payments shall not exceed (i) the
MaximumCoverage Amount fortheProduct,or(ii)theactualdamagehavingarisenfrompowersurgesdueto aProductDefect. NOTE:COMPENSATION
FORRESTORATIONOFDATALOSS ISNOTCOVEREDANDMONSTERDOESNOTASSUMEANYLIABILITYFORANYINCIDENTAL, CONSEQUENTIAL
ORINDIRECTDAMAGESUNDERTHISLIMITEDWARRANTY. SOMESTATES DONOTALLOWTHEEXCLUSIONORLIMITATIONOFINCIDENTALOR
CONSEQUENTIAL DAMAGES, SOTHE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLYTOYOU.
GENERAL PROVISIONS
CHOICE OF LAW/JURISDICTION. ThelawsoftheStateofCalifornia,USA,governthiswarranty. ItgivesYouspecificlegal rights,andYoumay
alsohaveother rightsthatvaryfromstatetostateand countrytocountry.Thiswarrantydoesnotaffectany additionalrightsYouhave underlawsinyour
jurisdiction governing the sale of consumer goods, including, without limitation, national laws implementing EC Directive 44/99/EC.
OTHER RIGHTS. THIS LIMITEDWARRANTY GIVESYOU SPECIFIC LEGAL RIGHTS, ANDYOU MAY ALSO HAVE OTHER RIGHTS,WHICHVARY FROM STATE
TOSTATEANDCOUNTRYTOCOUNTRY. THISWARRANTYEXTENDSONLYTOYOUAND CANNOTBETRANSFERREDORASSIGNED.Ifany provisionofthis
LimitedWarrantyisunlawful,voidorunenforceable, that provisionshallbedeemedseverableandshall notaffectany remainingprovisions.Incaseof
any inconsistency between the English and other versions of this LimitedWarranty, the English version shall prevail.
REGISTRATION. PleaseregisterYour Productatwww.monsterpower.com. Failureto registerwillnotdiminishYourwarrantyrights.
SPECIFICATIONS TABLE
Product Model No. Maximum Coverage
Amount
Warranty Period
for Product
Warranty Period for Connected
Equipment Damage
JP 900 $400,000.00 Lifetime* 5 years
*”Lifetime”meansthe lifetimeoftheoriginalindividualpurchaser oftheProduct,orfor aslongasthe originalindividualpurchaser owns theProduct,
whichever is less in time.

ENGLISH
FORMAL WARRANTY CLAIM
HOW TO MAKE A CLAIM. In the event damage has occurred to Products or Connected Equipment,You must follow these instructions: (1) Call
Monsterwithintwo (2)monthsafterYoudiscovera ProductDefect(orshouldhave discoveredit, ifsuchProductDefectwas obvious);(2) Giveadetailed
explanationofhowthedamageoccurred; (3)ObtainaReturnAuthorizationNumber;(4)Uponreceipt ofaclaimform(whichmaybesenttoYouafter
YoufiledYourFormalWarrantyClaim),fillouttheclaimformentirely;(5)Return theProducts,shippingprepaidbyYou(to berefundedifYouareentitled
to aremedyunderthe Scope ofthisLimitedWarranty),toMonsterforverificationofdamage, alongwithacopy ofYouroriginalsales receiptsandproof
of purchase (UPC label or packing slip) for such Products, the completed claim form, and printed Return Authorization Number on the outside of the
return package (the claim form will include instructions for return).
TELEPHONE NUMBERS. IfyouboughttheproductintheUnitedStates, Latin America,orAsiaPacific, contactMonster,LLC(455ValleyDrive,
Brisbane, CA94005)at415-840-2000or1877 800-8989(Mexico001-882-800-8989).Ifyouboughttheproductanywhereelse,contactMonster
TechnologyInternationalLtd.,BallymaleyBusinessPark,Ennis,Co.Clare,Ireland.Youcanwrite oruseoneofthe followingtelephonenumbers:Canada
866-348-4171, Ireland 353 65 68 69 354, Austria 0800296482, Belgium 0800-79201,Czech Republic 800-142471, Denmark 8088-2128, Finland 800-
112768,France0800-918201,Germany 0800-1819388,Greece00800-353-12008,Italy800971470, Netherlands0800-0228919,Norway800-10906,
Russia 810-800-20051353, Spain 900-982-909, Sweden 020-792650, Switzerland 0800834659, United Kingdom 0800-0569520
FURTHER PROCEEDINGS. MonsterwilldeterminewhetheraProductDefectexistedandthedamagetotheConnectedEquipmentwascaused
bytheProduct.Youmustallow Monsteraccesstothepremisesandsitewherethe damage occurredand allequipment andpropertyrelatedtheretofor
Monsterinspectionbyitsemployees orauthorizedrepresentatives.Monster may,atitsdiscretion,directYoutoobtainarepairestimateataservicecenter
or,tosendtheConnectedEquipmenttoMonster forrepair.Ifa repairestimateisrequired,Youwillbeinstructedonhow to properly submittheestimate
and the resulting invoice to Monster for payment. Any fees for repairs may be negotiated by Monster.
TIMING. IfYoubringaFormalWarrantyClaim andfully complywithall termsandconditionsofthisLimitedWarranty,Monsterwilluse itsbestefforts
to provideYou with a remedy within thirty (30) days after receipt ofYour FormalWarranty Claim (ifYou reside in the United States - forty-five (45) days if
You reside elsewhere), unless obstacles outside Monster’s control delay the process.
©2003 - 2010 Monster, LLC

FRANÇAIS
PARASURTENSEUR JP 900
POUR LE CINÉMA MAISON
Instructions et Informations
relatives à la garantie

FRANÇAIS
