Montana Instruments Cryostation s Series User manual

4117-DOC001
Option User Manual
Turbopump Vacuum Package
Cryostation s-series
Version: 1.2
December 2020
www.montanainstruments.com
[e-mail]
+1.406.551.2796
101 Evergreen Drive
Bozeman, MT 59715, USA

This page intentionally left blank.

Turbopump Vacuum Package
3
Specifications and product information listed in this document are accurate to the time of publishing
for a standard system. Options, custom designs, and/or other modifications may cause slight
differences. Future design changes to the system, including software updates, may change information.
© Montana Instruments® Corporation, All Rights Reserved
No part of this publication may be reproduced, distributed, or transmitted in any form or by any means,
including photocopying, recording, or other electronic or mechanical methods, without the prior written
permission of Montana Instruments.
Montana Instruments, Cryostation, nanoReveal, microReveal, Cryo Optic, and ATSM are trademarks of
Montana Instruments Corporation. Other brand names used are the property of their respective owners.

Option User Manual
4
Table of Contents
Section 1 - Preface ........................................................................................................................................................ 6
1.1 Conventions Used in this Manual...............................................................................................................................7
1.1.1 Abbreviations................................................................................................................................................................................ 7
1.1.2 Explanation of Safety Warnings.............................................................................................................................................7
1.1.3 Graphical Symbols ...................................................................................................................................................................... 8
1.2 General Hazard Information....................................................................................................................................... 9
1.3 Technical Support Information .................................................................................................................................10
1.3.1 Warranty & Repairs ..................................................................................................................................................................10
1.3.2 Accessories & Replacement Parts.......................................................................................................................................10
1.3.3 Contact Details ...........................................................................................................................................................................10
Section 2 - Option Overview..................................................................................................................................... 11
2.1 Turbopump Vacuum Package................................................................................................................................... 11
2.1.1 Intended Use...............................................................................................................................................................................11
2.1.2 Components................................................................................................................................................................................11
2.1.3 Technical Specifications..........................................................................................................................................................12
2.1.4 Safety Information ....................................................................................................................................................................13
Section 3 - Option Installation & Handling...........................................................................................................14
3.1 Packaging Contents .....................................................................................................................................................14
3.2 Installing the Turbopump Vacuum Package .........................................................................................................14
3.2.1 Installing the Vacuum Valve Assembly.............................................................................................................................14
3.3 Connecting System Cables and Power....................................................................................................................17
Section 4 - Option Usage & Operation ..................................................................................................................19
4.1 Primary Operations ......................................................................................................................................................19
4.1.1 Cooling Down with the Turbopump..................................................................................................................................19
4.1.2 Pulling Vacuum with the Turbopump ...............................................................................................................................20
Section 5 - Maintenance & Troubleshooting........................................................................................................21
5.1 Care & Maintenance ....................................................................................................................................................21
5.1.1 Vacuum System Best Practices.............................................................................................................................................21
5.1.2 Component Maintenance ......................................................................................................................................................21
5.2 Diagnostics & Troubleshooting ............................................................................................................................... 22
5.2.1 Vacuum System Diagnostics.................................................................................................................................................22

Turbopump Vacuum Package
5
5.2.2 Turbopump Errors.....................................................................................................................................................................23
Section 6 - Appendices..............................................................................................................................................24
6.1 Related Documentation............................................................................................................................................. 24
Manual Addendum........................................................................................................................see Supplement A

Option User Manual
6
Section 1 - Preface
WARNING
Read all instructions before using this product
All users must read and understand this manual and all other safety instructions before using the
equipment. Retain these instructions for future reference.
This manual is intended for users of the Montana Instruments products and systems described herein.
Users include anyone who may physically interact with the system or peripheral equipment, including
installing, setting up, or configuring the system or anyone who may operate system components via
operating panels, the supplied user interface, or remote interfaces.
This manual may be used by facilities personnel for determining infrastructure requirements in the
room or building where the equipment will be installed.
This manual should be referenced by authorized service personnel for important safety and hazard
information and other product restrictions.

Turbopump Vacuum Package
7
1.1 Conventions Used in this Manual
The following style conventions are used in this document:
•Vertical bar ( | )
oIndicates alternative selections. The bar may be used in place of “and” or “or”.
•Alphanumeric List (1., 2., 3…| a., b., c…)
oIndicates instructions or actions which should be completed in a specific ordered
sequence.
•Bulleted List (•| ◦ | -)
oIndicates instructions, commands, or additional information about an action.
oMay alternatively be used for unordered lists of materials or additional reference notes.
•Courier Font
oIndicates a label or indicator on a physical product or part.
oIndicates a system output, such as a display reading.
oMay also be used for URLs, file paths, file names, scripting language, prompts, or syntax.
1.1.1 Abbreviations
The following abbreviations may be used:
•ACM: Ancillary Control Module
•CAN: Controller Area Network
•DMM: Digital Multimeter
•HDMI: High Definition Multimedia Interface
•MI: Montana Instruments
•PCB: Printed Circuit Board
•TCM: Temperature Control Module
•UI: User Interface
•UPS: Uninterruptible Power Supply
•USB: Universal Serial Bus
•VNC: Virtual Network Computing
•International System of Units (SI) symbols
•System of Imperial Units symbols
•Element, molecule, and compound abbreviations
1.1.2 Explanation of Safety Warnings
Safety and hazard information includes terms, symbols, warnings, and instructions used in this manual
or on the equipment to alert users to precautions in the care, use, and handling of the system. The
following hazard levels and information are considered:

Option User Manual
8
DANGER
Serious personal injury
Imminent hazards which, if not avoided, will result in serious injury or death.
WARNING
Serious personal injury
Potential hazards which, if not avoided, could result in serious injury or death.
CAUTION
Possible personal injury
Potential hazards which, if not avoided, could result in minor or moderate injury.
NOTICE
Command or Product Safety Notice
Potential hazards which, if not avoided, could result in product damage.
» NOTE
Points of particular interest for more efficient or convenient equipment operation; additional
information or explanation.
1.1.3 Graphical Symbols
The following symbols may be used in diagrams, supporting text, and on physical parts:
Hazard Alert: General Warning
Hazard Alert: High Voltage
Hazard Alert: Laser Radiation
HDMI port
CAN bus module
USB port

Turbopump Vacuum Package
9
1.2 General Hazard Information
The following descriptions are of general hazards and unsafe practices that may result in product
damage, severe injury, or death.
•The products, parts, and components in this manual are to be serviced by authorized Montana
Instruments service representatives only. Failure to do so will void the warranty and may
damage the product and/or create a safety hazard.
•Only use all components provided for the intended purpose described herein.
•If the equipment or any component is used or modified in a manner not specified by the
manufacturer, the protection provided by the equipment may be impaired.
The following hazards may be typical for this product:
WARNING
Risk of injury when lifting or moving system components
System components, including standalone equipment and installed assemblies, may be heavy.
•Use caution when lifting or moving equipment or assemblies. Ensure proper lifting principles are
used to avoid injury.
•Equipment or assemblies >20 kg should always be lifted by two or more people or with a suitable
lifting device.
WARNING
High voltage: danger of electric shock
Electric shocks and burns from capacitor discharge or power circuits could lead to serious injury or
death.
•Before turning on any power supply, the ground prong of the power cord plug must be properly
connected to the ground connector of the wall outlet. The wall outlet must have a third prong or
must be properly connected to an adapter that complies with these safety requirements.
•Only use replacement power cords or power plugs with the same polarity and power rating as
that of the original ones. Do NOT use inadequately rated cables.
If the equipment or the wall outlet is damaged, the protective grounding could be disconnected.
•Do NOT use damaged equipment until its safety has been verified by authorized personnel.
•Do NOT disconnect or tamper with the operation of the protective earth terminal inside or
outside the apparatus.
NOTICE
Only clean exterior surfaces with acceptable fluids
•Only use deionized water, glass cleaner, or isopropyl alcohol to clean the exterior surfaces of any
enclosure. Do NOT use any volatile chemicals other than isopropyl alcohol.
•Apply fluid to a clean, lint-free cloth and wipe surface with cloth. Do NOT apply fluid directly to
any surfaces or enclosures.

Option User Manual
10
1.3 Technical Support Information
Any technical questions or issues with the system that cannot be resolved with the information in this
manual should be referred to an authorized Montana Instruments service representative.
1.3.1 Warranty & Repairs
If the system or parts need to be returned to the Montana Instruments factory or an authorized service
center for repair or service, contact an authorized service representative for a return merchandise
authorization (RMA) number and instructions on returning the unit.
For a copy of the Limited Warranty Agreement, visit: www.montanainstruments.com/About/Warranty
1.3.2 Accessories & Replacement Parts
Only use cables, hoses, accessories, and parts provided or approved by the manufacturer. Follow all
instructions for proper installation or replacement.
•To order spare or replacement parts, please contact your local service representative.
•To order new accessories or options, or for more information on other Montana Instruments
products and technologies, please contact your local sales representative.
1.3.3 Contact Details
For a complete list of sales and service centers visit: www.montanainstruments.com/Contact
North American Authorized Service
•M-F 8:30am-5pm MST | Call: +1.406.551.2796
•Email: [e-mail]
North American Sales
•M-F 8:30am-5pm MST | Call: +1.406.551.2796
•Email: [e-mail]
International Sales & Authorized Service
•Visit www.montanainstruments.com/Contact/Sales-Offices for contact information for your local
representative.

Turbopump Vacuum Package
11
Section 2 - Option Overview
2.1 Turbopump Vacuum Package
Models
Part Numbers
Turbopump Vacuum Package Assembly
(Valve, Gauge, Vacuum Tubing, Wiring)
4117-119-100V, 4117-119-200V
VC1130
4117-520-01
Turbopump Vacuum Package Assembly (shown on s100)
Turbopump Vacuum Control Unit (VC1130 rear panel)
2.1.1 Intended Use
The turbopump vacuum package is an assembly of vacuum hoses, valves, gauges, and components
designed for integrating a turbopump with the Montana Instruments Cryostation platforms. The
configuration should only be used with compatible Cryostation systems containing the appropriate
hardware, software, and electronics.
2.1.2 Components
The turbopump vacuum package consists of a VC1130 model vacuum control unit with integrated
Pfeiffer Vacuum® HiPace® 80 turbopump, a full-range Pirani/cold-cathode UHV vacuum gauge, a KF40
electromagnetic vacuum valve, a 4 ft KF50 vacuum hose, a 10 ft chamber vent hose, and several KF
clamps, O-rings, and adapter fittings.
Configuration
The UHV gauge is mounted on a manifold inside the main body of the cryostat tower behind the
cryocooler. The vacuum valve assembly then connects to the vacuum port on the back panel of the
cryostat with a KF25 cross adapter between the two connection points. A KF50 vacuum hose runs from
the other end of the valve to the nearby vacuum control unit with integrated turbopump. A 4 ft KF50
hose is provided standard, and up to one additional 4 ft extensions can be added if the vacuum control
unit needs to be placed further away from the cryostat.

Option User Manual
12
Rear Manifold Pumping Configuration
In the rear manifold pumping configuration, the sample chamber is pumped out through the crosslink
assembly that connects the sample chamber to the cryostat cooling tower. One side of the KF25 cross is
capped off.
» NOTE
Due to the location of the UHV gauge, vacuum pressure readings may be up to an order of
magnitude lower than actual sample chamber pressure when used in the rear manifold pumping
configuration.
Rear Manifold + Side Panel Pumping Configuration
Extra components for the alternative parallel side panel pumping configuration are provided. In this
assembly, a 20-in KF25 hose is connected to the KF25 cross inlet between the valve and vacuum port on
the back panel of the cryostat. The hose is then routed around the side of the cryostat to a KF25 side
panel on the sample chamber.
» NOTE
The rear manifold + side panel pumping configuration will provide greater conductance for pulling
vacuum in the sample chamber. For best turbopump vacuum performance, and for the most
accurate sample chamber pressure readings, it is recommended to use this configuration
whenever side panel access is available.
2.1.3 Technical Specifications
Environmental Specifications
Temperature of Environment
5 –40 °C
Humidity
5 –80% non-condensing
Altitude
<2000 m
Power Specifications
If configured without the optional cart with electronics rack, the turbopump vacuum package requires
one additional wall outlet for the vacuum valve mounted near the back panel of the cryostat.
Model
MVV-32
MVV-33
Mains Power Connector on Unit
Hardwired
Frequency
50 –60 Hz
Maximum Power Consumption
10 W
Line Voltage
100 –120 VAC
200 –240 VAC
Maximum Current Draw
0.1 A
0.05 A
Wall Outlet /
Receptacle
N. America & non-EU
Standard NEMA 5-15
NEMA 6-20R single-phase
CEE Europe (non-UK)
n/a
CEE 7/3 or CEE 7/5 w/
common ground terminal

Turbopump Vacuum Package
13
UK
n/a
BS1363 (UK) w/ common earth
ground terminal
Israel
n/a
I-32-3 w/ common earth
ground terminal
Cart Power Module
IEC 60320 C13
2.1.4 Safety Information
The following hazards may be typical for this product:
WARNING
Refer to associated product manuals for complete safety information
•The turbopump vacuum package contains a VC1130 vacuum control unit. Refer to the
Cryostation System User Manual for detailed instructions and important safety information
regarding this component.
•The VC1130 model contains a Pfeiffer Vacuum® HiPace® 80 turbopump. Refer to the Operating
Instructions provided by Pfeiffer for important safety information regarding this component.
•The turbopump vacuum package contains a VAT Series 264 KF40 HV inline valve with
electromagnetic actuator. Refer to the Operating Instructions provided by VAT for important
safety information regarding this component.
•The turbopump vacuum package contains an Agilent® FRG-700 Pirani Inverted Magnetron
Gauge. Refer to the Operating Instructions provided by Agilent for important maintenance and
safety information regarding this component.
NOTICE
Risk of product damage due to improper use
•Do NOT kink vacuum tubing or install vacuum tubing in an area where it may be pinched.
•Ensure all vacuum clamps and fittings are secured tightly prior to operation.
•Do NOT disturb vacuum tubing while the turbopump is operational.
Risk of turbopump damage due to improper use
Venting the system at rotor speeds higher than 250 Hz may cause damage to the turbopump
•Do NOT vent the system when the turbopump is rotating faster than 250 Hz. Observe rotational
speed on the UI to ensure safe rotating speeds prior to manual venting.
•If the system control unit unexpectedly shuts down prior to turning off the turbopump, turn off
the main power to the vacuum control unit and wait at least 15 minutes before venting the
system.

Option User Manual
14
Section 3 - Option Installation & Handling
3.1 Packaging Contents
The turbopump vacuum package components will arrive packed with the rest of the system. Depending
on the system configuration and options, the hoses, clamps, fittings, and valve assembly will be packed
in the accessory box. The UHV gauge will be pre-installed on the manifold inside the cryostat.
3.2 Installing the Turbopump Vacuum Package
NOTICE
Keep vacuum hoses, valves, and components free of contaminates
The vacuum hoses and fittings will ship with caps or covers. When not in use, replace the covers to
help keep the components free of dust and debris that may inhibit future vacuum performance.
3.2.1 Installing the Vacuum Valve Assembly
The vacuum valve assembly connects to the back panel of the cryostat cooling tower. Some of these
components may ship partially pre-assembled.
1. Locate the vacuum valve ①and fittings.
2. Connect the KF40 to KF50 adapter flange ②to the back port on the valve using a KF40 clamp
and O-ring ⓐ. Tighten the wing nut to secure.
a. The KF50 vacuum hose will attach to the KF50 end of this adapter flange using a KF50
clamp and O-ring ⓑ.
3. Next, connect the KF40 to KF25 adapter flange ③to the front port on the valve using another
KF40 clamp and O-ring ⓐ. Tighten the wing nut to secure.
4. Attach the KF25 cross ④to the KF25 adapter using a KF25 clamp and O-ring ⓒ.
5. Connect the opposite side of the cross to the rear VACUUM LINE port ⑤on the back panel of
the cryostat. Tighten the wing nuts to secure.
6. Connect the KF25-VCO adapter ⓓto the left-facing inlet of the KF25 cross ④using a KF25
clamp and O-ring ⓒ. Then, connect one end of the chamber vent line ⑥to the VCO adapter ⓓ.

Turbopump Vacuum Package
15
Steps 7 and 8 should only be completed for the side panel pumping configuration. If not using this
configuration, ensure a KF25 cap is installed on the right-facing inlet of the KF25 cross ④.
7. Connect the 20-inch KF25 hose ⑦to the right-facing inlet of the KF25 cross ④using a KF25
clamp and O-ring ⓒ.
8. Route the hose around the side of the cryostat body and connect to the KF25 port ⑧on the
lower sample chamber housing using a KF25 clamp and O-ring ⓒ. Tighten all wing nuts to
secure.

Option User Manual
16
Next, the valve should be suspended off the optical table by installing the bracket support components.
9. Locate the valve support brackets and hardware. Slide the U-shaped bracket ⑨directly
underneath the vacuum valve such that the valve rests on the Sorbothane pad.
10. Attach a right-angle bracket ⑩to either side of the middle bracket using M6 socket head
screws ⓔ. The middle bracket ⑨should be suspended slightly off the optical table.
11. Secure the two right-angle brackets ⑩to the optical table with appropriate hardware.

Turbopump Vacuum Package
17
3.3 Connecting System Cables and Power
NOTICE
Only use cables and hoses provided or approved by the manufacturer
Only use the cables and hoses in the manner described below.
The standard communication cables and hoses between system components do not change. Refer to
the System User Manual for instructions on connecting the standard system cables and other
components.
Turbo Control Cables:
1. Locate the turbopump communication USB cable. Connect one end to either of the USB ports
on the rear face of the system control unit. Connect the other end to the USB port on the rear
face of the vacuum control unit.
2. Locate the pressure gauge ethernet cable. This will typically be pre-connected to the UHV gauge
that is inside the main body of the cryostat tower and coiled and cable-tied to the back of the
cryostat. Carefully cut the cable tie to uncoil the cable, taking care not to cut the cable or other
hoses. Ensure one end is connected to the UHV gauge inside the cryostat body. Connect the
other end to the PRESSURE GAUGE location on the rear face of the vacuum control unit.

Option User Manual
18
3. Locate the DSUB9 to 4-pin circular connector valve signal cable. Connect the DSUB9 end to the
vacuum valve located behind the cryostat body. Connect the circular end to the EXT. VACUUM
VALVE CONTROL location on the rear face of the vacuum control unit.
Vacuum Line:
4. Locate the KF50 vacuum hose. Connect one end to the VACUUM LINE flange location on the
back of the vacuum control unit. Connect the other end to the KF50 flange on the back of the
vacuum valve assembly near the back panel of the cryostat. Tighten the wing nuts to secure.
Chamber Vent Line:
1. Locate the 10 ft flexible vacuum hose with VCO connections. Connect one end to the CHAMBER
VENT location on the back of the vacuum control unit. Connect the other end to the KF25 cross
inlet on the vacuum valve assembly near the back panel of the cryostat.
Valve Power:
After all other cables are connected, the vacuum valve can be connected to power.
1. Connect the vacuum valve power cord to the appropriate 100 –120 VAC (MVV-32 valve) or 200
–240 VAC (MVV-33 valve) wall outlet power source.
NOTICE
Valve power requirements vary by model
•The power requirements for the valve depend on the valve model. Refer to the Technical
Specifications on page 12 to determine which model you have based on your geographic location
and available receptacle.
•If ordered with the optional cart with electronics rack, the valve power will plug directly into the
cart power module.

Turbopump Vacuum Package
19
Section 4 - Option Usage & Operation
4.1 Primary Operations
The primary operations below cover turbopump-specific settings for the instrument. Refer to the
System User Manual for detailed user interface control functions and operating procedures.
4.1.1 Cooling Down with the Turbopump
Before initiating a cooldown, customize the options for how the turbopump will be used during the
cooldown cycle:
1. In the UI for the CRYOSTATION instrument, navigate to the SAMPLE CHAMBER display screen and
select the PLATFORM temperature channel to bring up its operation controls.
2. Press the COOLDOWN command button. On the popup, press CUSTOMIZE COOLDOWN > to adjust
the cooldown parameters.
3. To help clean out the system before cooling down, enable the Platform Bakeout and/or Dry
Nitrogen Purge procedures. It is recommended to run one or more purge cycles, especially if the
sample chamber has been exposed to atmosphere or if the system will be kept cold for an
extended period of time.
4. On this same popup, scroll down to the Turbopump Options controls. Press the value input
boxes to set the parameters.
a. Pre-Cooling Target Pressure: Pressure threshold to reach before cooling begins. The
turbopump will be used to pump out the vacuum space to this pressure before any
cryopumping occurs.

Option User Manual
20
b. Pre-Cooling Time Limit: Sets a maximum time limit for the pre-cooling target pressure
procedure. After the time has elapsed, the cooldown cycle will begin even if the pressure
threshold has not been reached.
c. Run Continuously During Cooldown: When toggled to NO, the turbopump will be
turned off and valved off after cryopumping takes over. When toggled to YES, the
turbopump will remain on for the duration of the cooldown until the system is warmed
back up.
5. Once all parameters are set as desired, press <BACK in the top left corner of the popup. Press
COOLDOWN to start the cooldown procedure.
4.1.2 Pulling Vacuum with the Turbopump
When the system is not in use, it is recommended to keep the sample chamber under vacuum to
prevent moisture and contaminates from entering the sample space. In a PULL VACUUM procedure, the
turbopump will be used to reach the target pressure.
1. In the UI, navigate to the SAMPLE CHAMBER display screen and select the PLATFORM temperature
channel to bring up its operation controls.
2. Press the PULL VACUUM command button. On the popup, press CUSTOMIZE PULL VACUUM > to
adjust the vacuum parameters.
a. Target Vacuum Pressure: Pressure threshold to reach before the turbopump turns off
and the sample chamber is valved off. To keep the pump running indefinitely, enter a
pressure value that the system cannot reach, such as 0 Torr.
3. Once all parameters are set as desired, press <BACK in the top left corner of the popup. Press
PULL VACUUM to start the vacuum procedure.
» NOTE
•At any time during the PULL VACUUM procedure, press the STOP command button to turn off the
vacuum pump and valve off the sample chamber.
•To access the sample chamber again, use the VENT command to vent the chamber to
atmospheric conditions.
