montpellier SFO60LED User manual

Installation and Operating Instructions
MODEL: SFO60LED
Built-In Oven
Please read these instructions carefully before attempting to install or use this appliance.
It is advisable to keep these instructions in a safe place for future reference.

2
In
t
roduc
t
ion
Thank you for choosing this montpellier branded appliance. It
has been designed to give years of trouble-free use provided
it is installed and maintained correctly.
Please read these instructions carefully before installing or
using your appliance. It is advisable to keep your purchase
and
installation receipts with these instructions in a safe place for
future reference. Included is some important safety information
in addition to guidelines and recommendations that will enab
le
you to take full advantage of all the functions available.
T
his
quali
t
y
applian
c
e
has
been
t
e
st
ed
and
c
e
r
t
i
f
ied
t
o
m
e
e
t
all
applicable UK electrical and safety standards.
This appliance must be installed and connected in
accordance with current regulations.
After unpacking the appliance ensure that there is no visib
le
damage. If the appliance has been damaged during transit,
do not use it, contact your retailer immediately.

3
Your 2 year Manufacturer's guarantee
THIS DOES NOT AFFECT YOUR STATUTORY RIGHTS.
Your new montpellier appliance carries a free guarantee which protects you against the cost of
repairs during the first 24 months from date of purchase provided that:
Any claim is accompanied by evidence of the model reference, model serial number and proof of
purchase, such as a Sales Receipt, showing that the appliance was purchased within the 24
months prior to the date of claim.
What is not covered under the Guarantee:
·Any appliance not correctly installed and operated in accordance with the manufacturer's
instructions.
·Any appliance that is used for anything other than domestic purposes.
·Any defect caused by accident, misuse, unauthorized modification or inexpert repair.
·Cost of Call-out where a fault cannot be found with the appliance.
·Cost of Call-out for work covering routine maintenance, such as, but not exclusively,
cleaning of filters or defrosting.
·Cost of Call-out for work required to correct the alignment of doors following door reversal
procedures carried out by you.
·Use of the appliance by anyone other than the Householder.
·Use in any commercial environment.
·Consumable items, such as, but not exclusively, fuses in plugs, bulbs and breakable items
which require routine replacement.
·Repair costs incurred that have not been authorised by Repairtech and/or carried out by a
non-approved Repairtech engineer.
YOUR GUARANTEE IS VALID ONLY IN THE UK.
To Register your Appliance simply complete the card in your appliance pack and return it with a
stamp affixed or Alternatively you can Register online at www.repairtechuk.com
SERVICE HELP-LINE
Should your appliance develop a fault, please call the
Repairtech Service Helpline on:
01527-888133
Please remember to have all your product details available, including the model number, serial
number, date of purchase and your retailers’details before registering a fault.
Your service call cannot progress without this information.

4
Description of the Appliance
1. Control Panel
2. Handle
3. Oven Door
4. Child Lock
5. Tray
6. Lower Heating Element
7. Upper Heating Element
8. Wire Grill
9. Racks
10. Oven Light
11. Turbo Heating Element
12. Fan
13. Air Outlet Shutters

5
CONTENTS:
Section 1. Safety Advice
Section 2. Installation
Section 3. Operating the Appliance
Section 4. Maintenance

6
Section 1. Safety Advice
-Please read this booklet thoroughly before installing and switching on the
appliance. The manufacturer accepts no responsibility for incorrect
installation and usage.
-This appliance is guaranteed for domestic use only.
-The appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning the use of the appliance by a person responsible for their
safety. Children should be supervised to ensure that they do not play with
the appliance.
-This appliance must only be used for cooking/heating foods and liquids.
Do not use it for any other purpose.
-If using an adaptor, this must be used in accordance with the
manufacturers instructions and ensure that the electrical circuit is not
overloaded as this could cause overheating.
-Do not twist or bend the cables, and keep them away from hot surfaces.
-Following installation make sure that the power cable is not trapped
underneath the appliance.
-Keep the appliance surfaces clean. Failure to do this could lead to the
appliance malfunctioning.
-The surface of this appliance will get hot during use. The surface of this
appliance will remain hot after it has been turned off.
-If the power supply cord is damaged, it must be replaced by a qualified
person in order to avoid a hazard.

7
Section 2 . Installation
-Remove all packaging and protective film from the appliance.
-Position the appliance in a dry atmosphere.
- The following dimensions are provided as a guide for installation –your installer will
carry out the installation in accordance with the current regulations.
- Your installer will connect the power cable in accordance with the current regulations.
To install this appliance, please proceed as follows:
2.1 Choosing a location for your oven
When choosing a location for your oven, ensure that there are no flammable or
combustible materials in the close vicinity, such as curtains. You may be required to
make changes to the area surrounding your built-in oven. These recommendations
can be seen in the image below.
Do not site your oven next to a cooling appliance.

8
2.2 Installing your Built-in Oven
Insert the oven into the cabinet by pushing it forward. Open the oven door and insert
2 screws into the holes located on the oven frame. When the product frame touches
the wooden surface of the cabinet, tighten the screws.

9
Installing your Built-in Oven Continued.
Contact with electrical or insulated parts must be prevented. Insulating parts must be
fitted in a way that ensures they cannot be removed using any kind of tool. We do not
recommend installing this appliance near a refrigerator or freezer as the performance
of those appliances will be affected due to residual heat. After removing your
appliance from its packaging ensure that there is no damage. If you suspect any
damage to the appliance, do not use it and contact your retailer immediately.

10
2.3 Electrical Connection
This appliance can be fitted with a 13 amp plug and plugged into a standard 13 amp
socket.
However, we recommend that it is ‘hard wired’to a suitable fused point adjacent to
the appliance housing and protected with a 20 amp fuse. Please note that a
switchable spur should be accessible above the work surface to allow the power to
be turned off by the user.
Your installer will connect this appliance in accordance with current regulations.
The wires in the mains lead are coloured in accordance with the following code:
Brown = L (Live), Blue = N (Neutral), Green/Yellow = Earth
If not supplied with a fitted cable, you should connect the power supply to the
appliance as follows:

11
Section 3. Operating the Appliance
3.1. Control Panel
3.2 Oven Function Control Knob
Defrost Function –The oven warning lights will be
turned on and the fan will start operating.
To use the defrost function, we recommend you place
your food on the third shelf from bottom. This function will
not cook or bake your food, it will only help defrost it.
Turbo Function –The oven thermostat and warning lights will be turned on and the
ring heating element and fan will start operating. The turbo function evenly disperses
heat in the oven. All foods on all racks will be cooked evenly. We recommend pre-
heating the oven for 10 minutes or until it is up to the required temperature.
Grilling Function –The oven thermostat and warning lights will be turned on and
the grill heating element will start operating. The function is used for grilling and
toasting foods, use the upper shelves of the oven. We recommend lightly brushing the
wire grid with oil to stop foods sticking and placing the food in the centre of the grid.
Warning: When grilling, the oven door must be closed and the oven temperature
should be adjusted to 190C.
Faster Grilling Function –The oven thermostat and warning lights will be turned
on and the grill and upper heating elements will start operating. This function is used
for faster grilling and for grilling a larger surface area. We recommend lightly brushing
the wire grid with oil to stop foods sticking and placing the food in the centre of the grid.
Warning: When grilling, the oven door must be closed and the oven temperature
should be adjusted to 190C.
Static Cooking Function –The ovens thermostat and warning lights will be turned
on and the upper and lower heating elements will start operating. This function ensures
even cooking of the lower and upper food. We recommend pre-heating the oven for 10
minutes or until it is up to the required temperature.
Fan Function –The ovens thermostat and warning lights will be turned on and the
upper and lower heating elements will start operating. This functions circulates the air
in the oven giving a slight grill effect to the food. We recommend pre-heating the oven
for 10 minutes or until it is up to the required temperature.

12
3.3. Thermostat and Timer
Oven Thermostat
-
Once you have selected an oven
cooking function you are able to adjust the oven
thermostat knob to the desired temperature. Upon
reaching the selected temperature the indicator light will
switch off.
The thermostat signal light will be on or off in order to
maintain the temperature.
Digital
Timer
Time Adjustment
–
The time must be
adjusted before using the oven. Switch on the oven, the
symbol “A”and three “0”s will begin to flash on the screen.
Press the (+) and (-) keys simultaneously. The
symbol will appear on the screen and the dot in the middle
of the screen will begin to flash. Using the (+) and (-)
buttons, adjust the days’time while the dot is flashing.
After the adjustment, the dot should show continuously.
When the symbol “A”and three “0”’s on the screen begin to flash, the oven cannot
be operated using the control buttons. When the (+) and (-) buttons are pressed
simultaneously for time adjustment the symbol will appear on the screen. When
this symbol appears you can manually operate the oven. In the event of a power
failure, the time will be reset and you will have to perform the time adjustment again.
Audible Warning Time Adjustment
–
Press the MODE key in
the middle. The symbol will flash on the screen and three “0”’s
will appear. Adjust the desired time period for the warning by
using (+) and (-) keys while the symbol is flashing. Sometime
after the completion of the adjustment, the symbol will become
lit continuously, at this point the warning time adjustment is done.
The audible warning time can be set to a time between 0 and
23:59.
When the set time is up, the timer gives an audible warning and the symbol
begins to flash on screen. Pressing any key will stop the noise and the symbol will
disappear.
This timer is for warning purposes only. The oven will not become activated
with this function

13
S
emi
-
Automatic Time Adjustment
–
This function is
used to cook within a desired time frame. Once the
function and thermostat are set and the food is in the oven,
press the MODE button until you see “stop”on the timer
screen, the symbol “A”will begin to flash. Adjust the
cooking period by using (+) and (-). Once the adjustment is
complete, the time of day will reappear on the screen and
the symbols (A) and will show continuously.
At this point the oven will start to operate.
A cooking period of between 0 and 10 hours can be set.
At the completion of the set duration, the timer will stop and give an audible
warning and the symbol (A) will begin to flash. After bringing the oven function and
oven thermostat to 0 position, pressing any button on the timer will stop the noise.
S
emi
-
Automatic Programming According to Finish
Time - This function is used to cook according to desired
finishing time. Once the function and thermostat are set
and the food is in the oven, press the MODE button until
you see “end”on the timer screen, the symbol (A) and
time of day will begin to flash.
Adjust the finishing time for the food you wish to cook by using the (+) and (-)
keys while the timer is in this position. After this the time of day will reappear
on the screen and the symbols (A) and will show continuously. At this
point the oven will start to operate.
You can set a time of up to 10 hours later.
After completion of the set duration, the timer will stop the oven and an
audible warning and the symbol (A) will begin to flash. After bringing the oven
function and oven thermostat to 0 position, pressing any button on the timer
will stop the audible signal.

14
Full Automatic Programming
–
This function is used to cook
after a certain period of time, within a certain duration. Once the
function and thermostat are set and the food is in the oven,
press the MODE button until you see “stop”on the timer screen,
the symbol (A) will begin to flash. Adjust the time for which you
wish the food to cook by using the (+) and (-) buttons. After this
the time of day will reappear on the screen and the symbols (A)
and will show continuously. At this point the oven will start
to operate.
A cooking period of between 0 and 10 hours can be set.
Once the above is complete, keep pressing the MODE button
until you see “end”on the timer screen, the symbol (A) and the
days’time will begin to flash with the addition of the cooking
period. Adjust the finishing time for food by using the (+) and (-)
keys while the timer is in this position. Sometime after the
adjustment operation is completed, the days’time will appear on
the screen and the symbol (A) will begin to continuously light
up.
An end time of up to 23:59 hours in the future can be set.
The oven will start operating at the time calculated by deducting
the cooking period from the set finishing time and will stop at the
set time. The timer will give an audible warning and the symbol
(A) will begin to flash. After bringing the oven function and oven
thermostat to 0 position, pressing any button of the timer will
stop the audible signal.

15
Section 4. Maintenance
Before any maintenance or cleaning work is carried out, DISCONNECT the
appliance from the ELECTRICITY supply and ensure that the appliance is
completely cool.
4.1. Cleaning the interior of the oven
Clean spillages from inside the oven as soon as possible after use.
Ensure the oven is turned off before cleaning. You will obtain the best cleaning
results if you clean the oven interior while it is slightly warm. To clean, wipe your oven
with a soft piece of cloth dampened with soapy water. After this wipe the oven with
another soft piece of cloth, dampened with water, once complete, dry the oven
interior.
Do not use other abrasive cleaners and/or wire wool etc as this may damage the
interior of your oven.
4.2. Replacing the Oven Light Bulb
This change must be performed by an authorised technician. The rating of the bulb
should be 230V, 25 watt. Type E14, T300. Before changing the bulb the oven should
be turned off and allowed to cool.
4.3. What to do if something goes wrong
There is no power to the appliance:
-Check there is not a power cut
-Check there is power to the electric socket/appliance
-Check the fuse in the plug (must be 13 amp)
The oven does not heat:
-Check that the temperature of the oven thermostat has been correctly used.
-Check that the timer has not been activated.
The oven is not cooking food evenly:
-Adjust the shelf locations, cooking time and heat values accordingly.

16
If aft
er the previous checks there is still a fault, please
contact the Repairtech Service Helpline below. Please
ensure that you have the model number, serial number,
date of purchase and retailers information available
before you make the call.
Should your appliance develop a fault, please call the
Repairtech Service Helpline on:
01527-888133

17
Important Note:
This appliance is marked according to the European directive
2002/96/EC on Waste Electrical and Electronic Equipment (WEEE).
By ensuring this product is disposed of correctly, you will help
prevent potential negative consequences for the environment and
human health, which could otherwise be caused by inappropriate
waste handling of this product.
The
symbol on the product, or on the documents accompanying the
product, the Crossed Out Wheelie Bin, indicates that this appliance
may not be treated as household waste. Instead it shall be handed
over to the applicable collection point for the recycling of electrical
and electronic equipment.
Disposal
must be carried out in accordance with local
environmental regulations for waste disposal. For more detailed
information about treatment, recovery and recycling of this product,
please contact your local authority, your household waste disposal
service or the retailer where you purchased the product.
We continuously try to improve our products for the benefit of our customers.
For this reason we reserve the right to make changes to any product at any
time, without notice
Issue: 01/26-02-2015
