montpellier DO3550UB User manual

Built In/Under Double Ovens
DO3550UB - 72cm - Black Glass
DO3570IB - 88cm - Black Glass
Please read these instructions carefully before attempting to install or use this appliance.
We recommend that you keep these instructions in a safe place for future reference.
Installation and Operating Instructions
THE PERFECT BALANCE OF FUNCTION AND STYLE
LAUNDRY - DISHWASHING - COOKING - COOLING

Thank you for choosing this Montpellier Built in or Built Under Double Oven.
Our Ovens have been designed to provide you with the best combination of style, reliability and performance to
give you years of trouble-free use.
You may be familiar with a similar product, but please take time to read these instructions carefully before installing
or using your Built in/under Double Oven to ensure you get the most from your purchase.
We recommend that you keep this manual in a safe place for future reference.
Your Double Oven is covered by a comprehensive two year Parts & Labour
Guarantee. In the unlikely event that you experience a problem with your
Oven, you can rest assured that you are fully protected against the cost of
repairs for the first 24 months . Please note that any claim must be
accompanied by the model reference number, serial number and proof of
purchase.
To activate your guarantee, you will need your product serial number. This can
be found on the rear of the machine.
There are two ways to register your Guarantee:
•Online: Visit the Support page on our website and complete the online Product
Registration form. www.montpellier-appliances.com
•By Post: Simply detach and ll in the form provided, attach a stamp and send
it in the post. Don’t forget to include your e-mail address so that we can send
conrmation through to you.
Welcome
Note: We are unable to take registrations over the phone.
ACROSS ALL OUR MODELS
YEAR
GUARANTEE
PA R T S & L A B O U R
www.montpellier-appliances.com

CONTENTS & INTRODUCTION
CONTENTS
• SAFETY
•USING THE PRODUCT
•ClEANING
•INSTAllATION INSTRUCTIONS
INTRODUCTION
Thank you for buying this
appliance from us.
This guide book is designed to help you
through each step of owning your new
oven, from installation to use. please
read it carefully before you start using
your product, as we have endeavored
to answer as many questions as
possible, and provide you with as much
support as we can.
Alternatively, general information,
spares and service information are
available from our website. The address
is located on the back page of this book.
WARRANTY
Your new appliance comes with our 12-
month guarantee, protecting you against
electrical and mechanical breakdown.
For full terms & conditions of the manu-
facturer’s guarantee.
In addition, you may wish to purchase an
extendedwarranty.Aleafletexplaining
how to do this is included with your
appliance.
our policy is one of constant
development and improvement, therefore
we cannot guarantee the strict accuracy
of all of our illustrations and
specifications-changesmayhavebeen
made subsequent to publishing.
2

Safety
BEFORE USING THE PRODUCT
Make sure that you have removed all
packaging and wrapping. Some of the
items inside this appliance may have
additional wrapping.
GENERAL
WARNING! - The
appliance and its
accessible parts become
hot during use. c are
should be taken to
avoid touching heating
elements. c hildren less
than 8 years of age shall
be kept away unless
continously supervised.
This appliance can
be used by children
aged from 8 years and
above and persons with
reduced physical sensory
or mental capabilities or
lack of experience and
knowledge if they have
been given supervision
or instruction concerning
the use of the appliance
in a safe way and
understand the hazards
involved. c hildren
shall not play with the
appliance. c leaning and
user maintenance shall
not be made by children
without supervision.
WARNING! -
Unattended cooking on
a hob with fat or oil can
be dangerous and may
resultinfi e.
NEVEr try to extinguish
afi ewithwater,but
switch off the appliance
andthencovertheflam
with a lid or damp cloth.
WARNING! - danger of
fi e:Donotstoreitems
on the cooking surfaces.
WARNING! - Servicing
should be carried out
only by authorised
personnel.
• The appliance must
never be disconnected
from the mains
supply during use,
as this will seriously
affect the safety
3

Safety
and performance,
particularly in
relation to surface
temperatures
becoming hot and gas
operated parts not
workingefficientl .
The cooling fan (if
fi ted)isdesigned
to run on after the
control knob has been
switched off.
• do not spray aerosols
in the vicinity of this
appliance while it is in
operation.
• do not store or use
flammabl liquidsor
items in the vicinity of
this appliance.
• do not modify this
appliance.
CAUTION:Theuseof
a gas cooking appliance
results in the production
of heat, moisture and
products of combustion
in the room in which it is
installed. Ensure that the
kitchen is well ventilated
especially when the
applianceisinuse:
prolonged intensive use
of the appliance may call
for additional ventilation,
for example opening
of a window, or more
effective ventilation, for
example increasing the
level of mechanical
ventilation where
present.
Excess spillage must be
removed before cleaning.
During pyrolytic cleaning,
accessible parts may
become hotter than
normal. Young children
should be kept away.
WARNING! -
do not operate the
appliance without the
glass door correctly
closed.
4

Safety
WARNING! -
The top element gets
extremely hot when in
WARNING! -
do not modify the outer
panels of this appliance
in any way.
WARNING! -
This appliance must be
earthed.
WARNING! -
Always allow the product
to cool down before you
change a bulb.There is a
risk of electric shock, so
always make sure you
have turned off and
unplugged your
appliance before starting.
WARNING! - do not
use harsh abraisive
cleaners or sharp metal
scrapers to clean the
ovendoor glass since
they can scratch the
surface, which may well
result in shattering of the
glass.
CAUTION: This
appliance is for cooking
purposes only. It must
not be used for other
purposes, for example
room heating.
WARNING! -
Never put items directly
on the base of the oven
or cover the oven base
with foil, as this can
cause the base element
to overheat.
use, so take extra care
to avoid touching it.
WARNING! -
If the supply cord is
damaged, it must be
replaced by the
manufacturer, its service
agent or similarly
qualified persons in order
to avoid a hazard.
5

Safety
stable and can lead to spillage or
injury.
• Always use the Minute Minder (if
fi ted)ifyouareleavingtheoven
unattended - this reduces the risk of
food burning.
Do Not
• Never place items on the door while
it is open.
• Never wrap foil around the oven
shelvesorallowfoiltoblocktheair flue.
• Never drape tea towels near the oven
whileitison;thiswillcauseafi e
hazard.
• Never pull heavy items, such as
turkeys or large joints of meat, out
from the oven on the shelf, as they
may overbalance and fall.
OVEN / GRILL
Do
•Always take care when removing food
from the oven as the area around the
cavity may be hot.
• Always use oven gloves when
handling any utensils that have been
in the oven as they will be hot.
• Always make sure that the oven
shelves are resting in the correct
position between two runners. do
not place the oven shelves on top
of the highest runner, as this is not
WARNING! -
The steam cleaner is not
to be used.
WARNING! -
The appliance must not
be installed behind a
decorative door in order
to avoid overheating.
6

USING THE GRILL - ELECTRIC
Caution: Accessible parts may be
hot when the grill is used - young
children should be kept away.
If cleaning the grill pan when it is hot, use
oven gloves to move it.
Food for grilling should be positioned
centrally on the trivet.
Using the TOP Oven grill
Important: The grill door must be fully
open when the grill is used.
open the gri ll door. Turn the control knob
to the required setting. For best cooking
results, we recommend that you preheat
the single grill for 5 minutes.
push the grill pan towards the back of the
shelf, to position it under the grill.
Turn the temperature knob to the MAX
position or by selecting a higher or lower
shelf position. For toast-ing, and for
grilling foods such as bacon, sausages or
steaks, use a higher shelf position. For
thicker foods such as chops or chicken
joint pieces, use a middle to low shelf
position.
To switch off, turn the control knob to the
off position.
Using aluminium foil
Using aluminium foil to cover the grill pan,
or putting items wrapped in foil under the
grillcreatesarehazard.
The cooling fan
When the grill is switched on, the cool-
ing fan comes on to keep the fascia and
control knobs cool during grilling.
during use the fan may cycle on and off,
this is normal.
Grill
7

USING THE TOP OVEN - ELECTRIC (if tted)
When you are cooking keep children
away from the vicinity of the oven.
Caution: The top element gets
extremely hot when in use, so
take extra care to avoid touch-
ing it.
The top oven is a conventional oven.
Note:Thetopovenisnotcontrolled
bytheprogrammer(iffitted).
To turn on the top oven
Turn the temperature control knob until
the required temperature is selected.
The red thermostat indicator will come on
until the selected temperature is reached,
and then go off; it will turn on and off
periodically as the thermostat operates to
maintain the selected temperature.
To switch off, return the top oven control
knob to the off position.
Important: Never put items directly on
the base of the oven, or cover the oven
base with foil, as this may cause the ele-
ment to overheat. Always position items
on the shelf.
The cooling fan
When the top oven is switched on, you
will hear the cooling fan come on - this
keeps the fascia and control knobs of the
appliance cool during cooking.
Preheating
The oven must be preheated when cook-
ing frozen or chilled foods, and we rec-
ommend preheating for yeast mixtures,
batters,soufflés,andwhiskedsponges.
preheat the oven until the indicator light
switchesoffforthersttime,thiswill
take up to 15 minutes depending on the
temperature selected.
If you are not preheating the oven, the
cooking times in the following guide may
need to be extended, as they are based
on a preheated oven.
Shelf positions
There are 3 shelf positions which are
counted from the bottom of the oven up-
wards, so shelf position 1 is the lowest.
When cooking frozen or chilled food, use
the highest possible shelf position, while
allowing some clearance between the
food and the top element.
The oven shelf must be positioned with
the up-stand at the rear of the oven and
facing up. position baking trays and roast-
ing tins on the middle of the shelves, and
leave one clear shelf position between
shelves, to allow for circulation of heat.
When using the top oven
Whenopeningtheovendoor,care should
be taken to avoid any possible contact
with potentially hot air, since this may
cause discomfort to people with sensitive
skin. We recommend that you hold the
underneath of the oven door handle.
8
