montwill M2 Series User manual

User manual M2
Alternating voltage / Alternating current signal rms-value (TRMS)
0-300 VAC, 0-600 VAC, 0-1 AAC, 0-5 AAC
96x48M2_14HGB.pdf update: 28.05.2020
Technical features:
• red display of -19999…99999 digits (optional: green, orange, blue)
• installation depth: 70 mm without plug-in terminal
• min/max-memory
• 30 adjustable supporting points
• display flashing at threshold value exceedance / undercut
• digital input for triggering of Hold, Tara
• permanent min/max value recording
• volume metering (totaliser)
• mathematical functions like reciprocal value, square roots, squaring or rounding
• setpoint generator
• sliding averaging
• brightness control
• programming interlock via access code
• protection class IP65 at the front
• pluggable screw terminal
• optional galvanic isolated digital input or analog output
• optional 2 relay outputs
• accessories: PC-based configuration kit PM-TOOL incl. CD and USB-adapter for devices
without keypad and for a simple adjustment of standard devices

Identification
STANDARD-TYPES ORDER NUMBER
AC current, AC voltage
Housing size: 96x48 mm M2-1VR5B.0004.570xD
Please state physical unit by order, e.g. A.
Options – breakdown of order code:
M 2- 1 V R 5 B. 0 H 0 4. 5 7 2 x D
Basic type M2 Dimension
D physical unit
Installation depth
89mm 2Version
incl. plug-in terminal x internal version
Housing size Switching points
B96xH48xT70 mm 1 0 no switching point
2 2 relay outputs
Type of display
V, A VProtection class
1 without keypad,
Display colour operation via PM-TOOL
Blue B 7 IP65 / plug-in terminal
Green G
Red RVoltage supply
Yellow Y 4 115 VAC
5 230 VAC
Number of digits
5-digit 5 Measuring input
4 AC current / AC voltage, TRMS
Digit height
14 mm BAnalog output
0 without
Digital input X 0-10 VDC, 0/4-20 mA
without 0
one IAC input
H 600 VAC, 300 VAC,
5 AAC, 1 AAC

Contents
1. Brief description 2
2. Assembly 3
3. Electrical connection 4
4. Description of function and operation 5
4.1. Programming software PM-TOOL 6
5. Setting up the device 7
5.1. Switching on 7
5.2. Standard parameterisation (flat operation level) 7
Value assignment for the triggering of the signal input
5.3. Programming interlock 10
Activation/Deactivation of the programming interlock or change into
professional
or flat operation level
5.4. Extended parametersation (professional operation level) 11
5.4.1. Signal input parameters 11
Value assignment for the triggering of the signal input incl. linearisation
5.4.2. General device parameters 14
Superior device functions like Hold, Tara, min/max permanent, setpoint value function /
nominal value function, averaging, brightness control, suppression of negative Offsets,
as well as the control of the digital input and keyboard layout
5.4.3. Safety parameters 19
Assignment of user and master code to lock or to receive access to defined parameter
such as analog output and alarms, etc.
5.4.4. Analog parameters 20
Analog output functions
5.4.5. Relay functions 22
Parameter for setpoint definition
5.4.6. Alarm parameters 24
Actuator and dependencies of the alarms
5.4.7. Totaliser (Volume metering) 26
Parameter for calculation of the sum function
6. Reset to factory settings 27
Reset parameters onto the delivery state
7. Alarms / Relays 28
Functional principle of the switching outputs
8. Sensor aligment 29
Diagram of functional sequences for sensors with existing adjustable resistor
9. Technical data 30
10. Safety advices 32
11. Error elimination 33

1. Brief description
1
1. Brief description
The panel meter instrument M2-14H is a 5-digit device for AC current / AC voltage signals
(TRMS) and a visual threshold value monitoring via the display. The configuration happens via
four keys at the front or by the optional PC software PM-TOOL. The integrated programming
interlock prevents unrequested changes of parameters and can be unlocked again with an
individual code. Optional the following functions are available: a digital input for triggering of
Hold (Tara), aswell as one analog output for further evaluating in the unit.
With help of the galvanic isolated setpoints (optional), free adjustable limit values can be
controlled and reported to a superior master display.
The electrical connection is done via plug-in terminals on the back side.
Selectable functions like e.g. the recall of the min/max-value, an averaging of the measuring
signals, a nominal presetting or setpoint presetting, a direct threshold value regulation during
operation mode and further measuring setpoints for linearisation, complete the modern device
concept.

2. Assembly
2
2. Assembly
Please read the Safety advices on page 32 before installation and keep this user manual for
future reference.
1. After removing the fixing elements, insert the device.
2. Check the seal to make sure it fits securely.
3. Click the fixing elements back into place and tighten the clamping screws by hand. Then use a
screwdriver to tighten them another half a turn.
CAUTION! The torque should not exceed 0.1 Nm!
The dimension symbols can be exchanged before installation via a channel on the side!
Sealing
48,0
3,0
M2
Gap for physical unit
