Moog Videolarm EOC1N Instruction sheet

SPECIFICATION NUMBER: 81-IN5392
MODEL: EOC1N
High-Speed Ethernet over Coax
STANDARD INSTALLATION PROCEDURE
EOC1N units are used to convert conventional Ethernet to
a signal that can be carried by 75ohm coaxial video cables
such as RG59.
EOC1N makes it possible to upgrade installed analogue
cameras to high-quality digital IP cameras without the
expense of replacing existing cabling.
In the example shown a pair of EOC1N units is used to allow
an IP (network) camera to communicate with other network
devices over an existing coaxial video cable.
GENERAL INSTRUCTIONS
1. Mounting
!
The EOC1N unit should only be installed indoors or
in an appropriately rated enclosure.
If the unit is to be located on a horizontal surface then the
enclosed rubber feet should be afxed to the underside of
the enclosure. The unit should be securely mounted and
should not be supported by the attached cables.
Mounting bracket part no VHW -WMB can be used for
bolting the unit to a wall or structure. Rack panel part no
VHW-1U allows installation of up to eight EOC1N units in 1U
of a 19 inch rack. The unit’s chassis should be earthed using
either a mounting bracket or a ground strap, secured by the
BNC connector nut, before any other cables are connected
Inline ground isolator part no VHW-XF should be tted where
there is a signicant ground potential difference between
each end of the cable.
2. Power Connection
EOC1N should only be used with a Class II Isolated power
supply. The unit can be powered from either a 12V DC
or 24V AC power supply (PSU), and adjusts to its type
and voltage automatically. If the PSU is shared with other
equipment such as a camera, ensure that the total load
current will not exceed the PSU’s rated output. If in any
doubt, measure the voltage at the PSU’s connector before
and after connecting the EOC1N or other equipment, to
ensure it is within range. If an existing power supply is not
available, up to two EOC1N units can be powered by PSU
part no VWH-12VPSU-xx (xx = UK or USA). Part no VHW-
RMPSU-xx is designed for rackmount installations and can
power up to eight units. The PSU cables should be bared,
tinned and securely connected to the EOC1N power plug
before switching on the PSU. Only one wire should be
connected to each of the power plug’s screw terminals,
with polarity as indicated on the unit’s top panel. The green
LED will blink every 1~2 seconds to indicate the presence of
power.
3. Coaxial Cable Connection
Connect the unit’s BNC socket to the coaxial cable. If
another EOC1N unit is connected at the far end and
powered up, then the green LED will light steadily to indicate
a good connection. In some installations, cable condition
will force the units to reduce their connection speed, and
this is indicated by the green LED ashing (approximately
half-on, half-off). Only two units should be connected, one
at each end of the cable. EOC1N is not compatible with
other equipment such as analog video ampliers.
4. Ethernet Cable Connection
Connect the unit's RJ45 Ethernet jack to the camera or
other network equipment using a standard Ethernet cable.
Both patch and crossover type Cat5 or Cat6 cables are
supported. The amber LED will light to indicate a network
connection, and will blink off during network activity.
Manufacturer’s Declaration of Conformity
The manufacturer declares that the equipment enclosed with
this certicate conforms with the essential protection
requirements of the EMC Directive 89/336/EEC and has
been designed and manufactured to the following
specications:
BS EN 55022:1998 Emissions (Radiated)
BS EN 55024:1998 Immunity
BS EN 61000-4-2:1995 Immunity to ESD
BS EN 61000-4-3:20002 Immunity to Radiated RF Fields
(3V/m).
PRODUCT INSTRUCTIONS
REVISION DATE:
March 12, 2007
CO-AXIAL VIDEO CABLE
NVR
NETWORK CABLENETWORK CABLE
EOC1N EOC1N
Power
cable
Network
cable
Coaxial
video
cable

- 2 -
!
CAUTION
RISK OF
ELECTRIC SHOCK!
CAUTION: TO REDUCE THE RISK OF
ELECTRICAL SHOCK, DO NOT EXPOSE
COMPONENTS TO WATER OR MOISTURE.
SAFETY PRECAUTIONSIMPORTANT SAFEGUARDS
1. Read Instructions - All the safety and operating instructions should be read
before the unit is operated.
2. Retain Instructions -The safetyandoperating instructionsshould be retained
for future reference.
3. Heed Warnings - All warnings on the unit and in the operating instructions
should be adhered to.
4. Follow Instructions - All operating & user instructions should be followed.
5. Electrical Connections - Only a qualified electrician should make electrical
connections.
6. Attachments - Do not use attachments not recommended by the product
manufacturer as they may cause hazards.
7. Cable Runs - All cable runs must be within permissible distance.
8. Mounting - This unit must be properly and securely mounted to a supporting
structure capable of sustaining the weight of the unit. Accordingly:
a. Installation should be made by a qualified installer.
b. Installation should be in compliance with local codes.
c. Care should be exercised to select suitable hardware to install the unit,
taking into account both the composition of the mounting surface and
the weight of the unit. Be sure to periodically examine the unit and the
supporting structure to make sure that the integrity of the installation
is intact. Failure to comply with the foregoing could result in the unit
separating from the support structure and falling,with resultant damages
or injury to anyone or anything struck by the falling unit.
UNPACKING
Unpackcarefully. Electroniccomponents canbe damagedif improperly handled
or dropped. If an item appears to have been damaged in shipment,replace it
properly in its carton and notify the shipper. Be sure to save:
1. The shipping carton and packaging material. They are the safest material in
which to make future shipments of the equipment.
2. These Installation and Operating Instructions.
!
The lightning flash with an arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of non-insulated "dangerous voltage" within the
product's enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intendedtoalerttheusertopresenceofimportantoperating
and maintenance (servicing) instructions in the literature
accompanying the appliance.
24 HOUR TECHNICAL SUPPORT
1-800-554-1124
SERVICE
If the unit ever needs repair service,customer should contact Videolarm
(1-800-554-1124) for return authorization & shipping instructions.
TECHNICAL SUPPORT
Videolarm has set-up a 24 hour technical support line for their customers.
