Mooreco 91153-A User manual

Up-Rite Electric Height Adjust Desk
UPDATED AS OF: 03/08/18
Part Number: 91153-A, 91153-B, 91153-C, 91153-D, 91153-E, 91153-F.
1 of 10
INSTRUCCIONES DE ENSEMBLAJE
NO LA TIRE
INSTRUCTIONS DE MONTAGE
NE PAS JETER
ASSEMBLY INSTRUCTIONS
DO NOT THROW AWAY!

UPDATED AS OF: 03/08/18 2 of 10
INSTRUCCIONES DE ENSEMBLAJE
NO LA TIRE
INSTRUCTIONS DE MONTAGE
NE PAS JETER
ASSEMBLY INSTRUCTIONS
DO NOT THROW AWAY!
PARTS
P2
(L+R)
P1
(2x)
P3
(L+R)
HARDWARE
B- (8x) M6-1.0
x12mm
C- (16x) M6-1.0
x15mm
D- (2x) M6-1.0
x75mm
K- (2x) 3/16”
Wood Screws
L- (4x) 5/32”
Wood Screws
J- #4 allen wrench
H- #2.5 allen wrench
I- #3 allen wrench
P8 P9
P7
(2x)
P6
P5
(2x)
P4
P12
(2x)
P10
(4x)
P14P13
A- (8x) M6-1.0
x10mm
E- (8x) M6-1.0
x6mm

Phone:
1.800.749.2258
(Monday – Friday, 8AM – 5PM
Central Time)
For full product warranty details, please visit:
Para obtener información sobre la garantía del producto, consulte este sitio (ingles):
Pour plus d’informations sur la garantie du produit, consultez ce site (anglais):
For questions on assembly or missing/damaged parts, please contact us using the
following information.
Para preguntas sobre el ensamblaje o piezas faltantes o dañadas, por favor
contáctenos usando la siguiente información.
Pour toute question sur le montage l-assamblage manquantes ou endommagées,
veuillez nous contacter en utilisant les l’information ci-dessous.
To register your product for warranty, please visit:
Para registrar la garantía del producto, vea este sitio (en ingles):
Pour enregistrer la garantie de votre produit, consultez ce site (en anglais):
UPDATED AS OF: 03/08/18
Review full assembly instructions and
check that all parts are present before
beginning assembly. Heavy or large
furniture may require multiple persons in
order to properly assemble. If you have
questions regarding assembly, contact
the manufacturer before continuing.
Damage due to incorrect assembly may
not be covered by warranty. Do not use
product unless all screws are tight. Check
all screws for tightness at least every
six months. If parts are broken, missing,
damaged, or worn, stop use of the product
until repairs are made by your dealer using
factory authorized parts.
Previo a comenzar el proceso de
ensamblaje favor de revisar las
instruccionesyasegurarsequecuentacon
todas las partes y materiales necesarios.
Es posible que los muebles grandes o
pesados, requieran mas de una persona
para ensamblarlos correctamente. Por
favor contacte al fabricante directamente
si tiene alguna duda o pregunta antes de
continuar con el proceso de armado del
producto. La garantía no cubrirá daños
que ocurrieron por errores cometidos
durante el proceso de ensamblaje. Todos
los tornillos deben estar ajustados previo
el uso del producto. Debe revisar los
tornillos periódicamente, por lo menos
cada seis meses y asegurarse de que
estén bien ajustados. Por favor detenga
el uso del producto si partes del producto
se pierden, rompen, se deterioran por uso
o se rompen. Favor de contactar a su
distribuidor para que le envíen las partes
necesarias o realice las reparaciones
necesarias con partes autorizadas por el
fabricante.
Avant de commencer l’ assamblage
veuillez consulter les instructions
complètes et vérier si vous avez toutes
les pièces nécessaires. Ill est possible que
plusieurs personnes soient nécessaires
pour assemble des meubles grand ou
lourds. En cas de doute sur l assamblage
contactez le fabricant avant de continuer.
Les dommages encourus pendant
l’assamblage ne seront pas couvert par
la garantie. Ne pas utiliser le produit sans
vérier que tous les vis soient serrées.
Vériez que les vis sont serrées au moins
tous le 6 mois. Si aucune pièce se casse,
manque, est endommagée ou usée,
arrêtez d’ utiliser de produit jusqu’à ce
que le vendeur le repaire a l’aide de pièces
autorisées par la fabricant.
WARNINGS AND DISCLAIMERS
WARRANTY
CARE & MAINTENANCE
PRODUCT REGISTRATION
SPANISH TRANSLATION FRENCH TRANSLATION
http://moorecoinc.com/warranty
https://moorecoinc.com/register
Email:
[e-mail]
3 of 10

STEP 1
Use 4 “A” screws to install
foot to leg upright. Repeat
for both legs.
UPDATED AS OF: 03/08/18 4 of 10
STEP 2
Screw glides into foot.
Repeat for both legs.
P2
P10
P1
A- 4x J-

STEP 3
Use 4 “B” screws to attach leg assembly to the P3
crossbar. Repeat for both legs.
Note: Match L to L and R to R to ensure holes align.
UPDATED AS OF: 03/08/18 5 of 10
STEP 4
Slide P5 square tube into leg/crossbar assemblies.
Use black dots to center the square tubes.
P5
P3
B- 4x
J-
Use 4 more “B” screws on
each side to further secure
the leg to crossbar.

H-
STEP 3
UPDATED AS OF: 03/08/18 6 of 10
STEP 4
Slide one end of the hexagonal rod through the motor
(P8). Push both ends of the rod assembly into the hole
shown in each leg.
P8
P6
P7
P7
Loosen pre-installed set screws on both
hexagonal rods. Slide the pointed end of the
hexagonal rods into the round center rod.

STEP 5
Use 2 “D” screws to secure
the motor to the frame.
UPDATED AS OF: 03/08/18 7 of 10
STEP 6
D- 2x
J-
J-
C- 8x
Align holes in the frame with
inserts in the top. Use 8 “C”
screws to secure the frame
to the table top.
NOTE- Ensure the rods
remains fully inserted to
each leg.
If they do not, that leg will
not rise when adjusting desk
height.

STEP 7
UPDATED AS OF: 03/08/18 8 of 10
STEP 8
E- 8x
H-
H-
Center the round middle rod and
slide the metal ”stops” up against
either end. Tighten the two set
screws to lock it in place.
Tighten 8 pre-installed
set screws to lock frame
position.

STEP 11
UPDATED AS OF: 03/08/18 9 of 10
STEP 12
Use 2 “K” screws to mount
the power brick bracket to
the bottom of the table in
desired location.
Use 4 “L” wood screws
to install control panel in
desired position on the
bottom of the top.
P9
L- 4x
P14

STEP 13
UPDATED AS OF: 03/08/18 10 of 10
STEP 13
Carefully, using two people,
lift the fully assembled table
and ip it right side up.
Plug power cord into
power brick. Then
into a nearby outlet,
being sure not to
create a trip hazzard.
Use 2 “K” screw to
install each plastic cord
management clip in
desired location.
Slide power brick into
mount bracket
Plug white plug from
contol panel into motor
through hole in leg
bracket.
Plug remaining control
panel wire into power
brick wire.
P12
P13
P12
