Moosoo HIC-AF-8081D User manual

AIR FRYER OVEN
INSTRUCTION MANUAL
Model: HIC-AF-8081D
For any questions and malfunctions of the appliance during use, please contact
our customer service email: [email protected]

CONTENTS
IMPORTANT SAFEGUARDS
SPECIFICATION
PARTS & ACCESSORIES
USING THE ACCESSORIES
COOKING PRESETS
GENERAL OPERATING INSTRUCTIONS
COOKING CHART
CLEANING & STORAGE CLEANING
TROUBLESHOOTING
FREQUENTLY ASKED QUESTIONS
WARRANTY
01
02
02
04
07
09
10
11
12
13
14

01
IMPORTANT SAFEGUARDS
1. Before initial use and after subsequent use, hand wash the Rotating Mesh Basket and other cooking accessories.
Then, wipe the outside and inside of the Unit with a warm moist cloth and mild detergent. Finally preheat the air
fryer for a few minutes to burn off any residue.
2. Electric Power: If the electrical circuit is overloaded with other appliances, your new Unit may not operate
properly. lt should be operated on a dedicated electrical circuit.
3. Automatic Shut-Off: The appliance has a built in shut-off device, that will automatically shut down the unit when
the Timer LED reaches zero. You can manually switch off the appliance by selecting the Power Button (Press 2
seconds).
4. Electromagnetic Fields (EMF): This appliance complies with all standards regarding electromagnetic fields
(EMF). If handled properly and according to the instructions in this user manual, the appliance is safe to use
based on scientific evidence available today.
5. This appliance is NOT INTENDED FOR USE by persons with reduced physical, sensory, or mental capabilities or
a lack of experience and knowledge unless they are UNDER THE SUPERVISION of a responsible person or
have been given proper instruction in using the appliance. This appliance is NOT INTENDED FOR USE by
children.
6. DO NOT USE the unit for any purpose other than described in this manual.
7. DO NOT USE this unit of the plug, the power cord, other appliance itself is damaged in any way.
8. MAKE SURE the appliance is plugged into a wall socket. Always make sure that the plug is inserted into the wall
socket properly.
9. To prevent food contact with the interior upper screen and heat element, DO NOT OVERFILL the Rotating Mesh
Basket.
10. DO NOT COVER the Air Intake Vent or Air Outlet Vent while the air fryer is operating. Doing so will prevent even
cooking and may damage the Unit or cause it to overheat.
11. NEVER POUR oil into the Rotating Mesh Basket. Fire and personal injury could result. •While cooking, the
internal temperature of the Unit is very high. TO AVOID PERSONAL INJURY, never place hands inside the Unit
unless it is thoroughly cooled.
12. DO NOT OPERATE the appliance on or near combustible materials, such as tablecloths and curtains.
13. When in operation, air is released through the Air Outlet Vent. KEEP YOUR HANDS AND FACE at a safe
distance from the Air Outlet Vent. Also avoid the air while removing the Rotating Mesh Basket from the appliance.
14. The Unit's outer surfaces may become hot during use. The Rotating Mesh Basket WILL BE HOT.
15. The cooktop may smoke the first time it is used. It is not defective and the smoke will burn of within a few
minutes.
16. When cooking, DO NOT PLACE the appliance against a wall or against other appliances. Leave at least 10cm
free space on the back and sides and above the appliance. Do not place anything on top of the appliance.
17. DO NOT PLACE the unit on stove top surfaces.
18. If the power cord is damaged ,YOU MUST HAVE IT REPLACED by the manufacturer, its service agent, or a
similarly qualified person in order to avoid hazard.
19. NEVER IMMERSE the Main Unit Housing, which contains electrical components and heating elements, in water.
Do not rinse under the tap.
20. TO AVOID ELECTRICAL SHOCK, DO NOT put liquid of any kind into the Main Unit Housing containing the
electrical components.
21. This appliance has a polarized plug(one blade is wider than the other).To REDUCE THE RISK OF ELECTRIC
SHOCK, this plug is intended to fit into a polarized outlet only one way. If the plug does not fitfully into the outlet,

02
SPECIFICATION
PARTS & ACCESSORIES
reverse the plug. If it still does not fit, contact a qualified electrician.DO NOT ATTEMPT to modify the plug in any
way.
22. KEEP THE POWER CORD AWAY from hot surfaces. DO NOT PLUG in the power cord or operate the Unit
controls with wet hands.
23. NEVER CONNECT this appliance to an external timer switch or separate remote-control system.
24. NEVER USE this appliance with an extension cord of any kind.
25. Keep the appliance and its power cord OUT OF THE REACH of children when it is in operation or in the cooling
process.
NOTE: Unpack all listed contents from packaging. Varies by model. Please remove any clear or blue protective film
on the components.
Model
Voltage
Power
Body material
Frying basket material
Frying basket coating
Weight
1. Main Unit
2. Control Panel
3. Air Intake Vents
4. Hot Air Outlet Vents
5. Air Flow Racks
6. Rotating Mesh Basket
7. Drip Tray
8a*. Skewers(10)
8b*. Adjustable Skewers Racks(2)
9. Rotisserie Shaft, Forks& Set Screws
10. Rotisserie Fetch Tool
11. Rotisserie Stand
12. Gloves
13. Pad
14. Food Clip
15. Power cord
HIC-AF-8081D
AC 120V~60Hz
1700W
PP
Aluminum plate
PTFE
8.9kg

5. Air Flow Racks (*Optional)
Can be used not only for dehydration, but also to cook crispy snacks or reheat items like pizza.
6. Rotating Mesh Basket
Great for fries, roasted nuts, and other snacks. Use Rotisserie Fetch Tool to place basket into the Unit
7. Drip Tray
Cook with the Drip Pan in place for easy clean-up.
8a. Skewers (*Optional)
Great for all your kabob recipes, meat, fish or veggies.
8b. Adjustable Skewer Racks (*Optional)
Used when making kabobs. Skewer Racks fit over Shaft and lock in place with Set Screws.
9. Rotisserie Shaft, Forks & Set Screws (*Optional)
Use for roasts and whole chicken, Force Shaft lengthwise through meat and center. Slide Forks onto shaft from
either end into meat, then lock in place with Set Screws. There are indentations on the shaft for the set screws. You
can adjust the screws closer to the middle if needed but never outward towards the ends.
NOTE: Make sure roast or chicken is not too large to rotate freely within the oven. Maximum Chicken or Roast,
1000-1500g.
10. Rotisserie Fetch Tool
Use to remove cooked roasts and chicken that have been prepared using the rotisserie or skewer methods. Place
under Rotisserie Shaft and lift(left side first) then gently extract the food.
03
12 13 14 15

04
USING THE ACCESSORIES
Placing Air Flow Racks into Unit
Components
11. Rotisserie Stand (*Optional)
Use for placing the Rotisserie Shaft when removing hot food from the Unit.
12. Gloves
Used for holding the racks or the rotating mesh basket to protect your hands.
13. Pad
Used for putting racks and rotating mesh basket on to protect your desk.
14.Food Clip
Used for fetching food.
Important
Please make sure that your air fryer oven has been shipped with the components , that you ordered (some
accessories may be sold separately). Check everything carefully before use. If any part is missing or damaged, do
not use this product. Contact shipper using the customer service number located in the back of the owner's manual.
NOTE: Some accessories may not be included with the purchase.
Warning
Forks, Skewers, and other metal parts with this unit are sharp and will get extremely hot during use.
Great care should be taken to avoid personal injury. Wear protective oven mitts or gloves.
1. Insert Drip Tray into bottom of the Unit.
2. Place Air Flow Racks into Unit by sliding through the side grooves and onto the back lip (FIG. A).
3. Place Air Flow Racks closer to the top heating element for faster cooking and added crisp (FIG. B).
4. Rotate the Air Flow Racks mid-cycle for even cooking.
FIG.A
FIG.B
SKEWER RACK(2)
FRONTAL VIEW
ROTISSERIE SHAFT
LEFTSIDE RIGHTSIDE
SKEWERS
X10
SETSCREWS
X2

05
Rotisserie Shaft & Skewers Racks
1. Place the two Skewer Racks at each end of the Rotisserie Shaft. Make sure the Set Screws are on the outer side
of the Rotisserie Shaft.
2. Slightly tighten Set Screws. Do not over tighten as you may need to adjust the tightness after you insert the
Skewers.
3. Carefully poke Skewers through food.
FINALASSEMBLY
FRONTAL VIEW
Rotisserie Spit Assembly
1. Insert each Skewer point through holes on the let Skewer Rack (FIG. C).
2. Squeeze the clip end of each Skewer as you insert into the opposite Skewer Rack slot to secure.
3. Release clip to securely rest in slot as shown(FIG. D).
4. Repeat steps 1-3 in a uniform manner around the Skewer Rack. Make sure Skewers are evenly spaced.
5. Tighten the Set Screws to make sure they are securely in place.
6. Use caution while inserting the Spit into the unit to prevent getting poked by the skewer ends.
FIG.C-LEFT SIDE
FINAL ASSEMBLY
FIG.D-RIGHT SIDE

06
Placing Rotisserie Spit or Rotating Mesh Basket into Unit
1. Insert the left side of the assembled Spit or Basket first into the Rotisserie Shaft socket. Be sure the Rotisserie
Shaft is in place to engage rotation (FIG. E).
2. Place the right side onto the hanger (FIG. F).
IMPORTANT
See the Final Assembly diagram to help identify the left and right sides of the Rotisseries Shaft before placing it in the
Unit.The right side has two notches.and the left has one.
Using the Accessories
Removing Rotisserie Spit or Rotating Basket from Unit
1. Open Unit door to pause cooking cycle or turn Unit off by pressing the Power Button.
2. Insert Rotisserie Fetch Tool beneath the Rotisserie Shaft.
3. Lift the right side of the Rotisserie Fetch Tool at a slight angle to clear the bracket, then shit to the right until the left
side of the Shaft slides out of the Rotisserie Shaft socket.
4. Carefully remove the rotisserie food from the oven.
FIG.E-LEFT SIDE
FIG.F-RIGHT SIDE
FIG.G
℃MIN8
7
4
11 2 15 12 1 13 14 3
6
9
10
5
