Moosoo MG75 User manual

1
MODEL: MG75
USER MANUAL
For any questions and malfunctions of the appliance during use, please contact our customer
service email: [email protected]

2
WINE CHILLER SAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey
all safety messages.
T
his is the Safety Alert Symbol. This symbol alerts you to potential hazards that can kill or injure
y
ou and others. All safety messages will follow the Safety Alert Symbol and either the words
“
DANGER”, “WARNING” or “CAUTION”.
Danger means that failure to heed this safety
statement may result in severe personal
injury or death.
Warning means that failure to heed this
safety statement may result in extensive
product damage, serious personal injury, or
death.
Caution means that failure to heed this
safety statement may result in minor or
moderate personal injury, or property or
equipment damage.
All safety messages will alert you do what the potential hazard is, tell you how to reduce the chance of injury, and
let you know what can happen if the instructions are not followed.

3
IMPORTANT SAFEGUIDES
B
efore the appliance is used, it must be properly positioned and installed as described in this
m
anual, so read the manual carefully. To reduce the risk of fire, electrical shock or injury when
u
sing the appliance, follow basic precaution, including the following:
Plug into a grounded 3-prong outlet, do not remove grounding prong, do not use an adapter, and do not
use an extension cord.
Replace all panels before operating.
It is recommended that a separate circuit, serving only your appliance be provided. Use receptacles that
cannot be turned off by a switch or pull chain.
Never clean appliance parts with flammable fluids. These fumes can create a fire hazard or explosion.
And do not store or use gasoline or other flammable vapours and liquids in the vicinity of this or any
other appliance. The fumes can create a fire hazard or explosion.
Before proceeding with cleaning and maintenance operations, make sure the power line of the unit is
disconnected.
Do not connect or disconnect the electric plug when your hands are wet.
Unplug the appliance or disconnect power before cleaning or servicing. Failure to do so can result in
electrical shock or death.
Do not attempt to repair or replace any part of your appliance unless it is specifically recommended in
this material. All other servicing should be referred to a qualified technician.
Use two or more people to move and install appliance. Failure to do so can result in back or other injury.
To ensure proper ventilation for your appliance, the front of the unit must be completely unobstructed.
Choose a well-ventilated area with temperatures above 16°C (60°F) and below 32°C (90°F). This unit
must be installed in an area protected from the element, such as wind, rain, water spray or drips.
The appliance should not be located next to ovens, grills or other sources of high heat.
The appliance must be installed with all electrical, water and drain connections in accordance with state
and local codes. A standard electrical supply (220V/50Hz), properly grounded in accordance with the
National Electrical Code and local codes and ordinances is required.
Do not kink or pinch the power supply cord of appliance.
The fuse (or circuit breaker) size should be 13 amperes.
It is important for the appliance to be leveled in order to work properly. You may need to make several
adjustments to level it.
Never allow children to operate, play with or crawl inside the appliance.
Do not use solvent-based cleaning agents of abrasives on the interior. These cleaners may damage or
discolor the interior.
Do not use this apparatus for other than its intended purpose.

4
IMPORTANT SAFETY INSTRUCTIONS
WARNING
To reduce the risk of fire, electrical shock, or injury when
using your appliance, follow these basic precautions:
Read all instructions before using the wine chiller.
DANGER or WARNING: Risk of child entrapment.
Child entrapment and suffocation are not problems of the past. Junked or abandoned
appliances are still dangerous.
Before you throw away your old wine chiller, take off the door but leave the shelves in place
so that children may not easily climb inside.
Never allow children to operate, play with, or crawl inside the appliance.
Never clean appliance parts with flammable fluids. The fumes can create a fire hazard or
explosion.
Do not store or use gasoline or any other flammable vapours and liquids in the vicinity of this
or any other appliance. The fumes can create a fire hazard or explosion.
-Save these instructions-
FLAMMABLE REFRIGERANT GAS
DANGER - Risk of fire or explosion. Flammable refrigerant used.
DO NOT use mechanical devices to defrost refrigerator. DO NOT puncture refrigerant
tubing.
DANGER - Risk of fire or explosion. Flammable refrigerant used. To be repaired only by trained
service personnel. DO NOT puncture refrigerant tubing.
CAUTION - Risk of fire or explosion. Flammable refrigerant used. Consult repair manual / owner’s
guide before attempting to service this product. All safety precautions must be followed.
CAUTION - Risk of fire or explosion. Dispose of property in accordance with federal or local
regulations. Flammable refrigerant used.
CAUTION - Risk of fire or explosion due to puncture of refrigerant tubing. Follow handling
instructions carefully. Flammable refrigerant used.
CAUTION - To prevent a child from being entrapped, keep out of reach of children and not in the
vicinity of the cooler.

5
OPERATION AND TEMPERATURE SETTING
This wine cooler is suitable for the ambient temperature 5-32℃. If temperature is higher or lower than it, the
performance may be affected.
Temperature setting
MG75
①LED ON/OFF；
②Temperature up (Press it, temperature will go up 1 degree)；
③Display window；
④Fahrenheit and Celsius indicate light；
⑤Temperature down (Press it, temperature will decrease 1 degree)；
⑥Fahrenheit & Celsius switch button；
⑦Power ON/OFF: Press“POWER”button for 3 seconds to turn off the appliance. Press it to turn on it
WARNING:
If the appliance is power off suddenly. Please turn on the appliance after 3-5 minutes later. The
temperature setting is with automatic memory function.
If it is the first time to use this appliance, it is normal that the preset temperature and display temperature is
different. Everything will back to normal after few hours working.
Shelf
To avoid the damage of door sealing, please open the door fully when you slide out the shelves.
For your convenience of taking wine, you can pull out the shelf by 1/3. Our product is designed with shelf
holder to prevent the shelf pull over and fall off the cabinet.
If need to take off the shelf from cabinet, you can pull out the shelf to the shelf holder position, then lift up the
shelf to remove the shelf. (See figure below)
Reverse the door
The door is reversible. The default way to open the door is left opening. If need to reverse the door, do as the
following figures shows
C
F
°
°
1 2 3 4 5 6 7

6
MG75:
，
A：Glass door B: Hexagonal wrench
Procedure to reverse the door：
1. Fig:1，remove the screws on lower hinge by hexagonal wrench. Please hold the door to avoid the door drop
down after loosing of screws.
2. Fig:2 Remove the door in position ①, then take out the door in position②. Fig:3 shows the door is taken
out；
3. Fig:4 Tilt the door and insert to the top like ①shows, then move the door levelly to make it in the same level
with the cabinet (③)Fig:5，before tighten the bottom screws, to make sure the door is in the same level with
the cabinet.
4. Fig 6: Door reverse is finished；
Built-in installation drawing
MG75
Fig:1 Fig:2 Fig:3
Fig:4 Fig:5 Fig:6
1
2
3
1
A
B

7
Care and Maintenance
Cleaning your wine cooler
Turn off the power, unplug the appliance, and remove all items including shelves
Wash the inside surfaces with a warm water and soft cloth
Wash the shelves with a mild detergent solution
Wring excess water out of the sponge or cloth when cleaning area of the controls, or any electrical parts
Wash the outside cabinet with warm water and mild liquid detergent. Rinse well and wipe dry with a clean
soft cloth. Do not use steel wool or steel brush on the stainless steel. These will contaminate the stainless
steel with steel particles and rusting may occur.
Power failure
Most power failures are corrected within a few hours and should not affect the temperature of your appliance if
you minimize the number of times the door is opened. If the power is going to be off for a longer period of time,
you need to take the proper steps to protect your contents.
Moving your wine chiller
-Remove all items (bottles)
-Tape down securely all loose items (shelves) inside your appliance.
-Turn the adjustable leg up to the base to avoid damage.
-Tape the door shut. Be sure the appliance stays secure in the upright position during transportation. If you
absolutely need to transport the chiller horizontally, transport the chiller on its back (door on top). Also protect
outside of appliance with a blanket, or similar item.
Energy saving tips
The wine chiller should be located in the coolest area of the room, away from heat producing appliances, and out
of the direct sunlight.

8
TROUBLESHOOTING
You can solve many common wine chiller problems easily, saving you the cost of a possible service call. Try the
suggestions below to see if you can solve the problem before calling the service.
Troubleshooting
PROBLEM
POSSIBLE CAUSE
Wine cooler does not operate.
Not plugged in.
The appliance is turned off.
The circuit breaker tripped or a blown fuse.
Wine cooler is not cold enough.
External environment may require a higher
setting.
The door is opened too often.
The door is not closed completely.
The door gasket does not seal properly.
The compressor turns on and off frequently.
The room temperature is hotter than normal.
A lots of bottles has been added to the chiller.
The door is opened too often.
The door is not closed completely.
The temperature control is not set correctly.
The door gasket does not seal properly.
The light does not work
Not plugged in.
The circuit breaker tripped or a blown fuse.
The light button is “OFF”.
Vibrations.
The chiller is not leveled
The bottles are vibrating.
There is an object under the chiller.
The chiller seems to make too much noise.
The flow of refrigerant is normal
The circulation of the refrigeration
The chiller is not level.
The door will not close properly.
The chiller is not level.
The door was reversed and not properly
installed.
The gasket is dirty.
The shelves are out of position.

WARRANTY
CUSTOMER CARE
WHAT IS NOT COVERED
WARRANTY SERVICE
The 1-year Limited Warranty is valid for products purchased from our MOOSOO only, starting from the date of the
original retail purchased. We will provide customer service for any defects in quality or materials under normal,
non-commercial use.
1. According to the requirements outlined in this instruction manual, the warranty is subject to the following condi-
tions and exclusions.
2.This warranty provides, at no extra cost to you all labor and parts necessary to ensure your machine is in proper
operating condition during the warranty period.
3. We provide the repair or replacement of your MOOSOO appliance if your MOOSOO appliance is found to be
defective due to faulty materials, workmanship function within 1 year of purchase or delivery. ( If any part is no
longer available or out of manufacture, we will replace it with a functional replacement part).
1. Under your MOOSOO guarantee, MOOSOO shall not be liable for costs of repair or replacement of a product
incurred as a result of: Accidental damage, faults caused by negligent use or care, misuse, neglect, careless
operation or handling of the MOOSOO appliance which is not in accordance with this MOOSOO Instruction
Manual.
2. Machines purchased from an unauthorized dealer.
3. Use of parts and accessories other than those produced or recommended by MOOSOO.
4. Repairs or alterations carried out by unauthorized parties or agents.
5. Use of the machine other than for normal domestic purpose, e.g. for commercial or rental purposes.
6. Reduction in battery run time due to battery age or use.
1. If you have a query about your MOOSOO appliance, please contact the MOOSOO customer service email:
[email protected]
2. Please inform us your model name/number, purchase date, order number, machine problem and your
requirement.
3. Your model number can be found on rating plate. For information on your rating plate see the inside front
cover.
4. Please keep your purchase receipt in a safe place to ensure you have this information.
5. Service under this warranty will not extend the available time of warranty.
9
