Motion SMD 4.0 Series Specification sheet

SMD4MAN.WRI 06-98
SMD 4.0
STEP MOTION DRIVE SYSTEM
TST 4.0
STEP MOTOR POWER FEED
DSD 4.0
DIGITAL SERVO SYSTEM
OPERATION AND INSTALLATION MANUAL
SECTION 1: SMD DRIVER CASE
SECTION 2: MS DRIVER CARD
FOR QUICK REFERENCE - REFER TO THE APPENDIX SECTIONS

General Description. The SMD, TST, and DSD 4.0 series units are identical to the 2.0 series with the
following exceptions:
1) The units support 4 amps of motor current; factory pre-set is 4 amps.
2) The units may require additional cooling or mounting of the system to a larger metal
surface if bottom lid or motor is too hot to touch (75OC). See Appendix C.
3) The units support Full, Half, Quad (factory pre-set), and Octal step.
4) The units are Auto-Parktm; park power is pre-set to 50% of the current adjustment
dial. Ignore references to the PARK signal in manual.
Current and Step Angle Setting. To remove the lid (bottom) and access the amplifier card which is
mounted to the lid:
1) Remove the 10 each hex-head screws.
2) Carefully lift and fold lid to label side of box so as not to disturb the wiring harness.
3) Adjust the blue pot, located on the card edge, to the desired output current as
required; pot is normally set to 4.0 amps.
Select the two jumper blocks (pins) for the desired step angle per the table.
JP1 JP2 STEP ANGLE
OPEN OPEN 1/8 STEP (* see note)
OPEN JUMP 1/4 STEP (factory pre-set, best for smoothness)
JUMP OPEN 1/2 STEP (best for high inertia loads)
JUMP JUMP 1/1 STEP (best for full speed and full power)
(* depending on motor, may not produce equally spaced steps)
