MotionGrey Motion Series User manual

Motion Series - L Shape Desk
Assembly Instruction

CAUTION / INFORMATION
USE / LIABILITY
Check that there are no obstacles in the desk's way.
Ensure the desk is not touching any walls.
Make sure the cords are long enough for height adjustments.
This height-adjustable desk features electric motors and is intended for use exclusively in dry work areas.
The desk height is adjustable to provide the most ergonomically suitable position.
Using it for any other purpose is at the user's own risk.
The manufacturer does not accept warranty claims or liability claims for damages resulting from improper
use or handling of the desk frame under any circumstances.
IMPORTANT: Please carefully review this manual. If this desk is sold,
please provide this manual to the new owner.
Pinch Point
Keep hands and
fingers clear.
Please ensure that children are kept away from thw electric height-adjustable desks,
control units, and handsets to prevent the risk of injury and electric shock.
Do not open any of the components - the legs, control box, or switch. There is a danger
of electric shock.
Avoid exposing any electrical components to liquids.
Do not sit or stand on the desk frame. Do not crawl or lie under the desk frame.
Do not place any objects taller than 20” underneath the desk.
In the event of a power outage or if the power cord is unplugged, a manual reset
may be necessary - see USE section.
This product is designed with a duty cycle of 10% (2 minutes on, 18 minutes off).
Scan to access the step-by-step
installation instructions and video.
1

2
ASSEMBLY
Note: Use M5*16 wood screws
to attach the Handset, Control
Box, and Desktop.
ACCESSORY LIST
PARTS LIST
Ⓐ
Ⓑ
Ⓑ
Ⓒ
Ⓓ
Ⓔ
Ⓔ
Ⓔ
Ⓓ
Ⓒ
Ⓒ
ⒷⒷ
Ⓐ
Ⓐ
A B C
1 2 3
D
F G H I
E
Lifting Column x3 Crossbar x4 Side Bracket x3 Central Rail x4 Foot Base x3
Keypad x1 Control Box x1 Power Cord x1 Cable x1
M6x10 M6x16 M5x16
5mm Allen Key

ASSEMBLY
❶ ❷
Insert the lifting column into the crossbar,
and then use the allen key to insert and
tighten the four M6x10 screws.
Screw on the side bracket using the
M6x10 screws and allen key.
For each leg assembly, attach then
screw on the foot base using four
M6x16 screws and tighten them
using the allen key.
❸ ❹
3
Connect the two crossbars using two central
rails. Make sure the frames are properly
positioned beneath the desk top.
①
Ⓐ
Ⓑ
①Ⓒ
②ⒺⒹ

Screw another crossbar into the existing
one and tighten it using two M6x10
screws and an allen key.
Secure the other set of leg assembly and
central rails to the desk top using M6x10
screws and an allen key.
Screw the keypad and control box onto the
desk and tighten them using M5x16 screws.
❺
❻ ❼
4
ASSEMBLY
①
①
①
Ⓓ
③
③
Ⓕ
Ⓖ
