Motorola solutions AVIGILON AVA BULLET Installation instructions manual

AVA BULETT CAMERA
MOUNTING GUIDE
Avigilon Alta Cloud Security
MOUNTING GUIDE | AVIGILON AVA BULLET CAMERA

MOUNTING GUIDE | AVIGILON AVA BULETT CAMERA 2 / 10
IMPORTANT WARNINGS AND SAFETY INSTRUCTIONS
Avoid exposing the camera to shocks, high pressure or temperatures above 50°C.
Avoid placing the camera near fans, ventilation or other noise sources. This will degrade audio performance.
Avoid scratching or leaving fingerprints on the lens cover, this degrades image quality. If possible, keep the protective plastic on the
lens cover during installation.
Do not clean the camera with harsh detergents, gasoline or chemicals such as acetone.
Do not try to repair the unit yourself. Refer all servicing of the camera to Avigilon or contact a reseller.
Do not install the camera during rain, mist or other conditions of high humidity. Water may be trapped inside, causing damage or
condensation issues.
This product should be supplied by a Power over Ethernet Power Sourcing Equipment (PSE) compliant to IEEE 802.3at Type 2 (PoE+).
The camera should be connected only to PoE networks without routing to the outside plant. The PoE PSE must be properly grounded.

MOUNTING GUIDE | AVIGILON AVA BULETT CAMERA 3 / 10
BOX CONTENTS

MOUNTING GUIDE | AVIGILON AVA BULETT CAMERA 4 / 10
USING THE WALL BRACKET
Screws are not included. The installer must use suitable fasteners.
1 2 3

MOUNTING GUIDE | AVIGILON AVA BULETT CAMERA 5 / 10
OPENING THE HOUSING AND REMOVING CABLE GLAND
It’s easier to access the screws when the ball joint is moved to an angle.
34

MOUNTING GUIDE | AVIGILON AVA BULETT CAMERA 6 / 10
OPENING THE HOUSING AND REMOVING CABLE GLAND
56

MOUNTING GUIDE | AVIGILON AVA BULETT CAMERA 7 / 10
INSTALLING CABLE GLAND AND CONNECTING ETHERNET CABLE
7 8
8 10 11

MOUNTING GUIDE | AVIGILON AVA BULETT CAMERA 8 / 10
CONNECT THE CAMERA AND ADJUST THE PICTURE
Add the Camera to Ava Aware and ensure that the video stream
is working.
Add the Camera to Alta Aware and ensure that the video stream is
working.
12 13
Install the top mounting plate.
Note the front indicators indicate the default front side of the
camera. Install the mounting plate with the orientation you prefer.
14

MOUNTING GUIDE | AVIGILON AVA BULETT CAMERA 9 / 10
CHANGE LENS ORIENTATION, HORIZONTAL (16:9)
- VERTICAL (9:16)
Please be aware of the screw, it can easily be lost during disassembly.

Motorola Solutions, Inc. 500 West Monroe Street, Chicago, IL 60661 U.S.A. motorolasolutions.com
© 2023, Avigilon Corporation. All rights reserved. MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M Logo are trademarks or registered trademarks of Motorola Trademark Holdings,
LLC and are used under license. All other trademarks are the property of their respective owners. 07-2023 [DS01]
To learn more, visit:
www.avigilon.com
CONNECT THE CAMERA AND ADJUST THE PICTURE
Ensure the camera body has been opened before
attempting to rotate the lens.
HORIZONTAL VERTICAL
