Motorola LA-5137 Quick setup guide


LA-5137 Compact Flash Adapter
Integration Guide

© 2007 Motorola, Inc. All rights reserved.
MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. Symbol is a registered
trademark of Symbol Technologies, Inc. All other product or service names are the property of their respective owners.

Introduction
1.1 Legal Statement
THE INFORMATION IN THIS GUIDE IS PROVIDED “AS IS” WITHOUT ANY EXPRESS OR IMPLIED WARRANTY
OF ANY KIND INCLUDING WARRANTIES OF MERCHANTABILITY, NONINFRINGEMENT OF INTELLECTUAL
PROPERTY, OR FITNESS FOR ANY PARTICULAR PURPOSE. IN NO EVENT SHALL MOTOROLA BE LIABLE FOR
ANY DAMAGES WHATSOEVER (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF PROFITS,
BUSINESS INTERRUPTION, LOSS OF INFORMATION) ARISING OUT OF THE USE OF OR INABILITY TO USE
THE INFORMATION IN THIS GUIDE, EVEN IF MOTOROLA HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES. BECAUSE SOME JURISDICTIONS PROHIBIT THE EXCLUSION OR LIMITATION OF LIABILITY FOR
CONSEQUENTIAL OR INCIDENTAL DAMAGES, THE ABOVE LIMITATION MAY NOT APPLY TO YOU.
Motorola further does not warrant the accuracy or completeness of the information, text, graphics, or other
items contained within this guide. Motorola may make changes to this guide, or to the products and/or
Software described therein, at any time without notice. Motorola makes no commitment to update the
Information.
1.2 Background
The LA-5137 is the next generation CF client card for embedded solutions and is intended for OEM
customers.
1.3 Purpose
The purpose of this document is to define the functional characteristics (electrical, mechanical, software
interfaces) of the LA-5137 CF Card and provide regulatory information helpful to OEM customers to integrate
or embed the CF card in a variety of systems.
1.4 LA-5137 Part Numbers
The LA-5137 Card is available in two SKUs:
Part Number SKU
LA-5137-1002-WWR 802.11a/g External Antenna Version
LA-5137-1020-WWR 802.11a/g Internal Antenna Version

1-2 LA-5137 Compact Flash Adapter Integration Guide
1.5 Key Features and Standards
The LA-5137 CF Card supports all required modes of operation as an 802.11a/b/g Mobile Unit (MU). In
802.11g mode, the radio supports three different modulation modes: Legacy 1 and 2 Mbps, Complimentary
Code Keying (CCK), and Orthogonal Frequency Division Multiplexing (OFDM). The radio supports the
following 12 data rates in 802.11b/g mode:
In addition to supporting 802.11g, LA-5137 supports all required modes of operation as an 802.11a mobile
unit. This radio supports the following 8 data rates in 802.11a mode:
The LA-5137 CF Card supports station operation in Continuous Aware Mode (CAM) and Fast Power-Save and
Max Power-Save modes.
Other features and standards supported:
• 802.11a/b/g
• 802.11d
• Robust roaming and dynamic rate switching
Data Rate (Mbps) Modulation
1DBPSK
2DQPSK
5.5 CCK
6 OFDM with BPSK Carrier Modulation
9 OFDM with BPSK Carrier Modulation
11 CCK
12 OFDM with QPSK Carrier Modulation
18 OFDM with QPSK Carrier Modulation
24 OFDM with 16QAM Carrier Modulation
36 OFDM with 16QAM Carrier Modulation
48 OFDM with 64QAM Carrier Modulation
54 OFDM with 64QAM Carrier Modulation
Data Rate (Mbps) Modulation
6 OFDM with BPSK Carrier Modulation
9 OFDM with BPSK Carrier Modulation
12 OFDM with QPSK Carrier Modulation
18 OFDM with QPSK Carrier Modulation
24 OFDM with 16QAM Carrier Modulation
36 OFDM with 16QAM Carrier Modulation
48 OFDM with 64QAM Carrier Modulation
54 OFDM with 64QAM Carrier Modulation

Introduction 1-3
• Range up to 300 ft./91m in standard office environments (1Mbps connectivity)
• Data security using WEP data encryption and Wireless Protected Access (WPA) and 802.11i (WPA2)
with Advanced Encryption Standard (AES)
• Advanced authentication using 802.1x
• Advanced Power Management for very low power consumption
• 16 bit host interface using CF mode (16 bit PC-Card® Interface)
• Driver/Firmware supports Linux 2.4 and Windows CE Embedded 5.0
1.6 User Profiles
The intended user-base for the LA-5137 includes:
• The LA-5137 product is optimized for embedded, mobile enterprise, and industrial applications
where security, feature, and technical service are required.
• Mobile workers in health care, education, retail, manufacturing, hospitality and other industries with
802.11a, 802.11b, and 802.11g wireless LAN access.
• Corporate Motorola device users with Wi-Fi wireless LAN access at the office, or with a subscription
to a public wireless LAN.

1-4 LA-5137 Compact Flash Adapter Integration Guide

Architecture
2.1 System Architecture
The LA-5137 is a modified type 1 CFA card. The LA-5137 Compact Flash Adapter CF card consists of all of the
integrated circuits necessary to provide WLAN transceiver functionality for the 2.4GHz and 5 GHz bands. The
Wireless LAN integrated Media Access Controller with Baseband processor directly interfaces with the Dual
Band Direct Conversion transceiver. With the addition of RF Front-end Module (FEM), the LA-5137 Compact
Flash Adapter card incorporates the WLAN chip set solution compliant with 802.11a/b/g standards.
Figure 2.1 Top-level LA-5137 CF Card architecture
The 40MHz crystal controlled clock provides the necessary clocks for both the PLL and the baseband & MAC
chip. The SDRAM provides additional memory to support SHoC (Self Hosted Client) operation. Not shown in
Figure 2.1 are the necessary voltage regulators that provide various supply voltages for the chips. The
regulators require 3.3V input supply.
The EEPROM is used to hold radio information including radio calibration information done at the automatic
manufacturing test step.

2-2 LA-5137 Compact Flash Adapter Integration Guide
2.2 Hardware Environment
2.2.1 Introduction
The LA-5137 CF card can be used in handheld mobile devices to provide wireless network access. It
communicates using Radio Frequencies (RF) between two or more users or between a user and the wired
network. The module implements the IEEE 802.11a/g physical (RF) specification. The chipset used provides
for modulation, demodulation, spreading, and despreading of the RF signals.
2.2.2 Card Dimensions
The LA-5137 is a modified type 1 CFA card. See Appendix A, Product Mechanical Interface Drawing for
Mechanical Interface Drawing.
2.2.3 Card Physical
2.2.3.1 Operational Environment
NOTE: The product is not required to be powered during test activities. Only parameters marked by an *
shall be powered during testing. Testing per Symbol Qualification Test Standard SS-03800-74.
• 0 to +55 degrees C max operating* (card installed environment)
• 95% RH non-condensing*
• Altitude to withstand 8,000 ft @ 28 degrees Celsius*
• Vibration to withstand .02g2/Hz, random, sine, 20-2k Hz
• Bench drop 36 inches to concrete @ -20, 23, 50 degrees Celsius
• Mechanical shock to withstand 50 G peak, 11 ms, half sine
• No water/rain/insect resistance (Damp cloth cleaning OK)
• No chemical resistance (Light cleaning solutions OK)
• Loose cargo/packaged to withstand 6 foot drop
• ESD to withstand 1.5KV contact per PCMCIA/CF Specification
2.2.3.2 Storage Environment
• -20 to +65 degrees C temperature range
• 95% RH non-condensing humidity
• Altitude to withstand 15,000 feet
2.2.4 Antenna Connectors (non embedded antenna)
The LA-5137-1002-WWR CF card (External Antenna Version) supports 2 RF connector (Hirose U.FL-R-SMT, or
equivalent). The antennas can be attached to the card through the connectors. There are two connectors on
the LA-5137-1002-WWR unit.

Architecture 2-3
NOTE: Antenna sharing with other radio modules is not supported on the LA-5137.
2.2.5 Antenna Requirements
For detailed antenna requirements, refer Chapter 7, Antenna Requirements (External Antenna).
NOTE: Regulatory Note: Many country regulations require special testing and reporting of antenna
performance or of the system with the antenna attached. Please check the appropriate regulatory
authority or contact Motorola for more information.
2.2.6 TX and RX Diversity
TX and RX diversity is only supported on the connector version of LA-5137 (LA-5137-1002-WWR).
2.2.7 Operating Channels
Table 2.1 IEEE 802.11g Channels
Channel
Number
Channel
Frequency
(MHz) Countries
1 2412 USA, Canada, EU, Japan
2 2417 USA, Canada, EU, Japan
3 2422 USA, Canada, EU, Japan
4 2427 USA, Canada, EU, Japan
5 2432 USA, Canada, EU, Japan
6 2437 USA, Canada, EU, Japan
7 2442 USA, Canada, EU, Japan
8 2447 USA, Canada, EU, Japan
9 2452 USA, Canada, EU, Japan
10 2457 USA, Canada, EU, Japan
11 2462 USA, Canada, EU, Japan
12 2467 EU, Japan
13 2472 EU, Japan
14 2484 Japan

2-4 LA-5137 Compact Flash Adapter Integration Guide
UNII Band Channel
Number
Channel
Frequency (MHz) Countries
240 4920 Japan
244 4940 Japan
248 4960 Japan
252 4980 Japan
5040 Japan
5060 Japan
5080 Japan
Lower Band
34 5170 Japan
36 5180 USA, Canada, EU, Japan
38 5190 Japan
40 5200 USA, Canada, EU, Japan
42 5210 Japan
44 5220 USA, Canada, EU, Japan
46 5230 Japan
48 5240 USA, Canada, EU, Japan
Middle Band
52 5260 USA, Canada, EU, Japan
56 5280 USA, Canada, EU, Japan
60 5300 USA, Canada, EU, Japan
64 5320 USA, Canada, EU, Japan
100 5500 USA, Canada, EU, Japan
104 5520 USA, Canada, EU, Japan
108 5540 USA, Canada, EU, Japan
112 5560 USA, Canada, EU, Japan
116 5580 USA, Canada, EU, Japan
120 5600 USA, Canada, EU, Japan
124 5620 USA, Canada, EU, Japan
128 5640 USA, Canada, EU, Japan
132 5660 USA, Canada, EU, Japan
136 5680 USA, Canada, EU, Japan
140 5700 USA, Canada, EU, Japan

Architecture 2-5
Table 2.2 IEEE 802.11a Channels
2.2.8 Electrical Interface
The electrical interface for LA-5137 is PC16. The chipset used supports this interface; therefore no external
component is required. The host must support the PC16 interface as well. This card only uses 16-bit interface.
2.2.9 Bluetooth Coexistence and Wake-on-WLAN
LA-5137 hardware is designed to support these features for future software implementation. THESE
FEATURES ARE NOT SUPPORTED AT PRESENT.
Three GPIO pins are assigned to support BT Coexistence. The following is the pin assignment to support BT
Coexistence with Broadcom’s BCM2045 BT Module:
• GPIO 2-3: BT0 (Tx Config) (Connected to A10 on CF interface)
• GPIO 2-4: BT1 (Status) (Connected to pin CSEL on CF interface)
• GPIO 2-5: BT2 (RF Active) (Connected to pin SPKR on CF interface)
The following GPIO signal is also available for Wake-on-WLAN functionality
• GPIO 2-11: WOL (Connected to STSCHG on CF interface)
Upper Band
149 5745 USA, Canada
153 5765 USA, Canada
157 5785 USA, Canada
161 5805 USA, Canada
165 5825 USA, Canada
UNII Band Channel
Number
Channel
Frequency (MHz) Countries

2-6 LA-5137 Compact Flash Adapter Integration Guide

Design Overview
The chipset used implements a dual band direct conversion transceiver supporting 2.4 GHz and 5 GHz bands.
The chipset uses Zero Intermediate Frequency (ZIF) architecture for the radio. The architecture contains low-
noise amplifiers, quad up/down converters, frequency synthesizers, low-pass filters, baseband AGC receiver
amplifiers, transmit/receive switches, and transmitter power amplifiers.
The 802.11 WLAN MAC protocol is implemented in firmware supporting BSS and IBSS operation. Low-level
protocol functions such as request to send (RTS)/clear to send (CTS) generation and acknowledgement,
fragmentation and de-fragmentation, and automatic beacon monitoring are handled without host
intervention.
3.1 Transmitter Path
After the Medium Access Controller (MAC) receives the data from the host computer through CF interface,
the MAC appends a preamble and header and sends the data to the Base-Band Processor (BBP).
The radio supports legacy and CCK data rates in 2.4GHz and the OFDM data modulation modes for both 2.4
GHz and 5 GHz bands.
The CCK mode transmitter is a Direct Sequence Spread Spectrum (DSSS) PSK modulator when in CCK mode
supporting 5.5 Mbps and 11 Mbps. It also supports DBPSK for 1 Mbps and DQPSK for 2 Mbps. The preamble
is always transmitted as the DBPSK waveform and the header can be configured as DBPSK or DQPSK while
the data packets can be DBPSK, DQPSK, or CCK.
The OFDM transmitter supports BPSK, QPSK, 16QAM or 64QAM modulation. The OFDM transmitter operates
in 2.4 GHz and 5 GHz bands providing 6, 9, 12, 18, 24, 36, 48, and 54 Mbps data rates. The OFDM signal is
fed to a pair of Digital to Analog Converters (DACs) to produce the In Phase (I) and the Quadrature (Q) signals.
The TX signals are then amplified by the PA and routed through the high-low band switch to the dual band
antenna for transmission.
3.2 Receive Path
The received signal from the antenna is fed to the diplexer, which separates the signal path for the low band
(2.4 GHz) and the high band (5 GHz). The signal is then fed to a filter/balun in the low band and to a balun in
the high band path. The signal then goes to the transceiver chip for direct down conversion for both low and
high bands. The design contains LNAs, Quad Up/Down Converters, Synthesizers, Low-Pass Filters, and
Baseband AGC Receiver Amplifiers.

3-2 LA-5137 Compact Flash Adapter Integration Guide
3.3 Microprocessor Control
The baseband and MAC chip contains an ARM946E processor core and the SRAM required for implementing
the Media Access Control (MAC) functionality. The embedded firmware runs the 802.11 MAC layer control.
The MAC control sends and receives packets and transfers data to and from the CF interface to the host
computer of the handheld device.
3.4 Frequency Generation
The MAC & Baseband chip has the voltage-controlled oscillator (VCO) required for the design. The VCO
operates in one of the two ranges: 9648 to 9936 MHz (4X channel frequency for low-band) or 9900 to 11,800
MHz (2X channel frequency for high band). The Synthesizer circuit uses the 40 MHz crystal oscillator to phase
lock the VCO to produce accurate channel frequency for the radio. The frequency range in the low-band is
covered in two MHz steps (1 MHz at the channel frequency) and in the high-band the LO frequency is covered
in five MHz steps (2.5 MHz at the channel frequency).

RF Signal Performance
4.1 Specifications
Unless otherwise stated the following specifications hold over 0C to +55C, and 3.3V +/- 5%.
NOTE: This environment is defined as the specific temperature envelop containing the LA-5137 radio
product. If embedded within a host product, this envelop is the internal ambient temperature of the host
under the host’s operating conditions.
Table 4.1 Functional Specification
Functional Typical Max Units
Continuous Transmit Current
(OFDM 54 Mbps) 481 580 mA
Continuous Transmit Current
(CCK/DS 11 Mbps) 501 600 mA
Continuous Receive Current
(OFDM 54 Mbps) 281 340 mA
Continuous Receive Current
(CCK/DS 11 Mbps) 281 340 mA
Continuous Ping (10,000 size)
Tx 54 Mbps 328 390 mA
Continuous Ping (10,000 size)
Rx 54 Mbps 304 370 mA
Supply Voltage 3.13 3.47 Volts
Table 4.2 Receiver “Legacy” 802.11b mode
Receiver (“Legacy” 802.11b mode) Min Max Unit Comments
Sensitivity, 11 Mbps -79 -10
dBm 8% PER 1024 Octets
0o C to 55o C
Sensitivity, 5.5 Mbps -82 -10
Sensitivity, 2 Mbps -83 -10
Sensitivity, 1 Mbps -86 -10

4-2 LA-5137 Compact Flash Adapter Integration Guide
Table 4.3 Transmitter “Legacy” 802.11b mode
Transmitter (“Legacy” 802.11b
mode) Min Max Unit Comments
Power Level, 0o C to +55o C 12 16 dBm
RF Power will have the appropriate
back-off to meet the regulatory
requirements at the band edges
Table 4.4 Receiver 802.11g OFDM Modes
Receiver (802.11g OFDM mode) Min Max Unit Comments
Sensitivity, 54 Mbps -65 -15
dBm 10% PER 1000 bytes
0o C to 55o C
Sensitivity, 48 Mbps -66 -15
Sensitivity, 36 Mbps -70 -15
Sensitivity, 24 Mbps -74 -15
Sensitivity, 18Mbps -77 -15
Sensitivity, 12Mbps -79 -15
Sensitivity, 9 Mbps -81 -15
Sensitivity, 6 Mbps -82 -15
Table 4.5 Transmitter 802.11g OFDM
Transmitter (802.11g OFDM mode) Min Max Unit Comments
Power Level, 54 Mbps 10 12
dBm
Power output measured at relative
constellation error specifications.
IEEE 802.11g, 17.3.9.6.3
0o C to +55oC
RF Power will have the appropriate
back-off to meet the regulatory
requirements at the band edges.
Power Level, 48 Mbps 10 12
Power Level, 36 Mbps 11 13
Power Level, 24 Mbps 11 13
Power Level, 18Mbps 12 15
Power Level, 12Mbps 12 15
Power Level, 9 Mbps 13 16
Power Level, 6 Mbps 13 16

RF Signal Performance 4-3
4.2 I/O Signals
The Table 4.8 describes the I/O signals for I/O mode operation:
Table 4.6 Receiver 802.11a OFDM
Transmitter (802.11a OFDM mode) Min Max Unit Comments
Sensitivity, 54 Mbps -65 -15
dBm 10% PER for 1000 bytes
0o C to +55oC
Sensitivity, 48 Mbps -66 -15
Sensitivity, 36 Mbps -70 -15
Sensitivity, 24 Mbps -74 -15
Sensitivity, 18Mbps -77 -15
Sensitivity, 12Mbps -79 -15
Sensitivity, 9 Mbps -81 -15
Sensitivity, 6 Mbps -82 -15
Table 4.7 Transmitter 802.11a OFDM
Transmitter (802.11a OFDM mode) Min Max Unit Comments
Power Level, 54 Mbps 10 12
dBm 10% PER for 1000 bytes
0o C to +55oC
Power Level, 48 Mbps 10 12
Power Level, 36 Mbps 11 13
Power Level, 24 Mbps 11 13
Power Level, 18Mbps 12 15
Power Level, 12Mbps 12 15
Power Level, 9 Mbps 13 16
Power Level, 6 Mbps 13 16
Table 4.8 I/O Signals for I/O mode operation
Pin # Signal Name Pin Type
1 GND DC In
2D03I/O
3D04I/O
4D05I/O
5D06I/O
6D07I/O
7 CE1J I
8A10 I

4-4 LA-5137 Compact Flash Adapter Integration Guide
9OEJ I
10 A09 I
11 A08 I
12 A07 I
13 VCC DC In
14 A06 I
15 A05 I
16 A04 I
17 A03 I
18 A02 I
19 A01 I
20 A00 I
21 D00 I/O
22 D01 I/O
23 D02 I/O
24 WP / IOIS16J O
25 CD2J O
26 CD1J O
27 D11 I/O
28 D12 I/O
29 D13 I/O
30 D14 I/O
31 D15 I/O
32 CE2J I
33 VS1J O
34 IORDJ I
35 IOWRJ I
36 WEJ I
37 RDYJ / BSYJ / IREQJ Out
38 VCC DC In
39 CSELJ I
40 VS2J O
41 RESET I
42 WAITJ O
Table 4.8 I/O Signals for I/O mode operation
Pin # Signal Name Pin Type

RF Signal Performance 4-5
See Appendix A, Product Mechanical Interface Drawing for pin orientation.
43 INPACKJ O
44 REGJ I
45 SPKRJ I/O
46 STSCHGJ I/O
47 DO8 I/O
48 DO9 I/O
49 D10 I/O
50 GND DC In
Table 4.8 I/O Signals for I/O mode operation
Pin # Signal Name Pin Type

4-6 LA-5137 Compact Flash Adapter Integration Guide
