Motorola Smart Nursery 7 User manual

User’s Guide
Brilliant Video Baby Monitor with Nursery Analytics and
Advanced Baby Care Camera
Model: Smart Nursery 7
The features described in this User’s Guide are subject to modifications without prior notice.

Welcome...
to your new Smart Nursery 7 system!
Thank you for purchasing your new Smart Nursery 7 system. Now you can
see and hear your baby sleeping in another room or you can monitor your
older children in their playroom via the mobile app and the Smart Nursery
Monitor.
Please retain your original dated sales receipt for your records.
For warranty service of your Motorola product, you will need to provide a
copy of your dated sales receipt to confirm warranty status. Registration is
not required for warranty coverage.
For product related questions, please call:
This User's Guide provides you with all the information you need to get the
most from your product.
Before you can use the product, we recommend you fully charge the
batteries, so that they continue to work if you disconnect them from the
power supply to carry it to another location. Please read the Safety
Instructions on pages 7 - 9 before you install the units.
Got everything?
• 1 x Smart Nursery Camera with built-in 1880mAH Lithium ion
rechargeable battery
• 1 x Smart Nursery Monitor with built-in 3500mAH Lithium polymer
rechargeable battery
• 2 x Power Adapters
• 1 x Quick Start Guide
In multi-camera packs, you will find one or more additional cameras and
power adapter units.
For Wi-Fi®internet viewing you will need a suitable Android or iPhone/
iPad device and Wi-Fi®internet connection of at least 0.6Mbps upload
bandwidth per camera.
US and Canada 1-888-331-3383
E-mail: [e-mail]
On the Web: www.motorolahome.com/support

Overview of the Smart Nursery Monitor
1. Display with touch screen control
2. Power Key 0
Press and hold to turn the monitor
ON/OFF
3. Volume Key
Press -/+ to decrease/increase
volume level on the monitor
4. Earphone Socket - 3.5mm, 2-pole
5. Micro-SD Card Socket - accepts up
to 32GB
6. Micro USB Power Socket
1
2
3
4
5
6

Important guidelines for installing your Smart Nursery Camera
• Use of other 2.4 GHz products, such as other wireless networks, Bluetooth®
systems or microwave ovens may cause interference with this product. Keep
the Smart Nursery Camera away from these types of products, or turn them off
if they appear to be causing interference.
• Always ensure that you have a good Wi-Fi®connection available.
1. Light Sensor (for night mode detection) 7. Speaker
2. Camera Lens 8. Micro-SD Card Slot - accepts
up to 32GB
3. Infrared LEDs (for night vision) 9. Charging LED
4. Power / Status indicator 10. ON/OFF Switch
5. Microphone 11. Micro USB Power Socket
6. PAIR Button
Overview of Your Smart Nursery Camera
1
2
3
4
5
6
7
8
9
10
11

Table of contents 5
ENGLISH
Table of contents
1. Safety Instructions ........................................................................................7
2. Getting Started ...........................................................................................10
2.1 Charging the Smart Nursery Camera ..................................................10
2.2 Powering the Camera On/Off .............................................................10
2.3 LED status indicators ............................................................................10
2.4 Charging the Smart Nursery Monitor ..................................................11
2.5 Smart Nursery Monitor Stand ...............................................................11
3. Setting up the Smart Nursery Monitor .......................................................12
3.1 Create a Hubble Account and Pair your Smart Nursery Monitor
with the Smart Nursery Camera...........................................................12
3.2 Pair your Smart Nursery Monitor with an additional Smart Nursery
Camera .................................................................................................13
4. Using the Smart Nursery Monitor ..............................................................14
4.1 Using the Baby Tools ............................................................................16
4.1.1 Automatic Expression Detection and Snapshot Capture ...16
4.1.2 Baby Calendar .......................................................................16
4.1.3 Baby Journal .........................................................................17
4.1.4 Sleep Quality .........................................................................17
4.1.5 BabyTube ..............................................................................18
5. Accessing the Smart Nursery Camera via your Mobile Devices ...............19
5.1 System Requirements ..........................................................................19
5.2 Connecting Devices ............................................................................20
5.3 User Account and Camera Setup on Android™ Devices ..................21
5.3.1 Download Hubble for Motorola Monitors App ....................21
5.3.2 Run Hubble for Motorola Monitors App on Android™
device ....................................................................................21
5.3.3 Add the Camera to your account .........................................21
5.4 Add additional Cameras to your Hubble Account..............................22
5.5 Connect the Camera to another Android™ Device ..........................22
5.6 User Account and Camera Setup on iPhone®/iPad®.........................23
5.6.1 Download Hubble for Motorola Monitors App ....................23
5.6.2 Run Hubble App on your iPhone®/iPad®............................23
5.6.3 Add the Camera to your account .........................................23
5.7 Add additional Cameras to your Hubble Account..............................24
5.8 Connect the Camera to another iOS®Device ...................................24
6. Camera Functions ......................................................................................25
6.1 On Android™ Devices.........................................................................25
6.1.1 Main Menu Options ..............................................................25
6.1.2 Camera Options ...................................................................26
6.1.3 Remove a Camera from your Hubble Account ...................29
6.2 Automatic Expression Detection and Snapshot Capture ...................29

6Table of contents
6.3 Motion Recording with 24-Hour Video History................................... 29
6.4 Review, Share and Download Recorded Events or Notifications ...... 30
6.5 On iOS®Devices ................................................................................. 31
6.5.1 Main Menu Options .............................................................. 31
6.5.2 Camera Options ................................................................... 31
6.5.3 Remove a Camera from your Hubble Account .................. 33
6.6 Automatic Expression Detection and Snapshot Capture................... 34
6.7 Motion Recording with 24-Hour Video History................................... 34
6.8 Review, Share and Download Recorded Events or Notifications ...... 35
7. Working with PC/Notebook...................................................................... 36
8. Procedure for Resetting the Camera ........................................................ 36
9. App and Firmware Upgrades .................................................................... 37
9.1 App Upgrade........................................................................................ 37
10. Disposal of the Device (Environment) ...................................................... 38
11. Cleaning ..................................................................................................... 39
12. Help ............................................................................................................ 40
13. General Information................................................................................... 47
14. Technical Specifications............................................................................ 53

Safety Instructions 7
ENGLISH
1. Safety Instructions
WARNING:
Strangulation Hazard: Children have
STRANGLED in cords. Keep this cord
out of the reach of children (more than 3ft
away). Never use extension cords with
AC Adapters. Only use the AC Adapters
provided.

8Safety Instructions
WARNING
This Camera is compliant with all relevant standards regarding
electromagnetic fields and is, when handled as described in the User's Guide,
safe to use. Therefore, always read the instructions in this User's Guide carefully
before using the device.
• Adult assembly is required. Keep small parts away from children when
assembling.
• This product is not a toy. Do not allow children to play with it.
• This Camera is not a substitute for responsible adult supervision.
HOW TO POSITION THE SMART NURSERY CAMERA:
• Keep the Camera out of the reach of children (more than 3ft away).
• NEVER place the Camera or cords within the crib.
• The Camera should be placed on a flat surface, such as a chest of
drawers, desk or shelf, or wall-mount it using the keyhole slots in the
Camera base.
• Make sure that the Camera captures the best view of your baby.
• Real-time analytics work best when the Camera is placed in a central
position and 3.3ft (1m) away from your baby, without dolls lying
around, background noises and obstacles.
3.3ft (1m)

Safety Instructions 9
ENGLISH
• Keep this User’s Guide for future reference.
• Do not cover the Camera with a towel or blanket.
• Never use extension cords with power adapters. Only use the power
adapters provided.
• Test this Camera and all its functions so that you are familiar with it prior to
actual use.
• Do not use the Camera near water.
• Do not place the Camera near a heat source.
• Only use the chargers and power adapters provided. Do not use other
chargers or power adapters as this may damage the device and battery
pack.
• Do not touch the plug contacts with sharp or metal objects.

10 Getting Started
2. Getting Started
2.1 Charging the Smart Nursery Camera
1. Connect the Micro USB plug of the power adapter to the Smart Nursery
Camera and the other end to a suitable electrical outlet.
The LED charging indicator lights up red and the LED status indicator lights
up blue initially, then flashes red.
NOTE
Only use the enclosed power adapter (5V DC / 1500mA) with the Micro USB
plug.
It takes about 6 hours to fully charge the built-in rechargeable battery.
A fully-charged built-in rechargeable battery supports up to 3 hours of video
streaming.
2.2 Powering the Camera On/Off
1. Slide the ON/OFF switch to the ON position.
The LED indicator located at the front of the Camera will light up in blue.
2. Slide the ON/OFF switch to the OFF position to turn off the Camera.
2.3 LED status indicators
Startup state • LED is red and flashing slowly
Ready for connection state • LED is blue and flashing slowly
Cloud connected state • LED is blue and always on
Slide to the ON position to
turn on the Camera
Insert Micro USB plug
LED status indicator
LED charging
indicator

Getting Started 11
ENGLISH
2.4 Charging the Smart Nursery Monitor
1. Connect the Micro USB plug of the power adapter to the Smart Nursery
Monitor and the other end to a suitable electrical outlet.
2. Press and hold the 0POWER ON/OFF button for 2 seconds to turn on the
Smart Nursery Monitor.
NOTE
Only use the enclosed power adapter (5V DC / 1500mA) with the Micro USB
plug.
It takes about 6 hours to fully charge the built-in rechargeable battery.
A fully-charged built-in rechargeable battery supports up to 3 hours of video
streaming.
2.5 Smart Nursery Monitor Stand
Pull out the monitor stand and place the monitor in front of you.
Insert Micro USB plug
0POWER ON/OFF button
Monitor Stand

12 Setting up the Smart Nursery Monitor
3. Setting up the Smart Nursery Monitor
IMPORTANT
The Smart Nursery Monitor only works with Smart Nursery Cameras. You
cannot use the analytic functions with other Motorola Camera models.
3.1 Create a Hubble Account and Pair your Smart Nursery
Monitor with the Smart Nursery Camera
1. Press and hold the 0POWER ON/OFF button for 2 seconds to turn ON
the Smart Nursery Monitor.
2. Tap Get Start to proceed.
3. Select a Wi-Fi Network and tap Continue.
4. Enter your Wi-Fi password and tap Connect.
5. Create a Hubble account.
6. Enter your account information, read through the Terms of Service, then
select "I agree to the Terms of Service" before you tap
Create .
NOTE
If you already have a Hubble App account, please select Already have an
Account? to login.
7. Tap Continue.
8. Plug in and switch on the Camera, then wait for 1 minute for it to initialize.
9. Press and hold the
PAIR button on the underside of the Camera for 3
seconds. You will hear a beep tone, followed by a voice prompt indicating
that the Camera is ready for pairing.
10. Tap
Continue .
The App will search for the Camera.
11. Tap to select the Camera (CameraHD-xxxxxxxxx).
The App will connect with the Camera and complete the registration to
Hubble server.
12. It will take a few minutes for the Camera to connect to your Wi-Fi®network
before showing the connection status.
If connection fails, tap
Retry and repeat the steps starting from step 10.
13. The screen will show the live stream of the paired Camera when pairing is
successful.
Note
Paired devices will remember each other when you power on and off the
devices.

Setting up the Smart Nursery Monitor 13
ENGLISH
3.2 Pair your Smart Nursery Monitor with an additional
Smart Nursery Camera
1. Plug in and switch on the Camera, then wait for 1 minute for it to initialize.
2. Press and hold the PAIR button on the underside of the Camera until you
hear a beep tone, followed by a voice prompt indicating that the Camera is
ready for pairing.
3. Tap to select the Camera (CameraHD-xxxxxxxxx).
The App will connect with the Camera and complete the registration to
Hubble server.
4. It will take a few minutes for the Camera to connect to your Wi-Fi®network
before showing the connection status.
If connection fails, tap
Retry and repeat the steps starting from step 1.
5. The screen will show the live stream of the paired Camera when pairing is
successful.

14 Using the Smart Nursery Monitor
4. Using the Smart Nursery Monitor
Pinch-to-zoom Pinch two fingers together or spread them apart to
adjust the zoom level.
Melody Tap to select one of the 5 pre-set melodies to play
on your Camera.
Two-way
communication
Tap to activate the function.
Tap and hold the round button to speak
through the Camera.
Release the button to listen to the audio feedback
from the Camera.
Photo/Video Tap to take a photo or record a video from
the Camera.
Pan and Tilt Tap to pan right and left, tilt up and down.
Sleep Quality Tap to enter Sleep Quality monitoring to obtain an
overview of the activity level, humidity,
temperature, noise level and more.
Smart Nursery
Wizard
Add Smart Nursery Wizard.
LIVE Tap to return to live streaming screen.
Gallery Tap to view the photos and videos taken from the
Camera, and Expression photos taken via
automatic Expression Detection, and share photos
on social media.
Note
Expression detection runs in the background of
LIVE view automatically.

Using the Smart Nursery Monitor 15
ENGLISH
Tool s Tap to access the tools available on your monitor:
• BabyCalendar
• BabyJournal
• Sleep Quality
• BabyTube
See Section 4.1 for details.
Indicates the battery level and connection signal
strength of the Camera.
Indicates the battery level and Wi-Fi signal
strength of the Monitor.
Camera Settings You can change Camera and Monitor settings by
tapping on the Settings icon.
• Tap
Camera to access the following settings:
- Add Device
- Camera Details (Unpair camera, video
resolution and more)
- Camera Settings (Notification sensitivity for
motion, sound and high/low temperatures)
• Tap
Settings to access the following Monitor
settings:
- WiFi
- Brightness
- Display Turn Off Time
- Sound
- Temperature Unit
- Camera Disconnected Alert
• Tap
Account to access the following settings:
- Email
- Change Password
- Edit Child Profile
- Log out
- Subscription Plan
- Enable or disable disconnection alert

16 Using the Smart Nursery Monitor
4.1 Using the Baby Tools
4.1.1 Automatic Expression Detection and Snapshot Capture
It’s among the notable moments for new parents when their baby smiles or cry.
The automatic expression detection and snapshot capture help you capture
these moments and stores them in the memory. You can then tap on Gallery >
Expression to review photos and tap share button to share them on social sites
like Facebook or Twitter, so that your relatives and friends can share your joy, no
matter how far away they may be.
4.1.2 Baby Calendar
Baby Calendar lets you set up schedules and record events that happened on a
specific date and time. You can switch the calendar between daily or weekly
view.
There are a number of pre-set tasks and events in the calendar. To set up a task
or event, you just need to tap on a task or event and you will be prompted to set
the time, date and more depending on the task or event you have selected.
Food Breast Feeding
Breast Pump
Bottle
Drink
Meal

Using the Smart Nursery Monitor 17
ENGLISH
4.1.3 Baby Journal
Baby Journal is a baby scrapbook that lets you document your baby’s life
through photos, videos and short stories.
You can also share the journal with your family and friends via FacebookTM or
TwitterTM.
4.1.4 Sleep Quality
Sleep Quality monitoring lets you check the activity level of your baby, noise
level, humidity level and temperature over a defined bedtime period. It uses the
Camera to monitor your baby’s activities when he or she is sleeping.
1. After your baby falls asleep in the crib, go to To ols >Sleep Quality menu in
your Smart Nursery monitor.
2. Tap on the Start button and select the time period to start recording sleep
data.
The time period for Sleep Quality monitoring can range from 1 to 12 hours. You
can review your baby’s sleep activity level and find out what keeps your baby
Hygiene Change Diaper
Bath
Brush Teeth
Tr i m N a i l s
Health Baby Growth
Body Temperature
Medicine
Vaccine

18 Using the Smart Nursery Monitor
from sleeping soundly at night, such as high or low temperatures, noise and
humidity levels, so that you can improve your baby’s sleep quality by managing
these environmental conditions.
It also records videos of the top 3 moments with the highest level of activity. You
may watch when your baby kicks off the quilt and when he or she turns upside
down in the crib.
4.1.5 BabyTube
BabyTube features songs and videos clips where your baby can view, listen and
learn new things.

Accessing the Smart Nursery Camera via your Mobile Devices 19
ENGLISH
5. Accessing the Smart Nursery Camera via
your Mobile Devices
Note:
You can only setup via a compatible smartphone or tablet and not via a PC.
5.1 System Requirements
Web Portal
• Windows®7
• Mac OS®10.7
• Chrome™ 24
• Internet Explorer®9
• Safari®6
• Java™ 7
• Firefox®18.0
• Adobe®Flash®Player 15.0
Android™System
• Version 4.2 or above
iPhone®/iPad®iOS
• Version 7.0 or above
Wi-Fi®requirements:
• At least 0.6 Mbps upload bandwidth per camera. Test your Internet speed at:
http://www.speedtest.net/

20 Accessing the Smart Nursery Camera via your Mobile Devices
5.2 Connecting Devices
How does it work?
When a user tries to access the Camera, our secure server authenticates the
user’s identity and permits access to the Camera.
Setup
• Connect the Micro USB plug of the power adapter to the Wi-Fi®Camera
Unit and the other end to a suitable electrical outlet.
• Make sure the power switch is in the ON position.
• The Camera must be within range of the Wi-Fi®router with which you want
to connect.
• Make sure the password of the router is available for entering during the in-
app setup process.
Note
You can only setup via a compatible smartphone or tablet and not via a PC.
View your Camera
from any
compatible
device remotely.
Smart Nursery
Camera
Wi-Fi®Router
Hubble
Server
