Motorola MBP854CONNECT User manual

MODELS:
MBP854CONNECT
MBP854CONNECT-2
MBP854CONNECT-3
MBP854CONNECT-4
QUICK START GUIDE
For a full explanation of all features and instructions, please refer to the User’s Guide.
1. Setting up your Digital Video Baby Monitor
ON OFF
Connect the micro USB plug of the power adapter to the Baby Unit and the
other end to a suitable electrical outlet.
Only use the enclosed adapter (5V DC/1500mA). Ensure the ON/OFF switch is
at "ON" position.
A. Connecting power supply for the Baby Unit
Switch to turn ON the camera
Power adapter plug
Connect the micro USB plug of the power adapter to the parent unit and the
other end to a suitable electrical outlet.
Only use the enclosed adapter (5V DC/1500mA). Recommend charging at
least 16 hours before first use.
B. Connecting the power supply for the Parent Unit
WARNING:
Strangulation Hazard: Children have STRANGLED in cords. Keep this cord out of the reach of children (more than 3ft (1m) away).
Never use extension cords with AC Adapters. Only use the AC Adapters provided.

Download the Hubble for Motorola Monitors App from the App Store for iOS®
devices or from the Google PlayTM Store for Android TM devices.
A. Install Hubble for Motorola Monitors App.
3. Setting up the Camera Unit for Wi-Fi
®
Internet Viewing
2. Basic operation of the keys
Parent Unit
0ON/OFF button Press and hold to switch on/off the Unit.
+- UP/DOWN buttons Press to tilt the camera upward or downward. Press to adjust menu settings.
<> LEFT/RIGHT buttons Press to pan the camera left or right. Press to access different menu options.
MMENU button Press to open menu options or exit.
OOK button Press to confirm a selection.
VIDEO button Press to turn on/off the LCD display.
TTALK button Press and hold to talk to your baby.
Volume button Press -/+ to select volume level.
RESET button Press and hold with small pin for resetting the unit.
Baby Unit
ON/OFF switch Push power switch to the right to switch on the Unit. Push power switch to the left to switch off the Unit.
V

4. Customer Support
If you are experiencing any issues with your Motorola Digital Video Baby Monitor, you can contact
our customer support team.
US and Canada 1-888-331-3383
Email: [email protected]
or visit our help section on our website www.motorola.com
Manufactured, distributed or sold by Binatone Electronics International LTD., official licensee for this product.
MOTOROLA and the Stylized M logo are trademarks or registered trademarks of Motorola Trademark Holdings,
LLC. and are used under license. Apple logo and Safari are trademarks of Apple Inc., registered in the U.S. and
other countries. App Store is a service mark of Apple Inc. Google Play, Android, and Chrome are trademarks of
Google Inc. Wi-Fi is a trademark of the Wi-Fi Alliance. Internet Explorer and Windows are trademarks of the
Microsoft group of companies. Firefox is a registered trademark of the Mozilla Foundation. Adobe and Flash are
either registered trademarks or trademarks of Adobe Systems Incorporated. Java is a registered trademark of
Oracle and/or its affiliates. All other trademarks are the property of their respective owners. © 2014 Motorola
Mobility LLC. All rights reserved.
Printed in China
EN_US Version 5.0
1. Run the Hubble App on your compatible smartphone or tablet.
2. Follow the in-app instructions to create your Hubble account.
3. Log in to your account on your compatible smartphone, tablet or via
https://app.hubbleconnected.com/#login on your PC to access your live
camera stream.
B. View on Compatible Smartphones, Tablets and Computers.
Wi-Fi®Camera Connect to Internet
via Wi-Fi®
Compatible
Viewing Devices
Please take note of the following minimum system requirements:
Smartphones/Tablets: iOS 7, Android™ 4.2 PC (if used for viewing): Windows®7, Mac OS®10.7, Chrome™ 24, Internet Explorer®9, Safari®6,
Firefox®18, Adobe®Flash®15, Java™ 7
