Motorola MBP853CONNECT User manual

QUICK START GUIDE
For a full explanation of all features and instructions, please refer to the User’s Guide.
1. Setting up your Digital Video Baby Monitor
MODELS:
MBP853CONNECT
MBP853CONNECT-2
MBP853CONNECT-3
MBP853CONNECT-4
WARNING:
Strangulation Hazard:
Children have
STRANGLED in cords.
Keep this cord out of the
reach of children (more
than 1m (3ft) away).
Never use extension
cords with AC Adapters.
Only use the AC Adapters
provided.
Connect the small plug of
the power adapter to the
Baby Unit and the other end
to a suitable mains power
socket
Only use the enclosed
adapter (5V DC/1500mA).
Ensure the ON/OFF switch
is at "ON" position.
A. Connecting power supply for
the Baby Unit.
ON OFF
Power
adapter plug
Switch to turn ON
the camera
Insert the wire tab of the
rechargeable battery
pack into the contact slot
as shown above and fit
the battery pack into the
compartment.
B. Installing the battery pack for the Parent Unit.
Red
Black
Small cross head or Flat
end screw driver
C. Fastening the cover for the Parent Unit.
D. Connecting the power supply for the Parent Unit.
Connect the small plug of
the power adapter to the
parent unit and the other
end to a mains power
socket.
Only use the enclosed
adapter (5V DC / 600mA).
Recommend charging
time of at least 16 hours
before first use.

2. Basic operation of the keys
Parent Unit
0ON/OFF button Press and hold to switch on/off the Unit.
+- UP/DOWN buttons Press to adjust menu settings or volume level.
<> LEFT/RIGHT buttons Press to access different menu options or brightness
level.
MMENU button Press to open menu options or exit.
OOK button Press to confirm a selection.
VIDEO button Press to turn on/off the LCD display.
TTALK button Press and hold to talk to your baby.
Baby Unit
ON/OFF switch Push power switch to the right to switch on the Unit.
Push power switch to the left to switch off the Unit.
V
3. Setting up the Camera Unit for Wi-Fi
®
Internet Viewing
Download the Hubble for Motorola Monitors App from the
App Store for iOS devices or from the Google PlayTM Store
for AndroidTM devices.
A. Install Hubble for Motorola Monitors App.

1. Open the Hubble for Motorola Monitors app on your compatible smartphone or tablet.
2. Follow the in-app instructions to create your Hubble account and connect to your Wi-Fi®
Camera.
3. Log in to your account on your compatible smartphone, tablet or via
https://app.hubbleconnected.com/#login on your PC to access your live camera stream.
B. View on Compatible Smartphones, Tablets and Computers.
Wi-Fi®Camera Connect to Internet
via Wi-Fi®
Compatible
Viewing Devices
Please take note of the following minimum system requirements:
Smartphones/Tablets: iOS 7, Android™ 4.2
PC (only for viewing – NOT setup): Windows
®
7, Mac OS
®
10.7, Chrome™ 24, Internet Explorer
®
9,
Safari
®
6, Firefox
®
18, Adobe
®
Flash
®
15, Java™ 7
Wi-Fi®requirements:
At least 0.6 Mbps upload bandwidth per camera. Test your Internet speed at:
http://www.speedtest.net/

4. General Information
If your product is not working properly, read this Quick Start Guide or the User’s Guide of one of the
models listed on page 1.
Contact Customer Service:
[phone] (UK only) [phone] (ROI)
Consumer Products and Accessories Limited Warranty ("Warranty")
Thank you for purchasing this Motorola branded product manufactured under license by Binatone
Electronics International LTD ("BINATONE").
What Does this Warranty Cover?
Subject to the exclusions contained below, BINATONE warrants that this Motorola branded product
("Product") or certified accessory ("Accessory") sold for use with this product that it manufactured to
be free from defects in materials and workmanship under normal consumer usage for the period
outlined below. This Warranty is your exclusive warranty and is not transferable.
Who is covered?
This Warranty extends only to the first consumer purchaser, and is not transferable.
What will BINATONE do?
BINATONE or its authorised distributor at its option and within a commercially reasonable time, will
at no charge repair or replace any Products or Accessories that does not conform to this Warranty.
We may use functionally equivalent reconditioned/ refurbished/ pre-owned or new Products,
Accessories or parts.

What Other Limitations Are There?
ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED TO THE
DURATION OF THIS LIMITED WARRANTY, OTHERWISE THE REPAIR OR REPLACEMENT
PROVIDED UNDER THIS EXPRESS LIMITED WARRANTY IS THE EXCLUSIVE REMEDY OF THE
CONSUMER, AND IS PROVIDED IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED. IN
NO EVENT SHALL MOTOROLA OR BINATONE BE LIABLE, WHETHER IN CONTRACT OR TORT
(INCLUDING NEGLIGENCE) FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF THE
PRODUCT OR ACCESSORY, OR FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR
CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS OF REVENUE OR PROFITS, LOSS OF
BUSINESS, LOSS OF INFORMATION OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN
CONNECTION WITH THE ABILITY OR INABILITY TO USE THE PRODUCTS OR ACCESSORIES
TO THE FULL EXTENT THESE DAMAGES MAY BE DISCLAIMED BY LAW.
Some jurisdictions do not allow the limitation or exclusion of incidental or consequential damages, or
limitation on the length of an implied warranty, so the above limitations or exclusions may not apply
to you. This Warranty gives you specific legal rights, and you may also have other rights that vary
from one jurisdiction to another.

Exclusions
Normal Wear and Tear. Periodic maintenance, repair and replacement of parts due to normal wear
and tear are excluded from coverage.
Batteries. Only batteries whose fully charged capacity falls below 80% of their rated capacity and
batteries that leak are covered by this Warranty.
Abuse & Misuse. Defects or damage that result from: (a) improper operation, storage, misuse or abuse,
accident or neglect, such as physical damage (cracks, scratches, etc.) to the surface of the product
resulting from misuse; (b) contact with liquid, water, rain, extreme humidity or heavy perspiration, sand,
dirt or the like, extreme heat, or food; (c) use of the Products or Accessories for commercial purposes
or subjecting the Product or Accessory to abnormal usage or conditions; or (d) other acts which are not
the fault of MOTOROLA or BINATONE, are excluded from coverage.
Use of Non-Motorola branded Products and Accessories. Defects or damage that result from the use
of Non-Motorola branded or certified Products or Accessories or other peripheral equipment are
excluded from coverage.
Products Covered Length of Coverage
Consumer Products One (1) year from the date of the products original purchase by
the first consumer purchaser of the product.
Consumer Accessories Ninety (90) days from the date of the accessories original
purchase by the first consumer purchaser of the product.
Consumer Products and
Accessories that are Repaired or
Replaced
The balance of the original warranty or for Ninety (90) days
from the date returned to the consumer, whichever is longer.

Unauthorised Service or Modification. Defects or damages resulting from service, testing,
adjustment, installation, maintenance, alteration, or modification in any way by someone other than
MOTOROLA, BINATONE or its authorised service centres, are excluded from coverage.
Altered Products. Products or Accessories with (a) serial numbers or date tags that have been
removed, altered or obliterated; (b) broken seals or that show evidence of tampering; (c)
mismatched board serial numbers; or (d) nonconforming or non-Motorola branded housings, or
parts, are excluded from coverage.
Communication Services. Defects, damages, or the failure of Products or Accessories due to any
communication service or signal you may subscribe to or use with the Products or Accessories is
excluded from coverage.
How to Obtain Warranty Service or Other Information?
To obtain service or information, please call:
[phone] (UK only) [phone] (ROI)
You will receive instructions on how to ship the Products or Accessories at your expense and risk, to
a BINATONE Authorised Repair Centre. To obtain service, you must include: (a) the Product or
Accessory; (b) the original proof of purchase (receipt) which includes the date, place and seller of
the Product; (c) if a warranty card was included in your box, a completed warranty card showing the
serial number of the Product; (d) a written description of the problem; and, most importantly; (e)
your address and telephone number.

These terms and conditions constitute the complete warranty agreement between you and
BINATONE regarding the Products or Accessories purchased by you, and supersede any prior
agreement or representations, including representations made in any literature publications or
promotional materials issued by BINATONE or representations made by any agent, employee or
staff of BINATONE, that may have been made in connection with the said purchase.
CE DECLARATION
This product is in compliance with the essential requirements and other relevant provisions of the
R&TTE directive 1999/5/EC.
Download User Guide from website: www.motorolahome.com
Manufactured, distributed or sold by Binatone Electronics International LTD., official licensee
for this product. MOTOROLA and the Stylised M logo are trademarks or registered trademarks
of Motorola Trademark Holdings, LLC. and are used under license. Apple logo and Safari are
trademarks of Apple Inc., registered in the U.S. and other countries. App Store is a service mark
of Apple Inc. Google Play, Android, and Chrome are trademarks of Google Inc. Wi-Fi is a
trademark of the Wi-Fi Alliance. Internet Explorer and Windows are trademarks of the
Microsoft group of companies. Firefox is a registered trademark of the Mozilla Foundation.
Adobe and Flash are either registered trademarks or trademarks of Adobe Systems
Incorporated. Java is a registered trademark of Oracle and/or its affiliates. All other trademarks
are the property of their respective owners. © 2015 Motorola Mobility LLC. All rights reserved.
Printed in China
UK_EN Version 5.0
