Motorola I700 User manual

Motorola
iDEN®
Digital Multi-Service Phone
i700plusPhone User’s Guide

TTY Access
TTY access is available on your phone. See the Wireless Data Services User’s
Guide for complete instructions.
Large-Print Manuals
A large-print version of your user’s guide is available. For information on
Motorola products for people with disabilities, contact Motorola Customer Care
at 1-800-453-0920 or TTY 1-877-483-2840.
Patent & Trademark Information
This product is protected under one or more of the following patents:
4817157, 4896361, 4857928, 5041793, 5060294, 5066923, 5134718, 5140156,
5239963, 5257411, 5287387, 5265219, 5289504, 5316168, 5317247, 5338396,
5389927, 5406588, 5424921, 5457376, 5460906, 5551063, 5557079, 5596487,
5615412, 5638403, 5559468, 5469465, 5170413, 5140615, 5519730, 5241544,
5584059, 5574992, 5396656, 5487091, 5533004, 5299199, 5343499, 5369501,
5509031, 5515379, 5528723, 5598417, 5066923, 5241650, 5278833, 5359696,
5548631, 5410632, 5440582, 5457735, 5457818, 5471670, 5477550, 5481537,
5566181, 5229767, 5208804, 5295140, 5381449, 5440590, 5467398, 5490230,
5620242, 5623523, 5655913, 5715240, 5771440, 5854578, 5675281, 5721787,
5729539, 5788523, 5869204, 5911124, 5946620, 5949774, 5949821, 5951317,
5987332, 6002948
Additional patents are pending.
MOTOROLA, the stylized M and all other trademarks indicated as such herein
are trademarks of Motorola, Inc. ®Reg. U.S. Pat. & Tm. Off.
© 2000, Motorola, Inc. All rights reserved.
Manufactured under one or more of the U.S. patents listed in the User Guides.
T9 is a trademark owned by Tegic Communications, Inc.
All other product or service names are the property of their respective trademark
owners.
Important!
Be sure to read “Safety and General Information”on page
66 before using your phone.
