Welcome
Greetings upon receiving your LEX 700 Mission Critical Handheld device. This state-of-the-art Windows®
Mobile 6.5 based device delivers many features and benefits in a mission critical environment, enabling
enhanced communication on the move.
Meet the LEX 700
The LEX 700 combines high-speed LTE data and phone services, in a rugged and intuitive device which
helps to monitor the environment, and gather information effectively.
With the LEX 700, mission critical data can be brought to the field on demand, while field information is
immediately available back at the command center.
The LEX 700 operates over Band 14 (Public Safety) LTE, Band 13 (Verizon Wireless) LTE, 3G cellular,
Wi-Fi®and uses Bluetooth®and Mission Critical Wireless technology to create personal area networks.
The LEX 700 can be used to remotely change volume and channels on an APX®7000 radio, without
reaching for the radio. Push-To-Talk and Quick Action buttons can be used to notify a dispatcher or
command staff that the user needs assistance.
The device provides secure data exchange as a user roams across private and public networks, with a
mobile VPN connection.
The device has a 4-inch, high-resolution, capacitive touch screen that enables the user to easily read
maps and blueprints and to watch vibrant video. Noise-canceling technology is used to capture clear
audio from the incident scene and the 8 megapixel camera is capable of recording DVD-quality video.
For detailed information on the LEX 700 features and operation, refer to the LEX 700 User’s Guide p/n
6802988C27 at: motorolasolutions.com/LEX700. BEFORE USING THIS device, READ the Product
Regulatory, Safety & RF Exposure Guide (p/n 6802988C25) included with this package.
700 Quick Start Guide.fm Page 4 Thursday, May 31, 2012 1:20 PM

5
Getting Started for the First Time
The activation process is dependent upon your
carrier. If you are using a LTE carrier, you must
install a SIM card prior to installing the battery.
To get started, perform the following steps:
• Remove the battery cover.
• Install the microSD card (optional).
• Install the LTE SIM card.
• Install the battery.
• Charge the battery.
Remove the Battery Cover
To remove the battery cover:
1. Hold the LEX 700 firmly as shown.
2. Move the Battery Cover Latch to the right and
hold.
3. With your thumb, push the battery cover toward
the lower side of the LEX 700.
4. Lift the battery cover off the LEX 700.
AB
1
2
Battery Cover Latch
700 Quick Start Guide.fm Page 5 Thursday, May 31, 2012 1:20 PM

6
Install a microSD Card (Optional)
1. Slide the microSD Card Holder to Open.
2. Lift the microSD Card Holder.
3. Place the microSD card onto the holder with
contacts facing down and ensure that the SIM
card is fully seated and flat.
4. Close the microSD Card Holder.
5. Slide the microSD Card Holder to Lock.
Install a SIM Card
1. Slide the SIM Card Holder to Open.
2. Open the SIM Card Holder.
3. Slide the SIM Card onto the SIM Card Holder
with the contacts facing down. Note the Card
Notch position.
4. Close the SIM
Card Holder
and ensure that
the SIM card is
fully seated and
flat.
5. Slide the SIM
Card Holder to Lock.
12
microSD Card Holder Location
Open
3
4
Lock
5
1 23
SIM Card Holder Location
Card
Notch
Open
45
Lock
700 Quick Start Guide.fm Page 6 Thursday, May 31, 2012 1:20 PM

7
Install the Battery
1. Remove the battery from the packaging.
2. Locate the Battery Contacts.
3. Insert the battery into the battery compartment
with the Battery Contacts facing down.
4. Press the top of battery into place.
5. Slide the Battery Lock Latch up to secure the
battery.
6. Replace the battery cover - the LEX 700 starts.
NOTE: The LEX 700 will not charge until the
battery cover is locked in place.
Remove the Battery
To remove the battery:
1. Remove the Battery Cover (see page 5).
2. Slide the Battery Lock Latch down to unlock the
battery.
3. With the tip of your finger, lift up the battery from
the side closest to the lower side of the LEX
700.
AB
Battery Contacts Side
Battery Lock Latch
1
2
Lock
Unlock
AB
3
700 Quick Start Guide.fm Page 7 Thursday, May 31, 2012 1:20 PM

8
Charge the Battery
To charge the battery:
1. Install the plug head into the USB Charger.
2. Plug the supplied USB Cable into the rectangu-
lar slot in the USB Charger.
3. Plug the USB Charger into an AC wall outlet.
4. Lift the rubber flap that covers the USB port on
the side of the LEX 700.
5. Plug the microUSB connector into the USB port.
6. The Charge LED slowly blinks amber, indicating
that the battery is charging. When the battery is
fully charged, the LED becomes solid green.
NOTE: For charging indications, see page 11.
B
Charge LED
USB Charger
USB Cable
Plug Head
700 Quick Start Guide.fm Page 8 Thursday, May 31, 2012 1:20 PM

9
The Keys
• Home: Press briefly to minimize all active appli-
cations and return to the Home screen.
• Phone: Press to launch the phone dialer screen
with the last called contact in the dialer.
• Programmable Button: This programmable but-
ton is customized by your agency for a specific
use. Contact your system administrator for
details.
• Back/OK: Press to return to the previous screen.
In a Windows message, press to send a mes-
sage. In the Home Screen, press briefly to flip
cards.
Power On/Off and Suspend
Use the Power button for the following operations:
Power Off
To power off:
1. Press and hold the Power button for at least
two seconds.
2. When the dialog box appears, tap Power Off.
Power On
To power on:
Press and hold the Power button for at least two
seconds.
Suspend
To toggle between Suspend and On:
Press and release the Power button.
PhoneHome Programmable Button Back/OK
B
Power Button
700 Quick Start Guide.fm Page 9 Thursday, May 31, 2012 1:20 PM

10
Lock/Unlock the LEX 700
Lock the device to protect your information and to
prevent unwanted key presses.
You can set the Lock to access the device with or
without a password.
To lock the LEX 700:
1. Press the Power but-
ton for at least two sec-
onds.
2. Select Lock.
When the LEX 700 is
locked, you will still be
notified of new mes-
sages, missed calls
and incidents.
To unlock the LEX 700:
Swipe your finger across
the screen from left to
right.
NOTE: A PIN may also be required to unlock your
device.
Covert Mode
In Covert mode, all audio is routed to your
headset. Sound, vibrating, LED indications and
the screen remain off. The display is blacked out,
the touch screen is disabled.
To enter Covert mode:
1. Press and hold the
Power button for at
least two seconds.
2. When the dialog box
appears, tap Covert.
You can also slide your
finger on the Home
screen to the Mode card
and tap Covert.
To exit Covert mode:
1. Press and hold the
Power button for at
least three seconds and release.
2. Select Exit Covert Mode.
