Motorola DCH200 User manual

USER GUIDE
DCH200
Standard-Definition All-Digital
Cable Receiver

i
IMPORTANT SAFETY INSTRUCTIONS
•Read these instructions.
•Keep these instructions.
•Heed all warnings.
•Follow all instructions.
•Do not use this apparatus near water.
•The apparatus shall not be exposed to dripping or splashing and no
objects filled with liquids, such as vases, shall be placed on the
apparatus.
•Clean only with dry cloth.
•Do not block any ventilation openings. Install in accordance with
the manufacturers instructions.
•Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
•Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the
other. A grounding type plug has two blades and a third grounding
prong. The wide blade or the third prong is provided for your
safety. If the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
•Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point where
they exit from the apparatus.
•Only use attachments/accessories specified by the manufacturer.
•Unplug this apparatus during lightning storms or when unused for
long periods of time.
•Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way, such
as the power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate normally, or
has been dropped.

ii
IMPORTANT SAFETY CONSIDERATIONS
Be sure to follow these requirements during transportation and
installation.
The plug is the mains disconnect device. It shall remain readily
accessible and operable.
During Transportation to the Subscriber Home
Transport the cable terminal in its shipping box or an equally padded
container.
Do not expose the terminal to rain or moisture.

iii
During Installation
Do not place the cable terminal in an enclosed area where the
cooling vents are blocked or impede the flow of air through the
ventilation openings.
Install the terminal so that its position does not interfere with its
proper ventilation. For example, do not place the terminal on a bed,
sofa, rug, or similar surface that could block the ventilation
openings.
Install the terminal away from heat sources such as radiators, heat
registers and stoves. Installation of the terminal near consumer
electronics devices, such as stereo receiver/amplifiers and
televisions, is permitted as long as the air surrounding the terminal
does not exceed 40 ºC (104 ºF).
Place the terminal on a flat surface not prone to vibration or impact.
Do not install the terminal in an area where condensation occurs.
To prevent the temporary loss of guide data and cause a
temporarily non-responding terminal, do not plug the AC power
cord into a switched power outlet.
FCC COMPLIANCE
Note: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.

iv
Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Caution: Changes or modifications not expressly approved by Motorola
for compliance could void the user’s authority to operate the
equipment.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
FCC DECLARATION OF CONFORMITY
Motorola Inc., Connected Home Solutions, 101 Tournament Drive,
Horsham, PA 19044, 1-215-323-1000, declares that the DCH200
receiver complies with 47 CFR Parts 2 and 15 of the FCC rules as a
Class B digital device.
Canada Industry Canada (IC)
This Class B digital device complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-
003 du Canada.
CARING FOR THE ENVIRONMENT BY RECYCLING
When you see this symbol on a Motorola product, do not
dispose of the product with residential or commercial
waste.
Recycling your Motorola Equipment
Please do not dispose of this product with your residential
or commercial waste. Some countries or regions, such as
the European Union, have set up systems to collect and
recycle electrical and electronic waste items. Contact your
local authorities for information about practices
established for your region. If collection systems are not
available, call Motorola Customer Service for assistance.

v
Software License
IMPORTANT: PLEASE READ THIS SOFTWARE LICENSE (“LICENSE”)
CAREFULLY BEFORE YOU USE ANY SOFTWARE, FIRMWARE AND
RELATED DOCUMENTATION (“SOFTWARE”) PROVIDED WITH
MOTOROLA’S DIGITAL CABLE RECEIVER OR HOME THEATER
SYSTEM (EACH SHALL BE REFERRED TO IN THIS LICENSE AS A
“RECEIVER”). BY USING THE RECEIVER AND/OR USING ANY OF THE
SOFTWARE, YOU INDICATE YOUR ACCEPTANCE OF EACH OF THE
TERMS OF THIS LICENSE. UPON ACCEPTANCE, THIS LICENSE WILL
BE A LEGALLY BINDING AGREEMENT BETWEEN YOU AND
MOTOROLA. THE TERMS OF THIS LICENSE APPLY TO YOU AND TO
ANY SUBSEQUENT USER OF THIS SOFTWARE.
IF YOU DO NOT AGREE TO ALL OF THE TERMS OF THIS LICENSE (I)
DO NOT USE THE SOFTWARE AND (II) RETURN THE RECEIVER AND
THE SOFTWARE (COLLECTIVELY, “PRODUCT”), INCLUDING ALL
COMPONENTS, DOCUMENTATION AND ANY OTHER MATERIALS
PROVIDED WITH THE PRODUCT, TO YOUR POINT OF PURCHASE
OR SERVICE PROVIDER, AS THE CASE MAY BE, FOR A FULL
REFUND.
The Software includes associated media, any printed materials, and any
“on-line” or electronic documentation. Software provided by third
parties may be subject to separate end-user license agreements from
the manufacturers of such Software. The Software is never sold.
Motorola licenses the Software to the original customer and to any
subsequent licensee for personal use only on the terms of this License.
Motorola and its third party licensors retain the ownership of the
Software.
You may:
USE the Software only in connection with the operation of the Product.
TRANSFER the Software (including all component parts and printed
materials) permanently to another person, but only if the person agrees
to accept all of the terms of this License. If you transfer the Software,
you must at the same time transfer the Product and all copies of the
Software (if applicable) to the same person or destroy any copies not
transferred.
TERMINATE this License by destroying the original and all copies of the
Software (if applicable) in whatever form.

vi
You may not:
(1) Loan, distribute, rent, lease, give, sublicense or otherwise transfer
the Software, in whole or in part, to any other person, except as
permitted under the TRANSFER paragraph above. (2) Copy or translate
the User Guide included with the Software, other than for personal use.
(3) Copy, alter, translate, decompile, disassemble or reverse engineer
the Software, including but not limited to, modifying the Software to
make it operate on non-compatible hardware. (4) Remove, alter or
cause not to be displayed, any copyright notices or startup message
contained in the Software programs or documentation. (5) Export the
Software or the Product components in violation of any United States
export laws.
The Product is not designed or intended for use in on-line control of
aircraft, air traffic, aircraft navigation or aircraft communications; or in
design, construction, operation or maintenance of any nuclear facility.
MOTOROLA AND ITS THIRD PARTY LICENSORS DISCLAIM ANY
EXPRESS OR IMPLIED WARRANTY OF FITNESS FOR SUCH USES.
YOU REPRESENT AND WARRANT THAT YOU SHALL NOT USE THE
PRODUCT FOR SUCH PURPOSES.
Title to this Software, including the ownership of all copyrights, mask
work rights, patents, trademarks and all other intellectual property
rights subsisting in the foregoing, and all adaptations to and
modifications of the foregoing shall at all times remain with Motorola
and its third party licensors. Motorola retains all rights not expressly
licensed under this License. The Software, including any images,
graphics, photographs, animation, video, audio, music and text
incorporated therein is owned by Motorola or its third party licensors
and is protected by United States copyright laws and international
treaty provisions. Except as otherwise expressly provided in this
License, the copying, reproduction, distribution or preparation of
derivative works of the Software, any portion of the Product or the
documentation is strictly prohibited by such laws and treaty provisions.
Nothing in this License constitutes a waiver of Motorola’s rights under
United States copyright law.
This License and your rights regarding any matter it addresses are
governed by the laws of the Commonwealth of Pennsylvania, without
reference to conflict of laws principles. THIS LICENSE SHALL
TERMINATE AUTOMATICALLY if you fail to comply with the terms of
this License.
Motorola is not responsible for any third party software that is provided
as a bundled application, or otherwise, with the Software or that is
downloaded to, or otherwise installed on, the Product.

vii
U.S. GOVERNMENT RESTRICTED RIGHTS
The Product and documentation is provided with RESTRICTED RIGHTS.
The use, duplication or disclosure by the Government is subject to
restrictions as set forth in subdivision (c)(1)(ii) of The Rights in Technical
Data and Computer Software clause at 52.227-7013. The
contractor/manufacturer is Motorola, Inc., Connected Home Solutions,
101 Tournament Drive, Horsham, PA 19044.
© 2007 Motorola, Inc. All rights reserved. MOTOROLA and the Stylized
M logo are registered in the US Patent and Trademark Office.
CableCARD and M-Card are trademarks or registered trademarks of
Cable Television Laboratories, Inc. Dolby is a trademark of Dolby
Laboratories. Macrovison is a registered trademark of Macrovision
Corporation. All other product or service names are the property of their
respective owners.
No part of this publication may be reproduced in any form or by any
means or used to make any derivative work (such as translation,
transformation, or adaptation) without written permission from
Motorola, Inc.
Motorola reserves the right to revise this publication and to make
changes in content from time to time without obligation on the part of
Motorola to provide notification of such revision or change. Motorola
provides this guide without warranty of any kind, implied or expressed,
including, but not limited to, the implied warranties of merchantability
and fitness for a particular purpose. Motorola may make improvements
or changes in the product(s) described in this manual at any time.

CONTENTS
viii
CONTENTS
1 Introduction...................................................................................................1
Front Panel ................................................................................................2
Rear Panel.................................................................................................3
2 Operation .......................................................................................................4
Turning Power On and Off.......................................................................4
Changing Channels..................................................................................4
Adjusting the Volume...............................................................................4
Interactive Program Guide .....................................................................4
M-Card™ ...................................................................................................5
3 Connecting Your DCH receiver...................................................................6
Connecting Your DCH Receiver to an A/V Receiver (Audio Only) ....7
Video Connection Options ......................................................................9
Connecting Your DCH Receiver to a Standard-Definition Stereo
TV.........................................................................................................10
Connecting Your DCH Receiver to a Stereo SDTV and Stereo VCR
.............................................................................................................12
Connecting Your DCH Receiver to an A/V Receiver, Stereo SDTV,
and Stereo VCR .................................................................................13
4 Recording Your Connections ......................................................................15
5 Data Features................................................................................................16
6 Troubleshooting ............................................................................................17

1 INTRODUCTION
1
1 INTRODUCTION
Congratulations on receiving a Motorola DCH200
Standard-Definition Cable Receiver. This User Guide
introduces you to the product’s basic features, outlines
important safeguards, and provides several options for
integrating this component into your current entertainment
system. Please take a few moments to read through this
User Guide as the configuration diagrams, on-screen menu
description, and troubleshooting section will help you
make the most of your home entertainment experience.
To determine which features of digital cable are provided in
your service area, please check with your local cable
operator. They will be happy to provide instructions for
these optional services.

1 INTRODUCTION
2
Front Panel
1 Power Indicator — Lit when the unit is powered ON, unlit when unit is
OFF
2 Message Indicator* — Lit when a new message is waiting to be read,
unlit otherwise

1 INTRODUCTION
3
Rear Panel
1 RF In — Connects to cable signal from your service provider
2 RF Out — Ch 3/4 modulated audio/video (SDTV) to TV or VCR
3, 5 Digital Audio (S/PDIF) — Provides Dolby®Digital 5.1 audio or PCM output
4 S-Video — Connects to S-Video (SDTV) input of TV or VCR
6, 7 Video/Audio Out — Composite video (SDTV)/audio outputs
8 USB* 1.1 — High-speed peripheral device connection
9 Serial — Service only
10 External IR connector
11 Power supply connector
12 M-Card — Inserted M-Card
*The availability of certain features is dependent upon
application support.

2 OPERATION
4
2 OPERATION
Turning Power On and Off
Press POWER on the remote control to turn the DCH
receiver on or off (standby). When using the remote
control, be sure it is in cable mode by pressing CABLE
before pressing POWER.
Changing Channels
You can change channels in three ways:
•Press channel + or – on the remote control to step
through the channel selection.
•Enter the number of the channel you wish to view
using the number keys on the remote control.
•Select the channel in the interactive program guide.
Adjusting the Volume
Press volume + or – on the remote control to adjust the
volume. When you adjust the volume, the volume scale is
displayed on the screen. Press mute on the remote
control to toggle the sound on and off.
For best audio quality, use the remote control to set the
DCH receiver to approximately three quarters of the
maximum volume level and then adjust the audio levels on
external devices such as your TV or A/V receiver.
Interactive Program Guide
The interactive program guide displays information about
TV programs and enables you to access features such as
Parental Control or Pay-Per-View. Interactive program
guides can vary with each cable service provider. Refer to

2 OPERATION
5
the interactive program guide instruction manual for
detailed instructions.
M-Card™
The M-Card is required to view cable television programs,
previously recorded programs on the DVR, or interactive
on-demand programs. The M-Card should not be removed.

3 CONNECTING YOUR DCH RECEIVER
6
3 CONNECTING YOUR DCH RECEIVER
Instructions and diagrams are included for the following
connections:
•A/V receiver (audio only)
•Stereo standard-definition TV (SDTV) (audio and video)
•Stereo SDTV and stereo VCR (audio and video)
•A/V receiver, SDTV, and VCR (audio and video)
Before you move or change components on your
entertainment system, review the following:
•For basic cable connections, use 75-ohm coaxial cables
equipped with F-type connectors.
•Disconnect power from your equipment before
connecting or changing cable connections.
CAUTION!
Do not place anything on top of your DCH receiver, especially other
home entertainment components. Be sure to provide adequate
ventilation to prevent overheating.

3 CONNECTING YOUR DCH RECEIVER
7
Connecting Your DCH Receiver to an A/V Receiver
(Audio Only)
There are three options available for audio connections to
your A/V receiver:
•Digital audio (OPTICAL S/PDIF) — optical and coaxial
•Digital audio (COAXIAL S/PDIF) — optical and coaxial
•Stereo audio (AUDIO L and R)
If your A/V receiver supports it, the optical S/PDIF or
coaxial S/PDIF audio outputs offer a higher level of audio
quality, including support for Dolby Digital 5.1 audio, than
the stereo audio outputs (AUDIO L and R).

3 CONNECTING YOUR DCH RECEIVER
8
Note: Only one audio connection is necessary.

3 CONNECTING YOUR DCH RECEIVER
9
Video Connection Options
The DCH receiver offers several different video connection
options. Composite video, S-Video, and RF coaxial
connections allow you to view standard-definition TV
programming. To determine whether your TV features RF
coaxial, S-Video or composite video, check the manual
supplied with your TV.
Use the guidelines below to determine the best video
connection for your home entertainment system.
•Use S-Video connections if your TV has an S-Video
input.
•If S-Video is not available, use the composite video
connection.
•If your TV has neither S-Video nor composite video
inputs, use the RF Output connection and set your TV
to channel 3 or 4.

3 CONNECTING YOUR DCH RECEIVER
10
Connecting Your DCH Receiver to a Standard-Definition Stereo TV
DCH200
RF IN
RF OUT
S VIDEO-VIDEO
AUDIO
USB SERIAL
EXT IR
POWER
R
L
DIGITAL
AUDIO
M CARD DEVICE ONLY-™
CABLE/
ANTENNA IN
INPUT
S-VIDEO
VIDEO
AUDIO LEFT
AUDIO RIGHT
Standard-Definition
stereoTV
either / or
L/R audio
connection
S-video
connection
Video
connection
(composite)
Cable in
Note: If your equipment supports it:
•The digital audio optical (optical S/PDIF) or digital audio
coaxial (S/PDIF) audio outputs may be used in place of
the stereo audio outputs (AUDIO L and R). In most
cases these outputs offer a higher level of audio
quality, including support for Dolby Digital 5.1 audio,
than stereo audio.
