1 Introduction
The Motorola RFS4010 RF Switch is a member of Motorola’s RFS Series Wireless Switch family. The
RFS4010 RF Switch provides centralized Wireless LAN (WLAN) configuration and management by
coalescing a network “intelligence” previously spread across physically distributed access points.
The RFS4010 simplifies deployment of a Wired/Wireless 802.11 a/b/g/n network, for a SME/SMB.
With the integrated Layer 2/Layer 3 Networking Services such as integrated Layer 2 Switching with
PoE+ ports, Onboard DHCP Server, Security Services like Wired/Wireless Firewall, Wireless IDS/IPS,
Onboard AAA Server and IPSEC VPN Gateway, and QoS mechanisms to support Voice & Video , the
RFS4000 transforms the enterprise by delivering a SMART Branch. The RFS4010 RF Switch is the
WLAN’s point of management reducing wireless networking complexity by moving management out
of the ceiling and into the wiring closet. The RFS4010 can adopt upto 6 Adaptive APs or Thin Access
Points and does not require any additional licenses at this time, for AP adoption.
This document is written for the network device installer.
1.1 Package Contents
Inspect the package contents and report any missing or damaged items to your sales representative.
The package should contain the following:
• RFS4010 RF Switch
• Console Cable
•Installation Guide (this document)
• Rubber Feet
• Power Supply Unit (Motorola Part Number: 50-14000-244R)
1.2 Document Conventions
The following graphical alerts are used in this document to indicate notable situations:
NOTE Tips, hints, or special requirements that you should take note of.
CAUTION Care is required. Disregarding a caution can result in data loss or
equipment malfunction.
!

RFS4010 RF Switch: Installation Guide
2
1.3 Warnings
•Read all installation instructions and site survey reports, and verify correct equipment installation before connecting
the system to its power source.
•Remove jewelry and watches before installing this equipment.
•Install the equipment in a rack or on a desktop with adequate dimensions and weight allowances.
•Verify the unit is grounded before connecting it to the power source.
•Verify any device connected to this unit is properly wired and grounded.
•Connect all power cords to a properly wired and grounded electrical circuit.
•Verify the electrical circuits have appropriate overload protection.
•Motorola strongly recommends the use of an Uninterruptible Power Supply (UPS) that supports the RFS4010 RF
Switch power rating. Not using a UPS can result in data loss or equipment damage due to a power surge or power
failure.
•Verify that the power connector and socket are accessible at all times during the operation of the equipment.
•Do not work with power circuits in dimly lit spaces.
•Do not install this equipment or work with its power circuits during thunderstorms or other weather conditions that
could cause a power surge.
•Verify there is adequate ventilation around the device, and ambient temperatures meet equipment operation
specifications.
•This product is designed for in building installation only and is not intended to be connected to exposed (outside
plant) networks.
1.4 Site Preparation
•Consult your site survey and network analysis reports to determine specific equipment placement, port capacity,
power drops, and so on.
•Assign installation responsibility to the appropriate personnel.
•Identify where all installed components are located.
•Verify appropriate rack mounting requirements, as required.
•Provide a sufficient number of power drops for your equipment.
•Ensure adequate, dust-free ventilation to all installed equipment.
•Identify and prepare Ethernet and console port connections.
•Verify that cable lengths are within the maximum allowable distances for optimal signal transmission.
•Verify that the RFS4010 RF Switch is powered through an Uninterruptible Power Supply (UPS).
WARNING! Indicates a condition or procedure that could result in personal injury or
equipment damage.

Specifications 3
2 Specifications
2.1 Physical Specifications
2.2 Power Cord Specifications
A power supply is included, however a power cord is not supplied with the switch. Use only a
correctly rated power cord certified (as appropriate) for the country of operation.
2.2.1 Power Protection
•If possible, use a circuit dedicated to data processing equipment. Commercial electrical
contractors are familiar with wiring for data processing equipment and can help with the load
balancing of these circuits.
•Install surge protection. Be sure to use a surge protection device between the electricity
source and the RFS4010 RF Switch.
•Install an Uninterruptible Power Supply (UPS). A UPS provides continuous power during a
power outage. Some UPS devices have integral surge protection. UPS equipment requires
periodic maintenance to ensure reliability. A UPS of the proper capacity for the data processing
equipment must be purchased.
Width 304.8mm (12.0in)
Height 44.45mm (1.75 in) 1 RU
Depth 254mm (10.0 in)
Weight 2.15 Kg (4.75 lbs)
Operating Temperature 0°C - 40°C (32°F - 104°F)
Operating Humidity 5% - 85% RH, non-condensing
Operating Altitude 10,000 ft @ 28deg C < 15% Relative Humidity

RFS4010 RF Switch: Installation Guide
4
3 LED Codes
The RFS4010 RF Switch has four vertically-stacked LEDs on its front panel. Each of the six Gigabit
Ethernet Ports have two status LEDs. These LEDs display two colors (green & amber), and three lit
states (solid, blinking, and off). The following tables decode the combinations of LED colors and
states for the System Status LEDs and the Gigabit Ethernet LEDs.
3.1 System Status LEDs
SYS
1
2
System Status 1
System Status 2
Fan status
Temperature status

LED Codes 5
3.1.1 Start Up / POST (Primary System or Redundant System)
System Status 1 LED System Status 2 LED Event
Off Off Power off
Green Blinking Green Blinking Power On Self Test (POST) running
Green Solid Green Blinking POST succeeded (Operating System Loading)
Green Solid Off POST succeeded (Normal Operation)
Amber Blinking Off POST Failure
Alternating Green Blinking
& Amber Blinking
Alternating Green Blinking
& Amber Blinking System Boot Up Error
NOTE During switch start up, the Temperature status LED will be lit Solid
Amber. This is normal behavior and does not indicate an error. At the
completion of start up the Temperature Status LED will switch to Solid
Green.

RFS4010 RF Switch: Installation Guide
6
3.1.2 Switch Status (Primary System)
3.1.3 Switch Status (Redundant System)
System Status 1 LED System Status 2 LED Event
Off Off Power off
Green Solid Off
Redundancy Feature Enabled
Primary System Normal Operation
No Access Ports Adopted
Green Solid Green Solid
Redundancy Feature Enabled
Primary System Normal Operation
Actively Adopting Access Ports
Green Solid Amber Blinking
No Country Code configured on the switch
or
Access Port or Adaptive AP License and Country
Code configured, but no APs adopted
System Status 1 LED System Status 2 LED Event
Off Off Power off
Green Solid Off Redundant System Normal Operation
Green Blinking Green Solid Redundant System failed over and adopting
ports
Green Blinking Alternating Green Blinking
& Amber Blinking Redundant System not failed over.

LED Codes 7
3.1.4 Fan LED
3.1.5 Temperature Status LED
Fan LED Event
Off System Off / POST Start
Green Blinking POST in Process
Green Solid All System Fans Normal Operation
Amber Solid Redundant Cooling Failure
System Operational
Amber Blinking
System Cooling Failure
System will be held in reset until the issue is
resolved
Temperature LED Event
Off System Off
Green Solid Ambient Inlet Temperature is within specified
operating limit
Amber Solid
Ambient Inlet Temperature is near the maximum
operating temperature
During switch start up this LED will be lit Solid
Amber. This is normal behavior and does not
indicate an error.
Amber Blinking
Ambient Inlet Temperature is above the
maximum specified operating temperature
System will be held in reset until the issue is
resolved

RFS4010 RF Switch: Installation Guide
8
3.2 RJ-45 Gigabit Ethernet LEDs
5
4
3
21
LAN
PoE
Port
speed Port activity
PoE Status LED

LED Codes 9
3.2.1 RJ-45 Port Speed LED
3.2.2 RJ-45 Port Activity LED
3.2.3 PoE Status LED
Port Speed LED Event
Off 10 Mbps
Green Solid 100 Mbps
Green Blinking 1000 Mbps
Amber Blinking Port Fault
Port Status LED Event
Off No Link or Administratively shut down
Green Solid Link present
Green Blinking Activity: Transmit and Receive
Amber Blinking Link Fault
PoE Status LED Event
Off PoE Disabled or Not in Use
Green Solid PoE Enabled and Powering Port
Amber Solid PoE Over-Limit
Amber Blinking PoE Port Fault

RFS4010 RF Switch: Installation Guide
10
3.3 SFP Gigabit Ethernet LEDs
3.3.1 SFP Port Speed LED
3.3.2 SFP Port Activity LED
Port Speed LED Event
Green Blinking 1000 Mbps
Amber Blinking Module or Tx/Rx Fault Loss
Port Status LED Event
Off No Link or Administratively shut down
Green Solid Link present / Operational
Amber Blinking Module or Tx/Rx Fault Loss
UPLINK
SFP
Port speed
Port activity

Hardware Setup 11
4 Hardware Setup
4.1 Cabling Information
The RFS4010 RF Switch has five RJ-45 Gigabit Ethernet ports, one Gigabit SFP (fiber) port, one USB
port, one Console connector and one ExpressCard slot. The above diagram shows each of those ports
and the cables or devices attached to them. The sections that follow describe detailed connection
and cabling information for each port. For software configuration, please see the RFS Series Wireless
LAN Switches Wi-NG System Reference Guide available from the Motorola website.
Console
LAN/PoE+ enabled gigabit ethernet
ports 1,2,3,4,5
USBUPLINK/
WAN ExpressCard Slot
Gigabit Ethernet
RJ-45 connectors
with per-port LEDs
and PoE+
UPLINK Console connector
USB
port
ExpressCard Slot

RFS4010 RF Switch: Installation Guide
12
4.2 Gigabit Ethernet on the RFS4010 RF Switch
The RFS4010 RF Switch has five RJ-45 Gigabit Ethernet ports and one 1 combo Gigabit (RJ45 + SFP)
uplink port. Using the RJ-45 ports requires connecting a Category-6 Ethernet cable to the port. To use
the Gigabit SFP port, first install the SFP Module (Motorola Part Number: Fiber-3000-1S-WWR).
4.2.1 Installing Gigabit Ethernet SFPs
1. Open the bail on the transceiver.
2. Insert the SFP transceiver into the corresponding port on the switch.
Open bail to insert or remove
SFP transceiver

Hardware Setup 13
3. Once the SFP transceivers are properly seated in their ports, close the bails to lock the
transceivers in place.
Close bail to lock
SFP transceiver in place

RFS4010 RF Switch: Installation Guide
14
4. Insert the fiber optic cables into the installed transceivers.

Hardware Setup 15
4.3 Connecting USB Devices
The RFS4010 RF Switch contains one USB port for connecting USB flash storage devices to the
switch. The switch can use the USB flash storage device for file transfers and firmware updates.
Follow the setup instructions below to connect the devices to the switch and then access those
devices through the Web UI or Command Line Interface.
1. Connect the USB flash drive to the USB .
2. Wait a few seconds for the drive to be recognized by the switch.
3. Follow the instructions in the RFS Series Wireless LAN Switches System Reference Guide or
CLI Reference for more information on accessing USB storage devices from the switch for file
transfers or firmware updates.
NOTE The switch supports USB flash devices formatted with FAT or VFAT
(FAT32) filesystems only. If your flash storage device is formatted with
another filesystem you will need to format your device with a FAT32
filesystem.
USB
port

RFS4010 RF Switch: Installation Guide
16
4.4 Rack Mount Instructions
To install the RFS4010 RF Switch in a rack:
1. Attach the switch to the 1U rack mount kit using the guides provided.
2. Place the power supply unit in the rack mount tray in the space provided.
3. Attach the mounting tray to the rack using screws appropriate for your rack’s mounting holes.
Attach to Rack 1U Rack Mount Kit
Back
Switch
Guides
Front
Power Supply Guide
Cable
Management
