Motorola QUENCH User manual

FOCUS ON
WHAT MATTERS.
MOTOROLA QUENCH™

1
Congratulations
MOTOROLA QUENCH
MOTOROLA QUENCH is the first touch tablet with
social skills.
•Streamlined messaging: Get messages and
updates from your office to today’s most popular
social sites.
•More web: The enhanced browser lets you see
more of the web, while pinch-and-zoom and
front-nav-pad features give you more control over it.
More information
On your computer—Go to
www.motorola.com/support/quench.
So, whether you want to read, watch or play, we can
help.
Caution: Before assembling, charging or using your
phone for the first time, please read the important
legal and safety information packaged with your
phone. Once your phone is up and running,
press Menu > Settings > About phone >
Safety & regulatory to read the full information.

2
Your phone
Barry Smyth
Check out my gig
on Friday night.
Two minutes ago
Browser
Market
Br
M
a
rk
et
11:35
3G
Search
Power Key
Press to put the
display to sleep
or hold to turn
off.
OMTP 3.5mm Headset Jack
Home Key
Back Key
Microphone
Search
Key
Micro USB
Connector
Charge or
connect to PC.
Notification
LED
On=charged
Flashing=
charging or
notification
Volume Keys
To u chscreen
Camera
Key
Menu Key
*If you use a wired headset with built-in microphone, you'll
need to use an OMTP (Open Mobile Terminal Platform)
compliant headset such as the Motorola OH15. Look for
the OMTP logo shown here, or go to
www.motorola.com/wired for additional information.
Note: Your phone might look a little different.
Tip: To change the Notification LED, press Menu >
Settings > Display & security > Notification LED.
Set your status
Post
Done
11:35
3G
is heading to Matt's birthday party. 15 minutes ago
has hired Kat Bleser as his Music Advisor. And in return
she gets dating advice.
1 day ago
is so glad he doesn't have a paper to write! 2 days ago
,.
QW
ASDFGH J K
ZXCVBNM
L
ERTYUIOP
?123
Enter message here
Setyour status
Post
Done
11:35
3G
isheading to Matt's birthday party. 15minutesago
hashired Kat Bleser as his Music Advisor. And in return
shegets dating advice.
1day ago
isso glad he doesn't have a paper to write! 2daysago
,.
QW
ASDFGHJK
ZXCVBNM
L
ERTYUIOP
?123
Entermessage here
Send
To:
?123 .,
QW
ASDFGHJK
ZXCVBNM
L
ERTYUIOP
Entermessage here
11:35
3G
Delete
Return Touch Pad
Numbers/
Symbols
Shift
When you turn your phone, the keypad adjusts
for you.
Space
To open the display keypad, touch
a text field, or press and hold Menu.
To close the keypad, press Back.

3Contents
Contents
Let’s go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Touchscreen & keys . . . . . . . . . . . . . . . . . . . . . . . . . 5
Home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
App menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Tips & tricks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Personalise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Photos & videos . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
YouTube™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Apps for all . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Bluetooth™ wireless . . . . . . . . . . . . . . . . . . . . . . . 36
Wi-Fi™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Memory card & file transfer . . . . . . . . . . . . . . . . . . 38
Synchronise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Safety, regulatory & legal . . . . . . . . . . . . . . . . . . . . 46
Let’s go
let’s get you up and running
Assemble & charge
1cover off 2SIM in
3battery in 4microSD in
(already done)
5cover on 6charge up
3
H

4Let’s go
Caution: Please read the battery use and safety text in
the important legal and safety information packaged
with your phone.
Tip: To save battery life, see “Battery tips” on page 20.
Set up & go
Create or log into a Google Mail account to get your
contacts and email. Registration is secure and should
only take a few minutes:
1Tu r n o n .
2Tap the Android to begin.
3Select a language.
4Register or log in.
Tip: Turn your
phone to type.
Already have an account?
Sign in with the Google account you want linked to this
phone.
Don’t have an account?
Create one now! It’s easy.
Create
Setting up a Google Account
Sign in
Communicating
with the server....
5When your phone shows
your home screen, import
your SIM contacts: Touch
Contacts, then
press Menu > More >
Settings > Import from SIM card. Touch OK to
confirm.
Turn it on & off
To turn on your phone,
press Power (on the right
side).
To turn off your phone, press and
hold Power , then
touch Power off in the menu that appears.
Wi-Fi™ connect
If you want to use a Wi-Fi network for even faster
Internet access, press Menu > Settings >
Wireless controls > Wi-Fi settings. Touch Wi-Fi to
search for and connect to wireless networks. There’s
more in “Wi-Fi™” on page 37.

5Touchscreen & keys
Cool content & more
Browse and download thousands of the coolest apps
on the planet from Android. On top of that, you get a
full HTML browser, so you can surf in style.
Download new apps with “Apps for all” on page 35.
Your phone comes with a microSD memory card
installed—you can fill it with photos, videos and music
from your computer using “Transfer files with a USB
connection” on page 38.
Note: Do not remove your memory card while your
phone is using it or writing files to it.
Touchscreen & keys
a few essentials
Touch tips
Here are some tips on how to navigate around your
phone.
To u ch
To choose an icon or
option, To u ch it. Try it: On
the home screen, touch
Contacts.
Touch & hold
To open special options,
touch and hold an icon or
other item. Try it: On the
home screen, touch
Contacts, then
touch and hold a contact to
open options.
Contacts: All contacts
Ar
t
h
u
r B
audo
V
i
ew contac
t
C
Ca
Ca
Ca
Ca
ll
ll
ll
ll
ll
Arthur Baudo

6Touchscreen & keys
Drag
To scroll through a list or
move slowly, drag across
the touchscreen. Try it: On
the home screen, touch
Contacts, then
drag your list up or down.
Tip: When you drag or flick
a list, a scroll bar appears
on the right. Drag the scroll
bar to move the list to a
letter from A - Z.
Flick
To scroll through a list or move quickly, flick across the
touchscreen (drag quickly and release).
Tip: When you flick a long list, touch the screen to stop
it from scrolling.
Contacts: All contacts
StatusHistory A-Z
Arthur Baudo
Todd Palminteri
Kristin Cullen
Barry Smyth
Kat Bleser
Jim Somers
Touch pad
You can use the touch pad
to select small items in
the display (like a small
link on a webpage), or
control a game without
blocking your view. Just
flick across the pad to
scroll or move, and press
the pad to select.
Key tips
Menu, home, search & back
Press Menu to open
menu options on your
home screen, lists and
other places.
Press Home to
close any menu or app
and return to the home
screen. Press and hold Home to show the last few
apps you used, then touch an app to open it. On the
home screen, press Home to open or close the
app menu.
Press Search to open “Search” on page 8.
Press Back to go to the previous screen.
Sauce Vin Blanc
Albufera
Allemande
Bercy
Poulette
Aurora
Hungarian
Sauce ravigote
Normandy
Suprême
Venetian
A
A
Bercy
Pl
Home
Key
Back
Key
Search
Key
Menu
Key

7Home screen
Sleep & wake up
To save your battery, prevent
accidental touches or when you
want to wipe smudges off your
touchscreen, put the touchscreen
to sleep by pressing Power .
To wake up the touchscreen, just press Power ,
Menu , Search , Home , or Back .
To change how long your phone waits before the
screen goes to sleep automatically, press Menu >
Settings > Display & security > Screen timeout.
Tip: To make the screen lock when it goes to sleep,
use “Screen lock” on page 43.
Power key menu
Press and hold Power to open a menu from which
you can turn off the phone (Power off) or turn off
features (Airplane mode, Bluetooth, Wi-Fi or GPS).
Adjust volume
Press the volume keys to
change the ring volume
(on the home screen) or
the earpiece volume
(during a call).
Volume
Keys
Home screen
quick access to the things you need most
Quick start: Home screen
The home screen gives you all your latest information
in one place. It’s what you see when you turn on the
phone or press Home from a menu. It looks like
this:
5
Barry Smyth
Check out my gig
on Friday night.
Two minutes ago
Browser
Market B
r
M
a
rk
et
11:35
3G
Search
Status Indicators
Widgets
Touch to open or touch &
hold to move or delete.
Flick left or right to open five
panels of widgets.
Shortcuts
Touch to open.
Open the main menu.
Notifications
Flick this bar down to see
details.

8Home screen
Use & change your home screen
On your home screen, shortcuts are icons that let you
open your favourite apps, web bookmarks, contacts,
mail labels or music playlists. Widgets display news,
weather, messages and other updates.
Flick the home screen left or right to open other panels
of shortcuts and widgets.
•To open something, touch it. Press Home to
return to the home screen.
•To change a widget’s settings, open it and then
press Menu > Setup.
You can find details about the settings for Messages
(“Other email” on page 16), Music (“Music” on
page 26) or Weather (“Set up widgets” on
page 21).
•To add something or change your wallpaper, touch
and hold an empty spot until you see the Add to
Home screen menu.
You can add a folder to organise your shortcuts.
•To move or delete something, touch and hold it
until you feel a vibration, then drag it to another
spot, another panel or the bin at the bottom of the
screen.
Search
To search, use a Search widget on your home screen
or press Search .
Tip: In your app menu or Contacts, you can press and
hold Menu to open a display keypad, then type
contact details to search.
Google Search
Type, then touch the icon for
a text search.

9App menu
Phone status & notifications
At the top of the screen, icons
on the left notify you about new
messages or events (flick the bar
down for details). Icons on the
right tell you about the phone's status:
Tip: To see today’s date, touch and hold the status
indicators.
Bluetooth™ active network (full signal)
GPS active network (roaming)
Wi-Fi™ active GPRS (fast data)
downloading EDGE (faster data)
vibrate 3G (fastest data)
silent airplane mode
mute call battery (charging)
speakerphone active battery (full charge)
Google™ sync active alarm set
11:35
3G
App menu
Quick start: App menu
The app menu shows you all of
your applications. To open it from
the home screen, touch . To
close it, touch again.
Tip: To find an app in the menu, press and hold
Menu to open a display keypad, then type the app
name.
Recent apps
Press and hold Home to see the last few apps you
have used, then touch the app you want.
Press Home to return to the home screen.

10 Calls
Calls
it’s good to talk
Quick start: Calls
Find it: Dialer
During a call, press Menu to choose Hold, New
call or Use Bluetooth or to wake up the touchscreen
Arthur Baudo
Barry Smyth
Kat Bleser
Jim Somers
Recent Frequent Dialer
GHI
ABC DEF
MNO
TUVPQRS WXY
*
+
#
4
123
6
8
79
0
5
JKL
Call
Spd Dial
Speed Dial List
Touch to open and press
to add or edit.
Frequent Call List
Touch to open, then touch an
entry to call.
Delete
Touch to delete a digit you
have entered.
Recent Calls
Touch to open, then touch an
entry to call.
Your Contacts
Call
Enter a phone number and
touch here to call it.
if it’s dark. Your touchscreen goes dark to avoid
accidental touches.
Tip: You can press Home or Back to hide the
active call display. To reopen it, touch Dialer.
Make & answer calls
To make a call, touch Dialer, enter a number,
then touch Call.
Tip: To enter the international dialling code, touch and
hold . To add a pause or wait after numbers,
press Menu .
End call
SpeakerMute
Active call ( 00:12 )
Mobile [phone]
Mary Morgan
Call Timer
Mute
Mute or unmute the call.
End Call
Hang up.
Speakerphone
Turn the speakerphone on or
off.
Dial Pad
Open a dial pad to enter
numbers during a call.

11Calls
To answer a call, drag Answer to
the right (when your phone is
unlocked, Answer is just a touch
button).
You can also press Power to ignore the call or
press a volume key to silence the ring.
End calls
To u ch End call.
Note: When you hold your phone
to your ear, the display goes dark
to avoid accidental touches.
When you move your phone away from your ear, the
display lights up again.
Tip: You can press Home or Back to hide the
active call display. To reopen it, touch Dialer.
Speed dial
Find it: Dialer > Spd Dial
•To call a number, touch it.
•To add, edit or clear entries, press Menu .
Slide to Answer
Ignore call by pressing Lock button
End call
SpeakerMute
Hands-free
Note: Using a mobile device or accessory while
driving may cause distraction and may be illegal.
Always obey the laws and drive safely.
During a call:
•To use the speakerphone, touch Speaker.
•To use a Bluetooth™ device, press Menu > Use
Bluetooth.
Mute & hold
During a call:
•To mute the current call, touch Mute.
•To put a call on hold, press Menu > Hold.
Enter numbers during a call
To enter numbers during a call,
touch and then touch the dial
pad.
Recent calls
Find it: Dialer > Recent
•To call a number, touch it.
•To send a text message, create a contact, view a
contact, add the call to speed dial or other options,
touch and hold an entry.
End call
SpeakerMute

12 Calls
•To filter the list, touch the view name (such as All
calls) at the top.
•To clear the list, press Menu .
Frequent calls
Find it: Dialer > Frequent
•To call a number, touch it.
•To send a text message, view a contact, add the call
to speed dial or other options, touch and hold an
entry.
Conference calls
To start a conference call, call the first number. After
the person has answered, press Menu > New call
and call the next number. When the next number
answers, press Menu > Join.
Your phone number
Find it: Menu > Settings > About phone >
Status > My telephone numbers
Your caller ID
To hide your number from the people you call,
press Menu > Settings > Call settings >
Additional call settings > Caller ID.
Call forwarding & waiting
You can forward calls all the time, or only when your
phone is busy, unanswered or unreachable (not on the
network):
Find it: Menu > Settings > Call settings > Call
forwarding
When you’re on a call and a second call comes in, Call
waiting lets you answer it by touching Answer. You
can turn off Call waiting, to send second calls straight
to your voicemail:
Find it: Menu > Settings > Call settings >
Additional call settings > Call waiting
Restrict outgoing calls
To restrict your phone so that it can only dial a few
numbers:
Find it: Menu > Settings > Call settings > Fixed
dialing number
•To turn fixed dialling on, touch FDN disabled.
•To add or delete allowed numbers from the list,
touch Manage FDN list.
Emergency calls
Note: Your service provider has programmed one or
more emergency phone numbers into your phone
(such as 999 or 112) that you can call under any

13Contacts
circumstances, even when your phone is locked.
Emergency numbers vary by country. Your
pre-programmed emergency number(s) may not work
in all locations, and sometimes it may not be possible
to place an emergency call due to network,
environmental or interference issues.
1To u ch Dialer (if your phone is locked,
touch Emergency Call or press Menu >
Emergency call).
2Enter the emergency number.
3To u ch Call to call the emergency number.
Note: Your mobile device can use AGPS satellite
signals to help emergency services find you (see the
important legal and safety information packaged with
your phone).
Contacts
contacts like you’ve never had before
Quick start: Contacts
Find it: Contacts
Tip: To search the list, press and hold Menu to
open a display keypad, then type a name. When you
flick or drag this list, a scroll bar appears on the right.
Drag the scroll bar to move the list more quickly.
Contacts: All contacts
Alex Pico
Mariana Bukvic
Luke Carmody
Dan Smith
Keith Zang
Kate Shunney
History A-Z
Group
Press Menu >
Display groupto choose
which group to show (such
as All, Favorites or
Facebook).
Create Contacts
Contacts List
Touch to view contact
information. Touch & hold
to edit, delete and more.
Views
See the list how you want.
Touch, or flick left/right for:
History - recently used
A-Z - list in alphabetical
order

14 Contacts
Import contacts from your SIM
Note: You might have already done this during “Set up
& go” on page 4.
If you need to import the
contacts from your SIM card,
touch Contacts, then
press Menu > More >
Settings > Import from SIM card.
Call, text or email contacts
Find it: Contacts
For Call, Send Text Message, Email, View contact or
other options, touch and hold the contact.
View & use contacts
With a MOTOROLA QUENCH, you’ll have contacts
like never before.
Find it: Contacts
•To filter the contacts by group, touch the filter name
at the top.
•To change the list view, touch History (recently
used) or A-Z (alphabetical) at the bottom.
•To find a contact, just type the name.
Touch a contact to open their details. To start a call
or compose a message, just touch their phone
number or other info. You can touch History or Info
at the bottom of the screen to see more.
Edit or delete contacts
Find it: Contacts
Touch the contact, then press Menu > Edit or
Delete. You can set a ringer, address and other details
that will be saved on your phone.
Where are contacts edited or deleted? Your phone
edits the contacts in its memory. Your changes won’t
affect your SIM card.
Link contacts
You might have two Contacts for the same person,
maybe a Facebook friend who is also stored on your
SIM card, or one friend with two email addresses. To
combine these two contacts:
Find it: Contacts
Touch a contact to open it, then press Menu >
Link contact and touch the second entry.

15Contacts
Create contacts
Find it: Contacts > Menu > Add contact
When you’re finished, press Save.
Touch Mobile to choose a
different type for this
entry.
+adds another entry.
-removes this entry.
To see more details, flick up.
Groups
You can put your Contacts into groups that you create
(such as “friends,” “family” or “work”). You can then
find contacts faster by showing one group at a time.
To create a group in your Contacts, press Menu >
Add group. Enter a group name, then touch Add to
add members.
To show only one group in your Contacts, touch
Contacts: All contacts at the top of your screen and
choose the group name.

16 Messaging
Messaging
sometimes it’s best to text, IM or email . . .
Quick start: Messaging
Find it: > Google Mail
Tip: To see more messages, flick or drag up.
Create messages
Find it: > Google Mail > Menu >
Compose
8:34 PM
Alex Pico
Some guys have all the luck...
Right now, you’re busy flexing...
Sep 25
Keith Zang
Job
It’s only a freelance gig, but it pays...
Sep 25
Kate Shunney
I have so much energy today, I
have no IDEA why.
Inbox (4)
Sep 25
Seth Rementer
The cinnamon bun place is right
next to the store. It’s like 8 hours...
Yi Liu
Re: weekend plans
Sep 25
Sep 25
Marianna Bukvic
Running
I’m glad we’re running again. I...
Google Mail
Message List
Touch to open a
message. Touch &
hold to move, delete
and more.
Send & receive attachments
To send a file in a message, open a new message,
press Menu > Attach and choose the file.
When you receive a message with an attachment,
open the message and touch the file name to
download it. Then, touch the name again to open it.
Some file formats can be converted to HTML for faster
viewing. Your phone will show a button that says Get
HTML version.
Tip: To send and receive large attachments more quickly,
use a Wi-Fi connection, in “Wi-Fi™” on page 37 .
Other email
Find it: touch > Email
Email is for most personal email accounts. For
account details, contact the account provider.
Note: While you are using a Wi-Fi network, you will
not be able to access Yahoo Mail accounts. You can
still use your browser to see these accounts at
mail.yahoo.com.
Instant messages
To send and receive instant messages, you can use an
instant messaging app or your browser.
If you don’t see an app for your IM provider, you can
use your web browser. Touch > Browser >

17Text entry
Menu > Go, then enter your provider’s website.
Once you’re there, follow the link to sign in.
Note: Your IM options will depend on your IM provider.
To browse instant messaging apps from your
computer, go to www.android.com/market.
Voicemail
When you have a new voicemail, will appear at the
top of your screen. To listen to the voicemail,
touch Dialer, then touch and hold .
If you need to change your voicemail number, on the
home screen press Menu > Settings > Call
settings > Voicemail.
Text e nt ry
think keyboard, now think smaller
Touchscreen keypad
To open the touchscreen keypad, touch a text box or
press and hold Menu . To close it, press Back .
For bigger keys, turn your phone to put the screen in
landscape mode.
To move the cursor, touch and hold a word you have
entered. A magnifier opens and you can drag the
cursor to another spot.
To switch the keypad to Android keyboard or
Swype, touch and hold a blank spot in the text box. A
menu opens, where you can choose Input Method.
Send
?123
.,
QW
ASDFGH J K
ZXCVBNM
L
ERTYUIOP
Enter message here
Delete
Return
Space
Numbers/symbols
Touch once for numbers and again for symbols.
Shift
Text Entry
Touch to open the
touchscreen keypad.

18 Text entry
Swype™ text entry
Swype lets you enter a word with one continuous
motion. To enter a word, just drag your finger over the
letters.
Tips:
qw
a
EN @# 123
_
%()
!7890
/
?
sdf gh jk
z
SYM
xcvbnm
_
,
‘
.
l
er tyui op
8$456
+
:;“
qw
a
EN @# 123
_
%()
!7890
/
?
sdf gh jk
z
SYM
xcvbnm
_
,
‘
.
l
er tyui op
8$456
+
:;“
qw
a
EN @# 123
_
%()
!7890
/
?
sdf gh jk
z
SYM
xcvbnm
_
,
‘
.
l
er tyui op
8$456
+
:;“
h
+
w
@
(
o
k
;
0
b
o
(
d
4
3
y
a
8
For double
letters,
circle the
letter.
To
capitalize,
go above
the keypad.
book
Who
day
•To enter apostrophes in common words (like “I’ll”),
drag through the nas though it was an apostrophe.
•To enter several symbols, touch SYM.
•To correct a word, double-tap it. Swype shows a
small menu of other word options. Swype might
also show a menu if it can’t guess your word.
•If Swype doesn’t know a word, you can still touch
the letter keys to enter it. Swype remembers, so
next time you can just drag over the letters.
Text entry settings
When you enter text, your phone automatically
corrects or suggests words. To change these settings,
press Menu > Settings > Locale & text, then:
•To change your Swype settings, touch Swype.
•To edit your word suggestion dictionary, touch User
dictionary.
•To change the language and the style of your
touchscreen keypad, touch Select locale.
•To change the sounds, corrections and other
settings for your touchscreen keypad,
touch Android keyboard.
