Mountain MTN2156 User manual

MTN2156 1 12/24/08
TWO STAGE
TRANSMISSION
JACK
1000
LBS.
CAPACITY
MTN2156
OWNER/USER RESPONSIBILITY
The owner and/or user must have an understanding of
the manufacturer’s operating instructions and warnings before
using this transmission jack. Personnel involved in
the use and operation of equipment shall be careful,
competent, trained, and qualified in the safe operation
of the equipment and its proper use when servicing motor
vehicles and their components. Warning information should
be emphasized and understood. If the operator is not fluent in
English, the manufacturer’s instructions and warnings shall be
read to and discussed with the operator in the operator’s native
language by the purchaser/owner, making sure the operator
comprehends its contents.
Owner and/or user must study and maintain for future
reference the manufacturer’s instructions. Owner and/or
user is responsible for keeping all warning labels and
instruction manuals legible and intact. Replacement labels
and literature are available from the manufacturer.
• Read, study, undeRstand and follow all instRuctions
befoRe opeRating. • inspect befoRe each use. do not use
if damaged, alteRed, modified, in pooR condition,
oR has loose oR missing haRdwaRe oR components.
take coRRectiVe action befoRe using the Jack. • do
not use Jack beyond its Rated capacity. • use only
on haRd, leVel, clean and dRy suRface capable of
suppoRting the load. • this Jack was designed foR
lifting tRansmissions only. • do not attempt any
woRk until Vehicle is stabiliZed by undeR hoist
stands. • use this Jack only with adapteRs and load
RestRaints pRoVided. use of this Jack is limited to the
RemoVal, installation, and tRanspoRtation (in the
loweRed position) of tRansmissions and tRansfeR
cases. • weaR eye pRotection that meets ansi Z87.1
and osha standaRds. • do not lift oR suppoRt the
Vehicle with this Jack. • secuRe the load to the
Jack. only attachments and/oR adapteRs supplied
by the manufactuReR shall be used. • always loweR
load slowly. • make suRe the gRound, woRk aRea,
and cleaRance undeR the Vehicle aRe fRee fRom
obstRuctions oR any hindRances that would pReVent
easy maneuVeRability of the Jack and tRansmission
undeR the Vehicle. • failuRe to heed these maRkings
may Result in seRious oR fatal peRsonal inJuRy and/
oR pRopeRty damage.
THIS OPERATING MANUAL CONTAINS
IMPORTANT SAFETY INFORMATION.
READ CAREFULLY AND UNDERSTAND
ALL INFORMATION BEFORE OPERATING
THIS DEVICE. SAVE THIS MANUAL FOR
FUTURE USE.
WARNING
Low Height ........................................... 35"
Raised Height ....................................... 75"
Saddle Tilt:
Forward ............................................... 45°
Backward ............................................. 28°
Side to Side.......................................... 10° - 23°
Base Size.............................................. 35" x 31.5"
Saddle Plate Size .................................. 15.5" x 15.5"
Shipping Weight................................... 181 Lbs
SPECIFICATIONS

MTN2156 2 12/24/08
SETUP
PLEASE REFER TO THE EXPLODED VIEW DRAWING IN THIS MANUAL IN ORDER TO IDENTIFY PARTS.
1. Before using jack for the first time, some assembly is required. Place hydraulic unit in upright position and bolt legs to base using
(4) 1/2" x 1" HHCS and (4) 1/2" internal tooth lock washers.
2. Assemble each caster to leg using (4) 5/16" x 3/4" hex bolts and (4) 5/16" nyloc locknuts.
3. Attach fingers to saddle using (4) 7/16" x 1-1/4" bolts, (4) 7/16" washers and (4) 7/16" hex nuts.
4. Open reservoir vent screw that is located on the reservoir and below the product label by turning the screw counterclockwise two
(2) full turns. NOTE: JACK WILL NOT OPERATE PROPERLY UNLESS THE VENT SCREW IS OPENED.
5. If the jack has been used without first opening the reservoir vent screw or the jack has been handled or shipped in different
positions, air may be trapped in the hydraulic system. An air trapped system is identified by insufficient incremental pump strokes
and failure to extend the telescopic rams to maximum height.
FOLLOW THESE INSTRUCTIONS TO PURGE AIR FROM THE SYSTEM:
a. Make sure the reservoir vent screw is opened two (2) full turns.
b. Open the release valve knob two (2) full turns.
c. Depress the release valve pedal while simultaneously operating the foot pump pedal fifteen (15) times.
d. Remove your feet from the pedals and close the release valve knob.
e. Pump the jack up. If the condition seems better, repeat steps (a. through e.) until all the air is purged from the system.
f. If air seems to be trapped in the secondary (smaller) ram, lower all rams to their collapsed position. Tighten the release
valve knob. Insert an allen wrench in the allen socket set screw located in the side of the secondary hexagonal cylinder nut.
Slightly turn the allen wrench in a counterclockwise direction while lightly depressing the pump pedal. Continue to depress the
pump pedal until the hydraulic fluid that escapes from the allen socket set screw hole has no air bubbles. Tighten the allen
socket set screw.
OPERATING INSTRUCTIONS
This is the safety alert symbol used for the OPERATING INSTRUCTIONS section of this manual to alert you to
potential personal injury hazards. Obey all instructions to avoid possible injury or death.
IMPORTANT: Before attempting to raise any vehicle, check vehicle service manual for recommended lifting surfaces.
OPERATION:
1. To raise load: Pump pedal to raise saddle to contact load. Position jack so weight of load will be equally distributed on saddle,
and adjust pitch and tilt controls as necessary. Position corner supporting brackets and secure load with load restraint chain.
WARNING: always use the load restraint chain, corner support brackets, and attachment to stabilize and firmly secure the load
to the saddle. The chain should be used as follows: place the chain over the load, pull tight and place into slot on opposite side of
saddle. Tighten wing nut.
2. To lower load: This jack includes two release mechanisms for the lowering of load. The foot pedal release is for moderate to
quicker lowering of load and requires slow and gradual depression of the foot pedal to achieve desired lowering speed. Lowering
of the load can be stopped by removing your foot from the release pedal.
The second release mechanism includes a hand operated release knob which is designed for very slow load release. Lowering of
load is accomplished by slowly turning the knob in a counterclockwise direction. Lowering of the the load can be stopped by
turning the release knob in a clockwise direction until tight.
OPERATING MANUAL & PARTS LIST FOR MTN2156

MTN2156 3 12/24/08
OPERATING MANUAL & PARTS LIST FOR MTN2156
TROUBLESHOOTING
PROBLEM ACTION
1. Unit will not lift load. Purge air from hydraulic system by following procedure
under SETUP.
2. Unit will not sustain load or feels “spongy” under load. Purge air from hydraulic system as above.
3. Unit will not lift to full height. Purge air from hydraulic system as above.
4. Unit still does not operate. Contact an authorized service center from enclosed list.
PREVENTATIVE MAINTENANCE
This is the safety alert symbol used for the PREVENTATIVE MAINTENANCE section of this manual to alert you
to potential personal injury hazards. Obey all instructions to avoid possible injury or death.
1. Always store the jack in a well protected area where it will not be exposed to inclement weather, corrosive vapors,
abrasive dust, or any other harmful elements. The jack must be cleaned of water, snow, sand or grit before using.
2. The jack must be lubricated periodically in order to prevent premature wearing of parts. A general purpose grease
must be applied to moving parts.
3. It should not be necessary to refill or top off the reservoir with hydraulic fluid unless there is an external leak.
An external leak requires immediate repair which must be performed in a dirt-free environment by an authorized
service center.
IMPORTANT: In order to prevent seal damage and jack failure, never use alcohol, hydraulic brake fluid or transmission oil in
the jack.
4. Every jack owner is responsible for keeping the jack labels clean and readable. Use a mild soap solution to wash
external surfaces of the jack but not any moving hydraulic components.
5. Inspect the jack before each use. Do not use the jack if any component is cracked, broken, bent, shows sign of
damage or leaks hydraulic fluid. Do not use the jack if it has loose or missing hardware or components, or is
modified in any way. Take corrective action before using the jack again.
6. Any hydraulic repairs within the warranty period must be performed by an authorized service center.

MTN2156 4 12/24/08
1
2
8
9
7
5
3
4
12
Located on the side of the
hydraulic unit not visible in
this picture.
14
6
15
16
ITEM NO. PART NO. DESCRIPTION QTY.
1
RS7793BCYL Hydraulic Unit 1
2 RS540062 Leg 2
3 RS6644A Saddle Assembly 1
(Including #13)
4 RS7793PA Pump Assembly 1
5 RS7793FPA Foot Pedal Assembly 1
6 RS664406 Finger 4
7 RS7700CH Chain 1
8 RSSC301A Caster 4
9
RS305004WK Wheel Kit (8 bolts and nuts) 2
ITEM NO. PART NO. DESCRIPTION QTY.
10 RS7793BK Bolt Kit 1
11 RS7793SK Seal Kit
12 RS7793VS Reservoir Vent Screw 1
13 RS6644SB Saddle Bushing 1
(not shown, fits between saddle and ram)
14 RS7793BRV Release Valve 1
(located under foot pedal)
15 RS7793BRR Release Rod With Knob 1
16 RS6644AR Saddle Adjustment
Rod With Knob 2
TWO STAGE
TRANSMISSION
JACK
1000
LBS.
CAPACITY
MTN2156

MTN2156 5 12/24/08
LIMITED WARRANTY:
MOUNTAIN™ BRANDED PRODUCTS ARE WARRANTED AGAINST DEFECTS IN WORKMANSHIP
AND MATERIALS FOR A PERIOD OF ONE YEAR FROM DATE OF ORIGINAL PURCHASE.
Any Mountain™ branded products which fail to give satisfactory service due to defective workmanship or materials will
be repaired or replaced at our option during the warranty period.
Other important warranty information...
This warranty does not cover damage to equipment or tools arising from alteration, abuse, misuse, damage and does
not cover any repairs or replacement made by anyone other than an authorized warranty service center.
The foregoing obligation is our sole liability under this or any implied warranty and under no circumstances shall we
be liable for any incidental or consequential damages.
Note: Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitation or exclusion may not apply to you.
Contact the nearest authorized warranty service center regarding any warranty questions. Be certain to include with
any returned products your name and address, evidence of the purchase date, and description of the suspected defect.
A complete listing of warranty service centers is included with this manual.
This warranty gives you specific legal rights and you may also have other rights which vary from state to state.
Repair kits and replacement parts are available for many Mountain™ branded products regardless of whether or not
the product is still covered by a warranty plan.
