Mova mc.mini User manual

mc.mini
User Guide

We thank you for purchasing our
Bluetooth Wireless Speaker mc.mini.
Before enjoying your speaker,
please read this manual.

TABLE OF CONTENTS
1PRODUCT MAIN FEATURES ______________________________________________ 1
2SPEAKER OVERVIEW –FRONT ____________________________________________ 2
3SPEAKER OVERVIEW –BACK _____________________________________________ 2
4CHARGING YOUR SPEAKER ______________________________________________ 3
5BATTERY STATUS ON IPHONE AND IPAD ___________________________________ 3
6PAIRING YOUR DEVICE__________________________________________________ 4
7USING THE LINE-IN AUDIO JACK __________________________________________ 4
8CONTROLLING YOUR MUSIC _____________________________________________ 5
9ANSWERING CALLS ____________________________________________________ 5
10 USING SIRI ___________________________________________________________ 6
11 SPECIFICATIONS_______________________________________________________ 6
12 SAFETY AND HANDLING INFORMATION ____________________________________ 7
13 FCC COMPLIANCE STATEMENT __________________________________________ 10
14 CE COMPLIANCE STATEMENT ___________________________________________ 10

PRODUCT MAIN FEATURES
1
1PRODUCT MAIN FEATURES
High-end wireless stereo Bluetooth speaker
Two pieces of 40MM driver for a massive and rich sound
Large speaker cavity inside for excellent sound effects
Passive subwoofer for outstanding bass
Long battery life for up to 10 hours of music
Built-in microphone for hands-free phone calls
Six buttons to control tracks on phone wirelessly
Compatible with SIRI ’s functions by pressing a button on mc.mini
Battery status displayed on iPhone / iPad
Low battery warning when battery power is low
Easy connect to any Bluetooth® devices
Can be used as a wired speaker

SPEAKER OVERVIEW –FRONT
2
2SPEAKER OVERVIEW –FRONT
3SPEAKER OVERVIEW –BACK AND TOP

CHARGING YOUR SPEAKER
3
4CHARGING YOUR SPEAKER
Before the first use or when the battery runs out, please charge mc.mini with the Micro USB
charging cable included in the package.
Plug the small Micro USB pin into the charging port on the back of mc.mini, and plug the other
end of the cable (the standard USB 2.0) into the USB port of a computer.
You can also charge your mc.mini with an official Mova Systems USB power adapter (available
separately), or with other third-party "Made for mc.mini" cables and power adapters that are
compatible with USB 2.0, or power adapters compliant with one or more of the following
standards: EN 301489-34, IEC 62684, YD/T 1591-2009, CNS 15285, ITU L.1000, or another
applicable Bluetooth speaker power adapter interoperability standard. In this case, please then
plug the USB charger to a power outlet.
WARNING For important safety information about the battery and charging mc.mini, see
Important safety information on page 7.
Using an inadequate third party charger could result in electric shock and could also damage
mc.mini.
The LED indicator light will turn red when it is being charged. When it is fully charged, the LED
indicator light will go off. A full charge takes about 3-4 hours.
Your mc.mini can be charged while working. The battery of mc.mini will be charged till the
charging process completes. Your mc.mini will be powered by the DC input directly and the
battery will be in sleep mode after it is fully charged.
Important: mc.mini battery may drain instead of charge, if mc.mini is connected to a
computer that’s turned off or is in sleep or standby mode.
5BATTERY STATUS ON IPHONE AND IPAD
When mc.mini is connected to iPhone/iPad via Bluetooth, the battery status of mc.mini can be
displayed on the top of the iPhone/iPad screen, near the Bluetooth logo.
Please note that the battery status icon can be vertical or horizontal, depending on the
Bluetooth device and its operation system.

PAIRING YOUR DEVICE
4
6PAIRING YOUR DEVICE
1. Make sure mc.mini is fully charged.
2. Activate Bluetooth on your Bluetooth device (mobile phone, tablet, portable gaming,
MP3/MP4 players, laptops, desktops). Bluetooth controls are typically found in the tools or
settings menu. Turn on Bluetooth connectivity and make sure your device is "visible" or
"discoverable". Important: for more information about how to enable Bluetooth on your
device, please refer to the user guide provided by the manufacturer of this device.
3. Turn on mc.mini by switching the button on the back of the speaker to "On".
4. After turning on mc.mini, the LED lights should alternate between shining red and blue. This
signal that the speaker is in "pairing mode".
5. Choose "add new Bluetooth device" or "setup Bluetooth device" on your device. It will
search for mc.mini.
6. As your Bluetooth device discovers possible items to connect to, it will list their names.
Select the device named mc.mini. This will connect your speaker to your Bluetooth device.
7. If the pairing attempt fails or times out (roughly 3 minutes), restart both devices and start
the pairing process again (steps 2 to 6).
8. Once paired successfully, the LED indicator lights will turn blue and blink twice every 3
seconds.
9. Enjoy your mc.mini and your music wirelessly anywhere now!
7USING THE LINE-IN AUDIO JACK
If your device is not Bluetooth enabled, you can still enjoy your mc.mini by using the Line-in
Audio Jack and by connecting mc.mini with the included audio jack cable to any device with a
3.5MM standard audio jack. Once done, mc.mini can be used as a wired speaker.
Important: the TALK, PLAY/PAUSE, PREVIOUS & NEXT, VOLUME UP and VOLUME DOWN
buttons only work when connected wirelessly via Bluetooth. In case of wired connection, music
can only be controlled on your device.

CONTROLLING YOUR MUSIC
5
8CONTROLLING YOUR MUSIC
Once your mc.mini is connected to a Bluetooth device (mobile phone, tablet, portable gaming,
MP3/MP4 players, laptops, desktops), you are free to control your music any way you want.
Press the VOLUME UP and VOLUME DOWN button to increase or decrease the volume. There
will be a reminder tone when mc.mini is at maximum or minimum volume. Pressing the
VOLUME UP and DOWN buttons only increase or decrease the volume of mc.mini, but it does
not increase or decrease the volume of the Bluetooth device. Volume can also be adjusted from
the Bluetooth devices (sound source).
WARNING For important information about avoiding hearing loss, see Important safety
information on page 7.
To switch to the previous or next music simply press the PREVIOUS and NEXT buttons on
mc.mini. This will switch to the previous/next music in the playlist of the Bluetooth device.
Press the PLAY/PAUSE button on mc.mini to start or pause musics.
Please note that the PREVIOUS, NEXT, and PLAY/PAUSE buttons can only control the music
playing from the default music software on the Bluetooth devices. If the music playing software
is not the default player, the music may not be able to be controlled using these 3 buttons and
the PLAY button may start another music in the playlist of the default player.
9ANSWERING CALLS
You can use mc.mini as a portable speakerphone for incoming calls when connected wirelessly
via Bluetooth. To answer a call, press the TALK button and talk as you would with your device if
it was on "speakerphone".
To answer a call, press the TALK button and talk as you would with your device if it was on
"speakerphone mode". The built in microphone will pick up your voice just like a phone.
To end a call, press the TALK button again. To refuse a call, press and hold the TALK button for 2
seconds. You can re-dial the last number called by double pressing the TALK button.

USING SIRI
6
10 USING SIRI
When mc.mini is connected to an iPhone/iPad via Bluetooth, press and hold the TALK button
for 3 seconds to activate the Siri function on your device. Then talk to mc.mini after hearing the
"Siri" sound. When the Siri conversation is finished, mc.mini will continue playing audio.
Important: please note that iPhone/iPad may not be able to recognize human speech when
mc.mini is being used in a noisy environment. Siri may not work if iPhone/iPad is not connected
to the internet.
11 SPECIFICATIONS
Dimensions:
Weight:
Speaker driver:
Speaker output:
Passive subwoofer dimensions:
Frequency Response:
Signal-to-Noise Ratio (SNR):
Distortion:
Battery life:
Battery Charging voltage:
Working voltage:
Battery charging time:
Battery capacity:
Interface:
Operating Frequency Range:
Bluetooth transmission distance:
Bluetooth compliant:
163*51*71 MM
430g (speaker only)
Stereo, 40MM, 4Ohm
5W*2
100*40MM
100Hz-20KHz
≥80db
≤0.1%
Up to 10 hours
5V(1A)
3.3−−5V
4-5 hours
1800 mAh
Bluetooth, 3.5MM audio line-in jack & line-
out jack, Micro USB charging port
2.4GHz-2.48GHz
10 meters
V.3.0

SAFETY AND HANDLING INFORMATION
7
12 SAFETY AND HANDLING INFORMATION
Important Safety Information
WARNING Please read these safety warnings and cautions carefully to ensure your personal
safety and prevent property damage. Failure to follow these safety instructions could result in
fire, electric shock, or other injuries, or damage to mc.mini or other property. Read all the
safety information below before using mc.mini.
Handling Handle mc.mini with care. It is made of metal and plastic and has sensitive electronic
components inside. Do not place mc.mini on high surfaces such as shelves. During music
playback mc.mini may move which could cause mc.mini to shift and fall off the edge. Do not
drop, disassemble, open, crush, bend, deform, puncture, shred, microwave, incinerate, paint,
or insert foreign objects in your mc.mini. Such actions could result in electric shock and may
cause injury. Your mc.mini can also be damaged if it comes in contact with liquid. Do not
expose your mc.mini to liquid, moisture, humidity, or rain. Do not use mc.mini near a bathtub,
sink, sauna, pool, or steam room. Exposure of mc.mini to moisture could result in electric
shock. Never use a damaged mc.mini as it may cause injury.
Distraction and automobile accident hazard Using mc.mini in some circumstances can distract
you and may cause a dangerous situation. Do not leave or store your mc.mini or any of its
accessories near or over your automobile’s air bag because serious injury may result when an
air bag deploys.
Hearing loss Listening to sound at high volumes may damage your hearing. Background noise,
as well as continued exposure to high volume levels, can make sounds seem quieter than they
actually are. For information about how to set the volume on mc.mini, see Controlling your
music on page 5.
WARNING To prevent possible hearing damage, do not listen at high volume levels for long
periods.
Charging Charge mc.mini with the included USB cable. You can also charge it using a Mova
Systems USB power adapter (available separately), or with other third-party "Made for
mc.mini" cables and power adapters that are compatible with USB 2.0, or power adapters
compliant with one or more of the following standards: EN 301489-34, IEC 62684, YD/T 1591-
2009, CNS 15285, ITU L.1000, or another applicable Bluetooth speaker power adapter
interoperability standard. In this case, please then plug the USB charger to a power outlet.
Other adapter may be needed to connect mc.mini to some compatible power adapters. Using
damaged cables or chargers, or charging when moisture is present, can cause electric shock. If
you an USB Power Adapter to charge, make sure that the AC plug or AC power cord is fully

SAFETY AND HANDLING INFORMATION
8
inserted into the adapter before you plug it into a power outlet. Only charge mc.mini in
accordance with this User Guide.
Battery Do not attempt to replace the battery of mc.mini by yourself. It is built-in, and not
changeable by the user. By trying to replace the battery by yourself, you may damage mc.mini
and it could cause overheating and injury. The battery in mc.mini should be replaced only by
Mova Systems or a Mova Systems Authorized Service Provider, and must be recycled or
disposed of separately from household waste. Do not dispose your mc.mini in a fire. The
battery could explode causing injury or death.
Repairing Do not attempt to repair, modify, or disassemble your mc.mini by yourself.
Disassembling mc.mini may damage it or may cause injury to you. If mc.mini is damaged,
malfunctions, or comes in contact with liquid, contact Mova Systems or any Mova Systems
Authorized Service Provider.
Prolonged heat exposure mc.mini and its accessories comply with applicable surface
temperature standards and limits. However, even within these limits, sustained contact with
warm surfaces for long periods of time may cause discomfort or injury. Use common sense to
avoid situations where your skin is in contact with a device or its power adapter when it’s
operating or plugged into a power source for long periods of time. Do not block ventilation
openings. For example, do not sleep or place mc.mini under a blanket, pillow, or your body
when it’s plugged into a power source. Take special care if you have a physical condition that
affects your ability to detect heat against the body. Do not leave mc.mini near open flames
such as cooking burners, candles, or fireplaces.
Explosive atmospheres Do not charge or use mc.mini in any area with a potentially explosive
atmosphere, such as a fueling area, or in areas where the air contains chemicals or particles
(such as grain, dust, or metal powders).
Radio frequency interference Observe all signs and displays that require an electrical device or
RF radio products to be switched off in designated areas.
High-consequence activities mc.mini is not intended for use where the failure of the device
could lead to death, personal injury, or severe environmental damage.

SAFETY AND HANDLING INFORMATION
9
Important handling information
Cleaning Clean mc.mini immediately if it comes in contact with anything that may cause stains
such as dirt, ink, makeup, or lotions. To clean:
Disconnect all cables and turn mc.mini off (by using the ON/OFF button at the back). Do
not clean mc.mini when it is being charged and always unplug the charger first before
cleaning mc.mini.
Use a soft, lint-free, dry cloth. Do not use abrasive cleaners to clean your mc.mini
because this could cause scratches or damage.
Avoid getting moisture in openings.
Don’t use cleaning products or compressed air.
Using connectors, ports, and buttons Do not insert anything into your mc.mini unless
otherwise specified in this User Guide. This may damage the internal components. Never force
a connector into a port or apply excessive pressure to a button, because this may cause damage
that is not covered under the warranty. If the connector and port don’t join with reasonable
ease, they probably don’t match. Check for obstructions and make sure that the connector
matches the port and that you have positioned the connector correctly in relation to the port.
Cables Discoloration of the cables after regular use is normal. Dirt, debris, and exposure to
liquids may cause discoloration. To remove the discoloration or if the charging cable becomes
warm during use or won’t charge your mc.mini, disconnect the cable from your computer or
power adapter and clean it with a soft, dry, lint-free cloth. Do not use liquids or cleaning
products when cleaning the connectors.
Operating temperature mc.mini is designed to work in ambient temperatures between 32° and
95° F (0° and 35° C) and stored in temperatures between -4° and 113° F (-20° and 45° C).
mc.mini can be damaged and battery life shortened if stored or operated outside of these
temperature ranges. Avoid leaving mc.mini in direct sunlight for extended periods of time.
When you’re using mc.mini or charging the battery, it is normal for mc.mini to get warm.

FCC COMPLIANCE STATEMENT
10
13 FCC COMPLIANCE STATEMENT
This device complies with part 15 of the FCC rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
Important: Changes or modifications to this product not authorized by Mova Systems could
void the electromagnetic compatibility (EMC) and wireless compliance and negate your
authority to operate the product. This product has demonstrated EMC compliance under
conditions that included the use of compliant devices and shielded cables between system
components. It is important that you use compliant devices and shielded cables between
system components to reduce the possibility of causing interference to radios, televisions, and
other electronic devices.
14 CE COMPLIANCE STATEMENT
This product is compliant with the CE directive. All returns must be made to the original place
of purchase.

Mova Systems SAS
© 2014 Mova Systems.
All rights reserved.
Mova Systems and the Mova
Systems logo are trademarks of
Mova Systems SAS, registered in the
U.S. and other countries.
Apple®, the Apple logo, iPad®,
iPhone® and Siri® are trademarks of
Apple Inc., registered in the U.S. and
other countries.
The Bluetooth® word mark and logos
are registered trademarks owned by
Bluetooth SIG, Inc. and any use of
such marks by Mova Systems SAS is
under license.
Other company and product names
mentioned herein may be
trademarks of their respective
companies.
