Movisens EcgMove 4 User manual

movisens GmbH, Karlsruhe, Germany E-Mail: [e-mail]
EcgMove 4
ECG and Physical Activity Sensor Quick Start Guide
Bedienungsaneitung
EcgMove 4 Quick Start Guide English, Version 15.08.2018
Welcome
Thank you for choosing the ECG and Physical Activity
Sensor EcgMove 4 from movisens. This sensor
represents the latest technology for the mobile
monitoring of ECG signals and physical activity in
everyday life.
Description of the Sensor
Featuring an integrated Bluetooth Smart Interface, the
EcgMove 4 expands researchers’ options by allowing
integration with the experience sampling platform
movisensXS.
A dry electrode chest belt provides greater comfort for
long term measurements or alternatively disposable
electrodes can also be used for shorter periods. A
multi-colored LED provides visual feedback on the
sensors operation.
Scope of Application
The EcgMove 4 captures a single channel ECG signal in
addition to physical activity (i.e. 3D Acceleration,
Angular Rate, Barometric Air Pressure…) and other
secondary parameters of a test subject.
It’s been designed and tailored for research and
scientific applications with a 2 week recording capacity.
Software Installation
Before starting a measurement, you have to install the programs on the USB stick.
SensorManager: Configures the sensor, starts a measurement
and downloads the data from the sensor
UnisensViewer: Views and preprocesses the stored data
DataAnalyzer: Analyzes the stored sensor data (30 days free trial version)

movisens GmbH, Karlsruhe, Germany E-Mail: [e-mail]
EcgMove 4
ECG and Physical Activity Sensor Quick Start Guide
Bedienungsaneitung
EcgMove 4 Quick Start Guide English, Version 15.08.2018
Handling
Charge the Sensor
Connect the sensor to a USB port until the LED is blinking green.
During charging, the status LED is blinking blue.
Start SensorManager
Connect EcgMove 4 to the PC, click on “Start Recording” and
configure the measurement parameters.
Attach the Sensor
Prepare the skin of the test person.
Position the dry electrode chest belt under
the sternum or attach the disposable electrodes
to the test person with the sensor logo upright.
Start SensorManager
After the measurement, connect the EcgMove 4 to the PC, click on
“Save Data” and enter the required information.
Start UnisensViewer
Click on “Show data” directly after storing the data.
Start DataAnalyzer
Select the desired analysis output to calculate secondary parameters
or to generate reports.
Please read the User Manual for further details !
Configure and start
the measurement
Measure
Read out and store
the data
Analyse the data
SensorManager
UnisensViewer
SensorManager
DataAnalyzer
UnisensViewer
results: .csv, .pdf, .xlsx
View and preprocess
the data
Prepare the sensor
