movistar HP4500-CL User manual

FRONT PANEL
LED
Blue (running mode)
Red (Standby mode)
USB port
Use HDMI cable to connect
between STB and TV or
home theater system
HDMI
Ethernet
input(10/100M)
Connect by network
cable
Ethernet port
Reset Button POWER
Connect with power
adaptor (12V 1A)
for power supply
REMOTE CONTROL
Ok
Confirm all actions selected
in the interface
Guide
Displays the TV guide,
showing all channels and
their respective programs
and schedules.
Back
Return to last
screen viewed or action
MoreOptions
Displays actions that can be
carried out in selected
content.
Home
Returns to the first page,
displaying the menu and
content strips
Navigation
controls navigation through
the areas of interface.
TV
Close any screen and tune
to the last channel watched
Search
Expand keyboard
alphanumeric to search any
content in your package.
UNPACKING
The terms HDMI, HDMI High-Definition Multimedia Interface,
HDMI Trade Dress and the HDMI Logos are trademarks or
registered trademarks of HDMI Licensing Administrator, Inc.
Manufactured under license from Dolby Laboratories. Dolby,
Dolby Audio, and the double-D symbol are trademarks of
Dolby Laboratories Licensing Corporation.
4K Ultra HD STB
HP4500-CL (IPTV)
USER MANUAL
0750-HP45LCPK-05
USER MANUAL
SPECIFICATIONS
Product Name:4K Ultra HD STB
Model No.:HP4500-CL (IPTV)
DC Power:12V 1A
Operation Temperature:0-45℃Manufacturer:ShenzhenSkyworth Digital Technology Co., LTD.
Address:14/F,Block A, Skyworth Building, Gaoxin Ave.1.S.,
Nanshan District, Shenzhen, China
Country of Origin:Made in China
REAR PANEL
LEFT PANEL
1: 公差(Tolerance): ±2mm
2: 原材料及后处理工艺均能满足ROHS和WEEE的要求.
(Raw materials and the corresponding post processing
should meet requirements defined in the ROHS and WEEE.)
技术要求(NOTES):
料号(Part No.):
展开尺寸(Unfolding Size):
成品尺寸(Folded Size):
印刷颜色(Print Color):
材质(Material):
0750-HP45LCPK-06
320*280 mm
160*140mm
厂家/Manufacturer: Jiahui/Voion/Fuweizhi 设计/Designer: leiping 认证加签/Certification Audit: 审核/Audit:
表面处理(Surface finishing):
80g书纸(80g Writing paper)
105g双铜(105g Coated paper)
黑色(Black)
哑油(Matt Varnish) 光油(Gloss Varnish)
四色印刷(4-Color Print)
TOP COWER
BACK COWER

FRONT PANEL
LED
Blue (running mode)
Red (Standby mode)
USB port
Use HDMI cable to connect
between STB and TV or
home theater system
HDMI
Ethernet
input(10/100M)
Connect by network
cable
Ethernet port
Reset Button POWER
Connect with power
adaptor (12V 1A)
for power supply
REMOTE CONTROL
Ok
Confirm all actions selected
in the interface
Guide
Displays the TV guide,
showing all channels and
their respective programs
and schedules.
Back
Return to last
screen viewed or action
MoreOptions
Displays actions that can be
carried out in selected
content.
Home
Returns to the first page,
displaying the menu and
content strips
Navigation
controls navigation through
the areas of interface.
TV
Close any screen and tune
to the last channel watched
Search
Expand keyboard
alphanumeric to search any
content in your package.
UNPACKING
The terms HDMI, HDMI High-Definition Multimedia Interface,
HDMI Trade Dress and the HDMI Logos are trademarks or
registered trademarks of HDMI Licensing Administrator, Inc.
Manufactured under license from Dolby Laboratories. Dolby,
Dolby Audio, and the double-D symbol are trademarks of
Dolby Laboratories Licensing Corporation.
4K Ultra HD STB
HP4500-CL (IPTV)
USER MANUAL
USER MANUAL
SPECIFICATIONS
Product Name:4K Ultra HD STB
Model No.:HP4500-CL (IPTV)
DC Power:12V 1A
Operation Temperature:0-45℃Manufacturer:Shenzhen Skyworth Digital Technology Co., LTD.
Address:14/F, Block A, Skyworth Building, Gaoxin Ave.1.S.,
Nanshan District, Shenzhen, China
Country of Origin:Made in China
REAR PANEL
LEFT PANEL
0750-HP45LCPK-06

Storage
Your device has been carefully checked and packed before shipping. When unpacking it, make sure that all the parts are
included and keep the packaging away from children. We recommend that you keep the carton during the warranty period,
to keep your device perfectly protected in the event of repair or warranty.
Software Description
This product includes a software that is restricted to be modified by a third party. The manufacture reserves the right to
publish software updates for maintenance or introducing new features.
Operating Environment
Do not install this equipment in a confined space such as a bookcase or similar unit.Do not use the set near damp, and
cold areas, protect the set from overheating.
Keep away from direct sunlight.
Do not use the set near dust place.
Do not place candles near the opening area, to avoid flammable foreign material from entering the device.
WARNING
Only use attachments/accessories specified or provided by the manufacturer (such as Any other adapter may cause
damage to the device. Such damage is not covered under warranty. Please refer to the information on the product
enclosure for electrical and safety information before installing or operating the apparatus. To reduce the risk of fire or
electric shock, do not expose this apparatus to rain or moisture. The apparatus shall not be exposed to dripping or
splashing and that objects filled with liquids, such as vases, shall not be placed on apparatus. The ventilation should not
be impeded by covering the ventilation openings with items, such as newspaper, table-cloths, curtains, etc. The batteries
(battery pack or batteries installed) shall not be exposed to excessive heat such as sunshine, fire or the like. The mains
plug/appliance coupler/direct plug-in adapter is used as disconnect device,the disconnect device shall remain readily
operable.
CAUTION
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. Risk of explosion if
the battery is replaced by an incorrect type.
Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery, that can result in an
explosion; Leaving a battery in an extremely high temperature surrounding environment that can result in an explosion or
the leakage of flammable liquid or gas; A battery subjected to extremely low air pressure that may result in an explosion
or the leakage of flammable liquid or gas.
This equipment is a Class II or double insulated electrical appliance. It has been designed in such a way that it does
not require a safety connection to electrical earth.
For the terminals marked with symbol of “ ” may be of sufficient magnitude to constitute a risk of electric shock.The
external wiring connected to the terminals requires installation by an instructed person or the used of ready-made leads or
cords.
Arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of
non-insulated“dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of
electric shock.
Warning: To reduce the risk of electric shock,
do not remove cover (or back) as there are no user-serviceable parts inside. Refer servicing to qualified personnel.
The exclamation point within an equilateral triangle is intended to alert the user to do not remove cover (or back) as there
are no user-serviceable parts inside. Refer servicing to qualified personnel.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating
and maintenance instructions in the literature accompanying the appliance.
WEEE Directive
Correct Disposal of this product. This marking indicates that this product should not be disposed with other
household wastes throughout the EU. To prevent possible harm to the environment or human health from
uncontrolled waste the sustainable reuse of material resources. To return your used device, please use the return
and collection systems or contact the retailer where the product was purchased. They can take this product for
environmentally safe recycling.
FCC compliance statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device
may not cause harmful interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority
to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
Radiation Exposure statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment
should be installed and operated with minimum distance 20 cm between the radiator and your body.
SAFETY INSTRUCTIONCONNECTION INSTRUCTION
Power on STB and TV set.
Select correct HDMI input on TV.
.
.
HDMI CABLE
Taking remote control for operation
.
Connect STB with router by Ethernet cable
Make sure internet is available
.
.
ETHERNET CABLE
WWW
