Chapter 1. Introduction
The ioLogik R2140 is a stand-alone remote analog I/O server that can connect sensors for
automation applications over an RS-485 connection.
The following topics are covered in this chapter:
Overview
Optional Liquid Crystal Display Module (LCM)
Product Features
Packing List
Specifications
Physical Dimensions
Product Overview
Pin Assignments
LED Indicators

ioLogik R2140 User’s Manual Introduction
Overview
The ioLogik R2140 is a remote I/O server that is designed to link sensors, transmitters, transducers,
and valves to an RS-485 network.
The ioLogik R2140 can be attached to an ioLogik E2000 server so I/O points can be accessed from
within a single IP environment. One ioLogik E2000 server can connect up to 31 ioLogik R2000
servers.
Optional Liquid Crystal Display Module (LCM)
The ioLogik R2140 supports an optional hot-pluggable liquid crystal display module (LCM) for
field management and configuration. The module can be used for on-site configuration or
monitoring, and works with any ioLogik E or R series product.
Product Features
z8 analog input (AI) channels, mV/V/mA with wire-off detection (at 4 to 20 mA)
z2 analog output (AO) channels for voltage or current actuator control
zBundled Windows utility and quick programming library for VB, VC++, BCB
zSupport for SCADA software such as Wonderware InTouch and GE Intellution iFix32
zConfigurable power-on and safe status settings for AO channels
zOptional LCM for status display and configuration
zNIST traceable calibration
zROHS compliant
Packing List
The ioLogik R2140 is shipped with the following items:
Standard Accessories
zioLogik R2140 RS-485 I/O server
zDocument & Software CD
Optional Accessories
zLDP1602 ioLogik liquid crystal display module (LCM)
Please notify your sales representative if any of the above items are missing or damaged.
1-2

ioLogik R2140 User’s Manual Introduction
Specifications
Serial
Interface 2-wire RS-485 with Data+, Data-, GND
Serial Line Protection 15 KV ESD for all signals
Baudrates 9600 to 115200 bps
Parity None
Data Bits 8
Stop Bits 1
Flow Control None
Built-in RTC No
Analog Input
Channels 8
Resolution 16-bit
Input Range +/-150 mV, +/-500 mV, +/-5 V, +/-10 V, 0 to 20 mA, 4 to 20 mA
Data Format 16-bit integer
Accuracy +/- 0.1%, FSR @ 25°C, +/- 0.3%, FSR @ -10, 60°C
Sampling Rate (All Channels) 10 samples/sec (voltage); 6 samples/sec (current)
Input Impedance 900 kΩ
Current Input Resistor 106 Ω
Protection Continuous overvoltage protection (-10V to 10V)
3000 VDC optical isolation
Analog Output
Channels 2
Resolution 12-bit
Output Range 0 to 10 V, 4 to 20 mA
Drive Voltage: 12 VDC for current output
Data Format 12-bit integer
Accuracy +/- 0.1%, FSR @ 25°C, +/- 0.3%, FSR @ -10, 60°C
CMR @ 50/60 Hz 95 dB min.
Zero Drift +/- 9 µV/°C
Span Drift +/- 25 ppm/°C
Load Resistor current load < 250 Ω, voltage load > 1 MΩ
Control and Configuration
Protocols Modbus/RTU
Utilities ioAdmin for Windows for remote configuration and monitoring
Programming DLL for VB, BCB, VC++ with comprehensive examples
(coming soon)
Power Requirements
Power Input 24 VDC nominal, 12 to 48 VDC
Power Consumption 183 mA @ 24 VDC (typical)
Mechanical
Wiring I/O cable max. 14 AWG
Environmental
Operating Temperature -10 to 60ºC (14 to 140ºF), 5 to 95%RH
Storage Temperature -40 to 85ºC (-4 to 185ºF), 5 to 95%RH
Shock IEC60068-2-27
Freefall IEC60068-2-32
Vibration IEC60068-2-6
MTBF > 200,000 hrs @ 25°C
1-3

ioLogik R2140 User’s Manual Introduction
AgencyApprovals
EMC FCC Part 15, CISPR (EN55022) Class A
CE-IEC61000-4-2 (ESD), level 2/3
CE-IEC61000-4-3 (RS), level 2
CE-IEC61000-4-4 (EFT), level 2
CE-IEC61000-4-5 (Surge), level 3
CE-IEC61000-4-6 (CS), level 2
CE-IEC61 000-4-8 (PM), level 1
CE-IEC61 000-4-11 (Dip)
CE-EN61000-6-2
CE-EN61000-6-4
Safety UL 508
Warranty 2 years
Physical Dimensions
Without LCM
(all units in mm)
1-4

ioLogik R2140 User’s Manual Introduction
With Optional LCM
(all units in mm)
1-5

ioLogik R2140 User’s Manual Introduction
Product Overview
NOTE: The reset button restarts the server and resets all settings to factory defaults. Use a pointed
object such as a straightened paper clip to hold the reset button down for 5 sec. The RDY LED will
turn red as you are holding the reset button down. The factory defaults will be loaded once the RDY
LED turns green again. You may then release the reset button.
Pin Assignments
System Bus
Pin 1 2 3 4 5
Signal V+ V- V+ V- NC
Pin 6 7 8 9 10
Signal NC Data+ SYNC Data- GND
TB1 and TB2 (Power Input & RS-485 Connector)
TB1 (Power Input) TB2 (RS-485)
Pin 1 2 3 4 5 6
Signal V+ V- FG D+ D- SG
NOTE: FG is Frame Ground, SG is Signal Ground
1-6

ioLogik R2140 User’s Manual Introduction
TB3 (Analog Input and Output Terminal)
Pin 1 2 3 4 5 6 7 8 9
Signal VIN0+ VIN0- VIN1+ VIN1- VIN2+ VIN2- VIN3+ VIN3- VIN4+
Pin 10 11 12 13 14 15 16 17 18
Signal VIN4- VIN5+ VIN5- VIN6+ VIN6- VIN7+ VIN7- VOUT
0+
VOUT
0-
Pin 19 20 21 22 23 24
Signal IOUT
0+
IOUT
0-
VOUT
1+
VOUT
1-
IOUT
1+
IOUT
1-
LED Indicators
System LEDs
red Power is on
PWR off Power is off
red System error
green (steady) ioLogik is functioning normally
green & red (flashing) ioLogik is in Safe Status
RDY
off Power is off or there is a power problem
Serial (flashing) Serial port is receiving/transmitting data
1-7

2
2
Chapter 2. Initial Setup
This chapter describes how to install the ioLogik R2140.
The following topics are covered:
Hardware Installation
¾Connecting the Power
¾Grounding the ioLogik R2140
¾Connecting to Analog Sensors and Devices
¾Setting the RS-485 Baudrate
¾Setting the RS-485 Unit ID
¾Modbus/RTU Devices
Software Installation

ioLogik R2140 User’s Manual Initial Setup
Hardware Installation
Connecting the Power
Connect the 12 to 48 VDC power line to the ioLogik R2140’s terminal block (TB1). If power is
properly supplied, the power LED will glow a solid red color until the system is ready
ATTENTION
Disconnect the power before installing and wiring.
Disconnect the power cord before installing and/or wiring your ioLogik R2140.
To protect your system, power up the ioLogik first, then the sensors.
When powering down, shut off power to the sensors first, then the ioLogik.
Do not exceed the maximum current for the wiring.
Determine the maximum possible current for each power wire and common wire. Observe all
electrical codes dictating the maximum current allowable for each wire size.
If the current exceeds the maximum rating, the wiring could overheat, causing serious damage to
your equipment.
Grounding the ioLogik R2140
The ioLogik R2140 is equipped with two grounding points, one on the back wall-mounting plate and
the other on the DIN-rail attachment. Both grounding points are connected to the same conducting
pathway.
Connecting to Analog Sensors and Devices
Analog Output
2-2

ioLogik R2140 User’s Manual Initial Setup
Analog Input
Setting the RS-485 Baudrate
The RS-485 port is used to communicate with other RS-485 devices or to link to another ioLogik
RS-485 I/O server. The RS-485 port can run Modbus/RTU or I/O command sets. The baudrate is set
by a physical dial on the back of the ioLogik R2140. The default settings are baudrate = 115200,
parity check = N, data bits = 8, and stop bit = 1.
Baudrate for RS-485
(parameters are N, 8, 1)
Dial setting and corresponding baudrate:
0:115200 1:57600 2:38400 3:19200
4:9600 5:4800 6:2400 7:1200
Setting the RS-485 Unit ID
The ioLogik R2140 needs to be assigned a unit ID in order to use the RS-485 bus. You may assign a
number from 1 to 31. Unit ID 0 is reserved for the first device on the RS-485 bus, such as a PC or
PLC.
Modbus/RTU Devices
The RS-485 port runs Modbus/RTU and can connect to any Modbus device. You may use different
methods to connect different combinations of ioLogik R2000 servers and other Modbus devices.
Some examples are shown below:
Connecting One Modbus/RTU Device
2-3

ioLogik R2140 User’s Manual Initial Setup
Connecting Multiple Modbus/RTU Devices
Software Installation
ioAdmin is a Windows utility that can connect to the ioLogik R2140 for configuration and
management. The ioLogik R2140 may also be configured through the optional LCM.
1. Install from the Document and Software CD: Insert the Document and Software CD into the
host computer. In the root directory of the CD, locate and run SETUP.EXE. The installation
program will guide you through the installation process and install the ioAdmin utility. You can
also install the MXIO DLL library or ioEventLog separately.
2. Open ioAdmin: After installation is finished, run ioAdmin from Start ÆProgram Files Æ
MOXAÆIO Server ÆUtility ÆioAdmin.
3. Search for the server: On the menu bar, select System ÆAuto Scan Remote I/O Server. In
the dialog window, select RS-232/485 I/O server and click Start Search.
If ioAdmin is unable to find the ioLogik R2140, there may be a problem with your COM port
settings. Click Port Settings to view or modify the settings.
2-4

ioLogik R2140 User’s Manual Initial Setup
4. Monitor I/O status: Once the unit is found by ioAdmin, you may view the status of all
attached I/O devices on ioAdmin’s main screen.
You may now use ioAdmin to setup or configure the unit.
2-5

3
3
Chapter 3. Using ioAdmin
This chapter goes over the functions available in ioAdmin, the ioLogik R2140’s main configuration
and management utility.
The following topics are covered:
Introduction to ioAdmin
Features of ioAdmin
¾Searching for the Unit
ioAdmin Main Screen
¾Main Screen Overview
¾Wiring Guide
Menu Items
Main Window
¾I/O Configuration Tab (General)
¾Server Info Tab
¾Server Settings Tab (General)
ioAdminAdministrator Functions
¾I/O Configuration Tab (Administrator)
¾Server Settings Tab (Administrator)
¾Firmware Update Tab
¾Watchdog Tab
¾Server Context Menu

ioLogik R2140 User’s Manual Using ioAdmin
Introduction to ioAdmin
The ioLogik I/O server may be managed and configured over the Ethernet by ioAdmin, a Windows
utility provided with your ioLogik R2140. ioAdmin’s graphical user interface gives you easy access
to all status information and settings.
ioAdmin consists of following software:
zioAdmin
zioLogik 2000 Wiring Guide
zioLogik 4000 Wiring Guide
Features of ioAdmin
Remote Management
Over the RS-485 network, ioAdmin
allows users to
zfind and configure multiple
ioLogik servers
zmonitor and configure attached
I/O devices
ztest I/O devices
zreset the server
On-line Wiring Guide
An on-line wiring guide can be
opened from within ioAdmin for
your convenience. The easily
accessible wiring guide can save
administrators much time while
planning or troubleshooting.
3-2

ioLogik R2140 User’s Manual Using ioAdmin
Configuration File
ioAdmin allows the entire
configuration of the ioLogik R2140
to be saved as a file. The file is
viewable as text and can serve three
purposes:
zas a record or backup of
configuration
zas a template for the
configuration of other servers
zas a quick reference guide for
you to configure Modbus drivers
in a SCADA system
The file includes the following
information:
zfile name, date, and time
zmodel information
zModbus addresses
Server Management List
ioAdmin can import and export a
list of ioLogik servers that are being
managed. This file can make it
easier to manage all devices on the
network, and includes the following
information:
zserver name
zmodule type
zIP address
zunit ID
3-3

ioLogik R2140 User’s Manual Using ioAdmin
Searching for the Unit
After opening ioAdmin, you will need to find your unit over the RS-485 connection. From the
pull-down menu, choose System - Auto Scan Remote I/O Server.
Select RS-232/485 I/O server and click Port Settings to set/verify the serial port settings.
When you click Start Search, ioAdmin will begin searching up to 99 ports for your ioLogik unit.
The timeout interval is for RS-485 communication and defaults to 2000 ms. As soon as your ioLogik
R2140 appears as shown below, you may click Stop. Otherwise, ioAdmin will continue to search all
99 ports.
ATTENTION
If ioAdmin is unable to find your ioLogik R2140, make sure that the baudrates match. Please
refer to Chapter 2 for setting or viewing the baudrate.
ATTENTION
Even if ioAdmin is unable to find your ioLogik R2140, you may still access the On-line Wiring
Guide. Please refer to the On-line Wiring Guide section for details.
3-4
